Search Results (63)

Early identification of thermal and electrical anomalies in grid-connected photovoltaic (PV) systems is becoming increasingly important to reduce energy losses, limit power quality (PQ) degradation, and avoid excessive operating stress on power electronic converters. Conventional electrical monitoring methods can provide overall performance information, but they are generally unable to detect and localize early-stage defects occurring at module or cell level. In this context, the present study proposes an integrated diagnostic framework that combines non-destructive infrared thermography (IRT) with advanced electrical signal processing techniques for PV condition monitoring. The proposed approach correlates thermographic information, capable of revealing defects such as hotspots, cell cracks, and bypass diode failures, with high-frequency electrical signal analysis based on frequency-domain and time–frequency methods, together with deep learning-driven thermographic segmentation. By associating thermal acquisitions with electrical PQ indicators, the framework enables the early detection of physical defects linked to inefficient Maximum Power Point Tracking (MPPT) operation and progressive degradation of PV system performance. The methodology was experimentally validated on a grid-connected photovoltaic installation under different fault conditions, including hotspots, bypass diode anomalies, and localized overheating effects, demonstrating the potential of the proposed approach for predictive maintenance and intelligent PV monitoring applications. The obtained results indicate that the proposed framework improves the reliability of photovoltaic fault detection by combining thermographic inspection with advanced electrical signal analysis and AI-based defect interpretation, thus supporting predictive maintenance strategies in smart PV infrastructures. The proposed approach demonstrates image segmentation capabilities, as evidenced by a precision (PA) of 96.88%, a mean IoU (mIoU) of 77.83% and a macro F1-score of 87.47%. The proposed framework maintained reduced computational requirements compatible with real-time monitoring applications. Full article

Irreversible anterior segment blindness with preserved retinal integrity (e.g., dense corneal opacity) remains a major clinical challenge because effective sight-restoring options are limited. Here, we describe an intraocular micro-light-emitting diode (Micro-LED) epiretinal microdisplay intended to deliver patterned optical stimulation to intact photoreceptors by bypassing opaque anterior optics. The prototype was based on a color-capable VGA microdisplay (640 × 480 pixels) and operated at <30 mW under typical conditions. An ultra-thin flexible cable and a copper-mesh–reinforced polydimethylsiloxane (PDMS) encapsulation provided a compact, conformable intraocular package with high pixel density. We evaluated a monochromatic (green) prototype in a single beagle eye $(n=1)$ using a transscleral implantation approach and performed 7 days of postoperative follow-up with slit-lamp examination and multimodal imaging. Patterned stimulation via the implanted display elicited flash-evoked visual evoked potentials (VEPs) with consistent within-session waveform morphology, providing preliminary neurophysiological surrogate evidence of upstream visual pathway activation under the tested conditions in this single-animal pilot. The short-term postoperative course included transient hypotony and anterior segment inflammation, and implant rotation with associated inferior retinal detachment was observed by day 7, highlighting current biomechanical limitations. Beyond anterior segment opacity, the same intraocular optical interface could be explored as a modular light-delivery platform to pair with emerging retinal therapies (e.g., optogenetics), pending chronic safety and functional validation. This pilot large-animal study therefore provides a translationally relevant testbed while delineating key engineering constraints that must be addressed next. Full article

Photovoltaic (PV) performance in desert environments is significantly hindered by soiling and partial shading. To bridge the gap in empirical data for extreme Saharan conditions, this study presents a novel techno-economic assessment of uniform horizontal shading (UHS) specifically conducted in Mauritania. Controlled outdoor experiments were performed using a 250 W crystalline silicon PV module and a PVPM 2540C I–V curve tracer, applying progressive shading levels from 2.5% to 20%. The novelty of this work lies in the integration of high-resolution experimental I–V/P–V characterization with a localized techno-economic model for five pre-commercial PV plants. It was observed that PV modules are exceptionally sensitive to shading; specifically, a mere 10% shaded area leads to a catastrophic 90% drop in power and current, while the voltage remains remarkably stable. Thermographic analysis further validates the thermal gradients and bypass diode functionality. By quantifying the financial impacts, this research highlights that cumulative economic losses across the five real-world sites reached 87.95%, exceeding 55,000 MRU. These findings provide a strategic framework for optimizing PV systems in arid terrains and offer a robust tool for enhancing the design and operation of large-scale solar applications in desert environments. Full article

With the expansion of photovoltaic (PV) systems, failures of bypass diodes (BPDs) embedded in PV modules can degrade the power-generation performance and pose safety risks. When a BPD fails, current circulates within the module, leading to overheating and eventual burnout of the failed BPD. The heating characteristics of a BPD depend on its fault resistance, and although many modules are connected in series in actual PV systems, the heating risk at the module-string level has not been sufficiently evaluated to date. In this study, a numerical simulation model is constructed to reproduce the operation of PV modules and module strings containing failed BPDs, and its validity is verified through experiments. The validated numerical simulation results quantitatively illustrate how series-connected PV modules modify the fault-resistance dependence of BPD heating under maximum power-point operation. The results show that, under maximum power-point operation, the fault resistance at which BPD heating becomes critical shifts depending on the number of series-connected modules examined, while the magnitude of the maximum heating decreases as the string length increases. The heat generated in a BPD at the maximum power point decreases as the number of series-connected modules increases for the representative string configurations analyzed. However, under open-circuit conditions due to power-conditioner abnormalities, the power dissipated in the failed BPD increases significantly, posing a very high risk of burnout. Considering that lightning strikes are one of the major causes of BPD failure, adopting diodes with higher voltage and current ratings and improving the thermal design of junction boxes are effective measures to reduce BPD failures. The simulation model constructed in this study, which was experimentally validated for short PV strings, can reproduce the electrical characteristics and heating behaviors of PV modules and strings with BPD failures with accuracy sufficient for comparative and parametric trend analysis, and serves as a practical tool for system-level safety assessment, design considerations, and maintenance planning within the representative configurations analyzed. Full article

Bypass diode failure, particularly in the short-circuit mode, remains an under-addressed reliability issue in photovoltaic (PV) modules, causing severe power suppression and often leading to premature disposal of otherwise functional units. This study presents a non-destructive, field-applicable plug-in repair protocol for restoring modules affected by short-circuited bypass diodes. From twenty-two field-deployed modules, nine were analyzed in detail under healthy, single-fault, and dual-fault conditions. Controlled diode faults were introduced and subsequently repaired using commercially available plug-in bypass diodes. Electroluminescence (EL) imaging, current–voltage (I–V) testing, and extraction of series and shunt resistances were performed before and after repair. Results show that a single shorted diode deactivates one substring, reducing power by ~34–37%, while dual faults suppress over two-thirds of the active area, causing power losses above 67%. After repair, power deviation decreased to <3% for single faults and <7% for dual faults, with shunt resistance increasing by 52–262%, confirming removal of diode-induced leakage paths. Series resistance remained largely unchanged except in modules with irreversible cell-level damage accumulated during prolonged faulty operation. The findings demonstrate that short-circuited bypass diode faults are readily repairable and that component-level intervention can restore module performance, extend operational lifetime, and reduce unnecessary PV recycling. Full article

Bypass diode faults are among the most hard-to-detect but impactful anomalies in photovoltaic (PV) systems, especially under partial shading conditions, where their electrical signatures often resemble those caused by non-critical irradiance variations. This study presents a systematic simulation-based investigation into how different bypass diode fault types—short-circuited, open-circuited, and healthy—affect the electrical behavior of PV strings under diverse irradiance profiles. A high-resolution MATLAB/Simulink model is developed to simulate 27 unique diode fault configurations across multiple shading scenarios, enabling the extraction of key features from resulting I–V curves. These features include global and local maximum power point parameters, open-circuit voltage, and short-circuit current. To address the challenge of feature redundancy and classification ambiguity, a preprocessing step is applied to remove near-duplicate instances and improve model generalization. An artificial neural network (ANN) model is then trained to classify the number of faulty bypass diodes based on these features. Comparative evaluations are conducted with support vector machines and random forests. The results indicate that the ANN achieves the highest test accuracy (93.57%) and average AUC (0.9925), outperforming other classifiers in both robustness and discriminative power. These findings highlight the importance of feature-informed, data-driven approaches for fault detection in PV systems and demonstrate the feasibility of diode fault classification without precise fault localization. Full article

Partial shading is a common challenge influencing the performance of photovoltaic (PV) systems, particularly in urban and residential applications. A practical solution to mitigate hotspot formation due to shading is the use of bypass diodes. Increasing the number of bypass diodes further enhances PV system performance but alters the global maximum power points (MPPs), shifting their voltage locations and power magnitudes, consequently resulting in a change in the operating points in the efficiency curve of the inverters. This study investigates the impact of bypass diode numbers and inverter efficiency curves on PV system performance under various partial shading conditions. The analysis systematically deals with three inverters with different efficiency characteristics in terms of loading and input voltage, as well as module configurations with different numbers of bypass diodes. Additionally, three more factors—ambient temperature, inverter loading ratio by varying the number of series-connected PV modules, and shading intensity—are considered in the context of bypass diodes and inverter characteristics through the efficiency curve. The global MPPs of PV modules under different cases are simulated using a Simscape/Simulink-based circuit model with random irradiance samples. The results indicate the formation of bands according to the voltage that vary with bypass diode configurations. In this manner, utilizing the probabilities of these bands and inverter efficiency curves, the average PV system performance is determined for each case. The findings reveal the effects of the relationship between bypass diode configurations and inverter efficiency on PV system performance. As partial shading is especially common in dense urban areas, the results are of interest for the development of resilient and sustainable PV installations. Full article

The rapid growth of solar photovoltaic (PV) installations worldwide has increased the need for the effective monitoring and maintenance of these vital renewable energy assets. PV systems are crucial in reducing greenhouse gas emissions and diversifying electricity generation. However, they often experience faults and damage during manufacturing or operation, significantly impacting their performance, while thermal infrared imaging provides a promising non-invasive method for detecting common defects such as hotspots, cracks, and bypass diode failures, current deep learning approaches for fault classification generally rely on computationally intensive architectures or closed-source solutions, constraining their practical use in real-time situations involving low-resolution thermal data. To tackle these challenges, we introduce SlantNet, a lightweight neural network crafted to classify thermal PV defects efficiently and accurately. At its core, SlantNet incorporates an innovative Slant Convolution (SC) layer that utilizes slant transformation to enhance directional feature extraction and capture subtle thermal gradient variations essential for fault detection. We complement this architectural advancement with a thermal-specific image enhancement augmentation strategy that employs adaptive contrast adjustments to bolster model robustness under the noisy and class-imbalanced conditions typically encountered in field applications. Extensive experimental validation on a comprehensive solar panel defect detection benchmark dataset showcases SlantNet’s exceptional performance. Our method achieves a 95.1% classification accuracy while reducing computational overhead by approximately 60% compared to leading models. Full article

Wide Bandgap (WBG) devices like SiC-MOSFETs have become quite popular in recent times due to their superior switching characteristics, high current carrying capability and temperature stability. They are being adopted for many different applications and for a wide range of power levels. For the case of PV applications, manufacturers are considering moving to SiC-based topologies due to higher converter efficiencies and improved power density. However, the present industry largely uses hybrid approaches (IGBT + SiC-diode) to optimize system cost. The aim of this paper is to present a fair comparison of an industry-grade hybrid converter with another similar counterpart where only the Si device has been replaced with the SiC device. The effects of such a direct replacement on the efficiency and losses of the converter are studied under various power ratings. Both converters consist of two stages—a boost converter and a three-phase three-level DC to AC converter. Simulation and experimental results comprehensively indicate a higher efficiency (improvements of up to 8 percent points) for the full-SiC converter, and this is more prominent at low input voltages, where the boost converter is active. However, the gains in efficiency are moderate for high input voltages (1 percent point at nominal voltage), where the boost converter is bypassed, and the losses are almost entirely attributed to the inverter. When set in the backdrop of the Austrian inverter market, the use of SiC devices in PV inverters has the potential for an estimated savings of 37.5 GWh/year in terms of loss reduction. Full article

This article presents the design and production work carried out jointly by Vitesco Technologies and the CEA in order to build a Self-Reconfigurable Battery (SRB) demonstrator representative of an electric vehicle traction battery pack. The literature demonstrates that the use of an SRB allows for individual bypassing or serialization of each cell in a battery pack, enabling control of the voltage output and dynamic balancing of the battery pack during all phases of vehicle use. The simulations and tests presented in this article confirm that the use of an SRB results in a 6% reduction in energy consumption compared to a Conventional Battery Pack (CBP) on a driving profile based on WLTP cycles. Additionally, an SRB enhances fast charging performance, with a charging time that is 22% faster than a CBP. Furthermore, it is shown that an SRB without a voltage inversion capability can still be connected directly to the AC grid for charging without the need for a dedicated converter, using only a single diode bridge rectifier for the whole system. Full article

The growing significance of photovoltaic (PV) monitoring systems and diagnostic methodologies is evident in their role in enhancing the power generation, efficiency, and durability of photovoltaic systems. The operational efficacy of these systems is primarily influenced by factors such as irradiation levels and cell temperature. Consequently, there exists a pressing need for dedicated scrutiny and scholarly investigation into the identification and diagnosis of defects within these systems, aiming for swift identification and rectification of failures in PV stations. This paper thus endeavors to introduce a diagnostic methodology focused on fault detection and categorization of eight types of faults occurring in shading, series resistance, shunt resistance, and bypass diode faults (disconnected, short circuited, shunted with resistor) within photovoltaic panels. This analysis employs two distinct algorithms: the initial algorithm employs the thresholding method, while the second algorithm is grounded in a Fuzzy Logic classifier (Sugeno model). Upon examination of the simulation outcomes, it becomes evident that the threshold method fails to identify all faults, necessitating the adoption of a more effective classification technique. Moreover, the Fuzzy Logic (FL) method has proven to be the most suitable approach for diagnosing PV module issues. The findings indicate that all specified faults are detectable in a discernible manner. These approaches have demonstrated proficient accuracy and efficacy in pinpointing and characterizing various faults within PV panels. Notably, our simulation endeavors were conducted utilizing Simulink/Matlab software (R2014a). Full article

Damage to photovoltaic power-generation systems by lightning causes the failure of bypass diodes (BPDs) in solar cell modules. Bypass diodes damaged by lightning experience high-resistance open- or short-circuit failures. When a bypass diode experiences short-circuit failure due to indirect lightning, the damage may not be immediately visible. When solar radiation is subsequently received, the current circulating in the closed circuit formed by the cell string and short-circuited bypass diode flows, resulting in overheating and burnout of the short-circuited bypass diode. The authors’ research group previously reported that when a bypass diode fails within a range of approximately 10⁻¹ Ω to 10 Ω, the heat generated by the failed bypass diode is high, posing the risk of burnout. However, the detailed failure characteristics of the bypass diode that fail because of indirect lightning surges are not clear. In this study, we performed indirect lightning fracture tests and clarified the dielectric breakdown characteristics of Schottky barrier diodes (SBDs) contained in the bypass diodes of photovoltaic solar cell modules, which are subjected to indirect lightning surges. Furthermore, we attempted to determine the conditions of indirect lightning that resulted in a higher risk of heat and ignition. As a result, short-circuit failures occurred in all the Schottky barrier diodes that were destroyed in the forward or reverse direction because of the indirect lightning surges. Moreover, the fault resistance decreased as the indirect lightning surge charge increased. These results indicate that the risks of heat generation and burnout increase when the Schottky barrier diode fails with a relatively low electric charge from an indirect lightning surge. In addition, we observed that for a forward breakdown of the Schottky barrier diode, the range of the indirect lightning surge that results in a fault condition with a higher risk of heat generation and burnout is wider than that for a reverse breakdown. Full article

Faults in solar photovoltaic (PV) modules often result from component damage, leading to voltage fluctuations and decreased stability in the power system. In this study, the original voltage signals of different PV modules show little variation. Therefore, a solution that combines symmetrized dot pattern (SDP) and AlexNet for fault detection in PV modules was proposed. This solution investigates three common faults: poor welding, cracking, and bypass diode failure, which can be applied to fault-free modules. First, a high-frequency signal was input into the PV module, and the raw signal was captured using an NI PXI-5105 high-speed data acquisition card. Next, we used SDP to process the signal and create images with specific snowflake-like features. These images were used as a basis for fault diagnosis. Finally, deep-learning algorithms were used to perform status detection on the PV module. This research also used 3200 training samples and 800 test samples (200 for each type) to evaluate a new method for diagnosing faults in PV modules. The results show that the accuracy of the new method reached 99.8%, surpassing traditional convolutional neural networks (CNN) and extension neural networks (ENN), whose accuracies were 99.5% and 91.75%, respectively. Furthermore, this study compares the proposed method with more traditional numerical fault diagnosis methods. SDP effectively extracts fault signals and presents them as images. With AlexNet used for fault identification, the method excels in accuracy, training time, and testing time, thereby enhancing the stability and reliability of future energy systems. Full article

Photovoltaic (PV) arrays have a considerably lower output when exposed to partial shadowing (PS). Whilst adding bypass diodes to the output reduces PS’s impact, this adjustment causes many output power peaks. Because of their tendency to converge to local maxima, traditional algorithms like perturb and observe and hill-climbing should not be used to track the optimal peak. The tracking of the optimal peak is achieved by employing a range of artificial intelligence methodologies, such as utilizing an artificial neural network and implementing control based on fuzzy logic principles. These algorithms perform satisfactorily under PS conditions but their training method necessitates a sizable quantity of data which result in placing an unnecessary demand on CPU memory. In order to achieve maximum power point tracking (MPPT) with fast convergence, minimal power fluctuations, and excellent stability, this paper introduces a novel optimization algorithm named PSO-AWDV (particle swarm optimization–adaptive weighted delay velocity). This algorithm employs a stochastic search approach, which involves the random exploration of the search space, to accomplish these goals. The efficacy of the proposed algorithm is demonstrated by conducting experiments on a series-connected configuration of four modules, under different levels of solar radiation. The algorithm successfully gets rid of the problems brought on by current traditional and AI-based methods. The PSO-AWDV algorithm stands out for its simplicity and reduced computational complexity when compared to traditional PSO and its variant PSO-VC, while excelling in locating the maximum power point (MPP) even in intricate shading scenarios, encompassing partial shading conditions and notable insolation fluctuations. Furthermore, its tracking efficiency surpasses that of both conventional PSO and PSO-VC. To further validate our results, we conducted a real-time hardware-in-the-loop (HIL) emulation, which confirmed the superiority of the PSO-AWDV algorithm over traditional and AI-based methods. Overall, the proposed algorithm offers a practical solution to the challenges of MPPT under PS conditions, with promising outcomes for real-world PV applications. Full article

Incorporating bypass diodes within photovoltaic arrays serves to mitigate the negative effects of partial shading scenarios. These situations can lead to the appearance of multiple peaks in the performance of solar panels. Nevertheless, there are cases where conventional maximum power point tracking (MPPT) techniques could encounter inaccuracies, causing them to identify the highest power point within a specific area (the local maximum power point; LMPP) instead of the overall highest power point across the entire array (the global maximum power point; GMPP). Numerous methods based on artificial intelligence (AI) were proposed to address this issue; however, they frequently used cumbersome and unreliable methodologies. This research presents the energy-valley-optimizer-based optimization (EVO) technique, which is designed to efficiently and dependably tackle the issue of partial shading (PS) in detecting the maximum power point (MPP) for photovoltaic (PV) systems. The EVO algorithm enhances the speed of tracking and minimizes power output fluctuations during the tracking phase. Through the utilization of the Typhoon hardware-in-the-loop (HIL) 402 emulator, extensive validation of the proposed technique is conducted. The effectiveness of the suggested method is compared with the established cuckoo search algorithm for achieving maximum power point tracking (MPPT) within a photovoltaic (PV) system. This comparison takes place under equivalent conditions to ensure a fair performance evaluation. Full article
