Sensor technology plays a fundamental role in neuro-motor rehabilitation by enabling precise movement analysis and control. This study explores the integration of brain–machine interfaces (BMIs) and wearable sensors to enhance motor recovery in individuals with neuro-motor impairments. Specifically, different time-frequency transforms are evaluated to analyze the correlation between electroencephalographic (EEG) activity and ankle position, measured by using inertial measurement units (IMUs). A low-cost ankle exoskeleton was designed to conduct the experimental trials. Six subjects performed plantar and dorsal flexion movements while the EEG and IMU signals were recorded. The correlation between brain activity and foot kinematics was analyzed using the Short-Time Fourier Transform (STFT), Stockwell (ST), Hilbert–Huang (HHT), and Chirplet (CT) methods. The 8–20 Hz frequency band exhibited the highest correlation values. For motor imagery classification, the STFT achieved the highest accuracy (92.9%) using an EEGNet-based classifier and a state-machine approach. This study presents a dual approach: the analysis of EEG-movement correlation in different cognitive states, and the systematic comparison of four time-frequency transforms for both correlation and classification performance. The results support the potential of combining EEG and IMU data for BMI applications and highlight the importance of cognitive state in motion analysis for accessible neurorehabilitation technologies. Full article

Treating ankle fractures in athletes, commonly resulting from training injuries, remains a significant challenge. Current approaches to managing both non-surgical and postoperative foot and ankle disorders have focused on integrating sensory systems into orthotic devices. Recent analyses have identified several gaps in rehabilitation strategies, especially regarding gait pattern reformation during recovery. This work aims to enhance rehabilitation effectiveness for patients with ankle injuries by controlling load distribution and monitoring joint flexion/extension angles, as well as the reactive forces during therapeutic exercises and walking. We developed an exoskeleton device model using SolidWorks 2024 software, based on data from two patients: one healthy and one with an ankle fracture. Pressure measurements in the posterior limb region were taken using the F-Socket system and a custom electromechanical sensor designed by the authors. The collected data were analyzed using the butterfly parameterization method. This research led to the development of an adaptive exoskeleton device that provided pressure distribution data, gait cycle graphs, and a diagram correlating foot angles with the duration of exoskeleton use. The device demonstrated improvement in the patients’ conditions, facilitating a more normalized gait pattern. A reduction in the load applied to the ankle joint was also observed, with the butterfly parameter confirming the device’s correct operation. Full article

Most exoskeletons designed to assist users in load-bearing tasks face a mechanical dilemma in their conception. Designers may find a compromise between stiff active actuators-based architectures which are powerful but bulky and compliant actuator-based designs which are much less assistive but less constraining for users. This article presents a new open-source simulation-based design tool and a human-centered method that lets orthosis designers explore different device configurations and evaluate some performance criteria. This framework was applied in three different young-adult subjects. The effects of design personalization on user morphology and gait were studied. First, an ankle–foot orthosis designed to support a 20 kg backpack was defined according to the user’s height, weight, and walking speed. Then, a simulation of the subjects fitted with their customized design walking at a self-selected speed on flat ground carrying this additional load was performed. First, the results showed that the designed method inspired by natural joint stiffness behavior provided viable personalized mechanisms. Second, significant reductions in peak joint torque and mean joint activity were observed when comparing muscle-generated torques while the subject was wearing the 20 kg backpack with ankle–foot orthoses on both legs or without. Finally, it shows the value of an open-access tool for exploring the coupling of passive and active actuators to generate lighter and more compliant designs. Full article

Lower limb exoskeletons have been developed to improve functionality and assist with daily activities in various environments. Although these systems utilize sensors for gait phase detection, they lack anticipatory information about environmental changes, which limits their adaptability. This paper presents a vision-based intelligent gait environment detection algorithm for a lightweight ankle exosuit designed to enhance gait stability and safety for stroke patients, particularly during stair negotiation. The proposed system employs YOLOv8 for real-time environment classification, combined with a long short-term memory (LSTM) network for spatio-temporal feature extraction, enabling the precise detection of environmental transitions. An experimental study evaluated the classification algorithm and soft ankle exosuit performance through three conditions using kinematic analysis and muscle activation measurements. The algorithm achieved an overall accuracy of over 95% per class, which significantly enhanced the exosuit’s ability to detect environmental changes, and thereby improved its responsiveness to various conditions. Notably, the exosuit increased the ankle dorsiflexion angles and reduced the muscle activation during the stair ascent, which enhanced the foot clearance. The results of this study indicate that advanced spatio-temporal feature analysis and environment classification improve the exoskeleton’s gait assistance, improving adaptability in complex environments for stroke patients. Full article

Ankle–foot orthoses (AFOs) are commonly prescribed to children with cerebral palsy (CP). The conventional AFO successfully controls the first and second ankle rocker, but it fails to correct the third ankle rocker, which negatively effects push-off power. The current study evaluated a new powered AFO (PAFO) design, developed to address the shortcomings of the conventional AFO. Eight children with spastic CP (12.4 ± 3.4 years; GMFCS I-III; 4/4-♂/♀; 3/5-bi/unilateral) were included. Sagittal kinematic and kinetic data were collected from 20 steps during barefoot walking, with conventional AFOs and PAFOs. In the PAFO-condition, an actuation unit was attached to a hinged AFO and through push–pull cables to a backpack that was carried by the child and provided patient-specific assistance-as-needed. SnPM-analysis indicated gait cycle sections that differed significantly between conditions. For the total group, differences between the three conditions were found in ankle kinematics (49.6–66.1%, p = 0.006; 88.0–100%, p = 0.011) and angular velocity (0.0–6.0%, p = 0.001; 45.1–51.1%, p = 0.006; 62.2–73.0%, p = 0.001; 81.2–93.0%, p = 0.001). Individual SnPM-analysis revealed a greater number of significant gait cycle sections for kinematics and kinetics of the ankle, knee, and hip. These individual results were heterogeneous and specific per gait pattern. In conclusion, the new PAFO improved the ankle range-of-motion, angular velocity, and power during push-off in comparison to the conventional AFO. Full article

Bone stress injuries are prevalent among athletes and military recruits and can significantly compromise training schedules. The development of an ankle–foot orthosis to reduce tibial load and enable a faster return to activity will require new device testing methodologies capable of capturing the contribution of muscular force on tibial strain. Thus, an actuated robotic surrogate leg was developed to explore how tibial strain changes with different ankle–foot orthosis conditions. The purpose of this work was to assess the reliability, scalability, and behavior of the surrogate. A dual actuation system consisting of a Bowden cable and a vertical load applied to the femur via a material testing system, replicated the action-reaction of the Achilles-soleus complex. Maximum and minimum principal strain, maximum shear strain, and axial strain were measured by instrumented strain gauges at five locations on the tibia. Strains were highly repeatable across tests but did not consistently match in vivo data when scaled. However, the stiffness of the ankle–foot orthosis strut did not systematically affect tibial load, which is consistent with in vivo findings. Future work will involve improving the scalability of the results to match in vivo data and using the surrogate to inform exoskeletal designs for bone stress injuries. Full article

Most lower limb rehabilitation robots are limited to specific training postures to adapt to stroke patients in multiple stages of recovery. In addition, there is a lack of attention to the switching functions of the training side, including left, right, and bilateral, which enables patients with hemiplegia to rehabilitate with a single device. This article presents an exoskeleton robot named the multistage hemiplegic lower-limb rehabilitation robot, which has been designed to do rehabilitation in multiple training postures and training sides. The mechanism consisting of the thigh, calf, and foot is introduced. Additionally, the design of the multi-mode limit of the hip, knee, and ankle joints supports delivering therapy in any posture and training sides to aid patients with hemiplegia in all stages of recovery. The gait trajectory is planned by extracting the gait motion trajectory model collected by the motion capture device. In addition, a control system for the training module based on adaptive iterative learning has been simulated, and its high-precision tracking performance has been verified. The gait trajectory experiment is carried out, and the results verify that the trajectory tracking performance of the robot has good performance. Full article

The global aging population faces significant health challenges, including an increasing vulnerability to disability due to natural aging processes. Wearable lower limb exoskeletons (LLEs) have emerged as a promising solution to enhance physical function in older individuals. This systematic review synthesizes the use of LLEs in alignment with the WHO’s healthy aging vision, examining their impact on intrinsic capacities and functional abilities. We conducted a comprehensive literature search in six databases, yielding 36 relevant articles covering older adults (65+) with various health conditions, including sarcopenia, stroke, Parkinson’s Disease, osteoarthritis, and more. The interventions, spanning one to forty sessions, utilized a range of LLE technologies such as Ekso^®, HAL^®, Stride Management Assist^®, Honda Walking Assist^®, Lokomat^®, Walkbot^®, Healbot^®, Keeogo Rehab^®, EX1^®, overground wearable exoskeletons, Eksoband^®, powered ankle–foot orthoses, HAL^® lumbar type, Human Body Posturizer^®, Gait Enhancing and Motivation System^®, soft robotic suits, and active pelvis orthoses. The findings revealed substantial positive outcomes across diverse health conditions. LLE training led to improvements in key performance indicators, such as the 10 Meter Walk Test, Five Times Sit-to-Stand test, Timed Up and Go test, and more. Additionally, enhancements were observed in gait quality, joint mobility, muscle strength, and balance. These improvements were accompanied by reductions in sedentary behavior, pain perception, muscle exertion, and metabolic cost while walking. While longer intervention durations can aid in the rehabilitation of intrinsic capacities, even the instantaneous augmentation of functional abilities can be observed in a single session. In summary, this review demonstrates consistent and significant enhancements in critical parameters across a broad spectrum of health conditions following LLE interventions in older adults. These findings underscore the potential of LLE in promoting healthy aging and enhancing the well-being of older adults. Full article

Lower limb exoskeletons and orthoses have been increasingly used to assist the user during gait rehabilitation through torque transmission and motor stability. However, the physical human-robot interface (HRi) has not been properly addressed. Current orthoses lead to spurious forces at the HRi that cause adverse effects and high abandonment rates. This study aims to assess and compare, in a holistic approach, human-robot joint misalignment and gait kinematics in three fixation designs of ankle-foot orthoses (AFOs). These are AFOs with a frontal shin guard (F-AFO), lateral shin guard (L-AFO), and the ankle modulus of the H2 exoskeleton (H2-AFO). An experimental protocol was implemented to assess misalignment, fixation displacement, pressure interactions, user-perceived comfort, and gait kinematics during walking with the three AFOs. The F-AFO showed reduced vertical misalignment (peak of 1.37 ± 0.90 cm, p-value < 0.05), interactions (median pressures of 0.39–3.12 kPa), and higher user-perceived comfort (p-value < 0.05) when compared to H2-AFO (peak misalignment of 2.95 ± 0.64 and pressures ranging from 3.19 to 19.78 kPa). F-AFO also improves the L-AFO in pressure (median pressures ranging from 8.64 to 10.83 kPa) and comfort (p-value < 0.05). All AFOs significantly modified hip joint angle regarding control gait (p-value < 0.01), while the H2-AFO also affected knee joint angle (p-value < 0.01) and gait spatiotemporal parameters (p-value < 0.05). Overall, findings indicate that an AFO with a frontal shin guard and a sports shoe is effective at reducing misalignment and pressure at the HRI, increasing comfort with slight changes in gait kinematics. Full article

The foot and ankle serve vital roles in weight bearing, balance, and flexibility but are susceptible to many diverse ailments, making treatment difficult. More commonly, Total Ankle Arthroplasty (TAA) and Total Talus Replacement (TTR) are used for patients with ankle degeneration and avascular necrosis of the talus, respectively. Ankle prosthesis and orthosis are also indicated for use with lower limb extremity amputations or locomotor disability, leading to the development of powered exoskeletons. However, patient outcomes remain suboptimal, commonly due to the misfitting of implants to the patient-specific anatomy. Additive manufacturing (AM) is being used to create customized, patient-specific implants and porous implant cages that provide structural support while allowing for increased bony ingrowth and to develop customized, lightweight exoskeletons with multifunctional actuators. AM implants and devices have shown success in preserving stability and mobility of the joint and achieving fast recovery, as well as significant improvements in gait rehabilitation, gait assistance, and strength for patients. This review of the literature highlights various devices and technologies currently used for foot and ankle prosthesis and orthosis with deep insight into improvements from historical technologies, manufacturing methods, and future developments in the biomedical space. Full article

The ankle exoskeleton is an auxiliary device designed to restore human independence. This paper proposes the development and initial testing of a passive ankle exoskeleton designed for movements with dorsal and plantar flexion. The device also includes a new mechanism design with four electric linear actuators, and the shank platform and the foot platform are connected to the ball by a swivel joint. Mechanical tests demonstrate the ability of the prototype to function adequately in the natural range of the ankle joint. Preliminary results show that the exoskeleton can reduce the activation of the calf muscles on the limb on which the device is installed. In the investigation of a passive ankle joint exoskeleton designed for movements with dorsal and plantar flexion, numerical test results can be highlighted by focusing on parameters such as speed, acceleration, and translation moment. These measurements provide valuable information about the performance and effectiveness of the exoskeleton. By focusing on these numerical test results, it is possible to obtain an idea of the performance of the exoskeleton, understand its impact on the movements of the ankle joint, and make informed decisions for further improvements or optimization of the design. Full article

Current gait rehabilitation strategies rely heavily on motor learning principles, which involve facilitating active patient participation, high-doses of biomechanical task-related motor activities and accurate feedback. Furthermore, appropriate muscle groups need to be recruited for the joint movements that constitute the biomechanical task-related activities in order to effectively promote motor learning. Recently, exoskeleton-type robots utilizing crutches have been incorporated into overground gait rehabilitation programs. However, it is unclear which gait-related tasks are being trained because the joint movements and muscle recruitment patterns deviate from those of natural gait. This raises concerns because repetitive training with these devices may not lead to desirable rehabilitative gains. In this study, we compare the lower limb joint angles and electromyography patterns of healthy subjects walking with and without ReWalk in accordance with the three major biomechanical tasks required by bipedal gait: weight acceptance (WA), single-limb support, and limb advancement. Furthermore, we investigate whether the physical constraints of ReWalk, most noticeably the use of crutches and fixed ankle joints, were responsible for the specific changes by conducting additional walking sessions with either crutches or ankle foot orthoses. The results from the six healthy male volunteers suggest that the gait patterns observed with ReWalk deviate significantly from those of natural gait, particularly during the WA, and closely resemble those of crutch gait. Full article

Energy expenditure is a key rehabilitation outcome and is starting to be used in robotics-based rehabilitation through human-in-the-loop control to tailor robot assistance towards reducing patients’ energy effort. However, it is usually assessed by indirect calorimetry which entails a certain degree of invasiveness and provides delayed data, which is not suitable for controlling robotic devices. This work proposes a deep learning-based tool for steady-state energy expenditure estimation based on more ergonomic sensors than indirect calorimetry. The study innovates by estimating the energy expenditure in assisted and non-assisted conditions and in slow gait speeds similarly to impaired subjects. This work explores and benchmarks the long short-term memory (LSTM) and convolutional neural network (CNN) as deep learning regressors. As inputs, we fused inertial data, electromyography, and heart rate signals measured by on-body sensors from eight healthy volunteers walking with and without assistance from an ankle-foot exoskeleton at 0.22, 0.33, and 0.44 m/s. LSTM and CNN were compared against indirect calorimetry using a leave-one-subject-out cross-validation technique. Results showed the suitability of this tool, especially CNN, that demonstrated root-mean-squared errors of 0.36 W/kg and high correlation (ρ > 0.85) between target and estimation (${\overline{\mathrm{R}}}^2$ = 0.79). CNN was able to discriminate the energy expenditure between assisted and non-assisted gait, basal, and walking energy expenditure, throughout three slow gait speeds. CNN regressor driven by kinematic and physiological data was shown to be a more ergonomic technique for estimating the energy expenditure, contributing to the clinical assessment in slow and robotic-assisted gait and future research concerning human-in-the-loop control. Full article

In our currently ageing society, fall prevention is important for better healthy life expectancy and sustainable healthcare systems. While active outdoor walking is recommended as adequate exercise for the senior population, falls due to tripping and slipping exist as the primary causes of severe injuries. Minimum foot clearance (MFC) is the lowest vertical height of the foot during the mid-swing phase and indicates the risk of tripping. In contrast, coefficient of friction (COF) factors determine the occurrence of falls from slipping. Optimisation of the MFC and the COF for every step cycle prevents tripping and slipping, respectively. Even after the initiation of hazardous balance loss (i.e., tripping and slipping), falls can still be prevented as long as the requirements for balance are restored. Biomechanically, dynamic balance is defined by the bodily centre of mass and by the base of support: spatially—margin of stability and temporally—available response time. Fall prevention strategies should, therefore, target controlling the MFC, the COF and dynamic balance. Practical intervention strategies include footwear modification (i.e., shoe-insole geometry and slip-resistant outsoles), exercise (i.e., ankle dorsiflexors and core stabilisers) and technological rehabilitation (i.e., electrical stimulators and active exoskeletons). Biomechanical concepts can be practically applied to various everyday settings for fall prevention among the older population. Full article

Forecasted gait trajectories of children could be used as feedforward input to control lower limb robotic devices, such as exoskeletons and actuated orthotic devices (e.g., Powered Ankle Foot Orthosis—PAFO). Several studies have forecasted healthy gait trajectories, but, to the best of our knowledge, none have forecasted gait trajectories of children with pathological gait yet. These exhibit higher inter- and intra-subject variability compared to typically developing gait of healthy subjects. Pathological trajectories represent the typical gait patterns that rehabilitative exoskeletons and actuated orthoses would target. In this study, we implemented two deep learning models, a Long-Term Short Memory (LSTM) and a Convolutional Neural Network (CNN), to forecast hip, knee, and ankle trajectories in terms of corresponding Euler angles in the pitch, roll, and yaw form for children with neurological disorders, up to 200 ms in the future. The deep learning models implemented in our study are trained on data (available online) from children with neurological disorders collected by Gillette Children’s Speciality Healthcare over the years 1994–2017. The children’s ages range from 4 to 19 years old and the majority of them had cerebral palsy (73%), while the rest were a combination of neurological, developmental, orthopaedic, and genetic disorders (27%). Data were recorded with a motion capture system (VICON) with a sampling frequency of 120 Hz while walking for 15 m. We investigated a total of 35 combinations of input and output time-frames, with window sizes for input vectors ranging from 50–1000 ms, and output vectors from 8.33–200 ms. Results show that LSTMs outperform CNNs, and the gap in performance becomes greater the larger the input and output window sizes are. The maximum difference between the Mean Absolute Errors (MAEs) of the CNN and LSTM networks was 0.91 degrees. Results also show that the input size has no significant influence on mean prediction errors when the output window is 50 ms or smaller. For output window sizes greater than 50 ms, the larger the input window, the lower the error. Overall, we obtained MAEs ranging from 0.095–2.531 degrees for the LSTM network, and from 0.129–2.840 degrees for the CNN. This study establishes the feasibility of forecasting pathological gait trajectories of children which could be integrated with exoskeleton control systems and experimentally explores the characteristics of such intelligent systems under varying input and output window time-frames. Full article
