Search Results (66)

This paper describes the design and implementation of an automated irrigation control system that uses data collected by a wireless sensor network. Each sensor node, built on a custom-designed printed circuit board, includes sensors for light intensity, temperature, and a custom soil moisture sensor. Data is transmitted to a central control node via ESP-NOW, where it is processed and compared with configurable thresholds retrieved from Google Sheets over Wi-Fi. Irrigation is triggered automatically when conditions meet the remotely defined thresholds. A key contribution is the development and testing of a custom soil moisture sensor, with results compared to commercial models. The system supports low-power operation through deep sleep modes, enabling long-term field deployment. The novelty lies in the complete integration of hardware, software, and cloud-based control, providing a flexible and low-cost solution for precision agriculture. The system can be deployed in greenhouses or open fields and serves as a platform for future research in smart irrigation. The fundamental aspect is a very user-friendly solution for any farmer attributable to easy accommodation to the Google Sheets interface, no maintenance cost over the cloud account, and up to 45 days of battery life or a built-in alternative for solar power. Full article

Despite its significant water-saving potential, the adoption of alternate wetting and drying (AWD) irrigation remains limited due to infrastructure constraints and intensive manual monitoring requirements. An automated precision irrigation system was developed and tested at the Bangladesh Rice Research Institute research farm in Gazipur, Bangladesh. The system combined ultrasonic water-level sensors, capacitive soil moisture sensors, an Arduino-based microcontroller, a GSM communication module, and solar-powered automatic control gates. Field performance was evaluated following a Randomized Complete Block Design (RCBD) under four irrigation treatments: IRRISAT, IRRI35, IRRI25, and continuous flooding (CF). The first three irrigation treatments were operated using scheduled daily decision windows, in which irrigation actions were automatically triggered based on predefined schedules and sensor threshold values. In IRRISAT, irrigation started when soil moisture dropped slightly below saturation and stopped at a ponding depth of 5 cm, while IRRI35 and IRRI25 were triggered at volumetric soil water contents of 35% and 25%, respectively, with the same upper cutoff of 5 cm ponding depth; CF served as the control. The IRRI35 treatment achieved a high grain yield (7.76 t ha⁻¹) while reducing water use by 28% and energy consumption by 37% compared to CF. Water use efficiency was considerably higher under IRRI35 (9.4 kg ha⁻¹ mm⁻¹) than under CF (6.7 kg ha⁻¹ mm⁻¹). The automated system proved to be reliable and precise in scheduled irrigation control, significantly reducing water use and labor requirements. The findings suggest that large-scale adoption of the system under real-world cultivation conditions could reduce irrigation energy needs and contribute to sustainable water governance in rice production. Full article

In irrigated areas around the world, the recommendation for the use of subsurface drainage is also associated with controlling salinity problems. Due to the high implementation cost, the search for solutions that make this requirement more flexible is necessary. Among the options to be investigated is the hypothesis that the height and salinity of the water table in plots located at the highest points of a toposequence are lower and do not compromise plant development, even without underground drainage systems. In this context, the present work was developed to monitor and evaluate the variation in water level or mottling over twelve months, as well as to measure and analyze the electrical conductivity and average pH of the water table during this period and its possible impact on plants. For this purpose, three lots in toposequence were selected in the Senador Nilo Coelho Public Irrigation Project, Petrolina—PE, with previously defined characteristics: soil classification (Plinthic Yellow—Ultisol), crop planted (Mangifera indica L.) and irrigation system used (micro-sprinkler). Precipitation, reference evapotranspiration and volume of water applied via irrigation were monitored by an automatic weather station and hydrometers in each lot. In each plot, nine observation wells were installed, distributed in a grid, with the aim of make monthly measurements of the water table level or mottling. The electrical conductivity and pH of the groundwater were also measured to obtain the average monthly value for each lot. Illustrative 3D maps of the water table level in relation to the ground surface were created using the simple kriging method, in the UTM SIRGAS 2000 24S projection system. The absence and presence of groundwater in the upper and lower hillslope lots, respectively, were favored by the toposequence. The decision to install underground drainage or not can be made on a case-by-case basis; this must take into account, among other aspects, changes in physical characteristics along the soil profile, possible occurrence of mottling, the quality of water for irrigation, the irrigation management adopted and the position of the lot in the toposequence. Full article

To address the issue of low fertilizer proportioning accuracy in irrigation and fertilization systems due to neglecting the influence of target ions in raw water, this study designed a high-precision online automatic water–fertilizer mixing device that can directly mix raw water (without water purification treatment) with fertilizer stock solution. This device is capable of preparing mixed fertilizer solutions containing N, K, and Ca elements. It employs ion-selective electrodes and flow meters for online detection and feedback of target ion concentrations in the fertilizer solution and flow rate information, and adopts an online fertilizer mixing control strategy that uses a constant raw water flow rate and a fuzzy PID control method to dynamically adjust the pulse frequency of metering pumps, thereby changing the injection volume of nutrient solution. Simulation and experimental analyses show that the piping system of the device is reasonably designed, ensuring stable and smooth fertilizer injection. The temperature-compensated concentration detection models for the three target ions in the fertilizer solution, constructed using a stepwise fitting method, achieve average relative detection errors of 1.94%, 1.18%, and 2.87% for K⁺, NO₃⁻, and Ca²⁺, respectively. When preparing single-element or mixed fertilizer solutions, the device achieves an average steady-state error of no more than 4% and an average steady-state time of approximately 40 s. Compared with deionized water, the average relative errors for potassium ions, nitrate ions, and calcium ions when preparing fertilizer solutions with raw water are 1.33%, 1.12%, and 1.19%, respectively. Compared with the theoretical errors of fertilizer preparation with raw water, the fertilizer proportioning errors of this device for potassium ions, nitrate ions, and calcium ions can be reduced by a maximum of 10.55%, 66.84%, and 62.71%, respectively, which is superior to the performance requirements for water–fertilizer integration equipment specified in the national industry standard DG/T 274-2024. Additionally, the device achieves accurate and stable fertilizer proportioning with safe and reliable operation during 6 h of continuous operation. This device significantly reduces the impact of raw water on fertilizer proportioning accuracy, improves the adaptability of the device to irrigation water sources, and provides theoretical basis and technical support for water-fertilizer integration systems in cost-sensitive agriculture. Full article

This study addresses the problem of inaccurate channel flow simulation and uneven irrigation water distribution caused by the spatiotemporal variability of Manning’s roughness coefficient. The SCE-UA optimization algorithm was applied to calibrate Manning’s roughness coefficients and quantify their spatiotemporal variation patterns using 1728 sets of measured water level–discharge data collected in the Yellow River Irrigation District. Results show that accounting for spatiotemporal variability reduces the mean absolute percentage error (MAPE) for water level simulation by nearly 8%. Based on these findings, an automatic roughness update system specifically designed for grassroots water distribution stations has been developed, which can integrate water demand and gate control to achieve efficient water allocation in canals in the future. Full article

To address the issue of existing automatic irrigation systems’ excessive reliance on electrical power and communication networks, a one-inlet, four-outlet Hydraulically Actuated Irrigation Control Valve (HAICV) was designed that operates based on water pressure variations. Its hydraulic characteristics and flow field features were investigated through experimental and numerical simulation methods. The results indicated that power–function relationships exist between pressure and flow rate, as well as between flow rate and head loss. The flow coefficient and resistance coefficient were found to range within [77.46, 81.06] and [15.94, 17.46], respectively. Dynamic simulations based on User-Defined Functions (UDF) revealed that during the opening process, the internal pressure of the valve spool remains high, with the primary pressure drop concentrated in the outlet region, and the low-pressure zone shrinks as the opening degree increases. A high-velocity band forms at the outlet, with jet flow and turbulence observed at small to medium openings, while the flow field stabilizes after full opening. The unique spool shape and non-straight flow passage structure of the HAICV result in relatively high energy loss, making it suitable for self-pressure irrigation systems. This study provides a theoretical foundation for evaluating its performance and broader applications. Full article

In order to sustain food production under conditions of limited water and in arid regions using the least amount of irrigation water possible, two experiments were conducted during the years 2021 and 2022 in the Nubaria region, Egypt. The performance of an automated drip irrigation control system was evaluated as a potentially efficient and sustainable alternative to manual irrigation to increase the fertilization frequency (N P K) of lemon trees. This study underlines the importance of automatically applying and controlling the addition of irrigation water as a sustainable alternative to manual irrigation, while increasing the number of mineral fertilization times under sandy soil conditions to the largest possible number (12 times during the growing season of lemon trees) instead of three times. The application of automatic irrigation reduced the water stress on the roots of the lemon trees, in addition to increasing the efficiency of the addition. The latter led to the creation of a healthy environment in the area where the roots spread and increased the rate of absorption of irrigation water loaded with the necessary major elements, thus increasing the canopy volume of the lemon trees. This, in turn, led to an improvement in the efficiency of the photosynthesis process, resulting in an increase in the productivity, water productivity, and quality characteristics of lemon in sandy soil in dry areas. Increasing the number of times of mineral fertilization to 12 during the growing season led to a long-term increase in the concentrations of those minerals within the area of root spread, avoiding losing them by deep percolation, as occurs fertilization is carried out only three times per season. The highest values of the productivity and irrigation water saving were 47.6% and 47.4%, respectively, during the first season and 48.7% and 48.8%, respectively, during the second season. The highest values of water productivity and lemon fruit quality were also achieved under the same conditions. Therefore, this study recommends the automatic control of irrigation schedules, in addition to increasing the frequency of fertilization times, not only in lemon plantations, but also with most horticultural fruit trees grown in dry sandy lands. Full article

The online dynamic collection of irrigation and plant physiological information is crucial for the precise irrigation management of nutrient solutions and efficient crop cultivation in vegetable soilless substrate cultivation facilities. In this study, an intelligent weighing system was installed in a tomato substrate cultivation greenhouse. The monitored values from the intelligent weighing system’s pressure-type module were used to calculate irrigation start–stop times, frequency, volume, drainage volume, drainage rate, evapotranspiration, evapotranspiration rate, and stomatal conductance. In contrast, the monitored values of the suspension-type weighing module were used to calculate the amount of weight change in the plants, which supported the dynamic and quantitative characterization of substrate cultivation irrigation and crop growth based on an intelligent weighing system. The results showed that the monitoring curves of pressure and flow sensors based on the pressure-type module could accurately identify the irrigation start time and number of irrigations and calculate the irrigation volume, drainage volume, and drainage rate. The calculated irrigation amount was closely aligned with that determined by an integrated-water–fertilizer automatic control system (R² = 0.923; mean absolute error (MAE) = 0.105 mL; root-mean-square error (RMSE) = 0.132 mL). Furthermore, transpiration rate and leaf stomatal conductance were obtained through inversion, and the R², MAE, and RMSE of the extinction coefficient correction model were 0.820, 0.014 mol·m⁻²·s⁻¹, and 0.017 mol·m⁻²·s⁻¹, respectively. Compared to traditional estimation methods, the MAE and RMSE decreased by 12.5% and 15.0%, respectively. The measured values of fruit picking and leaf stripping linearly fitted with the calculated values of the suspended weighing module, and R², MAE, and RMSE were 0.958, 0.145 g, and 0.143 g, respectively. This indicated that data collection based on the suspension-type weighing module could allow for a dynamic analysis of plant weight changes and fruit yield. In summary, the intelligent weighing system could accurately analyze irrigation information and crop growth physiological indicators under the practical application conditions of facility vegetable substrate cultivation, providing technical support for the precise management of nutrient solutions. Full article

The automatic flushing valve (AFV) enables automatic flushing of drip irrigation systems, improving their anti-clogging performance. This study focuses on a subsurface drip irrigation system (SDI) for alfalfa, selecting T20 and T70 AFVs (with designed flushing durations of 20 and 70 s, respectively) installed at the end of the dripline and a buried dripline without an AFV as a control. The aim of this study was to explore the variations in AFV hydraulic performance over two years of operation and the impact on the irrigation uniformity of SDI systems. The results revealed that the flushing duration (FD) and flushing water volume (FQ) of both T20 and T70 fluctuated over time, with an average coefficient of variation (CV) of 13.2%. The FD and FQ of the two types of AFVs are affected by the daily average temperature (T), and when T increases from 20.1 °C to 25.7 °C, the FD and FQ increased by an average of 22.6%. After 2 years of operation, the average relative flow rate (Dra) and irrigation uniformity (Cu) of the T20 and T70 SDI emitters were 93.7% and 96.8%. Both the Dra and Cu were significantly influenced by FD (p < 0.05). Compared with CK and T20, T70 significantly increased the Dra and Cu by 6.3% and 4.6%, respectively. The order of degree of clogging at different positions in the dripline was rear > middle > front for the CK and T20 treatments, whereas for T70, it was middle > front > rear. With the installation of the T70 AFV, the time required for the SDI system to reach moderate clogging (Dra = 50~80%) was extended from 3~7 years to 8~20 years, resulting in a 180% increase in operation time. The T70 AFV is recommended for use in the alfalfa SDI of this study. Full article

Drip irrigation pressure is considered a key parameter for controlling and designing the drip irrigation system in sandy soils. Understanding soil water content (SWC) movements under varying pressures can enhance water use efficiency and support sustainable irrigation strategies for crops in arid regions. The objectives of this study were to investigate the effects of irrigation pressure on the spatial, vertical, and temporal variability of SWC in sandy loam soil using surface drip irrigation. Experiments were carried out in a soil bin located in a greenhouse. SWC sensors were placed at depths 10, 20, 30, 40, and 50 cm to monitor SWC variability under low, medium, and high drip irrigation pressures (25, 50, and 75 kPa) at a constant emitter flow rate of 3 L/h. A pressure controller was used to regulate drip irrigation pressure, while microcontrollers communicated with SWC sensors, collected experimental data, and automatically recorded the outputs. At low irrigation pressure, water content began to increase at 0.53 h and saturated at 3.5 h, with both values being significantly lower at medium and high pressures. The results indicated that lower pressures led to significant variability in water movement at shallow depths (10 to 30 cm), becoming uniform at deeper layers but requiring longer irrigation times. Competitively higher pressures showed uniform water distribution and retention statistically throughout the soil profiles with shorter irrigation times. The variation in water distribution resulting in non-uniform coverage across the irrigated area demonstrates how pressure changes affect the flow rate of the emitter. The results provide information maps with soil water data that can be adjusted with irrigation pressure to maximize water use efficiency in sandy loam soils, aiding farmers in better irrigation scheduling for different crops using surface drip irrigation techniques in arid environments. Full article

Spray systems in agriculture serve essential roles in the precision application of pesticides, fertilizers, and water, contributing to effective pest control, nutrient management, and irrigation. These systems enhance efficiency, reduce labor, and promote environmentally friendly practices by minimizing chemical waste and runoff. The efficacy of a spray is largely determined by the characteristics of its droplets, including their size and velocity. These parameters are not only pivotal in assessing spray retention, i.e., how much of the spray adheres to crops versus becoming environmental runoff, but also in understanding spray drift dynamics. This study introduces a real-time deep learning-based approach for droplet detection and tracking which significantly improves the accuracy and efficiency of measuring these droplet properties. Our methodology leverages advanced AI techniques to overcome the limitations of previous tracking frameworks, employing three novel deep learning-based tracking methods. These methods are adept at handling challenges such as droplet occlusion and varying velocities, ensuring precise tracking in real-time potentially on mobile platforms. The use of a high-speed camera operating at 2000 frames per second coupled with innovative automatic annotation tools enables the creation of a large and accurately labeled droplet dataset for training and evaluation. The core of our framework lies in the ability to track droplets across frames, associating them temporally despite changes in appearance or occlusions. We utilize metrics including Multiple Object Tracking Accuracy (MOTA) and Multiple Object Tracking Precision (MOTP) to quantify the tracking algorithm’s performance. Our approach is set to pave the way for innovations in agricultural spraying systems, offering a more efficient, accurate, and environmentally responsible method of applying sprays and representing a significant step toward sustainable agricultural practices. Full article

The automation of agriculture can transform farming from manual to dynamic, resulting in higher profits with less manual management. This article introduces the use of automatic irrigation to monitor and control soil moisture through automatic irrigation. The control unit is implemented by an ATMEGA328P microcontroller on the Uno platform. This device uses a hygrometer to measure actual humidity. This benefit ensures that the system uses water correctly, thus preventing excess/underwater. IoT is used to inform farmers about the status of the water supply. Sensor data are updated regularly via the GSM-GPRS website, and farmers can check whether the water head is open/closed at any time via the website. Sensor readings are transmitted to the object’s audio channel to create an image. Full article

Due to the time-varying, hysteresis and nonlinear characteristics of fertilizer concentration control in the water–fertilizer ratio control system, common control algorithms such as PID and fuzzy PID cannot obtain the expected control effect. In order to accurately control the cotton field water–fertilizer ratio regulation system drip irrigation process of the water–fertilizer ratio that will be controlled within a reasonable range, it is needed to design a bat-optimized variable-domain fuzzy PID water–fertilizer ratio control strategy, through the use of bat algorithm to find out the optimal expansion factor and the best domain of the current conditions, and then according to the changes in working conditions to automatically adjust the fuzzy control of the domain, through the control of the valve openings to change the fertilizer pump back to the amount of water. Realize the fast and precise control of fertilizer concentration in the water–fertilizer ratio control system. Comparative tests were conducted to verify the traditional PID, fuzzy PID, variable domain fuzzy PID and bat-optimized variable-domain fuzzy PID control algorithms. The results show that: if the water–fertilizer ratio is adjusted to 50:1 from the startup, the adjustment time required to reach the target water–fertilizer ratio under the bat-optimized variable-domain fuzzy PID control is 15.29 s, and the maximum overshooting amount is 16.28%, which is a smaller adjustment time and overshooting amount; if the water–fertilizer ratio is adjusted to 40:1 from 50:1, the advantages of bat-optimized variable-domain fuzzy PID are more obvious, with the best balance of response speed, overshooting amount and optimal control effect. In terms of response speed, overshooting amount and regulation time, the optimal balance is achieved, showing the optimal control effect. It is proved that the performance of the water–fertilizer ratio regulation system in cotton field under bat-optimized variable-domain fuzzy PID control designed in this paper can meet the actual production requirements, and these findings can help to develop precise irrigation technology for cotton cultivation under drip irrigation conditions. Full article

Efficient irrigation water use directly affects crop productivity as demand increases for various agricultural products due to population growth worldwide. While technologies are being developed in various fields, it has become desirable to develop automatic irrigation systems to reduce the waste of water caused by traditional irrigation processes. This paper presents a novel approach to an automated irrigation system based on a non-contact computer vision system to enhance the irrigation process and reduce the need for human intervention. The proposed system is based on a stand-alone Raspberry Pi camera imaging system mounted at an agricultural research facility which monitors changes in soil color by capturing images sequentially and processing captured images with no involvement from the facility’s staff. Two types of soil samples (sand soil and peat moss soil) were utilized in this study under three different scenarios, including dusty, sunny, and cloudy conditions of wet soil and dry soil, to take control of irrigation decisions. A relay, pump, and power bank were used to achieve the stability of the power source and supply it with regular power to avoid the interruption of electricity. Full article

Innovation has been the transforming tool of precision agriculture as a response to population growth and the demand for more food with quality, less waste, food security, and sustainable management of environmental resources. The challenges are to increase the productivity of cultivated areas, both for current and future areas, to manage the use of potable water, scarce in many regions, to keep the soil fertile, and to reduce waste through reuse, optimization, resource sharing, and operational and strategic management based on accurate information of planting, harvesting, and management of environmental conditions, which are also objectives of the Circular Economy. Therefore, using Industry 4.0 technologies in agriculture becomes fundamental to facing such challenges. This paper presents a systematic literature review on Industry 4.0 technologies adopted in agriculture for sustainable development, considering environmental, economic, and social benefits. The research pointed to the use of IoT in irrigation control systems by sending automatic commands, monitoring soil and weather conditions, in the use of machinery with some automation features and in cloud data storage systems, and with the use of Big Data analytical tools, with access by mobile devices, these uses contribute to operational and strategic decision making in the management of planting and harvesting. However, the literature review did not find a technological architecture for Integrated Services in Agriculture 4.0. Thus, this paper proposes a Service Architecture that enables the promotion of a Circular Economy in Agriculture 4.0. The contribution of this article to the theory is in the expansion of knowledge of the use of technologies in Agriculture 4.0. In terms of practice, this article provides an Integrated Service Architecture so that new products can be developed for Agriculture 4.0 and thus contribute to society in reducing food insecurity, generating environmental, economic, and social benefits, and promoting the Circular Economy in Agriculture 4.0. Full article
