Autonomous vehicles at level 3 and above must maintain high navigation accuracy, particularly in global navigation satellite system (GNSS)-denied environments. The main innovations of this work are threefold. First, we integrate visual inertial odometry (VIO) and light detection and ranging (LiDAR) inertial odometry (LIO) as external updates to mitigate the rapid drift of micro-electromechanical system (MEMS)-based industrial-grade inertial measurement units (IMUs) during long-term GNSS outages. Second, we adopt a redundant IMU (RIMU) approach that fuses multiple low-cost IMUs to reduce sensor noise and improve reliability. Third, we propose a system calibration methodology using both static and dynamic vehicle motion to estimate extrinsic parameters (boresight angles and lever arms) of the sensors, achieving an overall boresight angle root-mean-square error of 0.04 degrees in the simulation. Experiments were conducted under a 7 min GNSS-denied scenario in an underground parking lot, allowing for comparison of the error characteristics of multi-sensor fusion schemes against a navigation-grade reference. The INS/GNSS/LIO framework achieved a two-dimensional root-mean-square position error of 1.22 m (95% position error within 2.5 m), meeting the lane-level (1.5 m) accuracy requirement under a GNSS outage exceeding 7 min without prior maps. In contrast, the RINS/GNSS/VIO framework yielded a 4.71 m 2D mean position error under the same conditions. This paper provides a quantitative comparison of the baseline error characteristics of VIO-, LIO-, and RIMU-assisted INS/GNSS fusion under a GNSS-denied navigation scenario. Full article

Spaceborne synthetic aperture radar (SAR) absolute radiometric calibration relies on point targets with a known radar cross-section (RCS), such as triangular trihedral corner reflectors (TTCRs). Traditionally, radiometric calibration using TTCRs requires precise alignment of the corner reflector (CR) boresight to the radar line-of-sight (LOS), leading to frequent field operations and high labor dependency. In this study, a novel compact bidirectional trapezoidal CR is proposed to eliminate such alignment reorientations. The novel CR adopts three design considerations: a scalene shape to optimize the boresight elevation angle and enhance the peak RCS; a bidirectional configuration with azimuth fine-tuning to align with the radar LOS for both ascending and descending passes; and trapezoidal plate trimming to reduce the volume and weight without sacrificing RCS performance. An in-orbit validation is conducted in Xi’an, China, using the SuperView Neo 2-03 satellite. The results demonstrate that the imaging quality of the bidirectional trapezoidal CRs is comparable to that of conventional TTCRs, with all the parameters meeting system specifications. The radiometric calibration constant of the bidirectional trapezoidal CR differs from that of the conventional TTCR by no more than 0.27 dB, with a total uncertainty of ~0.33 dB (1σ)—demonstrating that it achieves equivalent radiometric calibration accuracy to TTCRs. The experiment confirms the feasibility and engineering applicability of the bidirectional trapezoidal CR for X-band SAR radiometric calibration. Full article

The attitude accuracy of high-resolution satellite images is the main factor affecting their geometric positioning accuracy. Bundle block adjustment is the main method for realizing the simultaneous estimation of attitude models for overlapping images over a large area. In the current research on the joint positioning of high-resolution multi-line array satellite images, the adjustment is usually carried out with the view or load as a unit without considering the consistency of the error of the same platform. In this paper, we develop a self-calibration strip bundle adjustment scheme that considers the boresight misalignment among multiple cameras. By introducing the installation angle between multiple loads, we fully utilized their geometric constraint relationship with the same platform to establish a unified attitude compensation model for multiple loads. The experimental results of the ZiYuan3 (ZY-3) satellite image show that, when the ground control points (GCPs) are laid only at four corner points of the image, the image plane and elevation accuracies are 1.85 m and 1.87 m after an adjustment using this method, which can achieve comparable accuracies with those obtained by a traditional program based on an adjustment with more GCPs. Full article

A novel visual 3D reconstruction system, composed of a two-axis galvanometer scanner, a camera with a lens, and a set of control units, is introduced in this paper. By changing the mirror angles of the galvanometer scanner fixed in front of the camera, the boresight of the camera can be quickly adjusted. With the variable boresight, the camera can serve as a virtual multi-ocular system (VMOS), which captures the object at different perspectives. The working mechanism with a definite physical meaning is presented. A simple and efficient method for calibrating the intrinsic and extrinsic parameters of the VMOS is presented. The applicability of the proposed system for 3D reconstruction is investigated. Owing to the multiple virtual poses of the camera, the VMOS can provide stronger constraints in the object pose estimation than an ordinary perspective camera does. The experimental results demonstrate that the proposed VMOS is able to achieve 3D reconstruction performance competitive with that of a conventional stereovision system with a much more concise hardware configuration. Full article

The Ziyuan3-01 (ZY3-01) satellite is China’s first civilian stereo surveying and mapping satellite to meet the 1:50,000 scale mapping requirements, and has been operated in orbit for 10 years. The boresight misalignment of the three-line camera (TLC) is an essential factor affecting the geolocation accuracy, which is a principal concern for stereo mapping satellites. However, the relative relationships of TLC are often regarded as fixed for the same ground scene in most traditional geometric calibrations, without considering the on-orbit long-periodic changes. In this paper, we propose a long-periodic method to analyze and estimate the boresight misalignments between three cameras, with the attitude estimation of a nadir (NAD) camera as the benchmark. Offsets and drifts of the three cameras were calculated and calibrated with different compensation models using scale invariant feature transform (SIFT) points as the ground control. Ten simultaneous NAD–Forward (FWD)–Backward (BWD) imagery of the ZY3-01 satellite acquired from 2012 to 2020 were selected to verify the long-periodic changes in TLC boresight misalignments. The results indicate that the boresight alignment angles of ZY3-01 TLC are dynamic during the long-periodic flight, but the structure of TLC is stable for the misalignments of both FWD and BWD within only 7 arc seconds, which can provide a positive reference for subsequent satellite design and long-periodic on-orbit geometric calibration. Full article

Mobile laser scanning has become an established measuring technique that is used for many applications in the fields of mapping, inventory, and monitoring. Due to the increasing operationality of such systems, quality control w.r.t. calibration and evaluation of the systems becomes more and more important and is subject to on-going research. This paper contributes to this topic by using tools from geodetic configuration analysis in order to design and evaluate a plane-based calibration field for determining the lever arm and boresight angles of a 2D laser scanner w.r.t. a GNSS/IMU unit (Global Navigation Satellite System, Inertial Measurement Unit). In this regard, the impact of random, systematic, and gross observation errors on the calibration is analyzed leading to a plane setup that provides accurate and controlled calibration parameters. The designed plane setup is realized in the form of a permanently installed calibration field. The applicability of the calibration field is tested with a real mobile laser scanning system by frequently repeating the calibration. Empirical standard deviations of <1 ... 1.5 mm for the lever arm and <0.005 ${}^{\circ }$ for the boresight angles are obtained, which was priorly defined to be the goal of the calibration. In order to independently evaluate the mobile laser scanning system after calibration, an evaluation environment is realized consisting of a network of control points as well as TLS (Terrestrial Laser Scanning) reference point clouds. Based on the control points, both the horizontal and vertical accuracy of the system is found to be < 10 mm (root mean square error). This is confirmed by comparisons to the TLS reference point clouds indicating a well calibrated system. Both the calibration field and the evaluation environment are permanently installed and can be used for arbitrary mobile laser scanning systems. Full article

Advances in micro-electro-mechanical navigation systems and lightweight LIDAR (light detection and ranging) sensors onboard unmanned aerial vehicles (UAVs) provide the feasibility of deriving point clouds with very high and homogeneous point density. However, the deformations caused by numerous sources of errors should be carefully treated. This work presents a rigorous calibration of UAV-based LiDAR systems with refinement of the boresight angles using a point-to-plane approach. Our method is divided into a calibration and a parameter mounting refinement part. It starts with the estimation of the calibration parameters and then refines the boresight angles. The novel contribution of the paper is two-fold. First, we estimate the calibration parameters conditioning the centroid of a plane segmented to lie on its corresponding segmented plane without an additional surveying campaign. Second, we refine the boresight angles using a new point-to-plane model. The proposed method is evaluated by analyzing the accuracy assessment of the adjusted point cloud to point/planar features before and after the proposed method. Compared with the state-of-the-art method, our proposed method achieves better positional accuracy. Full article

This paper details a new automatic calibration method for the boresight angles between a LiDAR (Light Detection and Ranging) and an inertial measurement unit (IMU), based on a data selection algorithm, followed by the adjustment of boresight angles. This method, called LiDAR-IMU boresight automatic calibration (LIBAC), takes in input overlapping survey strips following simple line patterns over regular slopes. We first construct a boresight error observability criterion, used to select automatically the most sensitive points to boresight errors. From these points, we adjust the boresight angles. From a statistical analysis of the adjustment results, we derive the boresight angle precision. Results obtained with LIBAC on several LiDAR system integrated within drones are presented. We also give results about the reproducibility of the method. Full article

Mobile LiDAR Scanning (MLS) systems and UAV LiDAR Scanning (ULS) systems equipped with precise Global Navigation Satellite System (GNSS)/Inertial Measurement Unit (IMU) positioning units and LiDAR sensors are used at an increasing rate for the acquisition of high density and high accuracy point clouds because of their safety and efficiency. Without careful calibration of the boresight angles of the MLS systems and ULS systems, the accuracy of data acquired would degrade severely. This paper proposes an automatic boresight self-calibration method for the MLS systems and ULS systems using acquired multi-strip point clouds. The boresight angles of MLS systems and ULS systems are expressed in the direct geo-referencing equation and corrected by minimizing the misalignments between points scanned from different directions and different strips. Two datasets scanned by MLS systems and two datasets scanned by ULS systems were used to verify the proposed boresight calibration method. The experimental results show that the root mean square errors (RMSE) of misalignments between point correspondences of the four datasets after boresight calibration are 2.1 cm, 3.4 cm, 5.4 cm, and 6.1 cm, respectively, which are reduced by 59.6%, 75.4%, 78.0%, and 94.8% compared with those before boresight calibration. Full article

The trihedral corner reflector (TCR) is widely used as the calibration device in monostatic synthetic aperture radar (SAR) calibration, and the performance of the TCR in radiometric calibration has been studied and verified in depth. As for the bistatic SAR system calibration problem, there have been few published studies. There is a lack of knowledge regarding the exact bistatic radar cross-section (RCS) pattern of TCR with different bistatic angles, and it is also not clear whether the TCR can be used as the calibration target in bistatic SAR. Moreover, the bistatic and monostatic radar cross-section (RCS) characteristics of the TCR are different, even if the bistatic angle is very small. Therefore, the feasibility, design, and deployment requirements of the TCR for bistatic SAR calibration should be carefully investigated. In this paper, we outline the theoretical and practical requirements that need to be satisfied when choosing appropriate calibration devices for bistatic radiometric calibration. Based on these requirements, we analyzed the bistatic RCS patterns using electromagnetic simulation, and concluded that the TCR is feasible for bistatic SAR calibration under relatively small bistatic angles (less than 6°). The change of TCR boresight with the bistatic angle is not considered generally. However, we found that the TCR boresight and peak RCS will change with the bistatic angle. We have also proposed that the bistatic angle can be extended to 20° by taking the change of the TCR boresight into account. In this condition, we should get the TCR boresight according to the bistatic angle and then align it during the deployment. Both of these two conditions have their own unique advantages. Different error sources of TCR RCS from manufacture, misalignment, and deformation were investigated quantitatively with simulations, which can provide a theoretical basis for how to design a suitable TCR and guarantee the calibration accuracy for bistatic calibration. In addition, simulation results are different from those of monostatic calibration. Through experiments, we have further verified the feasibility by comparing the quality of bistatic SAR images and point target energy with several typical bistatic angles as the TCR boresight is considered or not. If the bistatic angle is larger than 6°, taking the TCR optimum boresight into account can improve imaging quality and point target energy. Full article

Light Detection and Ranging (LiDAR) is a technology that uses laser beams to measure ranges and generates precise 3D information about the scanned area. It is rapidly gaining popularity due to its contribution to a variety of applications such as Digital Building Model (DBM) generation, telecommunications, infrastructure monitoring, transportation corridor asset management and crash/accident scene reconstruction. To derive point clouds with high positional accuracy, estimation of mounting parameters relating the laser scanners to the onboard Global Navigation Satellite System/Inertial Navigation System (GNSS/INS) unit, i.e., the lever-arm and boresight angles, is the foremost and necessary step. This paper proposes a LiDAR system calibration strategy for a Unmanned Aerial Vehicle (UAV)-based mobile mapping system that can directly estimate the mounting parameters for spinning multi-beam laser scanners through an outdoor calibration procedure. This approach is based on the use of conjugate planar/linear features in overlapping point clouds derived from different flight lines. Designing an optimal configuration for calibration is the first and foremost step in order to ensure the most accurate estimates of mounting parameters. This is achieved by conducting a rigorous theoretical analysis of the potential impact of bias in mounting parameters of a LiDAR unit on the resultant point cloud. The dependency of the impact on the orientation of target primitives and relative flight line configuration would help in deducing the configuration that would maximize as well as decouple the impact of bias in each mounting parameter so as to ensure their accurate estimation. Finally, the proposed analysis and calibration strategy are validated by calibrating a UAV-based LiDAR system using two different datasets—one acquired with flight lines at a single flying height and the other with flight lines at two different flying heights. The calibration performance is evaluated by analyzing correlation between the estimated system parameters, the a-posteriori variance factor of the Least Squares Adjustment (LSA) procedure and the quality of fit of the adjusted point cloud to planar/linear features before and after the calibration process. Full article

The complexity of the single linear hyperspectral pushbroom imaging based on a high altitude airship (HAA) without a three-axis stabilized platform is much more than that based on the spaceborne and airborne. Due to the effects of air pressure, temperature and airflow, the large pitch and roll angles tend to appear frequently that create pushbroom images highly characterized with severe geometric distortions. Thus, the in-flight calibration procedure is not appropriate to apply to the single linear pushbroom sensors on HAA having no three-axis stabilized platform. In order to address this problem, a new ground-based boresight calibration method is proposed. Firstly, a coordinate’s transformation model is developed for direct georeferencing (DG) of the linear imaging sensor, and then the linear error equation is derived from it by using the Taylor expansion formula. Secondly, the boresight misalignments are worked out by using iterative least squares method with few ground control points (GCPs) and ground-based side-scanning experiments. The proposed method is demonstrated by three sets of experiments: (i) the stability and reliability of the method is verified through simulation-based experiments; (ii) the boresight calibration is performed using ground-based experiments; and (iii) the validation is done by applying on the orthorectification of the real hyperspectral pushbroom images from a HAA Earth observation payload system developed by our research team—“LanTianHao”. The test results show that the proposed boresight calibration approach significantly improves the quality of georeferencing by reducing the geometric distortions caused by boresight misalignments to the minimum level. Full article

Spatial information plays a critical role in remote sensing and mapping applications such as environment surveying and disaster monitoring. An Unmanned Aerial Vehicle (UAV)-borne mobile mapping system (MMS) can accomplish rapid spatial information acquisition under limited sky conditions with better mobility and flexibility than other means. This study proposes a long endurance Direct Geo-referencing (DG)-based fixed-wing UAV photogrammetric platform and two DG modules that each use different commercial Micro-Electro Mechanical Systems’ (MEMS) tactical grade Inertial Measurement Units (IMUs). Furthermore, this study develops a novel kinematic calibration method which includes lever arms, boresight angles and camera shutter delay to improve positioning accuracy. The new calibration method is then compared with the traditional calibration approach. The results show that the accuracy of the DG can be significantly improved by flying at a lower altitude using the new higher specification hardware. The new proposed method improves the accuracy of DG by about 20%. The preliminary results show that two-dimensional (2D) horizontal DG positioning accuracy is around 5.8 m at a flight height of 300 m using the newly designed tactical grade integrated Positioning and Orientation System (POS). The positioning accuracy in three-dimensions (3D) is less than 8 m. Full article

The operation and test of a multi-spot digital sun sensor for precise sun-line determination is described. The image forming system consists of an opaque mask with multiple pinhole apertures producing multiple, simultaneous, spot-like images of the sun on the focal plane. The sun-line precision can be improved by averaging multiple simultaneous measures. Nevertheless, the sensor operation on a wide field of view requires acquiring and processing images in which the number of sun spots and the related intensity level are largely variable. To this end, a reliable and robust image acquisition procedure based on a variable shutter time has been considered as well as a calibration function exploiting also the knowledge of the sun-spot array size. Main focus of the present paper is the experimental validation of the wide field of view operation of the sensor by using a sensor prototype and a laboratory test facility. Results demonstrate that it is possible to keep high measurement precision also for large off-boresight angles. Full article
