The roughness of the Earth’s surface dictates the nature of air flow across it. Detailed meteorological data that are necessary to access the aerodynamic roughness ($z_0$) are not widely collected and, as such, the geometry of a surface can be used to estimate $z_0$. Here, we present a novel formulation, and the corresponding computer code, to compute $z_0$ based on the Lettau (1969) geometric approach. The new code produces a mean $z_0$, as well as a histogram of all $z_0$ values for each individual roughness element (e.g., 10 s of thousand for the 1000 × 1000 grids) discretized using watersheds, as well as directional $z_0$ diagrams, which can be matches with the wind rose for the location. The formulation includes two parameters that may optionally be applied to smooth the surface before calculating $z_0$. By calculating $z_0$ as a function of these two parameters, we demonstrate the sensitivity of the $z_0$ value to these parameter choices. Since a large portion of the Earth’s surface is snow covered during some parts of the year, and the roughness of the snow surface varies over the snow season and over space, we apply the code to three snow surface datasets. Each surface is during a different phases of the snowpack. Each surface is evaluated at two resolutions). These surfaces are: fresh snow accumulation (1 m² at 1 and 10 mm), peak accumulation (1 km² at 1 and 10 m) and ablation sun cups (25 m² at 5 and 50 mm). Full article

Eight balls were manufactured with a 3D printer to resemble various types of 32-panel soccer balls. One ball was completely smooth, whereas the other seven possessed various dimple patterns on their surface panels. Seam width and seam depth were also varied. Wind-tunnel experiments were performed to extract aerodynamic coefficients, and also to determine the critical Reynolds number for each manufactured ball. A new surface roughness parameter is introduced, and a fitting formula is presented, which allows for the prediction of the critical Reynolds number if the new parameter is known. Full article

In the present paper, the effect of air density variations on cup anemometer performance is analyzed. The effect on the sensor’s performance is mainly due to the difference between the altitude at which the cup anemometer is working and the altitude at which this instrument was calibrated. Data from the available literature are thoroughly analyzed, focusing on explaining the coupled effect of the air temperature on both the rotor’s friction torque and the air density (that is, related to the aerodynamic torque on the rotor). As a result, the effect of air density variation at constant temperature (that is, leaving aside any variation of friction forces at the anemometer rotor shaft) on the sensor transfer function (i.e., on the calibration constants) is evaluated. The analysis carried out revealed a trend change in the variation with air density of the transfer function of the cup anemometer. For densities greater than 0.65, the calibration constants of the instrument have a variation with density that must necessarily change suddenly as the start-up speed, represented by the calibration constant B, becomes zero around this value of air density. To highlight the relevance of the present research, some estimations of the effect of wind speed measurement errors associated with air density changes on the Annual Energy Production (AEP) of wind turbines are included. A 1.5% decrease in the AEP forecast at air density corresponding to 2917 m above sea level is estimated for 3000–4500 kW wind turbines. Full article

The term knuckleball in sporting jargon is used to describe a ball that has been launched with minimal spin, resulting in a trajectory that is erratic and unpredictable. This phenomenon was first observed in baseball (where the term originated) and has since been observed in other sports. While knuckleball has long fascinated the scientific community, the bulk of research has primarily focused on knuckleball as it occurs in baseball. Following the changes in the design of the soccer ball after the 2006 World Cup, knuckleball and ball aerodynamics were exploited by soccer players. This research examined the properties of a knuckleball in the sport of soccer. We designed and evaluated a system that could reproduce the knuckleball effect on soccer balls based on previous theories and characteristics outlined in our literature review. Our system is comprised of the Adidas miCoach Smart Ball, a companion smart phone app for data collection, a ball-launching machine with programmable functions, and a video-based tracking system and Tracker motion analysis software. The results from the testing showed that our system was successfully able to produce knuckleball behaviour on the football in a highly consistent manner. This verified the dynamic models of knuckleball that we outline. While a small portion of the data showed some lateral deviations (zig-zag trajectory), this erratic and unpredictable trajectory was much smaller in magnitude when compared to examples seen in professional games. The sensor data from the miCoach app and trajectory data from the Tracker motion analysis software, showed that the knuckleballs were consistently reproduced in-line with theoretical dynamics. Full article

The purpose of this study was to find a generic method to determine the aerial phase of ski jumping in which the athlete is in a steady gliding condition, commonly known as the ‘stable flight’ phase. The aerial phase of ski jumping was investigated from a physical point mass, rather than an athlete–action-centered perspective. An extensive data collection using a differential Global Navigation Satellite System (dGNSS) was carried out in four different hill sizes. A total of 93 jumps performed by 19 athletes of performance level, ranging from junior to World Cup, were measured. Based on our analysis, we propose a generic algorithm that identifies the stable flight based on steady glide aerodynamic conditions, independent of hill size and the performance level of the athletes. The steady gliding is defined as the condition in which the rate-of-change in the lift-to-drag-ratio ($LD$-ratio) varies within a narrow band-width described by a threshold $\tau$. For this study using dGNSS, $\tau$ amounted to $0.01$$\mathrm{s}$⁻¹, regardless of hill size and performance level. While the absolute value of $\tau$ may vary when measuring with other sensors, we argue that the methodology and algorithm proposed to find the start and end of a steady glide (stable flight) could be used in future studies as a generic definition and help clarify the communication of results and enable more precise comparisons between studies. Full article

Background: Inhaled drugs have been available in the market for several years and for several diseases. Drugs for chronic obstructive pulmonary disease, cystic fibrosis, and diabetes have been used for several years. In the field of drug modification, these drugs range from tablets to aerosol. Methods: Milling as used to break down the tablets to powder and nebulisers are used to produce aerosol droplets. A mastersizer was used to measure the mass median aerodynamic diameter of the aerosol droplets. Results: Apremilast produced mmad diameters (2.43 μm) without any statistical difference between the different jet-nebulizers. The residual cup B contributed to greater mmad diameters as the 95% interval of mean values, based on those the ANOVA mean square clearly indicated, followed by cups C and F. The previous interval plot is much better clarified when the interaction means between drug and residual cap are plotted. The residual cups B, C and F produce mmad between (2.0–3.2). Conclusion: In the current research study we demonstrated our methodology to create apremilast powder and produce apremilast aerosol droplets with different nebulisers and residual cups. Full article

Cupressaceae pollen is responsible for winter respiratory allergies in the Mediterranean area. Pollen grains of this diverse family share the same characteristics under light microscopy. Consequently, the partial contribution of each Cupressaceae species to the airborne pollen spectrum cannot be determined with conventional aerobiological methods. Studies on major aeroallergens offer better information on the allergic sensitization and appearance of symptoms in patients sensitized to airborne pollen and spores. Our aim was to determine if airborne Cupressaceae pollen concentrations correspond to aerodynamics of the major allergen of Cupressus (Cup a 1), as well as the aeroallergen correlation with different-sized particles. The air was sampled in two cities of Southern Spain (Granada and Córdoba) using the Hirst-type volumetric sampler for airborne pollen detection during 2006 to 2008 and the Andersen Cascade Impactor for aeroallergen detection during the main pollination period of Cupressaceae in the same period. The samples were analyzed by the methodology proposed by the Spanish Aerobiology Network (REA), the minimum requirements of the European Aeroallergen Society (EAS) for pollen, and by ELISA immunoassay to detect airborne Cup a 1. The distribution patterns of airborne Cupressaceae pollen and Cup a 1 were observed throughout the sampling period, although with some irregular oscillations. Cupressaceae pollen and Cup a 1 showed positive and significant correlation during the period of maximum concentrations (January to March). However, the results of this study showed that the period of exposure of aeroallergens depends on the Cupressus species and their abundance in cities. According to the allergy potential obtained, species like C. arizonica could release more allergens than other species like C. sempervirens. Full article

The panel patterns of soccer balls that change with each World Cup have a significant impact on the balls’ aerodynamic and flight characteristics. In this study, the aerodynamic forces of eleven types of soccer ball with different panel patterns were measured in a wind tunnel experiment. We characterized the panel shapes of soccer balls by the length, cross-sectional area, and the panel grooves’ volume. The results confirmed that the drag and drag crisis characteristics are dependent on the groove length and volumes. Flow separation points were visualized by an oil film experiment and particle image velocimetry (PIV) measurement to understand the drag crisis of the soccer balls. The results showed that the panel shape of the ball significantly changes the position of the separation point near the critical region, where the drags crisis occurs. In the critical region, laminar and turbulent flows coexist on the ball. On the other hand, the effect of panel shape on the separation point position is small in subcritical and supercritical states. Full article

The soccer ball panel pattern, which changes every World Cup, greatly affects the ball’s aerodynamics and flight characteristics. In this study, the fluid force of 11 soccer balls with different panel patterns was measured by wind tunnel tests. The drag crises with different Reynolds numbers were confirmed depending on the panel shape. To understand this, the shapes of panel grooves were measured and the relationship between them was investigated. The flow separation point was also visualized by the oil film method and the particle image velocimetry (PIV) analysis. The separation points were confirmed to be different depending on the panel groove by the oil film method in a supercritical Reynolds region. The flow separation points were found to be almost the same position in the subcritical and supercritical state and to be partly different around the Reynolds number of drag crisis. Full article

In this work, a new and low-cost Arduino-Based Data Acquisition System (ABDAS) for use in an aerodynamics lab is developed. Its design is simple and reliable. The accuracy of the system has been checked by being directly compared with a commercial and high accuracy level hardware from National Instruments. Furthermore, ABDAS has been compared to the accredited calibration system in the IDR/UPM Institute, its measurements during this testing campaign being used to analyzed two different cup anemometer frequency determination procedures: counting pulses and the Fourier transform. The results indicate a more accurate transfer function of the cup anemometers when counting pulses procedure is used. Full article

The Hawk-Eye electronic line-calling system gives players the ability to challenge line-calling decisions. It also creates large datasets of ball and player movements during competitive play. In this paper we used a dataset taken from 5 years of the Davis and Fed Cup tournaments (comprising 71,019 points in total) to examine the effect of ball wear on aerodynamic performance. Balls were categorized as new or used depending on whether they were used in the first two games following a ball change (new) or the last two games before a ball change (used). Data falling into neither category was discarded. The coefficients of drag (Cd) of 9224 first serves from the Davis Cup were calculated by simulating their trajectories. New balls had a significantly lower average Cd of 0.579 compared to used balls’ 0.603 (p < 0.0001)—first serves made with new balls arrive 0.0074 s sooner than first serves made with used balls on average. Large sport datasets can be used to explore subtle effects despite a relative lack of precision. Full article

In the present work, the research derived from a wide experience on cup anemometer calibration works at IDR/UPM Institute (Instituto Universitario de Microgravedad “Ignacio Da Riva”) is summarized. This research started in 2008, analyzing large series of calibrations, and is focused on two main aspects: (1) developing a procedure to predict the degradation level of these wind sensors when working on the field and (2) modeling cup anemometer performances. The wear and tear level of this sensor is evaluated studying the output signal and its main frequencies through Fourier analysis. The modeling of the cup anemometer performances is carried out analyzing first the cup aerodynamics. As a result of this process, carried out through several testing and analytical studies since 2010, a new analytical method has been developed. This methodology might represent an alternative to the classic approach used in the present standards of practice such as IEC 64000-12. Full article

The results of several research campaigns investigating cup anemometer performance carried out since 2008 at the IDR/UPM Institute are included in the present paper. Several analysis of large series of calibrations were done by studying the effect of the rotor’s geometry, climatic conditions during calibration, and anemometers’ ageing. More specific testing campaigns were done regarding the cup anemometer rotor aerodynamics, and the anemometer signals. The effect of the rotor’s geometry on the cup anemometer transfer function has been investigated experimentally and analytically. The analysis of the anemometer’s output signal as a way of monitoring the anemometer status is revealed as a promising procedure for detecting anomalies. Full article

The influence of anemometer rotor shape parameters, such as the cups’ front area or their center rotation radius on the anemometer’s performance was analyzed. This analysis was based on calibrations performed on two different anemometers (one based on magnet system output signal, and the other one based on an opto-electronic system output signal), tested with 21 different rotors. The results were compared to the ones resulting from classical analytical models. The results clearly showed a linear dependency of both calibration constants, the slope and the offset, on the cups’ center rotation radius, the influence of the front area of the cups also being observed. The analytical model of Kondo et al. was proved to be accurate if it is based on precise data related to the aerodynamic behavior of a rotor’s cup. Full article
