This study investigates the mechanical behaviour of timber–concrete composite (TCC) floor members with an innovative adhesive connection reinforced by granite chips, glass fibre yarn net in the epoxy adhesive layer, and polypropylene (PP) fibres in the concrete layer. Laboratory tests involved three groups of specimens subjected to three-point bending over a span of 500 mm with specimen lengths of 550 mm. Group A specimens exhibited crack initiation at approximately 8 kN and partial disintegration at an average load of 11.17 kN, with maximum vertical displacements ranging from 1.7 to 2.5 mm at 8 kN load, increasing rapidly to 4.3 to 5 mm post-cracking. The addition of reinforcing fibres decreased the brittleness of the adhesive connection and improved load-bearing capacity. Finite element modeling using the newly developed Verisim4D software (2025 v 0.6) and analytical micromechanics approaches demonstrated satisfactory accuracy in predicting the composite behavior. This research highlights the potential of reinforcing the adhesive layer and concrete with fibres to enhance the ductility and durability of TCC members under flexural loading. Full article

Timber–concrete composite (TCC) floors are gaining popularity in sustainable construction due to their enhanced stiffness and structural efficiency. However, excessive vibrations, particularly those induced by human activity, pose significant challenges to occupant comfort and structural integrity. This study investigates the application of Tuned Mass Dampers (TMDs) to mitigate vibrations in TCC floors, with a focus on enhancing damping performance through the incorporation of pre-strained Shape Memory Alloys (SMAs) (Kellogg’s Research Labs, New Boston, NH, USA). A novel pre-strained SMA–TMD system was designed and experimentally tested to evaluate its effectiveness in vibration control under various loading conditions. The results demonstrate that pre-straining significantly increases the damping ratio of the SMA–TMD, improving its vibration mitigation capability. Compared to non-pre-strained SMA–TMD, the pre-strained SMA–TMD system exhibited superior adaptability and robustness in reducing floor vibrations, achieving a peak acceleration reduction of up to 49.91%. These findings provide valuable knowledge into the development of advanced damping solutions for timber floors, contributing to the broader application of vibration control strategies in sustainable and high-performance building systems. Full article

Due to the low density and stiffness of wood, traditional timber floor systems are prone to producing large vibration responses. By combining timber beams with concrete floors, timber–concrete composite (TCC) floor systems show stronger bearing capacity, higher bending stiffness, and better thermal and sound insulation behaviors when compared with traditional timber floor systems. In this study, the vibration performance of TCC beams with crossed inclined coach screw connectors was investigated using dynamic tests. The influence of the screw diameters and slab dimensions on the dynamic performance of the composite beams was evaluated. The test results demonstrated that TCC beams show good dynamic performance when used as a floor component and meet the preliminary requirements of floor vibration comfort for fundamental frequency. The fundamental frequency and damping ratio of TCC beams decreases with the increase in slab dimensions. The bending stiffness and natural frequency of TCC beams decrease smoothly when reducing the screw diameter from 16 to 12 mm. Additionally, two theoretical models were used to predict the natural frequencies of the TCC beams, and the predicted values show good consistency with the measured ones. Full article

In recent years, there has been an increasing interest in timber–concrete composite (TCC) floors as a sustainable structural solution. Until now, only a few studies have investigated the demounting of TCC floors, which is essential to increase sustainability and improve the end-of-life environmental benefits of a floor system. This study investigates an innovative and straightforward demountable TCC slab that has notched and bolted connections. Six downscaled slabs are tested under four-point bending. The results show that the slab system has high composite action with an efficiency of 0.73. A three-dimensional finite element model is developed and calibrated with the experimental result. The model is used to study the influence of several parameters, such as the shape and dimensions of the notch as well as the bolt location on the load-bearing capacity and the load-deflection behavior of the slab. The results show that the failure tends to be more ductile when a birdsmouth-shaped notch is used, and the bolt is placed within the notch. Moreover, the load-bearing capacity of the shear connection increases by increasing the distance of the notch to the end of the slab and using a triangular notch. Full article

Floor vibration, although not a safety concern, is a prevalent performance complaint in multi-story structures. With the increasing use of mass timber construction, various types of long-span timber floors (LSTFs), including plain cross-laminated timber (CLT), CLT with secondary beams (ribbed-deck), and hybrid systems such as timber–concrete composite (TCC) and CLT on-steel-support beams, are gaining popularity. However, due to limited knowledge regarding their vibration characteristics and acceptance criteria, these construction types are often overlooked during the design stage by architects, engineers, and builders. Existing standards and guidelines primarily calibrated for steel and concrete floors lack a validated and calibrated method for evaluating the vibration performance of LSTFs. Nonetheless, it is essential for structural engineers to address vibration concerns during the design stage and potentially investigate excessive vibration in existing buildings, providing mitigation solutions. This article provides a comprehensive overview, discussion, and analysis of the measurement, analysis, design, perception, and acceptability of vibration of timber floors as outlined in international standards and commonly used guidelines. Experimental and theoretical case studies, including vibration measurements of a CLT floor and a comparison of vibration acceptability in lightweight timber floors using different methods, are reported. The results highlight discrepancies between simplified equation calculations and modal analysis observations, underscoring the limitations of relying solely on simplified equations. Furthermore, it is observed that current modal superposition methods tend to be conservative in predicting floor acceleration and velocity responses. Recommendations are provided for future research in the field to enhance floor vibration assessment techniques, aiming for improved design optimization and occupant comfort. Full article

Design for deconstruction (DfD) considers the end-of-life scenario of buildings at an early design stage to ensure that these buildings (or parts of the buildings) can be deconstructed without unproportional effort and material loss. After deconstruction, the elements or materials can be used for future purposes such as reusing (preferably), remanufacturing, or recycling. This opinion paper is aimed to advocate for DfD in timber–concrete composite (TCC) floors as it represents an important contribution toward circular economy design and creates a more sustainable built environment. Different end-of-life scenarios for TCC floors according to their original design and connection type were initially explored. Existing deconstructable connection systems that could enable DfD in TCC floors were reviewed. Furthermore, potential challenges relating to the implementation of DfD in TCC floors are briefly highlighted. Finally, a discussion around the outlook and actions that might be needed to address some of the identified challenges is provided. This paper proposes directions for future developments and contributes to the understanding and promotion of DfD in TCC floors with an emphasis on deconstructable connectors that can enable material recovery and reuse as the preferred end-of-life scenario. Full article

Pre-weaned dairy calves are very susceptible to disease in the first months of life due to having a naïve immune system and because of the numerous physiological stressors they face. Hygiene management is a key element in minimizing enteric disease risk in calves by reducing their exposure to pathogens. Samples of milk, concentrate feed and drinking water, boot swabs of bedding and swabs of feed equipment were collected from 66 dairy farms as part of a survey of calf rearing practice and housing design. All the samples were cultured to determine total viable counts (TVC), total coliforms (TCC) and Escherichia coli as indicators of hygiene. Target ranges for levels of TVC, TCC and E. coli were defined from the literature and the sample results compared against them. The TVC targets in milk, MR and water were <4.0 log₁₀ CFU/mL. TCC and E. coli targets of <1.1 log₁₀ CFU/mL (the detection limit) were used for milk, MR, concentrate feed and feeding equipment. For water, the TCC and E. coli targets were <1.0 log₁₀ CFU/100 mL. The targets used for bedding boot swabs were <6.3 log₁₀ TVC CFU/mL and <5.7 log₁₀ TCC or E. coli CFU/mL. Farm management factors were included as fixed effects in a generalized linear mixed model to determine the probability of samples being within each hygiene indicator target range. Milk replacer samples obtained from automatic feeders were more likely to be within the TVC target range (0.63 probability) than those prepared manually (0.34) or milk samples taken from the bulk tank (0.23). Concentrate feed samples taken from buckets in single-calf pens were more likely to have E. coli detected (0.89) than samples taken from group pen troughs (0.97). A very small proportion of water samples were within the indicator targets (TVC 9.8%, TCC 6.0%, E. coli 10.2%). Water from self-fill drinkers had a lower likelihood of being within the TVC target (0.03) than manually filled buckets (0.14), and water samples from single pens were more likely to be within TCC target ranges (0.12) than those from group pens (0.03). However, all self-fill drinkers were located in group pens so these results are likely confounded. Where milk feeders were cleaned after every feed, there was a greater likelihood of being within the TVC target range (0.47, compared with 0.23 when not cleaned after every feed). Detection of coliforms in milk replacer mixing utensils was linked with reduced probability of TVC (0.17, compared with 0.43 when coliforms were not detected) and TCC (0.38, compared with 0.62), which was within target in feeders. Key factors related to increased probability of bedding samples being within TCC target range were use of group calf pens (0.96) rather than single-calf pens (0.80), use of solid floors (0.96, compared with 0.76 for permeable floors) and increased space allowance of calves (0.94 for pens with ≥2 m²/calf, compared with 0.79 for pens with <2 m²/calf). Bedding TVC was more likely to be within the target range in group (0.84) rather than in single pens (0.66). The results show that hygiene levels in the calf rearing environment vary across farms and that management and housing design impact hygiene. Full article

The solution of timber-to-concrete composite (TCC) floors represents a well-established construction technique, which is consistently used for both the retrofitting of existing timber floors and the realization of new diaphragms. The success of TCC floors relies on the intrinsic effectiveness in increasing both the in-plane (for lateral loads) and the out-of-plane (for gravity loads) performance of existing timber floors. As a widespread retrofit intervention, it is common to use existing floorboards as a permanent formwork for the concrete pouring. Rather few research studies of literature, in this regard, highlighted an overall reduction of load capacity and slip modulus due to the presence of such an interposed interlayer. In this regard, the present paper focuses on the use of screws as efficient mechanical connectors and analyses different configurations and inclination angles for their arrangement. This main goal is achieved by performing parametric Finite Element (FE) numerical analyses, validated on previous experimental tests, in order to specifically investigate the influence of the in-between interlayer, as well as the role of friction phenomena and the influence of the test setup and experimental protocol to achieve the basic mechanical performance indicators. Full article

In the construction of modern multi-storey mass timber structures, a composite floor system commonly specified by structural engineers is the timber–concrete composite (TCC) system, where a mass timber beam or mass timber panel (MTP) is connected to a concrete slab with mechanical connectors. The design of TCC floor systems has not been addressed in timber design standards due to a lack of suitable analytical models for predicting the serviceability and safety performance of these systems. Moreover, the interlayer connection properties have a large influence on the structural performance of a TCC system. These connection properties are often generated by testing. In this paper, an analytical approach for designing a TCC floor system is proposed that incorporates connection models to predict connection properties from basic connection component properties such as embedment and withdrawal strength/stiffness of the connector, thereby circumventing the need to perform connection tests. The analytical approach leads to the calculation of effective bending stiffness, forces in the connectors, and extreme stresses in concrete and timber of the TCC system, and can be used in design to evaluate allowable floor spans under specific design loads and criteria. An extensive parametric analysis was also conducted following the analytical procedure to investigate the TCC connection and system behaviour. It was observed that the screw spacing and timber thickness remain the most important parameters which significantly influence the TCC system behaviour. Full article

Cross-laminated timber (CLT) slabs in residential buildings need additional weight, e.g., in the form of screeds or gravel layers, to fulfill the criterion for the highest impact-sound class. The additional mass is, however, not exploited for the load bearing behavior, but adds additional weight and leads to an increased height of the floor construction. In this study, such a CLT floor construction with a construction height of 380 mm is compared with a composite slab consisting of a CLT plate with a concrete layer on top with a floor construction height of 330 mm. The timber concrete composite (TCC) slab has a different creep behavior than the CLT slab. Thus, the development of the time-dependent deflections over the service life are of interest. A straightforward hybrid approach is developed, which exploits advanced multiscale-based material models for the individual composite layers and a standardized structural analysis method for the structural slab to model its linear creep behavior. The introduced approach allows to investigate load redistribution between the layers of the composite structure and the evolution of the deflection of the slab during the service life. The investigated slab types show a similar deflection after 50 years, while the development of the deflections over time are different. The CLT slab has a smaller overall stiffness at the beginning but a smaller decrease in stiffness over time than the investigated TCC slab. Full article

Triclocarban (TCC), a broad-spectrum lipophilic antimicrobial agent, is a diarylurea derivative that has been used for more than 60 years as a major ingredient of toys, clothing, food packaging materials, food industry floors, medical supplies and especially of personal care products, such as soaps, toothpaste and shampoo. In September 2016, the U.S. FDA banned nineteen antimicrobial ingredients, including TCC, in over-the-counter consumer antiseptic wash products, due to their toxicity. Withdrawal of TCC has prompted efforts to search for new antimicrobial compounds. In this paper, we present the synthesis and biological evaluation, as antibiotic and non-cytotoxic agents, of a series of diarylureas, analogues of TCC. These compounds are characterized by an intriguingly simple chemistry and can be easily synthesized. Among the synthesized compounds, 1ab and 1bc emerge as the most interesting compounds as they show the same activity of TCC (MIC = 16 µg/mL) against Staphylococcus aureus, and a higher activity than TCC against Enterococcus faecalis (MIC = 32 µg/mL versus MIC = 64 µg/mL). Moreover, 1ab and 1bc show no cytotoxicity towards the human mammary epithelial cells MCF-10A and embryonic kidney epithelial cells Hek-293, in opposition to TCC, which exhibits a marked cytotoxicity on the same cell lines and shows a good antitumor activity on a panel of cell lines tested. Full article

Timber-concrete composite (TCC) solutions are not a novelty. They were scientifically referred to at the beginning of the 20th century and they have proven their value in recent decades. Regarding a TCC floor at the design stage, there are some assumptions, at the standard level, concerning the action of concentrated loads which may be far from reality, specifically those associating the entire load to the beam over which it is applied. This naturally oversizes the beam and affects how the load is distributed transversally, affecting the TCC solution economically and mechanically. Efforts have been made to clarify how concentrated loads are distributed, in the transverse direction, on TCC floors. Real-scale floor specimens were produced and tested subjected to concentrated (point and line) loads. Moreover, a Finite Element (FE)-based model was developed and validated and the results were collected. These results show that the “loaded beam” can receive less than 50% of the concentrated point load (when concerning the inner beams of a medium-span floor, 4.00 m). Aiming at reproducing these findings on the design of these floors, a simplified equation to predict the percentage of load received by each beam as a function of the floor span, the transversal position of the beam, and the thickness of the concrete layer was suggested. Full article
