Search Results (21)

Low-Temperature Co-Fired Ceramic (LTCC)-based mechanical sensors are inherently limited by the thickness and rigidity of multilayer ceramic stacks, which restrict miniaturization and mechanical compliance. To overcome these constraints, this work presents a hybrid LTCC/Kapton^® platform enabling high-sensitivity mechanical sensing through mechanically tunable RF passive components. The proposed approach integrates a flexible polyimide membrane, bonded onto an LTCC substrate at low temperatures using selectively electroplated indium pillars that simultaneously define the air gap and provide mechanical fixation. Inductance tuning is achieved via metal-shielding proximity effects, whereas capacitance tuning relies on force-controlled air-gap modulation in a metal–insulator–metal configuration. The fabrication process ensures precise gap control, high compliance, and structural robustness without requiring deformable ceramic membranes. Experimental characterization, including three-dimensional surface profiling and impedance measurements, demonstrates a 48% inductance tuning range with a sensitivity of 0.715 nH/mN and a 36% capacitance tuning range with a sensitivity of 47.3 fF/mN at 1 MHz. The proposed hybrid platform provides a compact and scalable solution for high-sensitivity sensors and mechanically reconfigurable RF components suitable for harsh-environment and adaptive electronics applications. Full article

The quantification of solid debris in used lubricating oil is essential for assessing transmission system wear and optimizing maintenance strategies. This study introduces a low-cost capacitive proximity sensor for monitoring total solid particle contamination in lubricants, with a focus on ferrous (Fe), non-ferrous (Al), and non-metallic (SiO₂) debris. Controlled tests were performed using five mixing ratios of large-to-small particles (100:0, 75:25, 50:50, 25:75, and 0:100) at a fixed debris mass of 0.5 g per 25 mL of SAE 85W-140 automotive gear oil. Cubic regression analysis yielded high predictive accuracy, with average R² values of 0.994 for Fe, 0.943 for Al, and 0.992 for SiO₂. Further dimensionality reduction using Principal Component Analysis (PCA), along with Linear Discriminant Analysis (LDA) of multivariate statistical analysis, effectively classifies debris types and enhances interpretability. These results demonstrate the potential of capacitive sensing as an offline, non-invasive alternative to traditional techniques for wear debris monitoring in transmission systems. These results confirm the potential of capacitive sensing, supported by statistical modeling, as a non-invasive, cost-effective technique for offline classification and monitoring of wear debris in transmission systems. Full article

The interference of metal working surfaces on the electric field can lead to performance variations between the flush mounting and non-flush mounting of capacitive proximity sensors in industrial applications. Traditional active shielding circuit designs are complex, while grounding shields not only reduce the sensor sensitivity but are also unsuitable for grounded sensors. To address this issue, this paper proposes an innovative near-ground (NG) shielding structure. This structure effectively concentrates the electric field between the sensing electrode and ground by adding a common ground electrode around the sensing electrode, thereby reducing the electrical coupling between the metal working surface and the sensing electrode and achieving the desired shielding effect. Through finite element analysis and experimental verification, this study performed an in-depth investigation of the capacitance difference $C_d$ and the rate of change of capacitance with the target distance of sensors under the two mounting methods. The proposed structure achieved a performance comparable with active shielding (17 fF $C_d$) while operating passively, which addressed a critical cost–adaptability trade-off in industrial CPS designs. The results show that although the performance of the NG shielding was slightly inferior to active shielding, it was significantly better than traditional grounding shielding, and its structure was simple and low cost, showing great potential in practical applications. Full article

Recycled carbon fibre (rCF) composites are increasingly being explored for applications such as strain sensing, manufacturing of automobile parts, assistive technologies, and structural health monitoring due to their properties and economic and environmental benefits. The high conductivity of carbon and its wide application for sensing makes rCF very attractive for integrating sensing into passive structures. In this paper, capacitive sensors have been fabricated using rCF composites of varying compositions. First, we investigated the suitability of recycled carbon fibre polymer composites for different sensing applications. As a proof of concept, we fabricated five touch/proximity sensors and three soil moisture sensors, using recycled carbon fibre composites and their performances compared. The soil moisture sensors were realised using rCF as electrodes. This makes them corrosion-resistant and more environmental-friendly, compared to conventional soil moisture sensors realised using metallic electrodes. The results of the touch/proximity sensing show an average change in capacitance (ΔC/C~34) for 20 mm and (ΔC/C~5) for 100 mm, distances of a hand from the active sensing region. The results of the soil moisture sensors show a stable and repeatable response, with a high sensitivity of ~116 pF/mL of water in the linear region. These results demonstrate their respective potential for touch/proximity sensing, as well as smart and sustainable agriculture. Full article

This paper discusses the development of an automated sorting machine designed as a comprehensive mechatronics educational project. The project integrates mechanical and electrical design, incorporating a robot arm, a microcontroller, sensors, and actuators. The sorting machine uses color identification to sort wooden blocks of three different colors. The blocks are stacked and dropped onto a conveyor belt by a hopper system that employs a solenoid actuator and a servo to release one block at a time at specific intervals. As the belt runs continuously, each block passes under a color sensor, which monitors the color and signals one of three servo-powered mechanical arms to guide the block into the appropriate chute. Each chute is equipped with a capacitive proximity sensor that sends a voltage signal to the robot controller, queuing commands for the robot to pick up the blocks from the bottom of each chute and return them to the hopper to form a continuously running sorting system. This paper details the design and integration of the system’s various elements and the development of the control software. The designed system can drop blocks every 8.05 s, sort each block within 5 s of being sensed, and return them to the sorting system every 12 s. It has a color-sensing accuracy of 97%, with a failure rate of around 7%. The system achieved quick and reliable sorting using various low-cost, accessible, and open-source parts. The project exemplifies a cost-effective solution suitable for mechatronics education, demonstrating the numerous challenges involved in developing automated sorting systems. Full article

Optimized surface-type impedimetric and capacitive proximity sensors have been fabricated on paper substrates by using rubbing-in technology. The orange dye (OD) and silicone glue (SG) composite-gel films were deposited on the zig-zag gap between two aluminum electrodes fixed on a paper (dielectric) substrate. The effect of proximity of various objects (receivers) on the impedance and the capacitance of the sensors was investigated. These objects were semi-cylindrical aluminum (metallic) foil, a cylindrical plastic tube filled with water, a kopeck-shaped plastic tube filled with carbon nanotubes and a human finger. The mechanism of sensing was based on the change in impedance and/or the capacitance of the sensors with variation of proximity between the surfaces of the sensor and the object. On decreasing proximity, the impedance of the sensors increased while the capacitance decreased. The impedimetric proximity sensitivities of CNT, water, metal-based receivers and the finger were up to 60 × 10³ Ω/mm, 35 × 10³ Ω/mm, 44 × 10³ Ω/mm and 6.2 × 10³ Ω/mm, respectively, while their capacitive sensitivities were −19.0 × 10⁻² pF/mm, −16.0 × 10⁻² pF/mm, −16.4 × 10⁻² pF/mm and −1.8 × 10⁻² pF/mm. If needed for practical application, the sensors can be built in to the Wheatstone bridge, which can also increase the sensitivity of the measurement. Moreover, the sensor’s materials are low cost, while the fabrication technique is easy and ecologically friendly. The sensor can also be used for demonstrative purposes in school and college laboratories. Full article

Knowledge of foot growth can provide information on the occurrence of children’s growth spurts and an indication of the time to buy new shoes. Podiatrists still do not have enough evidence as to whether footwear influences the structural development of the feet and associated locomotor behaviours. Parents are only willing to buy an inexpensive brand, because children’s shoes are deemed expendable due to their rapid foot growth. Consumers are not fully aware of footwear literacy; thus, views of consumers on children’s shoes are left unchallenged. This study aims to embed knitted smart textile sensors in children’s shoes to sense the growth and development of a child’s feet—specifically foot length. Two prototype configurations were evaluated on 30 children, who each inserted their feet for ten seconds inside the instrumented shoes. Capacitance readings were related to the proximity of their toes to the sensor and validated against foot length and shoe size. A linear regression model of capacitance readings and foot length was developed. This regression model was found to be statistically significant (p-value = 0.01, standard error = 0.08). Results of this study indicate that knitted textile sensors can be implemented inside shoes to get a comprehensive understanding of foot development in children. Full article

The profile generation is highly complex for roughness measurement using a capacitive sensor because of the small peak-to-peak width of the machined surface and the close proximity of the sensor setting with the machining setup which has the chance of damaging the sensor. Considering these shortcomings, a higher sensor sensing diameter with an appropriate resolution has been selected for a single-shot approach. An automated micro gantry XYZ system is integrated with a capacitive sensor to precisely target, move, and measure the roughness. For investigation, a vertical milled surface with a wide roughness range has been prepared. A Stylus profilometer has been used to measure the roughness (R_a) of the specimens for comparison. An experiment has been conducted on the above system with a 5.6 mm capacitance sensor, and an estimation model using regression has been obtained using sensor data to estimate R_a. In conclusion, the single-shot approach with a 5.6 mm sensing diameter sensor, the proposed micro gantry system, and the estimation model performs better in instantaneous noncontact measurement in the range of 0.3 µm to 2.9 µm roughness estimation. The influence of tilt and waviness has also been discussed using FEA analysis. Full article

Sensitive and flexible pressure sensors have invoked considerable interest for a broad range of applications in tactile sensing, physiological sensing, and flexible electronics. The barrier between high sensitivity and low fabrication cost needs to be addressed to commercialize such flexible pressure sensors. A low-cost sacrificial template-assisted method for the capacitive sensor has been reported herein, utilizing a porous Polydimethylsiloxane (PDMS) polymer and a multiwalled carbon nanotube (MWCNT) composite-based dielectric layer. The sensor shows high sensitivity of 2.42 kPa⁻¹ along with a low limit of detection of 1.46 Pa. The high sensitivity originates from adding MWCNT to PDMS, increasing the composite polymer’s dielectric constant. Besides this, the pressure sensor shows excellent stability at a cyclic loading of 9000 cycles, proving its reliability for long-lasting application in tactile and physiological sensing. The high sensitivity of the sensor is suitable for the detection of small deformations such as pulse waveforms as well as tactile pressure sensing. In addition, the paper demonstrates a simultaneous contact and non-contact sensing capability suitable for dual sensing (pressure and proximity) with a single data readout system. The dual-mode sensing capability may open opportunities for realizing compact systems in robotics, gesture control, contactless applications, and many more. The practicality of the sensor was shown in applications such as tactile sensing, Morse code generator, proximity sensing, and pulse wave sensing. Full article

Capacitive proximity sensors (CPSs) have recently been a focus of increased attention because of their widespread applications, simplicity of design, low cost, and low power consumption. This mini review article provides a comprehensive overview of various applications of CPSs, as well as current advancements in CPS construction approaches. We begin by outlining the major technologies utilized in proximity sensing, highlighting their characteristics and applications, and discussing their advantages and disadvantages, with a heavy emphasis on capacitive sensors. Evaluating various nanocomposites for proximity sensing and corresponding detecting approaches ranging from physical to chemical detection are emphasized. The matrix and active ingredients used in such sensors, as well as the measured ranges, will also be discussed. A good understanding of CPSs is not only essential for resolving issues, but is also one of the primary forces propelling CPS technology ahead. We aim to examine the impediments and possible solutions to the development of CPSs. Furthermore, we illustrate how nanocomposite fusion may be used to improve the detection range and accuracy of a CPS while also broadening the application scenarios. Finally, the impact of conductance on sensor performance and other variables that impact the sensitivity distribution of CPSs are presented. Full article

Capacitive proximity sensing is widespread in our everyday life, but no sensor for biomedical optics takes advantage of this technology to monitor the probe attachment to the subject’s skin. In particular, when using optical monitoring devices, the capability to quantitatively measure the probe contact can significantly improve data quality and ensure the subject’s safety. We present a custom novel optical probe based on a flexible printed circuit board which integrates a capacitive contact sensor, 3D-printed optic fiber holders and an accelerometer sensor. The device can be effectively adopted during continuous monitoring optical measurements to detect contact quality, motion artifacts, probe detachment and ensure optimal signal quality. Full article

This paper presents the development of a novel contactless omnidirectional capacitive proximity sensor. The presented device has been designed to be energy-efficient (≈5 mW power consumption) by means of duty-cycling the power supply. A comprehensive methodological experiment has been carried out to extensively evaluate the performance within the sensing range (5–10 cm). A simple boot-up self-adjustment mechanism has been implemented using a digital potentiometer. This feature allows for an effortless utilization of the proposed device in a wide variety of potential applications, including mobile robotics and human–machine interaction. Full article

This paper proposes a proximity imaging sensor based on a tomographic approach with a low-cost conductive sheet. Particularly, by defining capacitance density, physical proximity information is transformed into electric potential. A novel theoretical model is developed to solve the capacitance density problem using the tomographic approach. Additionally, a prototype is built and tested based on the model, and the system solves an inverse problem for imaging the capacitance density change that indicates the object’s proximity change. In the evaluation test, the prototype reaches an error rate of 10.0–15.8% in horizontal localization at different heights. Finally, a hand-tracking demonstration is carried out, where a position difference of 33.8–46.7 mm between the proposed sensor and depth camera is achieved at 30 fps. Full article

Rings are widely accepted wearables for gesture interaction. However, most rings can sense only the motion of one finger or the whole hand. We present PeriSense, a ring-shaped interaction device enabling multi-finger gesture interaction. Gestures of the finger wearing ring and its adjacent fingers are sensed by measuring capacitive proximity between electrodes and human skin. Our main contribution is the determination of PeriSense’s interaction space involving the evaluation of capabilities and limitations. We introduce a prototype named PeriSense, analyze the sensor resolution at different distances, and evaluate finger gestures and unistroke gestures based on gesture sets allowing the determination of the strengths and limitations. We show that PeriSense is able to sense the change of conductive objects reliably up to 2.5 cm. Furthermore, we show that this capability enables different interaction techniques such as multi-finger gesture recognition or two-handed unistroke input. Full article

This paper presents major improvements to a multimodal, adjustable sensitivity skin sensor module. It employs a geomagnetic 3-axis Hall effect sensor to measure changes in the position of a magnetic field generated by an electromagnet. The electromagnet is mounted on a flexible material, and different current values can be supplied to it, enabling adjustments to the sensitivity of the sensor during operation. Capacitive sensing has been added in this iteration of the module, with two sensing modalities: “pre-touch” detection with proximity sensing and normal force capacitive sensing. The sensor has been designed to be interconnected with other sensor modules to be able to cover large surfaces of a robot with normal and shear force sensing and object proximity detection. Furthermore, this paper introduces important size reductions of the previous sensor design, calibration results, and further analysis of other sensor characteristics. Full article
