Search Results (460)

Helicopter vibration is an inherent characteristic of rotorcraft operations, arising from transmission dynamics and unsteady aerodynamic loading, posing challenges to flight control and longevity of structural components. Excessive vibration elevates pilot workload and accelerates fatigue damage in critical components. Leveraging advances in optimal control and microelectronics, the active vibration control methods offer superior adaptability compared to the passive techniques, which are limited by added weight and narrow bandwidth. In this study, a comprehensive vibration analysis and optimal control framework are developed for the Bo 105 helicopter rotor blade exhibiting flapping, lead-lag, and torsional (triply coupled) motions, where a Linear Quadratic Regulator (LQR) is employed to suppress vibratory responses. An analytical formulation is constructed to estimate the blade’s sectional properties, used to compute the coupled natural frequencies of vibration by the modified Galerkin method. An orthogonality condition for the coupled flap–lag–torsion dynamics is established to derive the corresponding state-space equations for both hovering and forward-flight conditions. The LQR controller is tuned through systematic variation of the weighting parameter Q, revealing an optimal range of 10²–10⁴ that balances vibration attenuation and control responsiveness. The predicted frequencies of the vibrating rotor blade are compared with the finite element modeling results and published experimental data. The proposed framework captures the triply coupled rotor blade dynamics with optimal control, achieves modal vibration reductions of approximately 60–90%, and provides a clear theoretical benchmark for future actuator-integrated computational and experimental studies. Full article

Aiming at the reliability of ear picking and the consistency of stalk chopping length in the process of corn ear and stalk harvesting, a new type of corn harvester with both ear and stalk harvesting based on exciting ear picking was developed. Based on the vertical cutting table, the machine realizes the excitation of the ear during the process of stalk transportation by rotating the eight-edged special-shaped pick-up roll, and the stable and orderly transportation of stalks before cutting is realized by the way of clamping and conveying with the rear rollers. By analyzing the configuration and parameter determination methods of the main working parts, the high-efficiency and low-loss harvest of the ear was realized, and the consistency of the cut length of the stalk was guaranteed. A discrete element model (DEM) of ear-bearing maize plants was established using EDEM (version 2024, Altair Engineering, Troy, MI, USA) simulation software, and a five-factor, three-level quadratic orthogonal rotation experiment was conducted based on Response Surface Methodology (RSM). The simulation results indicated that the optimal operational quality was achieved under the following parameters: a header angle of 10°, a snapping roller speed of 942 rpm, a clamping roller speed of 215 rpm, and a moving blade speed of 1450 rpm. Furthermore, multiple sets of field trials were conducted at various forward speeds to validate these findings. The mean values of seed loss rate, ear loss rate, and seed breakage rate are 0.51%, 0.55%, and 0.32%, respectively, for the harvester at operating speeds of 4 km/h, 6 km/h, 8 km/h, and 10 km/h. The σ values are 97%, 98%, 97%, and 98%. The field harvesting performance indexes meet the requirements of technical specifications for evaluating the operation quality of corn combine harvester, and meet the design requirements of low loss, high efficiency, and consistency of stem chopping length. Full article

This study presents a frequency-domain analysis of a finite-element (FEM)-based rotor–nacelle model for wind turbines, validated against the open-source time-domain tool OpenFAST. The analysis was carried out using METHOD, an in-house computational framework implemented in Python. While time-domain models remain standard for nonlinear aeroelastic simulations, frequency-domain approaches offer advantages in early-stage design, control development, and system identification due to their efficiency, transparency, and suitability for parametric studies. The FEM model includes flexible blades, hub, and nacelle dynamics and includes tower and fixed or floating platform components with rotor–tower frequency interactions. In this work, a fixed tower is considered to isolate rotor behaviour. Beam-element formulation enables the computation of natural frequencies, mode shapes, and frequency response functions, and an equivalent rotor model is implemented in OpenFAST for consistent benchmarking. Validation results show close correspondence between the two modelling approaches. Key operational parameters agree within 3%, while structural responses, including flap-wise deflection, bending moments, and resultant quantities, typically fall within an overall accuracy range of 5–15%, consistent with expected differences arising from reference-frame conventions and modelling assumptions. Discrepancies are discussed in terms of numerical damping, model assumptions (differences in the axis system), and the influence of structural simplifications. Overall, the FEM model captures the dominant dynamic behaviour with satisfactory accuracy and a consistent orientation of global response. Computational efficiency results further highlight the advantages of the METHOD framework. Wind-field generation is completed roughly an order of magnitude faster, and long-duration aeroelastic simulations achieve substantial speed-ups, reaching more than one order of magnitude for multi-hour cases, demonstrating strong scalability relative to OpenFAST. Overall, the results confirm that a well-constructed yet still simplified frequency-domain FEM rotor model can provide a robust and computationally efficient alternative to conventional time-domain solvers. Moreover, the computational performance presented here represents a lower bound, as further improvements are readily achievable through parallelisation and solver-level optimisation. Future papers will present the full-system aero-hydro-elastic coupling for fixed and floating offshore wind turbine applications. Full article

This paper presents a numerical study of fluid–structure interaction (FSI) applied to wind turbines, combining computational fluid dynamics (CFD) and finite element analysis (FEA). The study focuses on a 3D wind turbine blade inspired by the GE 1.5XLE model. The blade features a twisted geometry with S818, S825, and S826 aerodynamic profiles, and is made of an orthotropic composite material with variable thickness and an internal spar. The fluid domain is defined by two circular sections upstream and downstream, aligned along the Z-axis. Simulations are performed under a wind speed of 12 m/s and a rotational speed of −2.22 rad/s (Tip Speed Ratio (TSR) = 8), with air modeled as an incompressible fluid at ambient temperature. On the CFD side, a periodic and symmetric modeling approach is applied, reducing the fluid domain to one-third of the full configuration by simulating flow around a single blade and extrapolating results to the remaining ones. This method achieves a 47% reduction in computation time while maintaining high accuracy in aerodynamic results. On the FEA side, spar condensation is performed by creating a superelement using the substructuring method. This strategy reduces structural computation time by 45% while preserving reliable predictions of displacements, stresses, and natural frequencies. These results confirm the effectiveness of the proposed techniques for accurate and computationally efficient aeroelastic simulations. Full article

Small multi-rotor UAVs face endurance limitations during long-range missions due to high rotor energy consumption and limited battery capacity. This paper proposes a folding-wing range extender integrating a sliding-rotating two-degree-of-freedom folding wing—which, when deployed, quadruples the fuselage length yet folds within its profile—and a tail-thrust propeller. The device can be rapidly installed on host small multi-rotor UAVs. During cruise, it utilizes wing unloading and incoming horizontal airflow to reduce rotor power consumption, significantly extending range while minimally impacting portability, operational convenience, and maneuverability. To evaluate its performance, a 1-kg-class quadrotor test platform and matching folding-wing extender were developed. An energy consumption model was established using Blade Element Momentum Theory, followed by simulation analysis of three flight conditions. Results show that after installation, the required rotor power decreases substantially with increasing speed, while total system power growth slows noticeably. Although the added weight and drag increase low-speed power consumption, net range extension emerges near 15 m/s and intensifies with speed. Subsequent parametric sensitivity analysis and mission profile analysis indicate that weight reduction and aerodynamic optimization can effectively enhance the device’s performance. Furthermore, computational fluid dynamics (CFD) analysis confirms the effectiveness of the dihedral wing design in mitigating mutual interference between the rotor and the wing. Flight tests covering five conditions validated the extender’s effectiveness, demonstrating at 20 m/s cruise: 20% reduction in total power, 25% improvement in endurance/range, 34% lower specific power, and 52% higher equivalent lift-to-drag ratio compared to the baseline UAV. Full article

To address the automation of table grape harvesting, a clamping and cutting integrated, four-point flexible end-effector is designed, based on the biological and mechanical characteristics of grapes. The clamping device is validated in regard to force closure requirements using a force spiral. On this basis, a finite element model of the grape pedicel–blade system is established, and dynamic simulations of pedicel cutting are conducted using ANSYS 2021/LS-DYNA. The simulation results indicate that when the pedicel diameter is 10 mm, the maximum shear stress is 1.515 MPa. A kinematic simulation of the clamping device is performed using ADAMS, producing a contact force curve between the end effector’s finger joints and the grape during the clamping process. The simulation results show that the peak contact force of 11 N is lower than the critical rupture force of the grape (24.79 N), satisfying the requirements for flexible, low-damage harvesting. Furthermore, to address the vulnerability of grapes, a contact-force control system is designed, employing a position–speed–torque three-loop control strategy. Pressure sensors integrated into the four clamping fingers provide real-time feedback to adjust the contact force, ensuring precise clamping control. Finally, a physical prototype of the end effector and controller is developed, and harvesting trials are conducted in a vineyard. The harvesting success rate reaches 96.7%, with an average harvesting time of 13.7 s per trial. The grape cluster damage and berry drop rates are 3.2% and 2.8%, respectively, meeting the expected design requirements. Full article

The quantitative measurement of bonding strength in hybrid bonding (HB) is an indispensable metrology for process and reliability evaluation. Methods currently used such as blade insertion (BI) and double cantilever bending (DCB) have suffered from a wafer edge-only capability and limited repeatability due to a lack of precise interface crack initiation. This study reports an improved DCB method by introducing a post-bonding crack (PBC) to avoid undesired cracking in a wafer substrate during DCB propagation. This method is firstly applied to measure the bonding strength of SiCN-SiCN under O₂ and N₂ activation. The test data shows that the bonding strengths are 3.53 J/m² and 2.93 J/m² with the deviations less than 3.84% and 1.84%. Based on the experimental data, finite element analysis (FEA) methods are used to simulate the crack propagation process of the PBC-DCB method. The results show that the bonding interface crack propagation can be accurately described by an optimized viscoelastic exponential model. The accuracy of simulation increased from 16.06% to 1.77%. Finally, it was found that the PBC-DCB method can solve the issue in conventional DCB where the crack may be initiated away from the target interface, therefore measuring the wrong interface. This advantage is further validated by simulations considering the offset of the PBC away from the bonding interface. Full article

Short fibre-reinforced adhesives (SFRAs) are increasingly used in wind turbine blades to enhance stiffness and fatigue resistance, yet their heterogeneous microstructure poses significant challenges for predictive modelling. This study presents a fully automated digital workflow that integrates micro-computed tomography (µCT), image processing, and finite element modelling (FEM) to investigate the mechanical response of SFRAs. Our aim is also to establish a computational foundation for data-driven modelling and future AI surrogates of adhesive joints in wind turbine blades. High-resolution µCT scans were denoised and segmented using a hybrid non-local means and Gaussian filtering pipeline combined with Otsu thresholding and convex hull separation, enabling robust fibre identification and orientation analysis. Two complementary modelling strategies were employed: (i) 2D slice-based FEM models to rapidly assess microstructural effects on stress localisation and (ii) 3D voxel-based FEM models to capture the full anisotropic fibre network. Linear elastic simulations were conducted under inhomogeneous uniaxial extension and torsional loading, revealing interfacial stress hotspots at fibre tips and narrow ligaments. Fibre clustering and alignment strongly influenced stress partitioning between fibres and the matrix, while isotropic regions exhibited diffuse, matrix-dominated load transfer. The results demonstrate that image-based FEM provides a powerful route for structure–property modelling of SFRAs and establish a scalable foundation for digital twin development, reliability assessment, and integration with physics-informed surrogate modelling frameworks. Full article

Zero-depth nanopores present a promising solution to the challenges associated with ultrathin membranes used in solid-state resistive pulse sensors for DNA sequencing. Most existing fabrication methods are either complex or lack the nanoscale precision required. In this study, we introduce a cost-effective approach that combines PDMS molding at the intersection of silicon micro-blades with an innovative high-resolution nano-positioning technique. These blades are created through photolithography and a two-step KOH wet etching process, allowing for the formation of sub-50 nm 3D rhombic zero-depth nanopores featuring large vertex angles. To address the limitations of SEM imaging—such as dielectric charging and deformation of PDMS membranes under electron beam exposure—we devised a finite element model (FEM) that correlates electrical conductance with pore size and electrolyte concentration. This model aligns closely with experimental data, yielding a mean absolute percentage error of 3.69%, thereby enabling real-time indirect sizing of the nanopores based on the measured conductance. Additionally, we identified a critical channel length beyond which pore resistance becomes negligible, facilitating a linear relationship between conductance and pore diameter. The nanopores produced using this method exhibited a 2.4-fold increase in conductance compared to earlier designs, highlighting their potential for high-precision DNA sequencing applications. Full article

Although the hub blockage effect is generally disregarded for large-sized horizontal axis wind machines, it can significantly affect the performance of small-sized turbines whose ratio between the hub and rotor radii can attain values up to 25–30%. This article proposes a generalisation of the Blade-Element/Momentum Theory (BE/M-T), accounting for the effects of the hub presence on the rotor performance. The new procedure relies on the quantitative evaluation of the radial distribution of the axial velocity induced by the hub all along the blade span. It is assumed that this velocity is scarcely influenced by the magnitude and type of the rotor load, and it is evaluated using a classical CFD approach applied to the bare hub. The validity and accuracy of the modified BE/M-T model are tested by comparing its results with those of a more advanced CFD-actuator-disk (CFD-AD) approach, which naturally and duly takes into account the hub blockage, the rotor presence, an and the wake divergence and rotation, and the results are validated against experimental data. The comparison shows that the correction for the hub blockage effects in the BE/M-T model significantly reduces the differences with the results of the reference method (CFD-AD) both in terms of global (power coefficient) and local (thrust and torque per unit length) quantities. Full article

This work investigates the influence of ground effect on the performance of a UAV propeller through a combined experimental, analytical, and numerical approach. A dedicated test bench was designed and constructed to enable controlled measurements of thrust and power under static conditions. During experimental campaigns, it was observed that the measured thrust significantly exceeded theoretical free-air predictions, suggesting the presence of a ground-like amplification effect. To quantify and validate this phenomenon, complementary methods were employed: blade element momentum-based analytical modeling corrected for ground proximity and high-fidelity CFD simulations performed using ANSYS CFX. Three configurations were analyzed numerically—an isolated propeller, a propeller with a motor, and a propeller–motor–mounting plate configuration—highlighting the progressive impact of structural elements on the flow field. The results showed close agreement between corrected analytical predictions, CFD solutions, and experimental data, with deviations below 8%. The presence of the mounting plate induced pressure redistribution and jet reflection, analogous to the helicopter ground effect, leading to thrust amplification of up to 30% relative to free-air conditions. This study confirms the critical role of the experimental setup and mounting configuration in propeller characterization and establishes a validated methodology for capturing ground effect phenomena relevant to UAV propulsion systems. Full article

The wake characteristics of tidal turbines are significantly influenced by turbulence intensity (TI) and flow velocity in the marine environment. This study employs the Blade Element Momentum (BEM)–CFD method to model two-bladed horizontal tidal turbine wakes, simplifying the turbine geometry while ensuring computational efficiency. The numerical model, validated against experimental data, demonstrates reliable accuracy. Simulations were conducted for background TI levels of 2%, 6%, 10%, 14%, and 18%. Results indicate that wake regions initially expand and then contract, with the contraction point moving closer to the turbine as TI increases. At 2% TI, the wake influence region extends to an axial distance/diameter (X/D) ratio of 20, while at 18% TI, contraction begins at X/D = 4. Low TI results in more extensive low-speed regions, whereas high TI accelerates wake recovery. As TI increases, the wake’s turbulence rapidly blends with the background, leading to a reduction in turbulence increments within the wake. Additionally, an analytical wake model for tidal turbines was developed, incorporating turbulence intensity into the formula. The predicted curve exhibited good agreement with the CFD data. This model enables a quick and efficient prediction of wake velocity changes under varying turbulence intensities. Full article

Toroidal propellers have emerged as a promising substitute for next-generation marine propulsors due to their potential advantages in hydrodynamic efficiency and noise control. This article presents a hydrodynamic analysis of toroidal propellers using a potential-based boundary element method (BEM) that enables rapid computations of complex geometries when compared with computationally demanding viscous simulations. The method predicts the inviscid flow characteristics, forces, and circulation distributions of toroidal propellers and is validated against Reynolds-averaged Navier–Stokes (RANS) simulations under various loading conditions and geometric configurations. The comparison shows that the BEM successfully reproduces the overall thrust and torque trends observed in the viscous simulations, although discrepancies arise due to flow separation and the absence of leading-edge vortices that dominate the suction side dynamics in RANS results. The wake alignment model in the BEM captures the overall trajectories of the shed vortices with good consistency, though its concentrated wake representation occasionally brings the trailing wake substantially close to the rear blade surface, which causes locally low pressures that are not present in RANS where boundary layers prevent direct wake impingement. The BEM was further extended for a parametric study that varied pitch, axial spacing, and lateral angle, showing that pitch variations have the most significant influence on propeller loading and thrust characteristics. Overall, the present work demonstrates that the proposed BEM provides a computationally efficient and physically reasonable framework for predicting the performance of toroidal propellers, especially for early-stage geometric design and optimization. Full article

The Discrete Element Method (DEM) has become a cornerstone for analysing granular flow and mixing phenomena in static mixers. This review provides a comprehensive synthesis that distinguishes it from previous studies by: (i) covering a broad range of static mixer geometries, including Kenics, SMX, and Sulzer designs; (ii) integrating experimental validation methods, such as particle tracking, high-speed imaging, Particle Image Velocimetry (PIV), and X-ray tomography, to assess DEM predictions; and (iii) systematically analyzing computational strategies, including advanced contact models, hybrid DEM-CFD/FEM frameworks, machine learning surrogates, and GPU-accelerated simulations. Recent advances in contact mechanics—such as improved cohesion, rolling resistance, and nonspherical particle modelling—have enhanced simulation realism, while adaptive time-stepping and coarse-graining improve computational efficiency. DEM studies have revealed several non-obvious relationships between mixer geometry and particle dynamics. Variations in blade pitch, helix angle, and element arrangement significantly affect local velocity fields, mixing uniformity, and energy dissipation. Alternating left–right element orientations promote cross-sectional particle exchange and reduce stagnant regions, whereas higher pitch angles enhance axial transport but can weaken radial mixing. Particle–wall friction and surface roughness strongly govern shear layer formation and segregation intensity, demonstrating the need for geometry-specific optimization. Comparative analyses elucidate how particle–wall interactions and channel structure influence segregation, residence time, and energy dissipation. The review also identifies current limitations, highlights validation and scale-up challenges, and outlines key directions for developing faster, more physically grounded DEM models, providing practical guidance for industrial mixer design and optimization. Full article

This study presents the geometric optimization of a Savonius-type VAWT with multi-element blade profiles using a full factorial design integrated with RSM. Two crucial geometric parameters, the blade twist angle ($\gamma$) and the aspect ratio ($AR$), were systematically varied to assess their influence on the power coefficient ($C_p$). Experimental measurements were performed in a controlled wind tunnel environment, and a second-order regression equation was used to model the resulting data. The optimization approach identified the combination of $\gamma$ and $AR$ that maximized $C_p$. The optimal configuration was achieved with a $\gamma$ of 30° and an $AR$ of 2.0, for which the experimentally measured power coefficient ($C_p$) reached a value of 0.2326. The results confirm that lower twist angles and higher aspect ratios enhance aerodynamic efficiency, reduce manufacturing complexity, and improve structural reliability. These findings highlight the potential of Savonius turbines as competitive solutions for small-scale energy harvesting in low-wind-speed environments. Moreover, the identified optimal configuration provides a basis for future work that focuses on scaling the design, integrating power transmission and electrical generation components, and validating performance under real operating conditions. Full article
