This study investigates the influence of chromatic dispersion on the performance of Brillouin optical time-domain analysis (BOTDA) sensors, particularly under high-pump-power conditions, where nonlinear effects become significant. By incorporating dispersion terms into the coupled amplitude equations of stimulated Brillouin scattering (SBS), we theoretically analyzed the dispersion-induced pulse broadening effect and its impact on the Brillouin gain spectrum (BGS). Numerical simulations revealed that dispersion leads to a moderate broadening of pump pulses, resulting in slight changes to BGS characteristics, including increased peak power and reduced linewidth. To explore the interplay between dispersion and nonlinearity, we built a gain-based BOTDA experimental system and tested two types of fibers, namely standard single-mode fiber (SMF) with anomalous dispersion and dispersion-compensating fiber (DCF) with normal dispersion. Experimental results show that SMF is more prone to modulation instability (MI), which significantly degrades the signal-to-noise ratio (SNR) of the BGS. In contrast, DCF effectively suppresses MI and provides a more stable Brillouin signal. Despite SMF exhibiting narrower BGS linewidths, DCF achieves a higher SNR, aligning with theoretical predictions. These findings highlight the importance of fiber dispersion properties in BOTDA design and suggest that using normally dispersive fibers like DCF can improve sensing performance in long-range, high-power applications. Full article

Structural health monitoring (SHM) plays a vital role in ensuring the safety, durability, and performance of civil infrastructure. This review delves into the significant advancements in optical fiber sensor (OFS) technologies such as Fiber Bragg Gratings, Distributed Temperature Sensing, and Brillouin-based systems, which have emerged as powerful tools for enhancing SHM capabilities. Offering high sensitivity, resistance to electromagnetic interference, and real-time distributed monitoring, these sensors present a superior alternative to conventional methods. This paper also explores the integration of OFSs with Artificial Intelligence (AI), which enables automated damage detection, intelligent data analysis, and predictive maintenance. Through case studies across key infrastructure domains, including bridges, tunnels, high-rise buildings, pipelines, and offshore structures, the review demonstrates the adaptability and scalability of these sensor systems. Moreover, the role of SHM is examined within the broader context of civil and urban infrastructure, where IoT connectivity, AI-driven analytics, and big data platforms converge to create intelligent and responsive infrastructure. While challenges remain, such as installation complexity, calibration issues, and cost, ongoing innovation in hybrid sensor networks, low-power systems, and edge computing points to a promising future. This paper offers a comprehensive amalgamation of current progress and future directions, outlining a strategic path for next-generation SHM in resilient urban environments. Full article

Addressing the critical technological needs for the real-time monitoring of stress distribution in mining areas, a new method for inverting goaf pressure using distributed optical fiber monitoring data is proposed. By coupling the key stratum fracture mechanics model with the subsidence trajectory function model, a theoretical model is established to accurately describe spatial stress evolution during coal mining. The model quantifies the relationship between goaf pressure changes and key stratum failures through a two-stage analysis of the subsidence process, based on distinct mechanical properties before and after key stratum fracture. Physical model experiments (3 m × 0.2 m × 1.1 m) using Brillouin Optical Time Domain Analysis (BOTDA) technology validated the proposed method, with comprehensive monitoring of key stratum deformations. By coupling the fracture mechanics model of the critical layer and the settlement trajectory function model, the dynamic transformation of the pre-fracture and post-fracture stages is realized, and the stress evolution can be monitored and predicted in real time. The results demonstrate spatial consistency between key stratum fracture locations and goaf peak stress positions. High-precision optical fiber sensing detected an ultimate strain threshold of 4000 με for key stratum failure, with pre-fracture strain measurements consistently below this threshold. The developed stress inversion formula successfully predicted pressure distribution patterns within the goaf, achieving real-time monitoring capabilities. Compared with the BPPS measurements, the deviation in the inverted data is less than 8.88%, the root mean square error (RMSE) is 0.98–1.20 in different propulsion stages, and the coefficient of determination (R²) is between 0.72 and 0.85. These findings provide a crucial theory for predicting peak stress evolution in mining areas, with implications for improving safety monitoring systems and optimizing mining operations. Full article

This study presents a novel approach to the design and assessment of slender reinforced concrete (RC) columns by integrating Brillouin Optical Time Domain Analysis (BOTDA) for real-time, distributed strain monitoring and introducing a “time-dependent deterioration factor” strain decay (η_decay). Experimental tests on 200 mm × 200 mm RC columns with lengths of 1800 mm and slenderness ratios of 29.4, reinforced with four 12 mm bars, captured strain variations up to 400 microstrain under an axial load of 1200 kN, demonstrate BOTDA’s sensitivity and precision. Unlike conventional strain gauges, BOTDA provided a continuous strain profile along the column height, accurately capturing strain decay with a resolution exceeding 95%, enabling the detection of localized strain reductions often missed by traditional methods. The integration of η_decay into ACI 318 and Eurocode 2 models conservatively improved predictions, particularly for specimens tested with long-term testing (720 days), with experimental-to-predicted (E/P) ratios of 1.42 and 1.29, respectively, compared to higher discrepancies in the original codes. The η_decay factor accounts for strain reduction along the column height caused by time-dependent effects such as creep, shrinkage, and material degradation, significantly improving the accuracy of axial load capacity predictions. Finite element analysis (FEA) validated these improvements, showing good agreement with experimental data up to the yield load. Post-yield, the modified equations effectively addressed underestimations caused by microcracking, highlighting the necessity of η_decay for reliable long-term performance predictions. This research combines advanced BOTDA technology with an innovative η_decay framework, addressing long-term structural deterioration and refining design codes. It establishes a robust foundation for integrating time-dependent effects into predictive models, enhancing the resilience, safety, and sustainability of RC structures under real-world conditions. Full article

This paper investigates the use of the BOTDA (Brillouin Optical Time-Domain Analysis) technology to monitor a large-scale bored pile wall in the field. Distributed fiber optic sensors (DFOSs) were deployed to measure internal temperature and strain changes during cement grouting, hardening, and excavation-induced deformation of a secant pile wall. The study details the geological conditions and DFOS installation process. During grouting, the temperature increased by approximately 69 °C due to cement hydration 30 min post-grouting, while the strain decreased by 0.5% on average due to cement slurry shrinkage. During excavation, the temperature changes were minimal, but the excavation depth significantly influenced the strain distribution, with continuous compressive deformation observed in two monitored boreholes. Two analytical methods, the numerical integration method (NIM) and the finite difference method (FDM), were used to calculate the lateral pile displacement based on the monitored strain data. The results were compared with previous monitoring data, showing that the lateral displacement of the pile was minimal after excavation and was attributed to the high stiffness of the secant pile wall. This study demonstrates the effectiveness of DFOSs and BOTDA technology for monitoring complex pile wall behaviors during construction. Full article

Strong mine pressure often emerges when the working face of the lower coal seam in a closely spaced coal seam system passes through the remaining coal pillar in the overlying goaf. This study investigates the law of overburden movement and the manifestation of mine pressure during mining under the remaining coal pillar. A physical model measuring 2.5 × 0.2 × 1.503 m is constructed. Fiber Bragg grating sensing technology (FBG) and Brillouin optical time domain analysis technology (BOTDA) are employed in the physical model experiment to monitor the internal strain of the overlying rock as the working face advances. This study determines the laws of overlying rock fracture and working face pressure while mining coal seams beneath the remaining coal pillar. It analyzes the relationship between the pressure at the working face and the strain characteristics of the horizontally distributed optical fiber. A fiber grating characterization method is established for the stress evolution law of overlying rock while passing the remaining coal pillar. The experimental results indicated that the fracture angle of overlying rock gradually decreases during the mining stage through and after the coal pillar. In the mining stage through the coal pillar, the cycle pressure step distance of the working face is reduced by 33.3% compared to the stage after mining through the coal pillar. Initially, the strain pattern of the horizontal optical fiber is unimodal when pressure is first applied to the working face, and it transitions from unimodal to bimodal during periodic pressure. The peak value of fiber Bragg grating compressive strain and the range of influence of advanced support pressure are 3.6 times and 4.8 times, respectively, before passing through the remaining coal pillar. Finally, the accuracy of the FBG characterization method is verified by comparing it to the monitoring curve of the coal seam floor pressure sensor. The research results contribute to applying fiber optic sensing technology in mining physical model experiments. Full article

To address the issue of spatial resolution limitations in traditional Brillouin optical time-domain analysis systems due to phonon lifetime constraints, we employed pre-pumped pulse technology. Additionally, to mitigate the double-peak phenomenon observed in pre-pumped Brillouin optical time-domain analysis systems, we implemented a two-sided band interference method to reduce the linewidth of the double-peak fitting. We conducted bending measurements on three eccentric cores and intermediate cores spaced 120° apart. Our results demonstrate that the system described in this paper can achieve a spatial resolution of 30 cm, with bimodal linewidths of 23.1 MHz and 16.0 MHz. Using the parallel transmission frame algorithm, we determined the curvature of a seven-core fiber with a curvature diameter of approximately 10 cm to be 20.67 m⁻¹, with an error margin of 3.2%. Full article

This paper demonstrates how the processing of Brillouin gain spectra (BGS) by two-dimensional correlation methods improves the accuracy of Brillouin frequency shift (BFS) extraction in distributed fiber optic sensor systems based on the BOTDA/BOTDR (Brillouin optical time domain analysis/reflectometry) principles. First, the spectra corresponding to different spatial coordinates of the fiber sensor are resampled. Subsequently, the resampled spectra are aligned by the position of the maximum by shifting in frequency relative to each other. The spectra aligned by the position of the maximum are then averaged, which effectively increases the signal-to-noise ratio (SNR). Finally, the Lorentzian curve fitting (LCF) method is applied to the spectrum with improved characteristics, including a reduced scanning step and an increased SNR. Simulations and experiments have demonstrated that the method is particularly efficacious when the signal-to-noise ratio does not exceed 8 dB and the frequency scanning step is coarser than 4 MHz. This is particularly relevant when designing high-speed sensors, as well as when using non-standard laser sources, such as a self-scanning frequency laser, for distributed fiber-optic sensing. Full article

The quality of pump pulse in few-mode-fiber Brillouin optical time domain reflectometry (FMF-BOTDR) is vital for the spontaneous Brillouin scattering of modes LP₀₁ and LP₁₁ because it is the comprehensive effect of the main laser linewidth and pulse width, which is firstly discussed as we know. Numerical and experimental analysis are made for the amplitude and linewidth distribution, corresponding to the signal–noise ratio (SNR) and frequency resolution in BOTDR, respectively. Simulation shows the linewidths and peak values of Brillouin scattering have the same tendency for the LP₀₁ mode and LP₁₁ mode when the laser linewidth is less than 1 MHz but decreases slowly until they are the same when the laser linewidth is wider than 1 MHz. With the pulse width widening, the Brillouin linewidths for LP₀₁ and LP₁₁ modes both decrease sharply, almost to the natural linewidth of fiber 41 MHz and 35 MHz. Experimental results show that the amplitude distribution for the LP₀₁ mode is always larger than for the LP₁₁ mode if the main laser has the same linewidth and the frequency fluctuation is at least 2 MHz with the fiber laser and LP₁₁ mode. The above results could provide improved sensing resolution for FMF-BOTDR sensing system. Full article

A time-differential (TD) Brillouin optical correlation domain analysis (BOCDA) sensor system was applied to measure the Brillouin gain spectrum of a 1 km long sensing optical fiber. The optical delay line used in all BOCDA measurement systems was eliminated in the TD-BOCDA system by using a bit-delayed modulation relationship between the probe and pump lightwaves. These lightwaves were phase modulated using 2¹⁶-1 pseudo-random binary sequence codes at 5 Gbps. A 2 cm dispersion-shifted fiber placed at the end of the 1 km optical fiber was distinctly identified by the Brillouin frequency extracted from the Brillouin gain spectrum measurement. To investigate the measurement stability of the TD-BOCDA system, experiments were conducted under two different pumping conditions. A semiconductor optical amplifier (SOA) and an intensity modulator (MOD) were compared for the pump chopper used in the TD-BOCDA system to detect the extinction ratio of the pump and the resulting noise in the Brillouin gain measurement. The stability of the Brillouin frequency measurement from the Brillouin gain spectrum in the TD-BOCDA system was investigated by increasing the average value of the measurement using either the SOA or MOD. The repeated-measurement deviation of the system with the SOA was only half of the deviation observed in the system with the MOD. The performance of TD-BOCDA is equivalent to or better than that of conventional BOCDAs in terms of measurement reliability. Moreover, TD-BOCDA is free from the drawbacks of traditional BOCDA, which uses time-delayed fibers and varies the bit rates. Full article

Rayleigh Brillouin optical time domain analysis (BOTDA) uses the backscattered Rayleigh light generated in the fiber as the probe light, which has a lower detection light intensity compared to the BOTDA technique. As a result, its temperature-sensing technology suffers from a low signal-to-noise ratio (SNR) and severe sensing unreliability due to the influence of the low probe signal and high noise level. The pulse coding and LMD denoising method are applied to enhance the performance of the Brillouin frequency shift detection and temperature measurement. In this study, the mechanism of Rayleigh BOTDA based on a few-mode fiber (FMF) is investigated, the principles of the Golay code and local mean decomposition (LMD) algorithm are analyzed, and the experimental setup of the Rayleigh BOTDA system using an FMF is constructed to analyze the performance of the sensing system. Compared with a single pulse of 50 ns, the 32-bit Golay coding with a pulse width of 10 ns improves the spatial resolution to 1 m. Further enhanced by the LMD algorithm, the SNR and temperature measurement accuracy are increased by 5.5 dB and 1.05 °C, respectively. Finally, a spatial resolution of 1.12 m and a temperature measurement accuracy of 2.85 °C are achieved using a two-mode fiber with a length of 1 km. Full article

Brillouin-scattering-based sensors have been widely applied in distributed temperature or strain measurement in recent 20 years. Brillouin optical correlation-domain technology has extensive development and application prospects because of its millimeter-level spatial resolution, distribution measurement, and high accuracy. Traditional Brillouin-scattering-based sensors, requiring a time-consuming frequency-sweep process, struggle to achieve dynamic strain measurement. In this article, Brillouin optical correlation-domain analysis and reflectometry based on fast-sweep frequency and slope-assisted methods will be reviewed. The main merits, drawbacks, and performances of these schemes are compared, and the avenues for future research and development of these two technologies are also explored. Full article

In order to study the mountain deflection characteristics and the pressure law of the working face after the mining of a shallow coal seam under the valley terrain, a geometric size of 5.0 × 0.2 × 1.33 m is used in the physical similarity model. Brillouin optical time domain analysis (BOTDA) technology is applied to a similar physical model experiment to monitor the internal strain of the overlying rock. In this paper, the strain law of the horizontal optical fiber at different stages of the instability of the mountain structure is analyzed. Combined with the measurement of the strain field on the surface of the model via digital image correlation (DIC) technology, the optical fiber strain characteristics of the precursor of mountain instability are given. The optical fiber characterization method of working face pressure is proposed, and the working face pressures at different mining stages in gully terrain are characterized. Finally, the relationship between the deflection instability of the mountain and the strong ground pressure on the working face is discussed. The sudden increase in the strain peak point of the horizontally distributed optical fiber strain curve can be used to distinguish the strong ground pressure. At the same time, this conclusion is verified by comparing the measured underground ground pressure values. The research results can promote the application of optical fiber sensing technology in the field of mine engineering. Full article

The accuracy of pipeline temperature monitoring using the Brillouin Optical Time Domain Analysis system depends on the Brillouin Gain Spectrum in the Brillouin Optical Time Domain Analysis system. The Non-Local Means noise reduction algorithm, due to its ability to use the data patterns available within the two-dimensional measurement data space, has been used to improve the Brillouin Gain Spectrum in the Brillouin Optical Time Domain Analysis system. This paper studies a new Non-Local Means algorithm optimized through the Black Widow Optimization Algorithm, in view of the unreasonable selection of smoothing parameters in other Non-Local Means algorithms. The field test demonstrates that, the new algorithm, when compared to other Non-Local Means methods, excels in preserving the detailed information within the Brillouin Gain Spectrum. It successfully restores the fundamental shape and essential characteristics of the Brillouin Gain Spectrum. Notably, at the 25 km fiber end, it achieves a 3 dB higher Signal-to-Noise Ratio compared to other Non-Local Means noise reduction algorithms. Furthermore, the Brillouin Gain Spectrum values exhibit increases of 9.4% in Root Mean Square Error, 12.5% in Sum of Squares Error, and 10% in Full Width at Half Maximum. The improved method has a better denoising effect and broad application prospects in pipeline safety. Full article

In this study, Brillouin optical time domain analysis (BOTDA) sensing technology was utilized for monitoring settlement in a similarity model of a highway subgrade. As contact winding cannot be used for an optical fiber that is buried directly in the soil, uncoupling between the fiber and the soil can occur. Thus, an optical-fiber-embedded beam (OFEB) was developed, and a method for measuring and calculating the beam’s deformation was proposed. A calibration test and a test on a similarity model of a subgrade were carried out to investigate the applicability and monitoring accuracy of the OFEB. It was concluded that the OFEB can accurately measure beam deflection, and the maximum relative error between measurements by the optical fiber and a displacement transducer was approximately 5%. The OFEB was embedded directly into a similarity model of a subgrade to monitor settlement. The deflection deformation of the OFEB was found to be close to the subgrade settlement over a certain settlement range, with a relative error below 8.1%. Thus, the OFEB can be used to measure large-range distributed settlement in a subgrade. A numerical simulation was performed to identify appropriate beam dimensions and material design parameters, thereby extending the measurement range before decoupling of the OFEB and the soil occurs. The enhancement of the measurement range and the accuracy of the OFEB based on the preliminary experiments carried out in this study enables further investigation of settlement monitoring. Full article
