Search Results (94)

Common-path optical coherence tomography (CP-OCT) has garnered significant interest for use in biomedical imaging due to its compact configuration, enhanced phase stability, and reduced sensitivity to environmental disturbances. The imaging performance of a common-path probe is significantly influenced by the reference power generated within the probe, which determines the interference modulation, signal-to-noise ratio (SNR), phase stability, and ultimately, the image quality. This study presents a systematic optimization of reference power in a fiber-based common-path OCT probe through numerical simulation and experimental validation. The optical coupling efficiency was evaluated using the Fiber Coupling analysis implemented in Zemax OpticStudio and validated experimentally using a fabricated probe incorporating an index-matching UV-curable adhesive as a partial Fresnel reflector. The influence of fiber-to-reflector separation on the coupled reference power was investigated and correlated with SNR, phase stability, and OCT image quality. The results demonstrate that increasing the reference power improves SNR and phase stability up to an optimum range of 20–60 µw, beyond which a gradual performance reduction is observed. In contrast, phase stability shows minimal additional improvement. The optimized reference power also enhances image contrast and structural visibility. These findings establish practical design guidelines for selecting the fiber-to-reflector spacing to achieve balanced reference power and improved imaging performance in compact common-path OCT probes for biomedical imaging applications. Full article

High-index 4H-silicon carbide (4H-SiC) provides a larger waveguide k-space than conventional glass and is therefore attractive for wide field-of-view (FOV) diffractive augmented reality waveguides. However, the angular response of a slanted grating is asymmetric. For one grating-vector direction, the diffraction efficiency remains high over a wide positive-angle range but decreases rapidly at negative angles, leading to nonuniform image brightness over a broad field. Reversing the grating vector reverses this response. The field is therefore divided at 0°, with the positive and negative FOV channels assigned to two mirror-related slanted-grating domains with opposite grating vectors. The grating parameters for the red (648 nm), green (548 nm), and blue (448 nm) wavelengths were optimized separately using particle swarm optimization. Their angular diffraction responses were calculated by rigorous coupled-wave analysis and then introduced into Zemax for system-level ray tracing. At 548 nm, the optimized 4H-SiC, n = 1.8 glass, and n = 2.0 glass gratings provided effective angular bandwidths of approximately 88°, 31°, and 37°, respectively. Under the same 4H-SiC material and system conditions, the +G/−G arrangement reduced the root-mean-square (RMS) irradiance nonuniformity from approximately 40.3% to 32.8% and increased the effective fill factor from 40.8% to 61.5% compared with the single-+G configuration. In a separate system-level comparison, the optimized n = 1.8 glass and 4H-SiC models yield RMS irradiance nonuniformities of 44.0% and 32.8% and effective fill factors of 46.1% and 61.5%, respectively. These results connect the broad angular response of the optimized 4H-SiC grating with the system-level balancing produced by opposite grating-vector assignment. The optimized grating parameters and detector-plane response maps also provide a computational basis for subsequent fabrication and experimental validation of the proposed 4H-SiC waveguide design. Full article

Detector-multiplexed wide-field infrared imaging reuses detector area by folding several sub-fields of view onto a common focal-plane region, but the branch identity of an aliased small target is then unavailable from intensity alone. We propose a dual-domain optical code that combines a fixed Zemax-derived point-spread-function (PSF) library with a conditionally assigned linear-polarization codebook. To replace the earlier feature-level validation, we developed an image-level radiometric simulator that generates four analyzer images under a fixed incident-photon budget, applies mirror transfer, throughput loss, Poisson shot noise, background, read noise, and physical multi-target PSF superposition, and then re-extracts morphology and Stokes observables. The 1037 PSF samples were divided by sub-field into construction, calibration, and locked test sets of 623, 207, and 207 samples. The polarization-to-field assignment was selected by an exhaustive 9! search on the construction data, whereas the compound weight and separability threshold were fixed from calibration data only. In 25,000 locked target-level tests, the equal-weight-form compound decoder achieved 95.936% accuracy (95% confidence interval of 95.684–96.174%), compared with 10.836%, 45.564%, and 88.720% for intensity-only, shape-only, and polarization-only decoding. At the calibrated threshold, the effective capacities were five, four, and nine for the shape, polarization, and compound code spaces. The results are simulation-phase evidence and require experimental verification with measured infrared throughput and component tolerances. Full article

In laser phase-transformation hardening and laser cladding processes, the inherent thermodynamic limitations of conventional intensity distributions severely restrict the uniformity of metallurgical reaction. Although programmable beam shaping devices offer flexibility in profile reconstruction, their transmissive structure results in a low laser-induced damage threshold (LIDT), making them unsuitable for long-term stable operation at kilowatt-level power. This study proposes a reflective freeform mirror design method based on the principle of zonal energy mapping. The method constructs energy mapping relations that correlate the irradiance distribution in every sub-region of the incident Gaussian beam with the desired M-shaped irradiance profile. Relying on such mappings, the local surface generatrices of all sub-regions are solved separately; these generatrices are subsequently assembled to yield an integrated mirror surface. Optical performance was verified through Zemax non-sequential ray tracing simulations. The mirror was precisely machined using single-point diamond turning (SPDT). The experimental results show that the measured intensity distribution on the observation screen exhibits a typical M-shaped profile, with a peak-to-valley ratio of 1.28, which is in good agreement with the design target. This method provides a technically feasible and engineering-robust solution for complex thermal flux control requirements in high-power laser material processing. Full article

Traditional zoom semi-active laser seekers cannot adaptively adjust the spot size while maintaining a compact structure, which degrades angle measurement accuracy. This paper proposes a method based on aberration theory to analyze angle measurement designs an electrowetting dual-liquid zoom optical system that meets compactness constraints. The dynamic curvature control architecture replaces traditional mechanical zoom to achieve optimal detection spot for four-quadrant detectors throughout the entire trajectory. The Gaussian bracket method is employed to calculate and distribute the total optical power of the system, and a dynamic zoom optical system meeting compactness requirements is designed and simulated. Quantitative equations relating the spatial position of the liquid lens to aberrations are derived. A global optimization of the liquid lens zoom optical system for the seeker is performed on the ZEMAX 2024 platform, enabling the system to meet the detection requirements of the entire trajectory through voltage control. Design results show a total system length of 61.6 mm, with distortion controlled within 0.1% during continuous focallength adjustment from 30 to 57 mm. A quantitative evaluation model for aberration-induced angle measurement error is established, and calculations indicate a 62.8% reduction in the RMS angle measurement error over the full zoom range. Full article

High-precision measurement of six-degree-of-freedom relative pose is a critical challenge for deformation control and stability improvement of structural components in precision assembly and aerospace structural components. To address incomplete pose-parameter measurement and the difficulty of pose-parameter decoupling in existing methods, this paper proposes an error-modeling and crosstalk-compensation method for 6-DOF relative pose measurement based on the fusion of fiber-coupled heterodyne interferometry and laser collimation. First, a relative pose measurement model was established using homogeneous coordinate transformations and ray-tracing methods, wherein physically reasonable constraints on structural deformation were introduced to compensate for crosstalk caused by the coupling between angular and displacement errors based on COMSOL simulation, and this model was later validated via Zemax. Second, a measurement system was constructed, followed by calibration experiments and a 35 h stability test to characterize its measurement accuracy and long-term stability. Finally, three repeated plate loading and unloading cycles were conducted under structural deformation conditions. The comparative results show the maximum residuals of 0.92 μm, 0.79 μm, 1.00 μm, 0.54″, 2.53″, and 1.53″ for Δx, Δy, Δz, Δα, Δβ, and Δγ compared to reference instruments, while it drops from 61.13 μm to 1.00 μm for Δz after model compensation, reducing error by 96.79%. The proposed method provides an effective approach for high-precision measurement and decoupling of the 6-DOF relative pose of structural components under complex operating conditions. Full article

Spectral interrogation of fiber Bragg gratings (FBGs) in the ~850 nm band remains relatively uncommon, largely due to the limited availability of commercial instruments and the restricted applicability of conventional interrogation schemes in this wavelength range. This work presents a practical and high-precision wavelength demodulation method for 850 nm FBG sensing based on an imaging Charge-Coupled Device (CCD) spectrometer. A Czerny–Turner (C–T) optical configuration is employed for spatial spectral dispersion, and the optical system is theoretically analyzed and optimized using ZEMAX to balance spectral resolution, optical throughput, and compactness. A polynomial wavelength–pixel calibration model is established, and Gaussian fitting is adopted for robust peak-position extraction under multimode fiber conditions. Experimental validation is carried out using four serially cascaded FBGs distributed over 830–880 nm. The wavelength–pixel calibration yields an RMS residual of 0.46 nm. Within a strain range of 0–2000 με, the average wavelength demodulation bias of a single FBG is 6.8 pm, with a wavelength demodulation RMS error of 86.9 pm and a measured strain sensitivity of 0.72 pm/με. The results demonstrate that the proposed CCD-based imaging interrogation scheme is feasible for 850 nm FBG sensing and enables accurate wavelength demodulation in this relatively underexplored band. Since the system is implemented using standard off-the-shelf components, it also provides a practical technical route for the deployment of FBG sensing systems in engineering applications. Full article

Ultrahigh lateral resolution (UHLR) optical coherence tomography (OCT) technology, also called optical coherence microscopy (OCM), has gained popularity, especially in the field of biomedical imaging. In these systems, high numerical aperture (NA) Microscope objectives (MO) are employed in OCM systems to offer better than 3 µm lateral resolution. However, in the implemented broadband OCM configuration, the use of complex multi-element microscope objectives can reduce the detected returned signal compared with a simpler imaging lens configuration. This reduction in detected returned signals can become an important practical limitation in many OCM applications, particularly for biomedical imaging when high imaging speed is crucial. This study investigates whether a single off-the-shelf lens can provide a practical alternative to conventional MOs, achieving higher throughput while maintaining reasonable spatial resolution. We systematically evaluated 14 commercial lenses using Zemax OpticStudio simulations, identifying an aspherized achromatic lens (Edmund Optics #85302) that best met these key criteria. To validate its feasibility for OCM, performance was tested in both Full-Field Time-Domain OCM (FF-TD-OCM) and Line-Field Spectral-Domain OCM (LF-SD-OCM) configurations. Using a broadband composite Superluminescent Diode (SLD) source (750–920 nm), we quantified the resolvable features, axial resolution, and overall light transmission. The validated system demonstrated near-diffraction-limited performance. In the LF-SD-OCM setup, it successfully resolved features as fine as Group 8, Element 6, corresponding to a 2.2 µm line pair pitch (~1.1 µm line width) and achieved a 2.86 µm axial resolution in air. A through-focus comparison further showed practically useful contrast retention around focus. Additional imaging of onion epidermal tissue and ex vivo porcine corneal tissue demonstrated that the proposed lens could provide interpretable structural images on representative biological samples. Under the tested LF-SD-OCM detection configuration, the selected lens delivered approximately 2.0 dB higher returned signal than the Mitutoyo MY10X-823 objective according to 1.59× larger received signal. Full article

Designing high-speed wide-angle optics for large-format mirrorless cameras presents a fundamental engineering conflict between the short flange back distance and the requirement for high-resolution aberration correction. To address this challenge, this study proposes a compact 18.5 mm F/2.0 lens system utilizing a modified retrofocus architecture equipped with an internal floating-focus mechanism. The design methodology integrates glass-molded aspherical surfaces to suppress high-order aberrations and employs passive athermalization strategies to maintain stability across a temperature range of −30 °C to +70 °C. Performance was rigorously evaluated using numerical simulations in Zemax OpticStudio, alongside comprehensive Monte Carlo tolerance analysis. Simulation results demonstrate exceptional optical performance, with the Modulation Transfer Function (MTF) exceeding 0.5 at a spatial frequency of 100 lp/mm across the field. Furthermore, focus breathing is restricted to less than 1%, and optical distortion is strictly controlled within 2%. The Monte Carlo tolerance analysis predicts a manufacturing yield exceeding 80% under standard industrial precision levels. Ultimately, this work provides a theoretically sound, athermally stable, and highly manufacturable solution suitable for next-generation high-resolution mirrorless sensors. Full article

A detailed numerical optimization of side-pumped cerium- and neodymium-codoped yttrium aluminum garnet (Ce:Nd:YAG) solar laser architectures was performed using Zemax^® and LASCAD^TM, aiming for both high-power multimode and TEM₀₀-mode performances. Multiple rod configurations and laser resonator geometries were evaluated to maximize absorbed pump power, improve mode overlap, and ensure thermal stability. For multimode operation, the optimal design was a four-rod cross side-pumped configuration employing 4.0 mm diameter, 25 mm length rods, which numerically delivered a solar laser output power of 134 W (resulting in a collection efficiency of 49.1 W/m² and solar-to-laser conversion efficiency of 4.91%), representing a 1.50-times improvement over the best previously reported value of 89.29 W. For TEM₀₀-mode generation, the best performance was obtained with a three-rod horizontal side-pumped configuration using 2.5 mm diameter, 34 mm length rods, achieving a collection efficiency of 21.1 W/m² and solar-to-laser conversion efficiency of 2.11%, surpassing the record 16.49 W/m² reported in earlier literature. Thermal analyses revealed low peak temperatures, reduced thermally induced stress, and minimized refractive-index gradients in both architectures, confirming that multirod side pumping significantly improves the thermal environment and enables stable operation at high absorbed pump powers. These results demonstrate that carefully engineered multirod geometries can simultaneously enhance collection efficiency, beam quality, and thermal robustness, highlighting multirod side-pumped solar lasers as a promising pathway for further power scaling and next-generation high-performance solar laser systems. Full article

Coherent-dispersion spectroscopy enables high-precision Doppler measurements of stellar spectral lines, which serves as a vital technique for the indirect detection of exoplanets. In this study, the post-dispersion system of a coherent-dispersion spectrometer (CODES) was designed and optimized using Zemax, with the detection spectral range of 656 nm–716 nm and a spectral resolution of 0.06 nm. The relay optical path adopted a combination of a cylindrical lens group and an image slicer, which reshaped the circular spot with a diameter of 630 μm into a linear spot of 27 μm × 2038.8 μm, effectively matching the slit size and improving the light throughput. A flat-field design was employed for the dispersion module, which adopted two structures: the Czerny–Turner spectrometer and the Dyson spectrometer. Both spectrometer structures were designed and optimized, and their aberrations and structural characteristics were comparatively analyzed. The on-axis Modulation Transfer Function (MTF) values at the central wavelength of the two spectrometers were 0.4@37 lp/mm and 0.8@37 lp/mm, respectively, and both the spectral resolution and imaging resolution could meet the design requirements. This work provides a feasible design idea for high-precision CODES for exoplanet detection as well as general medium-to-high resolution spectrometers. Full article

The surface tension of a liquid droplet can be determined by fitting its actual profiles using the Young–Laplace equation, effectively reducing the measurement of surface tension to an accurate determination of the droplet’s profiles. Spectral confocal sensors are high-precision, interference-resistant, non-contact measurement systems for droplet surface profiling, employing a light source together with a dispersive objective lens and a spectrometer to acquire depth-dependent spectral information. The accuracy and stability of surface tension measurements can be effectively enhanced by spectral confocal sensors measuring the droplet surface profile. Although existing spectral confocal sensors have significantly improved measurement range and accuracy, their angular measurement performance remains limited, and deviations may arise at droplet edges with large inclinations or pronounced surface profile variations. This study presents the optical design of a large-angle spectral confocal sensor. By theoretically analyzing the conditions for generating linear axial dispersion in the dispersive objective lens, a front-end dispersive objective lens was designed by combining positive and negative lenses. Based on a Czerny–Turner (C-T) configuration, the back-end spectrometer was designed under the astigmatism-free condition, taking into account both central and edge wavelength effects. Zemax was employed for simulation optimization and tolerance analysis of each optical module. The results show that the designed system achieves an axial dispersion of 1.5 mm over the 430–700 nm wavelength range, with a maximum allowable object angle of ±40° and a theoretical resolution of 3 μm. The proposed spectral confocal sensor maintains high measurement accuracy over a wide angular range, facilitating precise measurement of droplet surface tension at large inclination angles. Full article

Lensless microscopy is a well-established imaging approach that replaces traditional lenses with phase modulators, enabling compact, low-cost, and computationally driven analysis of biological samples. In this work, we show how ray tracing simulations can be used to optimize lensless imaging systems for automated classification, particularly for detecting red blood cell (RBC) disease. Rather than improving the machine learning classification algorithm, our focus is on refining optical parameters such as element spacing and modulator type to maximize classification performance. We modeled a lensless microscope in Zemax OpticStudio (ray tracing) and compared the results against Fourier optics simulations. Despite not explicitly modeling diffraction, ray tracing produced classification results largely consistent with wave optics simulations, confirming its effectiveness for parameter optimization in lensless imaging setups used for classification tasks. Furthermore, to show the flexibility of the ray tracing model, we introduced a microlens array (MLA) as the phase modulator and performed the classification task on the generated patterns. These results establish ray tracing as an efficient tool for the optical design of lensless microscopy systems intended for machine learning based biomedical applications. The developed lensless microscopy model enables the generation of datasets for training neural networks. Full article

We present a differentiable, curriculum-based optimization workflow for the engineering-oriented design of large-aperture reflective optical systems. The method integrates physics-informed differentiable ray tracing with a progressive, two-stage optimization strategy that evolves from simple Ritchey–Chrétien (RC) foundations to complex four-mirror architectures. Without relying on pretrained models or large datasets, the workflow optimizes geometric and physical parameters under field-weighted RMS, focal length, and dynamic obscuration constraints while maintaining minimal perturbation to primary and secondary mirrors. Validated through Zemax-based analysis, the optimized systems achieve high imaging quality with improved RMS uniformity and stable convergence across varying aperture scales. This approach provides a practical and scalable pathway for the design and optimization of reflective optical instruments, offering strong robustness and adaptability for diverse imaging applications. Full article

In the field of high-temperature in situ sensing, highly reflective Fabry–Perot (F-P) cavity mirrors with thermal stress matching are urgently needed. The quartz-based volume Bragg grating (VBG) can replace the dielectric high-reflection film to prepare a high-temperature and high-precision F-P cavity sensitive unit by virtue of the integrated structure of homogeneous materials. The reflectivity of the VBG is a key parameter determining the performance of the F-P cavity, and its accurate measurement is very important for the pre-evaluation of the device’s sensing ability. Based on the reflectivity measurement of quartz-based VBG with a large aspect ratio, a free-space optical path reflective measurement system is proposed. The ZEMAX simulation is used to optimize the optical transmission path and determine the position of each component when the optimal spot size is achieved. After completing the construction of the VBG reflectivity measurement system, the measurement error is calibrated by measuring the optical path loss, and the maximum error is only 1.2%. Finally, the reflectivity of the VBG measured by the calibrated system is 30.84%, which is basically consistent with the multi-physical field simulation results, showing a deviation as low as 0.85%. The experimental results fully verify the availability and high measurement accuracy of the reflectivity measurement system. This research work provides a new method for testing the characteristics of micron-scale grating size VBGs. Additionally, this work combines optical characterization methods to verify the good effect of VBG preparation technology, providing core technical support for the realization of subsequent homogeneous integrated Fabry–Perot cavity sensors. Furthermore, it holds important application value in the field of optical sensing and micro-nano integration. Full article
