Methane is the second largest greenhouse gas. The detection of methane super-emitters and the quantification of their emission rates are necessary for the implementation of methane emission reduction policies to mitigate global warming. High-spectral-resolution satellites such as Gaofen-5 (GF-5), EMIT, GHGSat, and MethaneSAT have been successfully employed to detect and quantify methane point source leaks. In this study, a matched filter (MF) algorithm is improved using data from the EMIT instrument and applied to data from the Advanced Hyperspectral Imager (AHSI) onboard the Ziyuan-1 (ZY-1) satellite. Validation by comparison with EMIT′s L2 XCH₄ products shows the good performance of the improved MF algorithm, in spite of the lower spectral resolution of AHSI/ZY-1 in comparison with other point source imagers. The improved MF algorithm applied to AHSI/ZY-1 data was used to detect and quantify methane super-emitters in global methane hotspot regions. The results show that the improved MF algorithm effectively suppresses noise in retrieval results over both land and ocean surfaces, enhancing algorithm robustness. Sixteen methane plumes were detected in global hotspot regions, originating from coal mines, oil and gas fields, and landfills, with emission rates ranging from 0.57 to 78.85 t/h. The largest plume was located at an offshore oil and gas field in the Gulf of Mexico, with instantaneous emissions nearly equal to the combined total of the other 15 plumes. The findings demonstrate that AHSI, despite its lower spectral resolution, can detect sources with emission rates as small as 571 kg/h and achieve faster retrieval speeds, showing significant potential for global methane monitoring. Additionally, this study highlights the need to focus on methane emissions from marine sources, alongside terrestrial sources, to efficiently implement reduction strategies. Full article

The attitude accuracy of high-resolution satellite images is the main factor affecting their geometric positioning accuracy. Bundle block adjustment is the main method for realizing the simultaneous estimation of attitude models for overlapping images over a large area. In the current research on the joint positioning of high-resolution multi-line array satellite images, the adjustment is usually carried out with the view or load as a unit without considering the consistency of the error of the same platform. In this paper, we develop a self-calibration strip bundle adjustment scheme that considers the boresight misalignment among multiple cameras. By introducing the installation angle between multiple loads, we fully utilized their geometric constraint relationship with the same platform to establish a unified attitude compensation model for multiple loads. The experimental results of the ZiYuan3 (ZY-3) satellite image show that, when the ground control points (GCPs) are laid only at four corner points of the image, the image plane and elevation accuracies are 1.85 m and 1.87 m after an adjustment using this method, which can achieve comparable accuracies with those obtained by a traditional program based on an adjustment with more GCPs. Full article

Detailed information about mangroves is crucial for ecological and environmental protection and sustainable development. It is difficult to capture small patches of mangroves from satellite images with relatively low to medium resolution. In this study, high-resolution (0.8–2 m) images from Chinese GaoFen (GF) and ZiYuan (ZY) series satellites were used to map the distribution of mangroves in coastal areas of Guangdong Province, China. A deep-learning network, U²-Net, with attention gates was applied to extract multi-scale information of mangroves from satellite images. The results showed that the attention U²-Net model performed well on mangrove classification. The overall accuracy, precision, and F1-score values were 96.5%, 92.0%, and 91.5%, respectively, which were higher than those obtained from other machine-learning methods such as Random Forest or U-Net. Based on the high-resolution mangrove maps generated from long satellite image time series, we also investigated the spatiotemporal evolution of the mangrove forest in Shuidong Bay. The results can provide crucial information for government administrators, scientists, and other stakeholders to monitor the dynamic changes in mangroves. Full article

The main feature of grassland degradation is the change in the vegetation community structure. Hyperspectral-based grassland community identification is the basis and a prerequisite for large-area high-precision grassland degradation monitoring and management. To obtain the distribution pattern of grassland communities in Xilinhot, Inner Mongolia Autonomous Region, China, we propose a systematic classification method (SCM) for hyperspectral grassland community identification using China’s ZiYuan 1-02D (ZY1-02D) satellite. First, the sample label data were selected from the field-collected samples, vegetation map data, and function zoning data for the Nature Reserve. Second, the spatial features of the images were extracted using extended morphological profiles (EMPs) based on the reduced dimensionality of principal component analysis (PCA). Then, they were input into the random forest (RF) classifier to obtain the preclassification results for grassland communities. Finally, to reduce the influence of salt-and-pepper noise, the label similarity probability filter (LSPF) method was used for postclassification processing, and the RF was again used to obtain the final classification results. The results showed that, compared with the other seven (e.g., SVM, RF, 3D-CNN) methods, the SCM obtained the optimal classification results with an overall classification accuracy (OCA) of 94.56%. In addition, the mapping results of the SCM showed its ability to accurately identify various ground objects in large-scale grassland community scenes. Full article

The Ziyuan3-01 (ZY3-01) satellite is China’s first civilian stereo surveying and mapping satellite to meet the 1:50,000 scale mapping requirements, and has been operated in orbit for 10 years. The boresight misalignment of the three-line camera (TLC) is an essential factor affecting the geolocation accuracy, which is a principal concern for stereo mapping satellites. However, the relative relationships of TLC are often regarded as fixed for the same ground scene in most traditional geometric calibrations, without considering the on-orbit long-periodic changes. In this paper, we propose a long-periodic method to analyze and estimate the boresight misalignments between three cameras, with the attitude estimation of a nadir (NAD) camera as the benchmark. Offsets and drifts of the three cameras were calculated and calibrated with different compensation models using scale invariant feature transform (SIFT) points as the ground control. Ten simultaneous NAD–Forward (FWD)–Backward (BWD) imagery of the ZY3-01 satellite acquired from 2012 to 2020 were selected to verify the long-periodic changes in TLC boresight misalignments. The results indicate that the boresight alignment angles of ZY3-01 TLC are dynamic during the long-periodic flight, but the structure of TLC is stable for the misalignments of both FWD and BWD within only 7 arc seconds, which can provide a positive reference for subsequent satellite design and long-periodic on-orbit geometric calibration. Full article

Forest canopy height is an essential parameter in estimating forest aboveground biomass (AGB), growing stock volume (GSV), and carbon storage, and it can provide necessary information in forest management activities. Light direction and ranging (LiDAR) is widely used for estimating canopy height. Considering the high cost of acquiring LiDAR data over large areas, we took a two-stage up-scaling approach in estimating forest canopy height and aimed to develop a method for quantifying the uncertainty of the estimation result. Based on the generalized hierarchical model-based (GHMB) estimation framework, a new estimation framework named RK-GHMB that makes use of a geostatistical method (regression kriging, RK) was developed. In this framework, the wall-to-wall forest canopy height and corresponding uncertainty in map unit scale are generated. This study was carried out by integrating plot data, sampled airborne LiDAR data, and wall-to-wall Ziyuan-3 satellite (ZY3) stereo images. The result shows that RK-GHMB can obtain a similar estimation accuracy (r = 0.92, MAE = 1.50 m) to GHMB (r = 0.92, MAE = 1.52 m) with plot-based reference data. For LiDAR-based reference data, the accuracy of RK-GHMB (r = 0.78, MAE = 1.75 m) is higher than that of GHMB (r = 0.75, MAE = 1.85 m). The uncertainties for all map units range from 1.54 to 3.60 m for the RK-GHMB results. The values change between 1.84 and 3.60 m for GHMB. This study demonstrates that this two-stage up-scaling approach can be used to monitor forest canopy height. The proposed RK-GHMB approach considers the spatial autocorrelation of neighboring data in the second modeling stage and can achieve a higher accuracy. Full article

This project explored the integrated use of satellite, ground observations and hydrological distributed models to support water resources assessment and monitoring in High Mountain Asia (HMA). Hydrological data products were generated taking advantage of the synergies of European and Chinese data assets and space-borne observation systems. Energy-budget-based glacier mass balance and hydrological models driven by satellite observations were developed. These models can be applied to describe glacier-melt contribution to river flow. Satellite hydrological data products were used for forcing, calibration, validation and data assimilation in distributed river basin models. A pilot study was carried out on the Red River basin. Multiple hydrological data products were generated using the data collected by Chinese satellites. A new Evapo-Transpiration (ET) dataset from 2000 to 2018 was generated, including plant transpiration, soil evaporation, rainfall interception loss, snow/ice sublimation and open water evaporation. Higher resolution data were used to characterize glaciers and their response to environmental forcing. These studies focused on the Parlung Zangbo Basin, where glacier facies were mapped with GaoFeng (GF), Sentinal-2/Multi-Spectral Imager (S2/MSI) and Landsat8/Operational Land Imager (L8/OLI) data. The geodetic mass balance was estimated between 2000 and 2017 with Zi-Yuan (ZY)-3 Stereo Images and the SRTM DEM. Surface velocity was studied with Landsat5/Thematic Mapper (L5/TM), L8/OLI and S2/MSI data over the period 2013–2019. An updated method was developed to improve the retrieval of glacier albedo by correcting glacier reflectance for anisotropy, and a new dataset on glacier albedo was generated for the period 2001–2020. A detailed glacier energy and mass balance model was developed with the support of field experiments at the Parlung No. 4 Glacier and the 24 K Glacier, both in the Tibetan Plateau. Besides meteorological measurements, the field experiments included glaciological and hydrological measurements. The energy balance model was formulated in terms of enthalpy for easier treatment of water phase transitions. The model was applied to assess the spatial variability in glacier melt. In the Parlung No. 4 Glacier, the accumulated glacier melt was between 1.5 and 2.5 m w.e. in the accumulation zone and between 4.5 and 6.0 m w.e. in the ablation zone, reaching 6.5 m w.e. at the terminus. The seasonality in the glacier mass balance was observed by combining intensive field campaigns with continuous automatic observations. The linkage of the glacier and snowpack mass balance with water resources in a river basin was analyzed in the Chiese (Italy) and Heihe (China) basins by developing and applying integrated hydrological models using satellite retrievals in multiple ways. The model FEST-WEB was calibrated using retrievals of Land Surface Temperature (LST) to map soil hydrological properties. A watershed model was developed by coupling ecohydrological and socioeconomic systems. Integrated modeling is supported by an updated and parallelized data assimilation system. The latter exploits retrievals of brightness temperature (Advanced Microwave Scanning Radiometer, AMSR), LST (Moderate Resolution Imaging Spectroradiometer, MODIS), precipitation (Tropical Rainfall Measuring Mission (TRMM) and FengYun (FY)-2D) and in-situ measurements. In the case study on the Red River Basin, a new algorithm has been applied to disaggregate the SMOS (Soil Moisture and Ocean Salinity) soil moisture retrievals by making use of the correlation between evaporative fraction and soil moisture. Full article

Fine land cover classification (FLCC) of complex landscapes is a popular and challenging task in the remote sensing community. In complex surface-mined areas (CSMAs), researchers have conducted FLCC using traditional machine learning methods and deep learning algorithms. However, convolutional neural network (CNN) algorithms that may be useful for FLCC of CSMAs have not been fully investigated. This study proposes a multimodal remote sensing data and multiscale kernel-based multistream CNN (3M-CNN) model. Experiments based on two ZiYuan-3 (ZY-3) satellite imageries of different times and seasons were conducted in Wuhan, China. The 3M-CNN model had three main features: (1) multimodal data-based multistream CNNs, i.e., using ZY-3 imagery-derived true color, false color, and digital elevation model data to form three CNNs; (2) multisize neighbors, i.e., using different neighbors of optical and topographic data as inputs; and (3) multiscale convolution flows revised from an inception module for optical and topographic data. Results showed that the proposed 3M-CNN model achieved excellent overall accuracies on two different images, and outperformed other comparative models. In particular, the 3M-CNN model yielded obvious better visual performances. In general, the proposed process was beneficial for the FLCC of complex landscape areas. Full article

Time delay and integration (TDI) charge-coupled device (CCD) is an image sensor for capturing images of moving objects at low light levels. This study examines the model construction of stitched TDI CCD original multi-slice images. The traditional approaches, for example, include the image-space-oriented algorithm and the object-space-oriented algorithm. The former indicates concise principles and high efficiency, whereas the panoramic stitching images lack the clear geometric relationships generated from the image-space-oriented algorithm. Similarly, even though the object-space-oriented algorithm generates an image with a clear geometric relationship, it is time-consuming due to the complicated and intensive computational demands. In this study, we developed a multi-slice satellite images stitching and geometric model construction method. The method consists of three major steps. First, the high-precision reference data assist in block adjustment and obtain the original slice image bias-corrected RFM to perform multi-slice image block adjustment. The second process generates the panoramic stitching image by establishing the image coordinate conversion relationship from the panoramic stitching image to the original multi-slice images. The final step is dividing the panoramic stitching image uniformly into image grids and employing the established image coordinate conversion relationship and the original multi-slice image bias-corrected RFM to generate a virtual control grid to construct the panoramic stitching image RFM. To evaluate the performance, we conducted experiments using the Tianhui-1(TH-1) high-resolution image and the Ziyuan-3(ZY-3) triple liner-array image data. The experimental results show that, compared with the object-space-oriented algorithm, the stitching accuracy loss of the generated panoramic stitching image was only 0.2 pixels and that the mean value was 0.799798 pixels, achieving the sub-pixel stitching requirements. Compared with the object-space-oriented algorithm, the RFM positioning difference of the panoramic stitching image was within 0.3 m, which achieves equal positioning accuracy. Full article

Lake area, water level, and water storage changes of terminal lakes are vital for regional water resource management and for understanding local hydrological processes. Nevertheless, due to the complex geographical conditions, it is difficult to investigate and analyze this change in ungauged regions. This study focuses on the ungauged, semi-arid Gahai Lake, a typical small terminal lake in the Qaidam Basin. In addition to the scant observed data, satellite altimetry is scarce for the excessively large fraction of outlier points. Here, we proposed an effective and simple algorithm for extracting available lake elevation points from CryoSat-2, ICESat-2 and Sentinel-3. Combining with the area data from Landsat, Gaofen (GF), and Ziyuan (ZY) satellites, we built an optimal hypsographic curve (lake area versus water level) based on the existing short-term data. Cross-validation was used to validate whether the curve accurately could predict the lake water level in other periods. In addition, we used multisource high-resolution images including Landsat and digital maps to extract the area data from 1975 to 2020, and we applied the curve to estimate the water level for the corresponding period. Additionally, we adopted the pyramidal frustum model (PFM) and the integral model (IM) to estimate the long-term water storage changes, and analyzed the differences between these two models. We found that there has been an obvious change in the area, water level, and water storage since the beginning of the 21st century, which reflects the impact of climate change and human activities on hydrologic processes in the basin. Importantly, agricultural activities have caused a rapid increase in water storage in the Gahai Lake over the past decade. We collected as much multisource satellite data as possible; thus, we estimated the long-term variations in the area, water level, and water storage of a small terminal lake combining multiple models, which can provide an effective method to monitor lake changes in ungauged basins. Full article

To ensure the accuracy of large-scale optical stereo image bundle block adjustment, it is necessary to provide well-distributed ground control points (GCPs) with high accuracy. However, it is difficult to acquire control points through field measurements outside the country. Considering the high planimetric accuracy of spaceborne synthetic aperture radar (SAR) images and the high elevation accuracy of satellite-based laser altimetry data, this paper proposes an adjustment method that combines both as control sources, which can be independent from GCPs. Firstly, the SAR digital orthophoto map (DOM)-based planar control points (PCPs) acquisition is realized by multimodal matching, then the laser altimetry data are filtered to obtain laser altimetry points (LAPs), and finally the optical stereo images’ combined adjustment is conducted. The experimental results of Ziyuan-3 (ZY-3) images prove that this method can achieve an accuracy of 7 m in plane and 3 m in elevation after adjustment without relying on GCPs, which lays the technical foundation for a global-scale satellite image process. Full article

When in orbit, spliced satellite optical cameras are affected by various factors that degrade the actual image stitching precision and the accuracy of their data products. This is a major bottleneck in the current remote sensing technology. Previous geometric calibration research has mostly focused on stitched satellite images and has largely ignored the inter-chip relationship among original multi-chip images, resulting in accuracy loss in geometric calibration and subsequent image products. Therefore, in this paper, a novel geometric calibration method is proposed for spliced satellite optical cameras. The integral geometric calibration model was developed on inter-chip geometry constraints among multi-chip images, including the corresponding external and internal calibration models. The proposed approach improves uncontrolled geopositioning accuracy and enhances mosaic precision at the same time. For evaluation, images from the optical butting satellite ZiYuan-3 (ZY-3) and mechanical interleaving satellite Tianhui-1 (TH-1) were used for the experiments. Multiple sets of satellite data of the Songshan Calibration field and other regions were used to evaluate the reliability, stability, and applicability of the calibration parameters. The experiment results found that the proposed method obtains reliable camera alignment angles and interior calibration parameters and generates high-precision seamless mosaic images. The calibration scheme is not only suitable for mechanical interleaving cameras with large geometric displacement among multi-chip images but is also effective for optical butting cameras with minor chip offset. It also significantly improves uncontrolled geopositioning accuracy for both types of spliced satellite images. Moreover, the proposed calibration procedure results in multi-chip satellite images being seamlessly stitched together and mosaic errors within one pixel. Full article

Currently available high-resolution digital elevation model (DEM) is not particularly useful to geologists for understanding the long-term changes in fluvial landforms induced by tectonic uplift, although DEMs that are generated from satellite stereo images such as the ZiYuan-3 (ZY3) satellite include characteristics with significant coverage and rapid acquisition. Since an ongoing analysis of fluvial systems is lacking, the ZY3 DEM was generated from block adjustment to describe the mountainous area of the Qianhe Basin that have been induced by tectonic uplift. Moreover, we evaluated the overall elevation difference in ZY3 DEM, Shuttle Radar Topography Mission (1″ × 1″) (SRTM1), and Reflection Radiometer Global Digital Elevation Model (ASTER GDEM) by using the Ice Cloud and Land Elevation Satellite/Geoscience Laser Altimeter (ICESat/GLAH14) point cloud and a DEM of 1:50,000 scale. The values of the root mean square error (RMSE) of the elevation difference for ZY3 DEM were 9.31 and 9.71 m, respectively, and are in good agreement with SRTM1. The river long profiles and terrace heights were also extracted to compare the differences in channel steepness and the incision rates with SRTM1 and ASTER GDEM. Our results prove that ZY3 DEM would be a good alternative to SRTM1 in achieving the 1:50,000 scale for DEM products in China, while ASTER GDEM is unsuitable for extracting river longitudinal profiles. In addition, the northern and southern river incision rates were estimated using the ages and heights of river terraces, demonstrating a range from 0.12–0.45 to 0.10–0.33 m/kyr, respectively. Collectively, these findings suggest that ZY3 DEM is capable of estimating tectonic geomorphological features and has the potential for analyzing the continuous evolutionary response of a landscape to changes in climate and tectonics. Full article

Combined geometric positioning using images with different resolutions and imaging sensors is being increasingly widely utilized in practical engineering applications. In this work, we attempt to perform the combined geometric positioning and performance analysis of multi-resolution optical images from satellite and aerial platforms based on weighted rational function model (RFM) bundle adjustment without using ground control points (GCPs). Firstly, we introduced an integrated image matching method combining least squares and phase correlation. Next, for bundle adjustment, a combined model of the geometric positioning based on weighted RFM bundle adjustment was derived, and a method for weight determination was given to make the weights of all image points variable. Finally, we conducted experiments using a case study in Shanghai with ZiYuan-3 (ZY-3) satellite imagery, GeoEye-1 satellite imagery, and Digital Mapping Camera (DMC) aerial imagery to validate the effectiveness of the proposed weighted method, and to investigate the positioning accuracy by using different combination scenarios of multi-resolution heterogeneous images. The experimental results indicate that the proposed weighted method is effective, and the positioning accuracy of different combination scenarios can give a good reference for the combined geometric positioning of multi-stereo heterogeneous images in future practical engineering applications. Full article

Providing vegetation type information with accurate surface distribution is one of the important tasks of remote sensing of the ecological environment. Many studies have explored ecosystem structure information at specific spatial scales based on specific remote sensing data, but it is still rare to extract vegetation information at various landscape levels from a variety of remote sensing data. Based on Gaofen-1 satellite (GF-1) Wide-Field-View (WFV) data (16 m), Ziyuan-3 satellite (ZY-3) and airborne LiDAR data, this study comparatively analyzed the four levels of vegetation information by using the geographic object-based image analysis method (GEOBIA) on the typical natural secondary forest in Northeast China. The four levels of vegetation information include vegetation/non-vegetation (L1), vegetation type (L2), forest type (L3) and canopy and canopy gap (L4). The results showed that vegetation height and density provided by airborne LiDAR data could extract vegetation features and categories more effectively than the spectral information provided by GF-1 and ZY-3 images. Only 0.5 m LiDAR data can extract four levels of vegetation information (L1–L4); and from L1 to L4, the total accuracy of the classification decreased orderly 98%, 93%, 80% and 69%. Comparing with 2.1 m ZY-3, the total classification accuracy of L1, L2 and L3 extracted by 2.1 m LiDAR data increased by 3%, 17% and 43%, respectively. At the vegetation/non-vegetation level, the spatial resolution of data plays a leading role, and the data types used at the vegetation type and forest type level become the main influencing factors. This study will provide reference for data selection and mapping strategies for hierarchical multi-scale vegetation type extraction. Full article
