The anti-pillow effect of mesh antennas has adverse effects on satellite communication. The curvature isotropy of a negative Poisson’s ratio material is expected to be applied and solved for the anti-pillow effect of mesh deployable antennas. Based on the tension characteristics of mesh antennas, our research group has proposed a novel pre-wound six-ligament chiral material, and provided the analytical solutions of Poisson’s ratio and Young’s modulus under the assumption of a small deformation. Following on from the above work, this paper takes into account the variable curvature deformation of pre-wound ligaments and the bending deformation of straight ligaments. The analytical solutions of Poisson’s ratio and Young’s modulus under large deformations are derived, and verified by finite element simulation combined for both small and large deformations. The results show that theoretical solutions considering large deformation of the ligament are more consistent with the simulation results in the large-strain range of anisotropy in the material plane. The analytical solution of Young’s modulus derived from the energy equivalent principle of elastic deformation with a curved beam and a straight beam is consistent with the simulation results under large tensile strain. It has been verified that the existence of a pre-wound ligament can slow down the deformation of the node and reduce the loss of in-plane isotropy to a certain extent, so it is easier to maintain the negative Poisson’s ratio characteristic and maintain an excellent in-plane isotropic deformation mechanism over a larger strain range under tensile load. This characteristic proves the reliability of the prospects applying the pre-wound six-ligament chiral structure in deployable mesh antennas, which lays a theoretical foundation for the subsequent prototype. Full article

Space mesh antennas require large-diameter reflectors to achieve aperture surfaces with high gain. To date, many pioneering studies have pursued deployable mechanisms capable of achieving high deployment ratios, primarily focusing on ring and umbrella structures for spaceborne antennas. In this work, a conceptual design of a Deployable Pantograph Rib structure-based parabolic Antenna (De-PaRA) is presented by employing pantograph structures that ensure high stowage efficiency. This approach addresses the shortcomings of conventional space antenna mechanisms. In parallel, this study aims to overcome the structural safety issues that may arise from insufficient axial stiffness of the rib geometry after deployment. To achieve these objectives, superelastic shape memory alloy (SMA) wires were integrated along the antenna ribs to reinforce axial stiffness while maintaining constant inter-rib spacing. Modal analysis demonstrated that SMA wire integration increases the axial stiffness by approximately 2-fold, with eigenfrequency rising from 9.932 to 14.3 Hz. A prototype with a 1.6 m deployed diameter, achieving a volume deployment ratio of 58.8, was quantitatively evaluated through multi-body dynamics simulations and experiments. These results demonstrate reliable deployment operation and mechanical feasibility. Full article

This study is an initial study for the development of a large truss-type deployable mesh antenna, and it involved the development process of a 1.5 m-scale deployable mesh antenna. The geometric characteristics of the reflector were considered for the initial net design. Based on the antenna’s operating frequency, the L-band, the surface root mean square (RMS) error and focal length/diameter (F/D) ratio of the reflector were calculated. Design requirements for the antenna’s weight, stowed/deployed dimensions, and fundamental frequency were established. The material properties of each component were applied to the design model, and the geometric dimensions were verified to ensure that the weight and stowed/deployed design were fulfilled. The fundamental frequency requirements under stowed/deployed conditions were verified through modal analysis, and the structural deformation of the ring truss was confirmed through load analysis. The reflector antenna was assembled to the ring truss with the net and mesh, according to the assembly procedure. The curvature of the reflector surface was shaped by adjusting the bolt length of the tension control device. Using V-Stars, a specialized surface error measurement device, the surface RMS error requirements for the reflector were confirmed to be satisfied. Finally, the development verification of the antenna was completed by performing repeated deployment and a thermal vacuum test. Full article

This paper presents a novel large-span ring deployable perimeter truss for the mesh reflector deployable antennas, which is made up of two parts including a single-mobility driving mechanism and a ring deployable metamorphic mechanism. The mechanism design employs polygon approximation, and each side is treated as a basic unit using a modular design approach. By reasonable assembly, a ring deployable metamorphic mechanism with a small folded state and a large deployed state can be formed. Here, multiple singular positions, the axis of its three revolute joints being parallel and coplanar, are used in the fully deployed state, which forms multiple dead-center positions and changes the constraint conditions. The metamorphic motion is thus achieved, and a stable self-locking state is established that greatly enhances the stability. The paper first introduces the mechanism design and evaluation method; the kinematic and dynamic analysis is then conducted, and the simulation validation is also performed. Moreover, a principle design for cable-net structural setting and connection is illustrated. Finally, with the design of a driving system and the fabrication of a physical prototype, the deployable experiments are carried out, and the results show that the perimeter truss can efficiently act as the mesh reflector deployable antennas. Full article

A LoRaWAN application architecture comprises three functional components: (i) nodes, which convert and wirelessly transmit data as LoRaWAN messages; (ii) gateways, which receive and forward these transmissions; and (iii) network servers, which process the received data for application delivery. The nodes convert data into LoRaWAN messages and transmit them wirelessly with the hope that one or more LoRaWAN gateway will receive the messages successfully. Then, the gateways pass on the received messages to a distant network server, where various processing steps occur before the messages are forwarded to the end application. If none of the gateways can receive the messages, then they will be lost. Although this default behaviour is suitable for some applications, there are others where ensuring messages are successfully delivered at a higher rate would be helpful. One such scenario is the application in this paper: monitoring maritime vessels and fishing equipment in offshore environments characterised by intermittent or absent shore connectivity. To address this challenge, the Custodian project was initiated to develop a maritime monitoring solution with enhanced connectivity capabilities. Two additional features are especially welcome in this scenario. The most important feature is the transmission of messages created in offshore areas to end users who are offshore, regardless of the unavailability of the ground network server. An example would be fishermen who are offshore and wish to position their fishing equipment, also offshore, based on location data transmitted from nodes via LoRaWAN, even when both entities are far away from the mainland. The second aspect concerns the potential use of gateway-to-gateway communications, through gateways on various ships, to transmit messages to the coast. This setup enables fishing gear and fishing vessels to be monitored from the coast, even in the absence of a direct connection. The functional constraints of conventional commercial gateways necessitated the conceptualisation and implementation of C-Mesh, a novel relay architecture that extends LoRaWAN functionality beyond standard protocol implementations. The C-Mesh integrates with the Custodian ecosystem, alongside C-Beacon and C-Point devices, while maintaining transparent compatibility with standard LoRaWAN infrastructure components through protocol-compliant gateway emulation. Thus, compatibility with both commercially available nodes and gateways and those already in deployment is guaranteed. We provide a comprehensive description of C-Mesh, describing its hardware architecture (communications, power, and self-monitoring abilities) and data processing ability (filtering duplicate messages, security, and encryption). Sea trials carried out on board a commercial fishing vessel in Sesimbra, Portugal, proved C-Mesh to be effective. Location messages derived from fishing gear left at sea were received by an end user aboard the fishing vessel, independently of the network server on land. Additionally, field tests demonstrated that a single C-Mesh deployment functioning as a signal repeater on a vessel with an antenna elevation of $15m$ above sea level achieved a quantifiable coverage extension of 13 km (representing a 20% increase in effective transmission range), demonstrating the capacity of C-Mesh to increase LoRaWAN’s coverage. Full article

Deployable mesh antennas offer advantages such as high gain, ultra-light weight, and high packaging efficiency. However, the mesh that constitutes the reflection surface is prone to deformation due to its low stiffness, which directly affects the performance of the antenna. Therefore, it is essential to minimize the mechanical deformation of the mesh caused by external forces in order to achieve the target performance. In particular, the fastening interface between the mesh and the antenna structure is a critical area where high tensile forces are incurred due to the dynamic behavior of the antenna structure during ground tests, launch environments, and on-orbit operation. This causes degradation in the precision of the reflection surface. Therefore, an important part of the antenna development process is researching mesh fabric fastening methods that minimize the deformation of the reflection surface. Nevertheless, existing studies have only briefly mentioned mesh fastening methods, with limited systematic analysis of their impact on the mechanical properties of mesh fabric. In this paper, we propose a clamping-type mesh fastening method that combines push-button rivets and thin plates, which have high workability during mesh assembly, and conduct experimental validation. The characteristics of each fastening method were analyzed through tensile strength tests conducted at the mesh fabric level, and the results of the repeated tensile tests verified the effectiveness of the proposed fastening method. Full article

Proper prediction of the temperature variation in a metallic wire mesh for spaceborne large deployable reflector antennas is essential for evaluating the dimensional stability of the antenna under extreme on-orbit thermal environments. However, predicting the temperature of a mesh is difficult because of its complex yarn configuration. To analyze the thermal behavior of the spaceborne mesh antenna reflector, the thermal optical characteristics with various knitting methods of the metallic mesh were obtained experimentally in this study. Subsequently, to analyze the thermal sensitivity of the reflector based on its optical properties, an on-orbit thermal analysis of the mesh reflector was performed based on measurements of the mesh specimen. We also investigated the influence of deployable solar panels on the thermal gradient of the reflector. Full article

This paper describes the design and experimental verification of a 6 m parabolic deployable mesh reflector antenna mechanism based on a superelastic shape memory alloy. This antenna mainly consists of a deployable primary reflector with a superelastic shape memory alloy-based hinge mechanism and a fixed-type secondary reflector mast, where a rotary-type holding and release mechanism and deployment speed control system are installed. The main feature of this antenna is the application of a superelastic shape memory alloy to the mechanism, which has the advantages of plastic deformation resistance, high damping, and fatigue resistance. A shape memory alloy is applied to the hinge mechanism of each primary reflector rib and to the rotary-type holding and release mechanism as a deployment mechanism. In addition, a superelastic shape memory alloy wire is applied to the antenna in the circumferential direction to maintain the curvature of the primary reflector. The effectiveness of the proposed mechanism design was verified through repeated deployment tests on models of the superelastic shape memory alloy-based hinge mechanism and the antenna system. Full article

With the deployment of cooperative intelligent transportation systems (C-ITSs), the telecommunication systems and their performance occupy a key position in ensuring safe, robust, and resilient services to the end-users. Regardless of the adopted protocol, adequate road network coverage might affect the service performance, in terms of traffic and environmental efficiency. In this study, we analyze the traffic efficiency and emission pollutant sensitivity to the location of ad hoc network antennas when the C-ITS services disseminate dynamic messages to control the speed limit and ensure sustainable mobility. We design the experimentation with short-range communication resulting from an ad hoc network and requiring Roadside Units (RSUs) along the road to broadcast messages within their communication range to the end-user. The performance variability according to the RSUs’ location and effective road network coverage are highlighted through our microscopic simulation-based experimentations. This paper develops a sensitivity analysis to evaluate the impact of the network mesh according to the C-ITS service under consideration. Focus is placed on the variable speed limit (VSL) service, controlling upstream speed to restrict congestion and ensure more sustainable mobility. The results show that, while the traffic efficiency improves even at a low market penetration rate (MPR) of the connected vehicles, the environmental efficiency improves only at a high MPR. From the telecommunication perspective, an expansive broadcast strategy appears to be more effective than the conservative approach. Full article

In this paper, we propose a deployable broadband mesh reflector antenna for use in signals intelligence (SIGINT) satellite systems, considering performance degradation due to shape deformation. To maximize gain by increasing the diameter of the reflector while reducing the weight of the antenna, the reflector of the antenna is designed using lightweight silver-coated Teflon mesh. The mesh reflectors are typically expanded by tension to maintain their parabolic structure; thus, shape deformation cannot be avoided. This shape deformation results in shape differences between the surface of the mesh reflector and the ideal parabolic reflector, thus resulting in the degradation of the performance of the mesh reflector antenna. To observe this degradation, we analyze antenna performance according to the number of arms, the number of joints, the feed distance, and the distance from the reflector center to each joint. The performance of the mesh reflector antenna is examined using an effective lossy conducting surface (ELCS) that has the same reflectivity as the silver-coated Teflon mesh to reduce simulation time and computing resources. The designed silver-coated Teflon mesh reflector and the double-ridged feed antenna are fabricated, and the bore-sight gain is measured using the three-antenna method. The measured bore-sight gain of the proposed antenna is 31.6 dBi at 10 GHz, and the measured and simulated results show an average difference of 3.28 dB from 2 GHz to 18 GHz. The proposed deployable mesh reflector antenna can be used in a variety of applications where small stowed volume is required for mobility, such as mobile high-gain antennas as well as satellite antenna systems. Through this study, we demonstrate that shape deformation of the mesh reflector surface significantly affects the performance of reflector antennas. Full article

Maintaining high system performance is critical for a multi-hop flying mesh network (FlyMesh) to perform missions in different environments. Although the Poisson point process (PPP) has been widely used for the performance analysis of FlyMesh, it still has flaws in describing the spatial distribution of the UAVs since it does not restrict the minimum distance between them. The spatial deployment of FlyMesh varies depending on the environment. Considering the relevance and practicality, we modeled the multi-hop FlyMesh using the $\beta$-Ginibre point process ($\beta$-GPP) and equipped each UAV with a directional antenna. Under the condition of the decode-and-forward protocol, we derived the connection probability and ergodic capacity of a multi-hop FlyMesh utilizing the Laplace transform of interference. Then, we calculated an approximate expression for the interference Laplace transform based on the diagonal approximation and further obtained the coverage probability. Finally, the numerical simulation results verified the correctness of the theoretical derivation, indicating that it is possible to optimize the system’s performance based on the expressions derived in this paper. Full article

In this study, a hybrid iteration force density method (HIFDM) was proposed to ensure both tension uniformity and accuracy of an antenna mesh reflector. Based on a genetic algorithm (GA), the boundary cable tension of the antenna reflector net was optimized, which further improved the precision of the antenna mesh reflector. The static model of the large deployable structure was established using the finite element method (FEM), and thus, an iterative strategy for form-finding of the antenna reflector net was proposed, which considered the influence of the elastic deformation of the deployable structure. The results showed that the HIFDM was effective for the form-finding of the antenna mesh reflector, and the shape precision was improved by further optimization using the GA. Finally, it was noted that the elastic deformation of the deployable structure will reduce the uniformity of cable tension and affect the precision of antenna reflectors. Due to the large-scale and soft stiffness, the large deployable structure had a high sensitivity to cable pretension, and it is important to design a reasonable cable pretension to ensure the accurate shape of antenna mesh reflectors. Full article

The dynamics of mesh reflectors are characterized by large deformation when antennas undergo a large motion in the deployment process. In this work, absolute node coordinate formulation (ANCF), with the merit of precise description of large deformation, is employed to consider the flexibility of the reflector net. From a practical perspective, the effect of the torsional spring is incorporated into the dynamic governing equations by an equivalent mechanical model. Deployment simulation of the mesh reflector antennas is performed by a numerical procedure. It can be found that with the action of a degenerative driven force caused by the friction effect, the deployed process of antennas exhibits a character of asynchronous deployment. Additionally, a significant increase in tension during the final period of deployment has an intense influence on smooth deployment. Full article

In this paper, we assess the features of a rectangular constellation of four anchors on the position estimation accuracy of a mobile tag, operating under the IEEE 802.15.4 specifications. Each anchor implements a smart antenna with eight switched beams, which is capable to collect Received Signal Strength Indicator (RSSI) data, exploited to estimate the mobile tag position within a room. We also aim at suggesting a deployment criterion, providing the discussion of the best trade-off between system complexity and positioning accuracy. The assessment validation was conducted experimentally by implementing anchor constellations with different mesh sizes in the same room. Mean accuracies spanning from 0.32 m to 0.7 m on a whole 7.5 m × 6 m room were found by varying the mesh area from 1.19 m² to 17 m², respectively. Full article

A compact synthetic aperture radar microsatellite antenna operating in the L-band is presented. To reduce size and weight of the small spaceborne SAR, we utilize a lightweight deployable parabolic mesh reflector and operate at low Earth orbital altitudes. The antenna is a wrap-rib center-fed parabolic reflector with dedicated receiving and transmitting feeds. Antenna requirements are: gain better than 30 dBic, center frequency of 1.275 GHz with bandwidth of 28 MHz and circular polarization with axial ratio better than 3 dB. This work describes the development of a compact Circularly Polarized SAR L-band antenna system and the design considerations suitable for small spacecrafts. Simulation of the parabolic reflector and effects of different structural elements to the main radiation pattern were analyzed, which include ribs, struts, feed blockage, and mesh surface. A research model of the parabolic reflector was constructed, and the reflector surface verification was realized using two different approaches, a laser distance meter along ribs and the other using 3D scanning of the reflector surface. RMS errors wree 1.92 mm and 3.86 mm, respectively, both below required 4.55 mm of surface accuracy. Near-field antenna measurements of the deployable reflector mesh antenna was realized for final antenna validation, presenting good agreement with the simulation results. Future work comprises prototyping and testing of the full polarimetric feed assembly. Full article
