Search Results (102)

To address the high false alarm rate of intrusion detection systems based on distributed acoustic sensing (DAS) for power cables in complex underground environments, an innovative GRT-Transformer multimodal deep learning model is proposed. The core of this model lies in its distinctive three-branch parallel collaborative architecture: two branches employ Gramian Angular Summation Field (GASF) and Recursive Pattern (RP) algorithms to convert one-dimensional intrusion waveforms into two-dimensional images, thereby capturing rich spatial patterns and dynamic characteristics and the third branch utilizes a Gated Recurrent Unit (GRU) algorithm to directly focus on the temporal evolution features of the waveform; additionally, a Transformer component is integrated to capture the overall trend and global dependencies of the signals. Ultimately, the terminal employs a Bidirectional Long Short-Term Memory (BiLSTM) network to perform a deep fusion of the multidimensional features extracted from the three branches, enabling a comprehensive understanding of the bidirectional temporal dependencies within the data. Experimental validation demonstrates that the GRT-Transformer achieves an average recognition accuracy of 97.3% across three typical intrusion events—illegal tapping, mechanical operations, and vehicle passage—significantly reducing false alarms, surpassing traditional methods, and exhibiting strong practical potential in complex real-world scenarios. Full article

Gas sensors can provide early warning of fires by detecting pyrolysis gas components in the sheaths of high-voltage cables. However, air humidity significantly affects the thermal decomposition gas production characteristics of the outer sheath of high-voltage cables, which in turn affects the accuracy of this warning method. In this paper, the thermal decomposition and gas production characteristics of the polyethylene (PE) outer jacket of high-voltage cables under different air humidities (20–100%) are studied, and the corresponding density functional theory (DFT) simulation calculations are performed using Gaussian 09W software. The results show that with the increase in humidity, the thermal decomposition gas yield of the PE outer jacket of high-voltage cables exhibits a decreasing trend. Under high-humidity conditions (≥68.28%RH), the generation of certain thermal decomposition gases is significantly reduced or even ceases. Meanwhile, the influence of moisture on the thermal decomposition characteristics of PE was analyzed at the micro level through simulation, indicating that the H-free radicals generated by moisture promote the initial decomposition of PE, but the subsequent combination of hydroxyl groups with terminal chain C forms a relatively stable alkoxy structure, increasing the activation energy of the reaction (by up to 44.7 kJ/mol) and thus inhibiting the generation of small-molecule gases. An experimental foundation is laid for the final construction of a fire warning method for high-voltage cables based on the information of thermal decomposition gas of the outer sheath. Full article

The recognition of ice thickness on transmission lines serves as a prerequisite for controlling de-icing robots to carry out precise de-icing operations. To address the issue that existing edge computing terminals fail to meet the demands of ice thickness recognition algorithms, this paper introduces an Efficient Edge Computing Network (EECNet) specifically designed for identifying ice thickness on transmission lines. Firstly, pruning is applied to the Efficient Neural Network (ENet), removing redundant components within the encoder to decrease both the computational complexity and the number of parameters in the model. Secondly, a Dilated Asymmetric Bottleneck Module (DABM) is proposed. By integrating different types of convolutions, this module effectively strengthens the model’s capability to extract features from ice-covered transmission lines. Then, an Efficient Partial Conv Module (EPCM) is designed, introducing an adaptive partial convolution selection mechanism that innovatively combines attention mechanisms with partial convolutions. This design enhances the model’s ability to select important feature channels. The method involves segmenting ice-covered images to obtain iced regions and then calculating the ice thickness using the iced area and known cable parameters. Experimental validation on an ice-covered transmission line dataset shows that EECNet achieves a segmentation accuracy of 92.7% in terms of the Mean Intersection over Union (mIoU) and an F1-Score of 96.2%, with an ice thickness recognition error below 3.4%. Compared to ENet, the model’s parameter count is reduced by 41.7%, and the detection speed on OrangePi 5 Pro is improved by 27.3%. After INT8 quantization, the detection speed is increased by 26.3%. These results demonstrate that EECNet not only enhances the recognition speed on edge equipment but also maintains high-precision ice thickness recognition. Full article

To reduce weight and improve dexterity performance, dexterous robot fingers usually use tendons for transmission, which may lead to complex nonlinear control problems. In order to improve tracking performance in joint space, this paper proposes an anti-interference controller, which synthesizes the nonsingular fast terminal sliding mode technique. A flexible joint dynamic model is established considering the flexibility of the cable-driven mechanism. A nonlinear disturbance observer is adopted to estimate and compensate the system uncertainties and various disturbances, and global fast terminal sliding mode is used to ensure good control performance in both the reaching phase and the sliding mode phase. Furthermore, symmetry is used to simplify dynamic modeling and control design, and the stability of the controller is proven with Lyapunov theory. Finally, the effectiveness of the controller is verified through simulation experiments. The simulation results demonstrate that the proposed controller achieves a steady state in 0.3 s, higher tracking accuracy than the other controllers through quantitative analysis of MAE and MSE metrics, and stronger anti-interference capability, which can satisfy the requirements of finger dexterity operation. Full article

As a relatively weak part of cable insulation, T-type cable terminals will have insulation defects due to process, installation, and other problems, resulting in partial discharge. Therefore, this paper uses Deep Convolution Neural Network (DCNN) and Empirical Mode Decomposition (EMD) to identify the partial discharge type of a 10 kV T-type cable terminal. This method uses the partial discharge experimental platform of the T-type cable terminal to collect the partial discharge signal. After the original signal that is difficult to identify is decomposed by EMD, a series of intrinsic mode components (IMFs) that are easy to locate are obtained. The deep learning network model is used to identify the defect type of the IMF signal. The results show that the overall defect recognition rate of this method reaches 95.3%. Compared with the traditional random forest algorithm (RF), the 10 kV T-type terminal partial discharge type recognition method based on EMD–DCNN is considered in this paper. The recognition accuracy of the main insulation scratch, bushing fouling, and joint loosening defects is higher than that of the traditional mechanical learning algorithm, RF, indicating that the method adopted in this paper can more effectively and accurately identify the defect type. Full article

Partial discharge is an important symptom of cable aging, and timely detection of potential defects is of great significance to ensure the stability and safety of the power supply. However, due to the diversity of inspection equipment and information blockage, the staff often show blindness to the partial discharge spectrum and the defects corresponding to the spectrum. In view of this phenomenon, a partial discharge spectrum recognition method based on a convolutional neural network was developed. Firstly, a database of typical partial discharge spectrum was established, including partial amplifiers in the laboratory and at the work site, and then the convolutional neural network was used to train the defect spectral library. This paper proposes a processing technology for the on-site partial discharge spectrum; the unified grayscale image is obtained by grayscale processing, linearized stretching and size unification, and then the shape and color feature parameters are extracted according to the grayscale image, which solves the image distortion and statistical spectrum movement caused by the on-site environment or photographic angle on the user side. The partial discharge type can be obtained by comparing the processed spectrum with the database through the intelligent terminal, which greatly improves the accuracy and efficiency of on-site operations. Full article

Due to the challenges in antenna installation and detection performance caused by metal obstruction along the propagation path at a Gas-Insulated Switchgear (GIS) cable terminal, as well as the adverse effects of environmental interference on the detection of partial discharge (PD) by existing flexible antennas, this paper proposes a directional flexible antenna design to mitigate these issues and improve detection performance. The proposed design employs a coplanar waveguide (CPW)-fed monopole antenna structure, where the grounding plane is extended to the back of the antenna to enhance directional reception. The designed flexible antenna measures 88.5 × 70 × 20 mm, and its low-profile design allows it to be easily mounted on the outer wall of the epoxy sleeve at the GIS cable terminal. The measurement results show that the flexible antenna has a Voltage Standing Wave Ratio (VSWR) of less than 2 in the 0.541–3 GHz frequency range. It also maintains stable impedance characteristics across various bending radii, with an average effective height of 10.79 mm in the 0.3–1.5 GHz frequency range. A GIS cable terminal PD experimental platform was established, and the experimental results demonstrate that the bending has minimal impact on the detection performance of the flexible antenna, which can cover the detection range of the GIS cable terminal; metal obstruction significantly impacts the PD signal amplitude, and the designed flexible antenna is suitable for detecting PDs in confined spaces with metal obstruction. Full article

High-voltage cables are widely used in power transmission and distribution systems, and their accessories (such as connectors, terminals, and insulators) are key parts to ensure the safe and reliable operation of power systems. These accessories may be affected by factors such as temperature, humidity, and mechanical stress during long-term operation, resulting in performance degradation or failure. In high-voltage environments, performance monitoring of cable accessories is crucial. The reference voltage circuit can withstand the influence of temperature changes and power supply fluctuations, support accurate current and voltage measurement, and thus detect potential faults in time to ensure the safe and stable operation of the power system. However, the traditional reference voltage circuit has a low-temperature curvature loss, which results in an inaccurate reference voltage, resulting in equipment damage. Therefore, in order to solve the problem of curvature loss in this part, this paper proposes a curvature compensation circuit, which realizes a high-precision reference voltage circuit through a high-temperature curvature compensation circuit, thereby meeting the current reference voltage requirements for cable accessory monitoring. Full article

Cable termination is an important part of energy transmission in high-speed trains, and it is also a weak link in the insulation. It is important to determine the insulation status of cable terminals by the detection results of partial discharge signals, but the partial discharge signals in the field test circuit are mixed with a large amount of external corona interference, which affects the detection accuracy. This paper proposes a signal recognition model that incorporates Stockwell transform (ST) and 2DCNN, which in combination with wavelet noise reduction can achieve a high-precision classification effect for partial discharge and corona interference with an accuracy rate of up to 98.75%. By selecting the maximum energy moment in the ST matrix to correct the position of the time window during the recognition of long time series signals, the problem of corona interference being truncated by the time window and being misidentified as partial discharge is overcome, and the generalization ability of the model is enhanced. Experimental results show that the method has an excellent performance in separating partial discharge and corona interference in long time series signals. Full article

During quadrotor load transport, the cable’s elasticity exacerbates load fluctuations, which may result in platform instability or a potential crash. This paper introduced a model of the connecting cable as a spring-damper system and established the dynamic model of the suspension system based on Newton’s law. Nonsingular fast terminal sliding mode control (NFTSMC) was employed for attitude, position, and anti-swing controller design. Adaptive controllers were integrated into altitude control to address uncertainties related to load mass and cable length. The inclusion of an anti-swing controller into the position control loop effectively dampens load oscillations while ensuring accurate position tracking. Numerical simulations demonstrated that the proposed controller outperforms both the energy-based controller and the conventional linear sliding mode controller. Full article

The overhead line (OHL)–cable hybrid transmission line, which connects floating photovoltaic (PV) power plants, needs to be considered regarding whether to block reclosing operations or not. However, due to the weak-feed characteristics of PV inverters, existing methods are difficult to apply in this scenario. This paper proposes a criterion for fault section identification in the transmission lines of floating PV power plants based on traveling wave power and the zero-sequence impedance angle. Firstly, the fault current characteristics of photovoltaic inverters under dual-vector control are analyzed, and the applicability of the sequence component impedance directional criterion in this scenario is discussed. Then, the transmission, refraction, and reflection processes of traveling waves in OHL–cable hybrid lines are analyzed, and a traveling wave energy criterion is designed to determine the fault section. Finally, based on the scope of application of the zero-sequence impedance angle and traveling wave energy criterion, a fault section identification method for the hybrid lines of floating PV power plants is established. A deployment method for the proposed method, based on feeder terminal units (FTUs) at the connection points between the OHL and cable is proposed. This method identifies fault sections through traveling waves and zero-sequence impedance angles, which are unaffected by PV week feed characteristics, can be applied to all the AC fault types, and do not rely on multi-terminal synchronous sampling. The proposed method is verified on a 1MW PV system built in the PSCAD. Full article

Among national infrastructure facilities, electric power facilities are very important sites that must maintain their functions properly even during a natural disaster or during social crises. Therefore, seismic design is required when necessary for major electric power facilities that have a significant impact when damaged in the event of an earthquake. In electric power facilities, bushings are generally installed in devices or structures. Therefore, ground acceleration can be amplified through devices, such as transformers, or sub-structures. Among various electric power facilities, cable terminations are representative cantilever-type substation facilities consisting of a bushing, a sub-structure, and support insulators. The bushings of cable terminations are generally made of porcelain or fiber-reinforced plastic (FRP) materials, and they may have different dynamic characteristics. This study attempted to estimate the acceleration amplification ratio in the main positions of cable terminations considering the materials of bushings. For two cable terminations with different specifications and bushing materials, three-axis shake table tests were conducted in accordance with IEEE 693, which includes a seismic performance evaluation method for a power substation facility. The acceleration amplification ratios at the top of the bushing, mass center, and top of the support structure were estimated using the acceleration responses of each cable termination. They were then compared with the acceleration amplification factors presented in design standards. Consequently, the acceleration amplification ratio of cable termination with an FRP bushing was lower than that of the cable termination with a porcelain bushing. Full article

Adding an insulating sheath to the exposed metal part of the outer insulation of a roof cable terminal can extend the creepage distance of the leakage current and significantly reduce the probability of pollution flashover on the outer insulation of the equipment. However, during the actual operation of the locomotive, the inner surface of the insulating sheath is discharged, resulting in cable insulation breakdown, the mechanism of which is unclear. This paper establishes a cable terminal–sheath electric field simulation model and studies the interface air gap, the interface with wet pollution, and the distribution of damp pollution on the outer surface and other factors on the electric field distribution of the cable terminal–sheath structure and the interface discharge, revealing the mechanism of discharge on the inner surface of the cable terminal’s insulation sheath. A voltage of 25 kV rms is applied, and the simulation results show that when the outer surface of the cable terminal is clean and there are air gaps and wet dirt on the inner surface, the maximum distortion electric field at the inner surface is 0.8 × 10⁵~3.4 × 10⁵ V/m, and the value of the electric field at this time is not enough to cause a partial discharge; when there is a uniform layer of wet dirt on the outer surface of the cable terminal, the electric field on the inner surface averages 1.5 × 10⁵ V/m, which is about 275% higher than the average electric field when the outer surface is clean; when there is wetting or an air gap on the inner surface at the same time, the maximum aberration electric field on the inner surface is 1.8 × 10⁵~1.9 × 10⁶ V/m. The wetting on the outer surface of the cable terminal strengthens the non-uniformity degree of the distribution of the electric field, and when there is wetting and an air gap on the inner surface, the over-voltage on the cable terminal inevitably leads to a discharge phenomenon in the air gap. This provides a theoretical basis for optimizing the insulation sheath structure to solve the discharge problem. Full article

The use of multi-terminal high voltage direct current (HVDC) power transmission systems is being adopted in many new links between different generation and consumption areas due to their high efficiency. In these systems, cable energization must be performed at the rated voltage. Healthy energizations at the rated voltage result in large inrush currents, especially in long cables, primarily due to ground capacitance. State-of-the-art protection functions struggle to distinguish between transients caused by switching and those associated with ground faults, leading to potential unwanted tripping of the protection systems. To prevent this, tripping is usually blocked during the energization transient, which delays fault detection and clearing. This paper presents a novel method for prompt discrimination between healthy and faulty energizations. The proposed method outperforms conventional protection functions as this discrimination allows for earlier and more reliable tripping, thus avoiding extensive damage to the cable and the converter due to trip blocking. The method is based on the transient analysis of the current in the cable shields, therefore, another technical advantage is that high voltage-insulated measuring devices are not required. Two distinct tripping criteria are proposed: one attending to the change in current polarity, and the other to the change in current derivative sign. Extensive computer simulations and laboratory tests confirmed the correct operation in both cases. Full article

The article presents a novel control strategy for cable-driven aerial manipulators (UAMs) aimed at enhancing impedance control during contact operations in complex environments. A fractional-order nonsingular terminal sliding mode control (FONTSMC) integrated with a disturbance observer (DOB) is proposed to improve the robustness and precision of the UAM under lumped disturbances. This developed approach utilizes the flexibility of fractional calculus, the finite-time stability of nonsingular terminal sliding mode, and the real-time disturbance estimation capabilities of the DOB to ensure smooth and compliant contact interactions. The effectiveness of the proposed control strategy is validated through comprehensive simulation studies, which demonstrate significant improvements in control performance, stability, and disturbance rejection when compared to traditional methods. The results indicate that the FONTSMC-DOB framework is highly suitable for complex aerial manipulation tasks, offering both theoretical and practical insights into the design of advanced control systems for UAMs. Full article
