Cantilevered unstable rock masses constitute a prevalent geological hazard, with their stability intrinsically governed by the depth of trailing edge cracks. Traditional stability assessment methods, which largely rely on static calculations or displacement monitoring, often suffer from poor timeliness and insufficient early warning capabilities. To address these limitations, this study employs the Extended Finite Element Method (XFEM) to simulate the natural crack propagation trajectory and investigate the associated dynamic response characteristics under loading. The simulation results demonstrate that XFEM effectively captures the natural “vertical-to-oblique” fracture morphology, overcoming the limitations of pre-defined crack models. A critical correlation is established between crack evolution and natural frequency: the first-order natural frequency exhibits a staged decline, characterized by a precipitous drop of approximately 7 Hz during the late stage of fracture development (80–97% depth). Consequently, a “crack evolution–frequency response” model is proposed. This model confirms that natural frequency is a significantly more sensitive indicator of internal damage than displacement, providing a novel theoretical foundation and technical pathway for the early identification and dynamic evaluation of rock mass stability. Full article

As the core load-transfer medium in bonded structures, the adhesive layer critically governs overall reliability, with Mode I fracture representing its dominant failure mechanism under tensile loading. This study systematically compares the eXtended Finite Element Method (XFEM) and its two coupled variants—the XFEM-Cohesive Zone Model (CZM) and XFEM-Virtual Crack Closure Technique (VCCT)—in simulating Mode I fractures of adhesive joints. Key comparisons include predictions of stress distribution, load-transfer evolution, and crack propagation paths, all validated through Double Cantilever Beam (DCB) simulations and experiments. Results show that standard XFEM accurately predicts initial stiffness (error < 8%) but overestimates peak load by 10.7%. XFEM-CZM maintains errors below 8% for both stiffness and peak load, while XFEM-VCCT achieves exceptional peak-load accuracy (error < 1%) but overestimates stiffness. In crack evolution, standard XFEM yields an idealized propagation path, whereas the coupled methods reveal a distinct three-stage process. Stress/strain fields in standard XFEM remain stable during propagation, while the coupled approaches exhibit interfacial irregularities before crack arrival, followed by tip concentration and band-like transfer during stable growth. Each method offers distinct advantages, underscoring that selection should align with specific research objectives and modeling requirements. Full article

Combining with the wheel–rail rolling contact models and extended finite element method (XFEM), this study systematically analyses the influence of wheel thermal expansion induced by braking thermal load on the tread cracking behavior of railway freight trains during the emergency braking process. Unlike the well-documented effect of material softening at elevated temperatures, the key contribution of this work lies in identifying and elucidating the dominant role of thermally induced geometrical changes in the contact conditions. The results demonstrate that wheel thermal expansion significantly alters the shape of the contact spot and the stress distribution, thereby reconstructing the mechanical driving force at the crack tip. Specifically, thermal expansion effectively suppresses Mode I cracking. Although it slightly reduces the magnitude of ΔK_II, the primary and critical outcome is a distinct shift in the location of the maximum ΔK_II from the deep interior of the crack to its superficial outer tip, driven by the altered contact geometry. This shift intensifies the crack propagation trend along the length direction near the surface. Therefore, although the nominal contact stress decreases when considering braking heat, the risk of surface-initiated damage increases, which needs to be paid attention to during operations and maintenance. Full article

Accurately predicting stress concentration factors (SCFs) is essential for assessing the structural integrity of components containing holes or discontinuities, especially in multi-material systems. Traditional Finite Element Method (FEM) models often require substantial mesh refinement near geometric discontinuities, whereas the Extended Finite Element Method (XFEM) allows discontinuities to be represented independently of the mesh through enrichment functions. This study provides a comparative assessment of FEM and XFEM for evaluating SCFs around a circular hole located near a bi-material interface. Both methods are implemented in MATLAB R2019a using the level-set approach to describe the hole. The displacement and stress fields obtained from FEM and XFEM are compared, followed by an evaluation against an established analytical reference solution. The findings show that while both methods reproduce global fields with good agreement, differences arise in the accuracy of SCF prediction. These results highlight the conditions under which XFEM may offer advantages over conventional FEM when modeling discontinuities in heterogeneous materials. Full article

Under long-term dynamic water pressure, weld zones in vertical shaft pressure-bearing steel pipes are prone to cracking induced by welding residual stresses (WRSs), which may further propagate and threaten structural safety. This study investigates the effects of initial crack angle and position on crack tip stress and propagation path under the influence of WRSs. Using the XFEM combined with a DFLUX-based thermomechanical simulation, a numerical model of crack growth in vertical shaft steel pipes is developed. Results indicate that increasing the initial crack angle raises the stress intensity factor, while crack-tip residual stress initially increases and then decreases, reaching a maximum value of 457.9 MPa when the initial crack angle is 30°. When WRSs are considered, localized stress concentration at the crack tip intensifies, leading to higher stress, stress amplitude, and stress intensity factor, with the amplitude peaking at 365.49 MPa. Moreover, cracks located outside the weld exhibit higher stress intensity factors than those inside. Overall, WRS, crack angle, and crack location all contribute to crack propagation, with crack angle being the dominant factor. Cracks within welds and oriented between 15° and 45° exhibit a significantly higher likelihood of propagation. These findings aid in identifying hazardous crack scenarios and provide guidance for the operation and monitoring of pressure pipelines. Full article

This study proposes a hybrid computational framework that integrates the Extended Finite Element Method (XFEM), Artificial Neural Network (ANN), and Monte Carlo simulation to evaluate the fatigue crack propagation and reliability of reinforced concrete (RC) bridge decks. First, XFEM was employed to simulate crack initiation and propagation under cyclic loading based on the statistical distributions of the Paris law parameters C and m. The fatigue life data generated from these simulations were used to train a multilayer feedforward ANN optimized with the Adam algorithm and the ReLU activation function. The trained network achieved a high prediction accuracy (R² = 0.99, MAPE = 0.977%) and demonstrated strong generalization capability for predicting the XFEM-derived fatigue life. Subsequently, 10,000 Monte Carlo samples of C and m were analyzed using the trained ANN to perform probabilistic fatigue life assessment. The results revealed a nonlinear degradation pattern in reliability: the structural reliability remained high at low fatigue cycles but decreased sharply once a critical threshold of approximately 1.45 × 10⁹ cycles was reached. When actual bridge traffic was considered, the deck maintained a reliability of 0.99 after 23 years and 0.95 after 67 years of service. Compared with the XFEM, the ANN-based prediction improved computational efficiency by more than 10⁴ times while maintaining satisfactory accuracy. The proposed hybrid framework effectively combines deterministic simulation, probabilistic analysis, and data-driven modeling, providing a rapid and reliable approach for predicting fatigue life and evaluating the reliability of concrete bridge structures. Full article

This study investigates the fatigue behavior of pressurized pipelines under cyclic internal pressure, focusing on the influence of elastic and elastoplastic material responses on crack propagation. The Extended Finite Element Method (XFEM), implemented in Abaqus 2002, is used to model crack initiation and propagation without remeshing. The analysis first considers elastic behavior to estimate maximum stresses and stress intensity factors (SIFs) at crack tips, and then introduces an elastoplastic model to account for local plastic deformation in regions of high stress concentration, improving fatigue life prediction accuracy. The numerical approach is coupled with the Basquin and Manson–Coffin fatigue models and supported by a test matrix varying internal pressure amplitudes to systematically evaluate parameter interactions. The novelty of this work lies in the systematic study of the interaction between internal pressure, material nonlinearity, plastic zone evolution, crack closure, and fatigue life estimation. Unlike previous studies, the analysis includes detailed comparisons with analytical predictions and validated experimental data from the literature, ensuring the reliability of the model. The results show significant differences between the elastic and elastoplastic regimes: under 12 MPa, the maximum stress reached 352.5 MPa and fatigue life was 1639 cycles, while under 28 MPa, stress increased to 850 MPa and life dropped to a single cycle. These findings highlight the critical role of plastic deformation in fatigue crack growth and demonstrate that neglecting plasticity can greatly overestimate pipeline durability, providing a more realistic assessment of structural integrity in pressurized systems. Full article

Cracking in asphalt layers of rigid–flexible composite pavements under coupled ambient temperature fields and traffic loading represents a critical failure mode. Traditional models based on uniform temperature assumptions inadequately capture the crack propagation mechanisms. This study developed a thermo-mechanical coupling model that incorporates realistic temperature-modulus gradients to analyze the compressive-shear behavior and simulate crack propagation using the extended finite element method (XFEM) coupled with a modified Paris’ law. Key findings reveal that the asphalt layer exhibits a predominant compressive-shear stress state; increasing the base modulus from 10,000 MPa to 30,000 MPa reduces the maximum shear stress by 22.8% at the tire centerline and 8.6% at the edge; thermal stress predominantly drives crack initiation, whereas vehicle loading governs the propagation path; field validation via cored samples confirms inclined top-down cracking under thermo-mechanical coupling; and the fracture energy release rate (G_f) reaches a minimum of 155 J·m⁻² at 14:00, corresponding to a maximum fatigue life of 32,625 cycles, and peaks at 350 J·m⁻² at 01:00, resulting in a reduced life of 29,933 cycles—reflecting a 9.0% temperature-induced fatigue life variation. The proposed model, which integrates non-uniform temperature gradients, offers enhanced accuracy in capturing complex boundary conditions and stress states, providing a more reliable tool for durability design and assessment of composite pavements. Full article

This study investigates the structural and fracture behavior of an automotive exhaust manifold with a predefined semi-elliptical surface crack under realistic thermo-mechanical loading. A combined FEM–XFEM workflow was applied; the FEM identified the critical stress concentration zone, where the maximum Von Mises stress reached 165.6 MPa at 700 °C, and the XFEM was used to model crack growth with a refined mesh. The computed Mode I stress intensity factors ranged from 21 to 24 MPa√m, remaining below the temperature-dependent fracture toughness of AISI 321 stainless steel, which confirmed stable crack behavior under service conditions. Fatigue life was assessed using the Smith–Watson–Topper (SWT) parameter. Two scenarios were considered: a quasi-pulsating case, giving a predicted life of 3.8 × 10⁸ cycles, and a fully reversed case, reducing the life to 6.7 × 10⁷ cycles. These results confirm that the manifold operates within the high-cycle fatigue regime, while also demonstrating the strong sensitivity of life predictions to the applied stress ratio. This combined FEM–XFEM methodology provides a reliable numerical framework for assessing crack driving forces and guiding durability-based design of exhaust manifolds. Full article

Natural cracks are prone to form in toppling deformed rock masses during the toppling process, and these cracks are likely to undergo hydraulic fracturing failure under the action of high water head. This paper leverages the advantage of the extended finite element method (XFEM) in simulating crack propagation, considers the effect of water pressure on the crack surface, conducts numerical simulation and analysis on the hydraulic fracturing of cracks in toppling deformed rock masses, and studies the influences of different crack lengths, rock formation dip angles and crack surface water pressures on crack propagation. The main conclusions are as follows: (1) After hydraulic fracturing occurs in the rock mass, with the continuous rise in the water level, the crack propagation rate is slow first and then fast. When the water pressure is low, microcracks extend slowly; when the water pressure reaches a certain level, the rock formation cracks expand rapidly and eventually fracture. (2) Under the same water pressure, rock formations with longer initial crack lengths are more prone to hydraulic fracturing, and their cracks expand faster; rock formations with a dip angle of 45° are more likely to undergo hydraulic fracturing than those with other dip angles, while rock formations with a dip angle close to 90° are hardly susceptible to hydraulic fracturing. (3) The instability failure mechanism of hydraulic fracturing in toppling deformed rock masses is tension shear action. As the fissure water pressure rises, the tensile stress at the crack tip will increase sharply. Once new microcracks appear in the initial crack, it will be in an unstable expansion state. Full article

Voids behind tunnel linings are common hidden defects in underground engineering, leading to reduced structural capacity and potential safety hazards. To address the deficiencies in the understanding of the mechanism and the optimization of design of the existing steel plate reinforcement methods, this study systematically investigates the reinforcement mechanisms and proposes refined design strategies through numerical simulations and experimental validation. First, a comparative analysis of the Concrete Damage Plasticity (CDP) model and the Extended Finite Element Method (XFEM) revealed that the CDP model exhibits superior accuracy and computational efficiency in simulating large-scale void linings. Second, the effectiveness of different reinforcement schemes (chemical anchor bolts alone, structural adhesive alone, and combined systems) was evaluated, demonstrating that structural adhesive dominates stress transfer, while chemical anchor bolts primarily prevent plate detachment. Through further optimization simulations of the steel plate spacing, it was found that a spacing of 0.25 m can balance the reinforcement effect and cost. This spacing restricts the maximum principal stress (1.83 MPa) below the tensile strength of concrete while essentially eliminating damage to the lower surface of the lining. An optimized steel plate reinforcement structure was ultimately proposed. By reducing the number of chemical anchor bolts and decreasing their size (with only M12 chemical anchor bolts arranged at the edges), local damage is minimized while maintaining reinforcement efficiency. The research results provide theoretical support and engineering guidance for the safe repair of tunnel void areas. Full article

This article is devoted to the prediction of the service life of selected structural materials under simulated operating conditions. Special attention is paid to the so-called representative volume element, which characterizes the damage behaviour, since it includes a critical number of microdefects. The overall damage prediction is based on the energy approach, and the development of damage comes from the traction separation laws; the shape of the damage varies for different materials. The calculations were performed using the extended finite element method (XFEM), where several minor modifications were made. This method has been successfully used in many areas of engineering sciences for research, simulation, and prediction of the behaviour of structures. XFEM reformulates the continuous boundary and initial value problems into similar variational forms instead of using the classical forms of differential equations. The simulation of fracture and damage phenomena is presented for two different materials: austenitic steel with a pronounced grain structure under creep (viscous) loading conditions and cement pasta reinforced with metal fibres under conditions of predominantly static loading. Full article

This scoping review paper provides an overview of the evolution, the current stage, and the future prospects of fracture studies on composite laminates. A fundamental understanding of composite materials is presented by highlighting the roles of the fiber and matrix, outlining the applications of various synthetic fibers used in current structural sectors. Challenges posed by interlaminar delamination, one of the critical failure modes, are highlighted. This paper systematically discusses the fracture behavior of these laminates under mixed-mode and complex loading conditions. Standardized fracture toughness testing methods, including Mode I Double Cantilever Beam (DCB), Mode II End-Notched Flexure (ENF) and Mixed-Mode Bending (MMB), are initially discussed, which is followed by a decade-wide chronological analysis of fracture mechanics approaches. Key advancements, including toughening mechanisms, Cohesive Zone Modeling (CZM), Virtual Crack Closure Technique (VCCT), Extended Finite Element Method (XFEM) and Digital Image Correlation (DIC), are analyzed. The review also addresses recent trends in fracture studies, such as bio-inspired architecture, self-healing systems, and artificial intelligence in fracture predictions. By mapping the trajectory of past innovations and identifying unresolved challenges, such as scale integration, dataset standardization for AI, and manufacturability of advanced architectures, this review proposes a strategic research roadmap. The major goal is to enable unified multi-scale modeling frameworks that merge physical insights with data learning, paving the way for next-generation composite laminates optimized for resilience, adaptability, and environmental responsibility. Full article

This study resolves the long-standing question of the origin of bilinear Low Cycle Fatigue (LCF) behavior in Ti-6Al-4V using a high-fidelity CPFEM-XFEM framework. We identify that the fundamental origin lies in a fundamental shift in the efficiency of converting macroscopic energy dissipation into microscopic damage. This energetic efficiency is directly governed by the evolution of plastic strain heterogeneity (quantified by the Coefficient of Variation, CV). At low strain amplitudes, high strain localization (high CV) creates a highly efficient “energy funnel,” concentrating dissipated energy into a few critical grains. This manifests physically as a single-crack failure mode, where the crack initiation phase is prolonged, consuming ~80% of the total fatigue life. Conversely, at high strain amplitudes, deformation homogenization (low CV) leads to inefficient, diffuse energy dissipation across many grains. The material must therefore activate a more drastic failure mechanism—multi-site crack initiation and coalescence—to accumulate sufficient damage, reducing the initiation phase to just ~45% of the total life. Therefore, the bilinear C-M curve is the macroscopic signature of this transition from an energetically efficient, localized damage mode to an inefficient, distributed one. This work provides a quantitative, mechanism-based framework for understanding and predicting the complex fatigue behavior of advanced metallic materials. Full article

Horizontal well fracturing is vital for low-permeability tight oil reservoirs, but multi-fracture effectiveness is hampered by stress shadowing and fluid-rock interactions, particuarly in optimizing fracture geometry and conductivity under different sequencing strategies. While previous studies have addressed aspects of pore pressure and stress effects, a comprehensive comparison of sequencing strategies using fully coupled models capturing the intricate seepage–stress–damage interactions remains limited. This study employs a novel 2D fully coupled XFEM model to quantitatively evaluate three fracturing approaches: simultaneous, sequential, and alternating. Numerical results demonstrate that sequential and alternating strategies alleviate stress interference, increasing cumulative fracture length by 20.6% and 26.1%, respectively, versus conventional simultaneous fracturing. Based on the research findings, fracture width reductions are 30.44% (simultaneous), 18.78% (sequential), and 7.21% (alternating). As fracture width directly governs conductivity—the critical parameter determining hydrocarbon flow efficiency—the alternating strategy’s superior width preservation (92.79% retention) enables optimal conductivity design. These findings provide critical insights for designing fracture networks with targeted dimensions and conductivity in tight reservoirs and offer a practical basis to optimize fracture sequencing design. Full article
