Bypass diffusers are used to drain the excess steam generated in the steam generator in case of sudden load reduction or shutdown of the steam turbine. However, the steam at the orifice outlet with the high flow velocity may reverse into the space of last-stage blades and cause forced vibration of the turbine blades. For this study, a full-scale CFD calculation model which couples the last stage and the second-last stage with the bypass diffusers was constructed. The fluid dynamic characteristics of the high-speed steam discharged from the outlet of the bypass diffusers and the effect of steam on the last-stage rotating blades were analyzed comprehensively via both steady and transient numerical methods. The steady results show that the steam at the orifice outlet of the bypass diffusers presents a typical jet flow with some steam flowing back into the last-stage blades region through the exhaust of the cylinders. This results in a notable disturbance to the last-stage rotating blades, characterized by a non-uniform circumferential pressure distribution. The transient numerical simulation results reveal that the outlet mass flow rate of the steam from the second-last-stage stationary blades has a significant effect on both the Mach number distribution and the surface forces acting on the last-stage rotating blades. The higher outlet mass flow rate of the steam escalates the instability of the flow field. The difference in the Mach number at the same position can reach as high as 60% or more under different operating conditions. The forces acting on the last-stage rotating blades in different directions change periodically with time, and the magnitude and period of the variation correlate with the outlet mass flow rate of the steam. Full article

Under the challenge of global energy transition, coal-fired cogeneration systems are undergoing a technical revolution towards enhanced efficiency, heating capacity, and flexibility. In this paper, four schemes using a steam ejector integrated into a cogeneration system are designed. Considering operational safety, integrated locations are selected at the front and back of high- and medium-pressure turbines. Subsequently, the thermodynamic and operational characteristics under both design and off-design conditions are analyzed based on a model built in EBSILON Professional. Finally, a sensitivity analysis of the heating process is conducted. The results show that the integration of steam ejectors can increase the waste heat recovery ratio of exhaust steam by 18.42–45.61% under design conditions. The largest waste heat recovery ratio is obtained in System 4, resulting in the power generation efficiency (${\eta }_g$) and gross energy utilization efficiency (${\eta }_p$) of 81.95% and 65.53%, respectively. Meanwhile, the steam ejector can expand the power-load regulation range of the cogeneration system, and System 4 has the lowest lower power limit among all the systems. The ${\eta }_p$ values of Systems 1–4 reach extreme values at different mixed steam pressures of the ejector. Increasing the pinch point temperature difference reduces the power load ${\eta }_g$ and ${\eta }_p$ of Systems 1–4. The results provide technical solutions for improving the heating capacity and efficient and flexible operation of cogeneration systems. Full article

This study focuses on using machine learning techniques to accurately predict the generated power in a two-stage back-pressure steam turbine used in the paper production industry. In order to accurately predict power production by a steam turbine, it is crucial to consider the time dependence of the input data. For this purpose, the long-short-term memory (LSTM) approach is employed. Correlation analysis is performed to select parameters with a correlation coefficient greater than 0.8. Initially, nine inputs are considered, and the study showcases the superior performance of the LSTM method, with an accuracy rate of 0.47. Further refinement is conducted by reducing the inputs to four based on correlation analysis, resulting in an improved accuracy rate of 0.39. The comparison between the LSTM method and the Willans line model evaluates the efficacy of the former in predicting production power. The root mean square error (RMSE) evaluation parameter is used to assess the accuracy of the prediction algorithm used for the generator’s production power. By highlighting the importance of selecting appropriate machine learning techniques, high-quality input data, and utilising correlation analysis for input refinement, this work demonstrates a valuable approach to accurately estimating and predicting power production in the energy industry. Full article

There is a big wave in China of retrofitting single-purpose coal-fired systems for district heating into heat-oriented combined heat and power (CHP) systems to save energy. Back-pressure steam turbines (BPSTs) and extraction steam turbines (ESTs) are both common in retrofitted systems, but contrastive analyses of their effects on the systems’ operation performance are lacking. Moreover, comprehensive evaluation methods of the retrofitted systems remain unknown. In this paper, exergy, exergoeconomic, and exergoenvironmental analyses were conducted to evaluate the thermodynamic, economic, and environmental performances of two real CHP systems: system A using a BPST and system B using an EST. Additionally, a new multi-criteria evaluation method based on rank correlation analysis was proposed for the retrofitted system. The results show that system A is better than system B in thermodynamic and environmental aspects but poorer in the economic aspect. Overall, the multi-criteria evaluation result indicates that system A has a better comprehensive performance than system B. Therefore, the BPST has a better effect than the EST on the retrofitted CHP system for district heating in this study. The findings could provide a reference point for retrofitting work in the future. Full article

In an effort to address the load adjustment time in the thermal and electrical load distribution of thermal power plant units, we propose an optimal load distribution method based on load prediction among multiple units in thermal power plants. The proposed method utilizes optimization by attention to fine-tune a deep convolutional long-short-term memory network (CNN-LSTM-A) model for accurately predicting the heat supply load of two 30 MW extraction back pressure units. First, the inherent relationship between the heat supply load and thermal power plant unit parameters is qualitatively analyzed, and the influencing factors of the power load are screened based on a data-driven analysis. Then, a mathematical model for load distribution optimization is established by analyzing and fitting the unit’s energy consumption characteristic curves on the boiler and turbine sides. Subsequently, by using a randomly chosen operating point as an example, a genetic algorithm is used to optimize the distribution of thermal and electrical loads among the units. The results showed that the combined deep learning model has a high prediction accuracy, with a mean absolute percentage error (MAPE) of less than 1.3%. By predicting heat supply load variations, the preparedness for load adjustments is done in advance. At the same time, this helps reduce the real-time load adjustment response time while enhancing the unit load’s overall competitiveness. After that, the genetic algorithm optimizes the load distribution, and the overall steam consumption rate from power generation on the turbine side is reduced by 0.488 t/MWh. Consequently, the coal consumption rate of steam generation on the boiler side decreases by 0.197 kg (coal)/t (steam). These described changes can greatly increase the power plant’s revenue by CNY 6.2673 million per year. The thermal power plant used in this case study is in Zhejiang Province, China. Full article

Thermal power plants (TPPs) with back-pressure steam turbines (BPSTs) were widely used for electricity and steam production in the Union of Soviet Socialist Republics (USSR) due to their high efficiency. The collapse of the USSR in 1991 led to a decrease in industrial production, as a result of which, steam production in Russia was reduced and BPSTs were left without load. To resume the operation of TPPs with BPSTs, it is necessary to modernize the existing power units. This paper presents the results of the thermodynamic analysis of different methods of modernization of TPPs with BPSTs: the superstructure of the steam low-pressure turbine (LPT) and the superstructure of the power unit operating on low-boiling-point fluid. The influence of ambient temperature on the developed cycles’ efficiency was evaluated. It was found that the usage of low-boiling-point fluid is thermodynamically efficient for an ambient temperature lower than 7 °C. Moreover, recommendations for the choice of reconstruction method were formulated based on technical assessments. Full article

Forecasts to 2030 indicate that demand for electricity will increase from 2% to 3% per year, and due to the observed high rate of development of the world economy, energy demand will continue to increase. More efficient use of primary energy has influence on reduction emissions and consumption of fuel. Besides, reducing the amount of fuel burned, it reveals a beneficial effect on the environment. Since extraction-back pressure turbines have some limitations, including the restriction of electricity production due to limited heat consumption in summer. The paper discusses the possibilities of integrating the adsorption aggregate with a combined cycle gas turbine and its impact on the operation of all devices. Simulations are performed on Sim tech IPSEPro software. The obtained results confirm that the adsorption aggregate, using a low grade of thermal energy, does not affect the operation of the gas and steam cycle and allows the production of electricity at a constant level. The calculated chemical fuel energy utilisation factor was 85.7% in cogeneration and 75.6% in trigeneration. These factors indicated a reduced utilisation of chemical fuel energy; however, this reduction is caused by a lower COP for adsorption chillers. Besides, the adsorption aggregate additionally generates chilled water for air conditioning or other technological processes, which stands for an added value of the innovative concept proposed in the paper. Full article

To improve the adaptability of direct air-cooled power generating units to the variations of both meteorological condition and power load, a piping-main arrangement of air-cooled condensers was proposed. The heat and mass transfer models of the air-side were established for the air cooling system of 2 × 600 MW thermal power generating units. The coupled model for both flow resistance loss and condensate flow rate distributions of exhaust steam inside air-cooled condensers were developed based on the temperature fields through numerical simulation. Calculation results, including the condensate flow rate, back pressure, and coal consumption rate, were acquired under different ambient temperatures and wind velocities. The results show that the proposed piping-main arrangement can weaken the ambient wind impacts and reduce the backpressure significantly in summer by adjusting the number of air-cooled condenser cells in operation. The steam flow rate can be uniformed effectively by adjusting the number of operating air-cooled condenser cells during winter. It can also avoid the freezing accident in winter while cooling the exhaust steam of two turbines by part air-cooled condenser cells. Full article

High back-pressure (HBP) heating technology has been identified as an effective approach to improve the efficiency of combined heat and power (CHP). In this study, the novel concept of a HBP heating system with energy cascade utilization is developed and its probability examined. In the reformative design, the extracted heating steam from the intermediate-pressure turbine (IPT) is first drawn to an additional turbine where its excess pressure can be converted into electricity, then steam with a lower pressure can be employed to heat the supply water. As a consequence, the exergy destruction in the supply water heating process can be reduced and the efficiency of the cogeneration unit raised. A detailed thermodynamic investigation was performed based on a typical coal-fired HBP–CHP unit incorporating the proposed configuration. The results show that the artificial thermal efficiency (ATE) promotion was as much as 2.01 percentage points, with an additional net power output of 8.4 MW compared to the reference unit. This was attributed to a 14.65 percentage-point increment in the exergy efficiency of the supply water heating process caused by the suggested retrofitting. The influences of the unit power output, unit heat output, supply water and return water temperatures and turbine back pressure on the thermal performance of the modified system are discussed as well. In addition, the economic performance of the new design is assessed, indicating that the proposed concept is financially feasible. Full article

The transformation of heat supply structures towards 4th generation district heating (4GDH) involves lower supply temperatures and a shift in technology. In order to assess the economic viability of the respective systems, adequate unit commitment models are needed. However, maintaining the formal requirements, while reducing the computational efforts of these models, often includes simplifications such as the assumption of constant supply temperatures. This study investigates the effect of introducing varying supply temperatures in mixed-integer linear programming models. Based on a case study of a municipal district heating system, how the temperature integration approach affects unit commitment and technology assessment for different temperature levels and scenarios is analyzed. In particular, three supply temperature levels are investigated with both variable and constant temperatures in two scenarios. Results indicate that lower flow temperature levels in the heating network tend to favor internal combustion engines, combined cycle power plants, and heat pumps; while back pressure steam turbines, peak loads, and electric boilers show declining operating hours. Furthermore, the effect of varying versus constant temperatures at the same temperature level is rather small, at least as long as technical restrictions do not come into play. Finally, it is found that the effect of changing temperature on a technology assessment is comparably small as opposed to adaptions in the regulatory framework. Full article

A conceptual high-back pressure (HBP) heating system cooperating raw coal pre-drying for combined heat and power (CHP) was proposed to improve the performance of the HBP-CHP unit. In the new design, besides of heating the supply-water of the heating network, a portion of the exhaust steam from the turbine is employed to desiccate the raw coal prior to the coal pulverizer, which further recovers the waste heat of the exhaust steam and contributes to raising the overall efficiency of the unit. Thermodynamic and economic analyzes were conducted based on a typical 300 MW coal-fired HBP-CHP unit with the application of the modified configuration. The results showed that the power generation thermal efficiency promotion of the unit reaches 1.7% (absolute value) owing to suggested retrofitting, and meanwhile, the power generation standard coal consumption rate is diminished by 5.8 g/kWh. Due to the raw coal pre-drying, the energy loss of the exhaust flue gas of the boiler is reduced by 19.1% and the boiler efficiency increases from 92.7% to 95.4%. The impacts of the water content of the dried coal and the unit heating capacity on the energy-saving effect of the new concept were also examined. Full article

Reducing losses in the secondary air system of gas and steam turbines can significantly increase the efficiency of such machines. Meanwhile, brush seals are a widely used alternative to labyrinth seals. Their most valuable advantage over other sealing concepts is the very small gap between the sealing package and the rotor and thus reduced leakage mass flow. This small gap can be achieved due to the great radial flexibility without running the risk of severe detrimental deterioration in case of rubbing. Rubbing between rotor and seal during operation might occur as a result of e.g., an unequal thermal expansion of the rotor and stator or a rotor elongation due to centrifugal forces or manoeuvre forces. Thanks to the flexible structure of the brush seal, the contact forces during a rubbing event are reduced; however, the frictional heat input can still be considerable. Particularly in aircraft engines with their thin and lightweight rotor structures, the permissible material stresses can easily be exceeded by an increased heat input and thus harm the engine’s integrity. The geometry of the seal has a decisive influence on the resulting contact forces and consequently the heat input. This paper is a contribution to further understand the influence of the geometrical parameters of the brush seal on the heat input and the leakage during the rubbing of the seal on the rotor. In this paper, a total of three seals with varied back plate inner diameter are examined in more detail. The experimental tests were carried out on the brush seal test rig of the Institute of Thermal Turbomachinery (ITS) under machine-relevant conditions. These are represented by pressure differences of 1 to 7 bar, surface speeds of 30 to 180 m/s and radial interferences of 0.1 to 0.4 mm. For a better interpretation, the results were compared with those obtained at the static test rig of the Institute of Jet Propulsion and Turbomachinery (IFAS) at the Technical University of Braunschweig. The stiffness, the blow-down and the axial behaviour of the seals as a function of the differential pressure can be examined at this test rig. It could be shown that the back plate inner diameter has a decisive influence on the overall operating behaviour of a brush seal. Full article

The microstructure and toughness of tungsten inert gas (TIG) backing weld parts in low-pressure steam turbine welded rotors contribute significantly to the total toughness of the weld metal. In this study, the microstructure evolution and toughness of TIG weld metal of 25Cr2Ni2MoV steel low-pressure steam turbine welded rotor under different post-weld heat treatment (PWHT) conditions are investigated. The fractography and microstructure of weld metal after PWHT are characterized by optical microscope, SEM, and TEM, respectively. The Charpy impact test is carried out to evaluate the toughness of the weld. The optical microscope and SEM results indicate that the as-welded sample is composed of granular bainite, acicular ferrite and blocky martensite/austenite (M-A) constituent. After PWHT at 580 °C, the blocky M-A decomposes into ferrite and carbides. Both the number and size of precipitated carbides increase with holding time. The impact test results show that the toughness decreases dramatically after PWHT and further decreases with holding time at 580 °C. The precipitated carbides are identified as M₂₃C₆ carbides by TEM, which leads to the dramatic decrease in the toughness of TIG weld metal of 25Cr2Ni2MoV steel. Full article

To reduce the exergy loss that is caused by the high-grade extraction steam of traditional heating mode of combined heat and power (CHP) generating unit, a high back-pressure cascade heating technology for two jointly constructed large-scale steam turbine power generating units is proposed. The Unit 1 makes full use of the exhaust steam heat from high back-pressure turbine, and the Unit 2 uses the original heating mode of extracting steam condensation, which significantly reduces the flow rate of high-grade extraction steam. The typical 2 × 350 MW supercritical CHP units in northern China were selected as object. The boundary conditions for heating were determined based on the actual climatic conditions and heating demands. A model to analyze the performance of the high back-pressure cascade heating supply units for off-design operating conditions was developed. The load distributions between high back-pressure exhaust steam direct supply and extraction steam heating supply were described under various conditions, based on which, the heating efficiency of the CHP units with the high back-pressure cascade heating system was analyzed. The design heating load and maximum heating supply load were determined as well. The results indicate that the average coal consumption rate during the heating season is 205.46 g/kWh for the design heating load after the retrofit, which is about 51.99 g/kWh lower than that of the traditional heating mode. The coal consumption rate of 199.07 g/kWh can be achieved for the maximum heating load. Significant energy saving and CO₂ emission reduction are obtained. Full article

The cooling efficiency of natural draft dry cooling system (NDDCS) are vulnerable to ambient winds, so the implementation of measures against the wind effects is of great importance. This work presents the combined air leading strategies to recover the flow and heat transfer performances of NDDCS. Following the energy balance among the exhaust steam, circulating water, and cooling air, numerical models of natural draft dry cooling systems with the combined air leading strategies are developed. The cooling air streamlines, volume effectiveness, thermal efficiency and outlet water temperature for each cooling delta of the large-scale heat exchanger are obtained. The overall volume effectiveness, average outlet water temperature of NDDCS and steam turbine back pressure are calculated. The results show that with the air leading strategies inside or outside the dry-cooling tower, the thermo-flow performances of natural draft dry cooling system are improved under all wind conditions. The combined inner and outer air leading strategies are superior to other single strategy in the performance recovery, thus can be recommended for NDDCS in power generating units. Full article
