Search Results (76)

Multi-slice mining of the 70 m ultra-thick coal seam in East Junggar coalfield, China is marked by large-scale mining space expansion and frequent stress disturbances. To address those, this study uses theoretical analysis, physical simulation, and numerical simulation to explore the evolution of an overburden bearing structure and the control of strata behavior in multi-slice mining. The results (1) clarify the overburden fracture-hinging characteristics: fractured blocks in lower hard strata form beam-type hinges (early stage), the lower hinged structure weakens and the beam-type hinge structure moves upward in steps (middle stage), the continuous increase in the mined-out space leads to the transverse O-X fracture of far-stope rock strata, and broken rock blocks are extruded into shells (late stage); this study also proposes an identification method for the morphology of roof bearing structures (including beam structure, higher beam structure, and arch structure); (2) define the support-controlled strata range and load calculation method at different stages, and show that the support load “increases slowly under the near-stope roof bearing structure and tends to stabilize under the far-stope roof bearing structure” as the roof bearing structure moves upward; and (3) guided by the aims of avoiding cantilever beams and ensuring near-stope roof stability, lead us to propose the following measures: pre-splitting main roof (early stage); short working faces with reduced layered thickness and rapid advance (late stage); and goaf/separation grouting (whole process). The maximum support load drops from 20,017.5 kN to 16,192.5 kN, enabling lightweight support selection. This study provides theoretical guidance for support selection and roof control in the multi-slice mining of ultra-thick coal seams. Full article

Tunnels excavated in weak ground can develop problems due to squeezing phenomena. This situation is much more critical in large-diameter and double-tube tunnels. The effects of the tubes on each other are also important. The NATM (New Austrian Tunneling Method) is employed in the design of the support systems for these types of tunnels, which is based on the flexible outer arch principle and allows for deformations or minimization of deformations by increasing the lining thickness and using a rigid pavement. The risk of deformations occurring in a flexible outer arch is determined by the occurrence of deformations in shallow tunnels, which can affect the surface; a ground reaction curve can quickly develop and lead to a collapse. It is also known that the stability of the tunnel whose support and excavation is completed first can be impacted by subsequent excavations for the other tunnel. The purpose of the present study was to describe the geological and geotechnical conditions of a shallow tunnel excavated in weak ground and to assess its stability using three-dimensional numerical analysis. For this purpose, the Cukurcayir 1 tunnel—a double-tube tunnel—was employed as a case study. The 3D numerical analyses were performed using the Flac3d V2.10-222 software. The results are discussed in detail and recommendations for the necessary support system for tunnel roof and face stability are given. Full article

Tunnel construction in weak and fractured strata often faces risks such as tunnel face instability and large deformation of surrounding rock, which are difficult to effectively control using conventional support methods. Based on the engineering background of the No. 8# TA Tunnel in the F3 section of Georgia’s E60 Highway, this study employed ADECO-RS and developed a 3D numerical model with finite difference software to simulate full-face tunnel excavation process. The influence of advanced reinforcement measures on the stability of the surrounding rock was systematically investigated. The control effectiveness of different advanced reinforcement schemes was evaluated by comparing the displacement field, stress field, and plastic zone distribution of the surrounding rock under three conditions: no support, advanced pipe roof support, and a combination of pipe roof and glass fiber bolts. A comprehensive quantitative analysis of the synergistic effect of the combined reinforcement was also performed. The results indicated that significant extrusion deformation of the tunnel face and vault settlement occurred after excavation. The pressure arch developed within a range of 17.5 to 22 m above the tunnel vault. The surrounding rock of this tunnel was classified as type B (short-term stable). Deformation primarily occurred within one tunnel diameter ahead of the face, with the deformation rate significantly reduced after support. Advanced pipe roof support effectively restrained surrounding rock deformation, while the combination of advanced pipe roof and glass fiber bolts delivered better performance: reducing final convergence by 73.10%, pre-convergence by 82.69%, and face extrusion by 87.66%. The combined support also contracted the pressure arch boundaries from 17.5 to 22 m to 6–12.5 m, reduced the extent of major principal stress deflection, and significantly shrinks the plastic zone. Glass fiber bolts played a key role in controlling plastic zone expansion and ensuring stability. This study provides theoretical and numerical references for safe construction and advanced support design in tunnels under complex geological conditions. Full article

When excavating roadways in underground mines, stress redistribution within the surrounding rock mass leads to stress concentration and release. Should the concentrated stresses exceed the rock mass’s tensile or shear strength, rock deformation and failure occur. Thus, a knowledge of stress distribution around the roadway is of great significance for revealing the roadway instability mechanism and design support methods. In this work, the powerful complex variable function theory was used to solve the surrounding rock stress around the triple-arched roadway and the analytical results were verified with the on-site stress state. The results show that the tensile stress occurs on the roadway roof and floor under low lateral stress coefficients, while concentrated compressive stress emerges on the two sidewalls. However, the surrounding stress distribution exhibits an opposite characteristic under high stress levels. Beyond five times the roadway radius, the stress in the surrounding rock is unaffected by the roadway and approaches the in-situ stress. For the +1890 m level trackless transport roadway in Kunyang No. 2 phosphate mine, it is further calculated that the minimum stress concentration factor in the rib area of the roadway within the stress relief zone is 0.34, while the maximum stress concentration factor in the concentrated stress zone of the roof, floor, and sidewalls of the roadway is 5.87. The measured stress values of two monitoring points in the surrounding rock of this roadway are fairly consistent with the analytical values, suggesting the complex variable method for solving excavation-induced stresses are effective and reliable. Full article

In order to determine appropriate anchoring parameters after enlarging the cross-section of the mining roadway, a comprehensive study was conducted to investigate the development of deformation and failure characteristics in the surrounding rock. The mechanical behavior of rock failure under high-stress conditions and the progressive evolution of deformation and failure from shallow to deep zones were thoroughly analyzed. It was proposed that the primary function of bolt support in mining roadways is to guide the surrounding rock to form a stable compressive arch or ring structure. The mechanical mechanism underlying the formation of such an arch under bolt guidance, along with the stability characteristics during this process, was investigated. The principles for determining bolt support parameters were established as follows: (a) ensuring the formation of a closed compressive ring within the anchorage zone around the roadway; (b) preventing shear failure at the roadway corners; and (c) controlling the extent of roof subsidence under gravitational loading. Design methodologies for determining rock bolt and anchor cable length and spacing were formulated and implemented in the support design of large-section mining roadways within million-ton fully mechanized mining faces. The cross-sectional dimensions of the supported roadway are 5.8 × 4.0 m. Field monitoring results indicate that, after stabilization of the surrounding rock deformation, the maximum convergence between both sides does not exceed 140 mm, the maximum roof subsidence remains below 40 mm, and the maximum roof separation is limited to within 4 mm. These findings provide strong evidence that the selected design parameters fully meet the engineering requirements for roadway support. Full article

In response to issues of long construction cycles, high pollution, and labor shortages in traditional cast in situ subway station construction, a refined 3D model of a large-segment prefabricated subway station was established using ABAQUS software 2024, with mechanical behavior throughout the construction process studied based on the Shenzhen Huaxia Station project case. The model incorporates a concrete inelastic damage constitutive model and a steel elastic–plastic model, accurately simulates key components, including dry joints of mortise–tenon grooves, prestressed reinforcement, and bolted connections, and implements a seven-phase construction sequence. Research findings indicate the following: (1) During component assembly, the roof vault settlement remains ≤3.8 mm, but backfilling significantly increases displacements (roof settlement reaches 45 mm, middle slab deflection measures 66.91 mm). (2) Longitudinal mortise–tenon joints develop stress concentrations due to stiffness disparities, with mid-column installation slots identified as vulnerable zones exhibiting maximum Von Mises stress of 32 MPa. (3) Mid-column eccentricity induces structural asymmetry, causing increased deflection in longer-span middle slabs, corbel contact stress differentials up to 6 MPa, and bolt tensile stresses exceeding 1.1 GPa. (4) The arched roof effectively transfers loads via three-hinged arch mechanisms, though spandrel horizontal displacement triggers 5 cm rebound in diaphragm wall displacement. Conclusions confirm overall the stability of the prefabricated structure while recommending the optimization of member stiffness matching, avoidance of asymmetric designs, and localized reinforcement for mortise–tenon edges and mid-column joints. Results provide valuable references for analogous projects. Full article

The layered composite roof of a coal mine roadway exhibits heterogeneity, with pronounced variations in layer thickness and strength. Fully grouted rock bolts installed in such layered roofs usually penetrate two or more strata and bond with them to form an integrated anchorage system. Roof failure typically initiates in the shallow strata and progressively propagates to deeper layers; thus, the mechanical properties of the rock at the free surface critically influence the overall stability of the layered roof and the load-transfer behavior of the bolts. In this study, a layered rock mass model was developed using three-dimensional particle flow code (PFC3D), and a triaxial loading scheme with a single free surface was applied to investigate the effects of free-surface rock properties, support parameters, and confining pressure on the load-bearing performance of the layered rock mass. The main findings are as follows: (1) Without support, the ultimate bearing capacity of a hard-rock-free-surface specimen is about 1.2 times that of a soft-rock-free-surface specimen. Applying support strengths of 0.2 MPa and 0.4 MPa enhanced the bearing capacity by 29–38% and 46–75%, respectively. (2) The evolution of axial stress in the bolts reflects the migration of the load-bearing core of the anchored body. Enhancing support strength improves the stress state of bolts and effectively mitigates the effects of high-stress conditions. (3) Under loading, soft rock layers exhibit greater deformation than hard layers. A hard-rock free surface effectively resists extrusion deformation from deeper soft rocks and provides higher bearing capacity. Shallow free-surface failure is significantly suppressed in anchored bodies, and “compression arch” zones are formed within multiple layers due to bolt support. Full article

The integration of photovoltaic (PV) panels in greenhouses enables dual land use, combining crop production with electricity generation. However, PV installations can reduce both the intensity and uniformity of light at the canopy level, potentially affecting crop growth. This study employed computational fluid dynamics (CFD) simulations to evaluate the effects of different layouts of commercial-size thin PV modules—both opaque and semi-transparent—installed at gutter height in greenhouses on irradiance and, in particular, on its distribution within the greenhouse. Achieving a homogeneous distribution of light is critical for effective plant growth beneath photovoltaic systems. The influence of greenhouse size and roof shape on the intensity and uniformity of visible radiation was investigated as well. The results showed that during winter (21 December), irradiance in a mono-span tunnel greenhouse was 4–6% higher than in a multi-span large structure; in summer (21 June), this difference increased to 10–13%. Among the opaque PV layouts tested, the north–south (NS) straight-line arrangement provided the most uniform light distribution, outperforming the checkerboard and east–west (EW) layouts. The EW straight-line layout was the least effective regarding light uniformity. Roof shape (arched vs. pitched) had minimal impact on radiation distribution. Semi-transparent PV modules consistently resulted in 17% higher irradiance and more uniform light distribution than opaque ones. These findings can inform efficient PV deployment strategies in greenhouses to enhance both energy yield and crop productivity. Full article

The instability of mine roadways is significantly influenced by the coupled effects of groundwater seepage and non-uniform loading. These interactions often induce localized plastic deformation and progressive failure, particularly in the roof and sidewall regions. Seepage elevates pore water pressure and deteriorates the mechanical properties of the rock mass, while non-uniform loading leads to stress concentration. The combined effect facilitates the propagation of microcracks and the formation of shear zones, ultimately resulting in localized instability. This initial damage disrupts the mechanical equilibrium and can evolve into severe geohazards, including roof collapse, water inrush, and rockburst. Therefore, understanding the damage and failure mechanisms of mine roadways at the mesoscale, under the combined influence of stress heterogeneity and hydraulic weakening, is of critical importance based on laboratory experiments and numerical simulations. However, the large scale of in situ roadway structures imposes significant constraints on full-scale physical modeling due to limitations in laboratory space and loading capacity. To address these challenges, a straight-wall circular arch roadway was adopted as the geometric prototype, with a total height of 4 m (2 m for the straight wall and 2 m for the arch), a base width of 4 m, and an arch radius of 2 m. Scaled physical models were fabricated based on geometric similarity principles, using defect-bearing sandstone specimens with dimensions of 100 mm × 30 mm × 100 mm (length × width × height) and pore-type defects measuring 40 mm × 20 mm × 20 mm (base × wall height × arch radius), to replicate the stress distribution and deformation behavior of the prototype. Uniaxial compression tests on water-saturated sandstone specimens were performed using a TAW-2000 electro-hydraulic servo testing system. The failure process was continuously monitored through acoustic emission (AE) techniques and static strain acquisition systems. Concurrently, FLAC^3D 6.0 numerical simulations were employed to analyze the evolution of internal stress fields and the spatial distribution of plastic zones in saturated sandstone containing pore defects. Experimental results indicate that under non-uniform loading, the stress–strain curves of saturated sandstone with pore-type defects typically exhibit four distinct deformation stages. The extent of crack initiation, propagation, and coalescence is strongly correlated with the magnitude and heterogeneity of localized stress concentrations. AE parameters, including ringing counts and peak frequencies, reveal pronounced spatial partitioning. The internal stress field exhibits an overall banded pattern, with localized variations induced by stress anisotropy. Numerical simulation results further show that shear failure zones tend to cluster regionally, while tensile failure zones are more evenly distributed. Additionally, the stress field configuration at the specimen crown significantly influences the dispersion characteristics of the stress–strain response. These findings offer valuable theoretical insights and practical guidance for surrounding rock control, early warning systems, and reinforcement strategies in water-infiltrated mine roadways subjected to non-uniform loading conditions. Full article

The dip angle and thickness of coal seams are key geological determinants in mine system engineering. Roadways excavated in steeply inclined or thick coal seams typically exhibit significant deformation, with the combined geological configuration of steeply inclined thick seams thus presenting heightened support demands. Therefore, taking the 1502 level roadway in the Dayuan Coal Industry—situated in a steeply inclined thick coal seam—as an engineering case, mechanical models of roadways with different cross-sectional shapes are established, and the deformation and failure mechanisms of surrounding rock under different coal seam dip angles are analyzed. Based on this analysis, an asymmetric support technology scheme is proposed, followed by surrounding rock deformation monitoring and a support effectiveness evaluation. Key findings include the following: (1) in steeply inclined thick coal seam roadways with different cross-sectional shapes, the stress distribution and plastic zone development of surrounding rock follow a descending sequence, inclined roof trapezoidal section > rectangular section > arched section. Among these, the arched section is identified as the optimal roadway cross-sectional shape for this engineering context. (2) The stress-concentration area in the arch roadway aligns with the inclined direction of the coal seam, forming asymmetric stress concentration patterns. Specifically, as the coal seam dip angle increases, stress increases at the arch shoulder of the upper sidewall and the wall foundation of the lower sidewall. Concurrently, such stress concentration induces shear failure in the surrounding rock, which serves as the primary mechanism causing asymmetric deformation and failure in steeply inclined thick coal seam roadways. (3) In the 1502 level roadway, the asymmetric support technology with dip-oriented reinforcement was implemented. Compared to the original support scheme, roof deformation and sidewall convergence decreased by 46.17% and 46.8%, respectively. The revealed failure mechanisms of steeply inclined thick coal seam roadways and the proposed asymmetric support technology provide technical and engineering references for roadway support in similar mining conditions. Full article

Gradient porous structures (GPS) offer significant mechanical and functional advantages over homogeneous counterparts. This paper proposes a computational design framework utilizing spatial Voronoi diagrams to create lightweight, stress-responsive spatial frames optimized for architectural double-curvature arched shell roofing components. The method integrates Solid Isotropic Material with Penalization (SIMP)-based topology optimization (TO) to establish initial stress-informed material distributions, adaptive Voronoi control point (CP) placement guided by localized stress data, and a bi-objective genetic algorithm (GA) optimizing maximum and average displacement. Following optimization, a weighted Lloyd relaxation (LR) refines Voronoi cells into spatial frameworks with varying densities corresponding to stress gradients. Finite Element Analysis (FEA) demonstrates that the optimized Voronoi-driven GPS achieves notable improvements, revealing up to 79.7% material volume reduction and significant improvement in structural efficiency, achieving a stiffness-to-weight ratio (SWR) exceeding 2200 in optimized configurations. Furthermore, optimized structures consistently maintain maximum von Mises (MVM) stresses below 20 MPa, well within the allowable yield strength of the Polyethylene Terephthalate Glycol (PETG) material (53 MPa). The developed framework effectively bridges structural performance, material efficiency, and aesthetic considerations, offering substantial potential for application in advanced, high-performance architectural systems. Full article

Bed-separation water hazards are a common and very harmful mining disaster in the mining areas of western China in recent years, which seriously threatens the safe mining of rich and thick coal seam resources in the West. The Yonglong mining area has become a high-risk area for bed-separation water hazards due to its particularly thick coal seams and strong water-rich overlying strata. In view of this, this paper investigates the development height of a water-flowing fractured zone in the fully mechanized caving mining of an ultra-thick coal seam in the Yonglong mining area, the evolution law of the bed separation of overlying strata, and the process of water inrush from a bed separation. Based on the measured water-flowing fractured zone height data of the Yonglong mining area and several surrounding mines, a water-flowing fractured zone height prediction formula suitable for the geological conditions of the Yonglong mining area was fitted. By using discrete element numerical simulation and laboratory similarity simulation, the evolution law of overlying strata separation under the conditions of fully mechanized caving mining in the study area was analyzed, and the space was summarized into “four zones, three arches, and five zones”. Through the stress-seepage coupling simulation of the water inrush process of the roof separation in the fully mechanized caving mining of an ultra-thick coal seam, the migration, accumulation, and sudden inrush of water in the aquifer in overlying strata under the influence of mining were analyzed, and the variation in the pore water pressure in the process of water inrush during coal seam mining separation was summarized. The pore water pressure in the overlying strata showed a trend of first decreasing, then increasing, and, finally, stabilizing. Combined with the height, water inrush volume, and water-rich zoning characteristics of the water-flowing fractured zone of the 1012007 working face of the Yuanzigou Coal Mine, the danger of water inrush from the overlying strata separation of the working face was evaluated. It is believed that it has the conditions for the formation of water accumulation and separation, and the risk of water inrush is high. Prevention and control measures need to be taken on site to ensure mining safety. The research results have important guiding significance for the assessment and prevention of water inrush hazards in overlying strata during fully mechanized longwall top-coal caving of ultra-thick coal seams with similar geological conditions worldwide. Full article

In order to solve the wall damage problem of roadways with deep and high stress in methane explosion accidents, mathematical-physical analysis models for the dynamic response damage of roadway walls were established by LS-Dyna software in this paper, and the models were validated to be effective. The roadway wall displacement, stress, and deformation characteristics under the methane explosion impact load were numerical simulated and the response and damage evolution process of the roadway wall was studied. The results indicate that the model established in this study can reflect the dynamic response damage characteristics of the roadway wall. The damage of the roadway wall caused by the methane explosion impact load was mainly concentrated in the methane accumulation section, but the maximum principal stress of the roadway wall near the methane accumulation section was still high, and the damage possibility was also high. The dynamic response damage of the roadway wall decreased with the increase in the distance from the initiation explosion point. The stress response of the curved part of the roadway roof was the most severe, and the stress response of the side part was second to that of the roof. The stress changes at the corners were significant, but the deformation was small. The bottom plate was minimally affected by the methane explosion impact loads. The arch top and two sides of the roadway were first subjected to significant impact, resulting in a high-pressure zone. The peak pressure of the side part was relatively high, and the difference in peak pressure between the corner and the bottom plate was not significant. Full article

In order to address the safety construction issues of tunnels in karst areas, this study investigated the stability and instability time prediction of the roof of karst tunnels based on catastrophe theory. By establishing a discrimination equation for the sudden instability of the tunnel roof arch based on the elastic beam model and considering factors such as the self-weight of surrounding rocks and the position of caves, the calculation formula for the safety thickness of the roof of the karst tunnel was obtained. The study analyzed the impact of relevant factors on the safety thickness of the roof. Furthermore, a new method for predicting the instability of the tunnel roof arch was proposed, and it was validated through engineering examples. The results indicate that the water pressure in caves, the size of caves, the elasticity modulus of surrounding rocks, and the position of caves have extremely adverse effects on the safety of the arch roof. The calculation formula for the safety thickness of the roof of the karst tunnel derived from the theory of sudden change demonstrates feasibility and high accuracy in practical engineering applications. The established model for predicting roof instability can effectively forecast the time of roof arch instability in karst tunnels. Full article

Due to the impact of disordered mining activities in previous years, numerous abandoned roadways exist in the second mining district of the 13# coal seam in Chejiazhuang Coal Mine. The stability of the new roadway roof was analyzed under various distributions of abandoned roadways above. It was determined that the ultimate stable thickness of the coal layer between the new and abandoned roadways is 4.0 m. When the thickness between the two is less than 4.0 m, the roof becomes unstable after excavation, posing a risk of collapse. Advanced grouting reinforcement is required to enhance roof stability before installing U-shaped steel arches. Mechanical experiments were conducted on the polymer grouting consolidation of fractured coal, showing a significant increase in residual strength compared to intact coal. Furthermore, the uniaxial compressive strength of the polymer grouting consolidation partially recovered. On average, the consolidation coefficient and recovery coefficient were 5.28 and 85.51%, respectively. Grouting increased the ductility of the fractured surrounding rock, enhancing its resistance to deformation and plasticity. A polymer grouting consolidation technology for supporting fractured surrounding rock under the unstable roof of abandoned roadways is proposed, along with the design of corresponding support schemes and parameters. Monitoring the results of mine pressure indicated that the surrounding rock remained stable after roadway excavation, validating the effectiveness of the support schemes and parameters. Full article
