Search Results (11)

This paper elaborates on the proposal of a new analytical model for a non-ballistic transport scenario for Schottky barrier carbon nanotube field effect transistors (SB-CNTFETs). The non-ballistic transport scenario depends on incorporating the effects of acoustic phonon (A-Ph) and optical phonon (O-Ph) electron scattering mechanisms. The analytical model is rooted in the solution of the Landauer integral equation, which is modified to account for non-ballistic transport through a set of approximations applied to the Wentzel–Kramers–Brillouin (WKB) transmission probability and the Fermi–Dirac distribution function. Our proposed model was simulated to evaluate the total current and transconductance, considering scenarios both with and without the electron–phonon scattering effect. The simulation results revealed a substantial decrease of approximately 78.6% in both total current and transconductance due to electron–phonon scattering. In addition, we investigated the impact of acoustic phonon (A-Ph) and optical phonon (O-Ph) scattering on the drain current under various conditions, including different temperatures, gate lengths, and nanotube chiralities. This comprehensive analysis helps in understanding how these parameters influence device performance. Compared with experimental data, the model’s simulation results demonstrate a high degree of agreement. Furthermore, our fully analytical model achieves a significantly faster runtime, clocking in at around 2.726 s. This validation underscores the model’s accuracy and reliability in predicting the behavior of SB-CNTFETs under non-ballistic conditions. Full article

Schottky barrier thin-film transistors (SBTFTs) are promising for low-power electronics due to advantages such as low saturation voltage and high stability. In this study, we developed a high-performance bilayer IGZO SBTFT by combining a 4.7 nm atomic layer deposition (ALD) IGZO layer with an 11.8 nm sputtering IGZO layer, using platinum (Pt) and molybdenum (Mo) electrodes. The device exhibits dual-mode operation. In Schottky barrier TFT (SB-TFT) mode (Pt as source), the bilayer structure reduces defect density, achieving a very low saturation voltage (~0.4 V), high field-effect mobility (up to 20 cm²/V·s), and enhanced stability under stress conditions, including positive/negative bias and negative illumination. In quasi-Ohmic TFT (QO-TFT) mode (Pt as drain), the device retains conventional saturation behavior in output characteristics while delivering similar mobility and robust stability. This work provides a novel bilayer SBTFT design with dual functionality, enabling a higher current drive, improved stability, and flexibility for energy-efficient applications. Full article

This study aimed to explore the impact of varying amounts of added Au (0.5 to 2 wt.%) and the structural characteristics of anatase TiO₂ supports (nanoparticles (TP, S_BET = 88 m²/g) and nanorods (TR, S_BET = 105 m²/g)) on the catalytic efficiency of TiO₂+Au catalysts in eliminating the herbicide glyphosate from aqueous solutions via the catalytic wet air oxidation (CWAO) process. The investigation was conducted using a continuous-flow trickle-bed reactor. Regardless of the TiO₂ support and the amount of Au added, the addition of Au has a positive effect on the glyphosate degradation rate. Regarding the amount of Au added, the highest catalytic activity was observed with the TP + 1% Au catalyst, which had a higher Schottky barrier (SB) than the TP + 2% Au catalyst, which helped the charge carriers in the TiO₂ conduction band to increase their reduction potential by preventing them from returning to the Au. The role of glyphosate degradation product adsorption on the catalyst surface is crucial for sustaining the long-term catalytic activity of the investigated TiO₂+Au materials. This was particularly evident in the case of the TR + 1% Au catalyst, which had the highest glyphosate degradation rate at the beginning of the CWAO experiment, but its catalytic activity then decreased over time due to the adsorption of glyphosate degradation products, which was favoured by the presence of strong acidic sites. In addition, the TR + 1% Au solid had the smallest average Au particle size of all analyzed materials, which were more easily deactivated by the adsorption of glyphosate degradation products. The analysis of the degradation products of glyphosate shows that the oxidation of glyphosate in the liquid phase involves the rupture of C–P and C–N bonds, as amino-methyl-phosphonic acid (AMPA), glyoxylic acid and sarcosine were detected. Full article

Ultraviolet (UV) photodetectors are key devices required in the industrial, military, space, environmental, and biological fields. The Schottky barrier (SB)-MOSFET, with its high hole and electron barrier, and given its extremely low dark current, has broad development prospects in the optoelectronics field. We analyze the effects of trap states on the output characteristics of an inversion mode n-channel GaN SB-MOSFET using TCAD simulations. At the oxide/GaN interface below the gate, it was demonstrated that shallow donor-like traps were responsible for degrading the subthreshold swing (SS) and off-state current density (I_off), while deep donor-like traps below the Fermi energy level were insignificant. In addition, shallow acceptor-like traps shifted the threshold voltage (V_t) positively and deteriorated the SS and on-state current density (I_on), while deep acceptor-like traps acted on a fixed charge. The output characteristics of the GaN SB-MOSFET were related to the resistive GaN path and the tunneling rate due to the traps at the metal (source, drain)/GaN interface. For the UV responses, the main mechanism for the negative V_t shift and the increases in the I_on and spectral responsivity was related to the photo-gating effect caused by light-generated holes trapped in the shallow trap states. These results will provide insights for UV detection technology and for a high-performance monolithic integration of the GaN SB-MOSFET. Full article

This study proposes a bidirectional chemical sensor platform using ambipolar double-gate ion-sensitive field-effect transistors (ISFET) with microwave-assisted Ni-silicide Schottky-barrier (SB) source and drain (S/D) on a fully depleted silicon-on-insulator (FDSOI) substrate. The microwave-assisted Ni-silicide SB S/D offer bidirectional turn-on characteristics for both p- and n-type channel operations. The p- and n-type operations are characterized by high noise resistance as well as improved mobility and excellent drift performance, respectively. These features enable sensing regardless of the gate voltage polarity, thus contributing to the use of detection channels based on various target substances, such as cells, antigen-antibodies, DNA, and RNA. Additionally, the capacitive coupling effect existing between the top and bottom gates help achieve self-amplified pH sensitivity exceeding the Nernst limit of 59.14 mV/pH without any additional amplification circuitry. The ambipolar FET sensor performance was evaluated for bidirectional electrical characteristics, pH detection in the single-gate and double-gate modes, and reliability in continuous and repetitive operations. Considering the excellent characteristics confirmed through evaluation, the proposed ambipolar chemical sensor platform is expected to be applicable to various fields including biosensors. And through linkage with subsequent studies, various medical applications and precision detector operations for specific markers will be possible. Full article

In this study, the efficient fabrication of nickel silicide (NiSi_x) Schottky barrier thin-film transistors (SB-TFTs) via microwave annealing (MWA) technology is proposed, and complementary metal-oxide-semiconductor (CMOS) inverters are implemented in a simplified process using ambipolar transistor properties. To validate the efficacy of the NiSi_x formation process by MWA, NiSi_x is also prepared via the conventional rapid thermal annealing (RTA) process. The Rs of the MWA NiSi_x decreases with increasing microwave power, and becomes saturated at 600 W, thus showing lower resistance than the 500 °C RTA NiSi_x. Further, SB-diodes formed on n-type and p-type bulk silicon are found to have optimal rectification characteristics at 600 W microwave power, and exhibit superior characteristics to the RTA SB-diodes. Evaluation of the electrical properties of NiSi_x SB-TFTs on excimer-laser-annealed (ELA) poly-Si substrates indicates that the MWA NiSi_x junction exhibits better ambipolar operation and transistor performance, along with improved stability. Furthermore, CMOS inverters, constructed using the ambipolar SB-TFTs, exhibit better voltage transfer characteristics, voltage gains, and dynamic inverting behavior by incorporating the MWA NiSi_x source-and-drain (S/D) junctions. Therefore, MWA is an effective process for silicide formation, and ambipolar SB-TFTs using MWA NiSi_x junctions provide a promising future for CMOS technology. Full article

Problems with doping in nanoscale devices or low temperature applications are widely known. Our approach to replace the degenerate doping in source/drain (S/D)-contacts is silicon nitride interface engineering. We measured Schottky diodes and MOSFETs with very thin silicon nitride layers in between silicon and metal. Al/SiN/p-Si diodes show Fermi level depinning with increasing SiN thickness. The diode fabricated with rapid thermal nitridation at 900 ${}^{\circ }$C reaches the theoretical value of the Schottky barrier to the conduction band ${\mathsf{\Phi }}_{\mathrm{SB},\mathrm{n}}=0.2$ eV. As a result, the contact resistivity decreases and the ambipolar behavior can be suppressed. Schottky barrier MOSFETs with depinned S/D-contacts consisting of a thin silicon nitride layer and contact metals with different work functions are fabricated to demonstrate unipolar behavior. We presented n-type behavior with Al and p-type behavior with Co on samples which only distinguish by the contact metal. Thus, the thermally grown SiN layers are a useful method suppress Fermi level pinning and enable reconfigurable contacts by choosing an appropriate metal. Full article

The transport and synaptic characteristics of the two-terminal Au/Ti/ amorphous Indium-Gallium-Zinc-Oxide (a-IGZO)/thin SiO₂/p⁺-Si memristors based on the modulation of the Schottky barrier (SB) between the resistive switching (RS) oxide layer and the metal electrodes are investigated by modulating the oxygen content in the a-IGZO film with the emphasis on the mechanism that determines the boundary of the abrupt/gradual RS. It is found that a bimodal distribution of the effective SB height (Φ_B) results from further reducing the top electrode voltage (V_TE)-dependent Fermi-level (E_F) followed by the generation of ionized oxygen vacancies (V_O²⁺s). Based on the proposed model, the influences of the readout voltage, the oxygen content, the number of consecutive V_TE sweeps on Φ_B, and the memristor current are explained. In particular, the process of V_O²⁺ generation followed by the Φ_B lowering is gradual because increasing the V_TE-dependent E_F lowering followed by the V_O²⁺ generation is self-limited by increasing the electron concentration-dependent E_F heightening. Furthermore, we propose three operation regimes: the readout, the potentiation in gradual RS, and the abrupt RS. Our results prove that the Au/Ti/a-IGZO/SiO₂/p⁺-Si memristors are promising for the monolithic integration of neuromorphic computing systems because the boundary between the gradual and abrupt RS can be controlled by modulating the SiO₂ thickness and IGZO work function. Full article

The fabrication of a single pixel sensor, which is a fundamental element device for the fabrication of an array-type pixel sensor, requires an integration technique of a photodetector and transistor on a wafer. In conventional GaN-based ultraviolet (UV) imaging devices, a hybrid-type integration process is typically utilized, which involves a backside substrate etching and a wafer-to-wafer bonding process. In this work, we developed a GaN-based UV passive pixel sensor (PPS) by integrating a GaN metal-semiconductor-metal (MSM) UV photodetector and a Schottky-barrier (SB) metal-oxide-semiconductor field-effect transistor (MOSFET) on an epitaxially grown GaN layer on silicon substrate. An MSM-type UV sensor had a low dark current density of 3.3 × 10⁻⁷ A/cm² and a high UV/visible rejection ratio of 10³. The GaN SB-MOSFET showed a normally-off operation and exhibited a maximum drain current of 0.5 mA/mm and a maximum transconductance of 30 μS/mm with a threshold voltage of 4.5 V. The UV PPS showed good UV response and a high dark-to-photo contrast ratio of 10³ under irradiation of 365-nm UV. This integration technique will provide one possible way for a monolithic integration of the GaN-based optoelectronic devices. Full article

Atomically thin molybdenum disulfide (MoS₂), a member of the transition metal dichalcogenide (TMDC) family, has emerged as the prototypical two-dimensional (2D) semiconductor with a multitude of interesting properties and promising device applications spanning all realms of electronics and optoelectronics. While possessing inherent advantages over conventional bulk semiconducting materials (such as Si, Ge and III-Vs) in terms of enabling ultra-short channel and, thus, energy efficient field-effect transistors (FETs), the mechanically flexible and transparent nature of MoS₂ makes it even more attractive for use in ubiquitous flexible and transparent electronic systems. However, before the fascinating properties of MoS₂ can be effectively harnessed and put to good use in practical and commercial applications, several important technological roadblocks pertaining to its contact, doping and mobility (µ) engineering must be overcome. This paper reviews the important technologically relevant properties of semiconducting 2D TMDCs followed by a discussion of the performance projections of, and the major engineering challenges that confront, 2D MoS₂-based devices. Finally, this review provides a comprehensive overview of the various engineering solutions employed, thus far, to address the all-important issues of contact resistance (R_C), controllable and area-selective doping, and charge carrier mobility enhancement in these devices. Several key experimental and theoretical results are cited to supplement the discussions and provide further insight. Full article

Dopant-segregated source/drain contacts in a p-channel Schottky-barrier metal-oxide semiconductor field-effect transistor (SB-MOSFET) require further hole Schottky barrier height (SBH) regulation toward sub-0.1 eV levels to improve their competitiveness with conventional field-effect transistors. Because of the solubility limits of dopants in silicon, the requirements for effective hole SBH reduction with dopant segregation cannot be satisfied using mono-implantation. In this study, we demonstrate a potential solution for further SBH tuning by implementing the dual implantation of boron (B) and aluminum (Al) in combination with microwave annealing (MWA). By using such a method, not only has the lowest hole SBH ever with 0.07 eV in NiSi/n-Si contacts been realized, but also the annealing duration of MWA was sharply reduced to 60 s. Moreover, we investigated the SBH tuning mechanisms of the dual-implanted diodes with microwave annealing, including the dopant segregation, activation effect, and dual-barrier tuning effect of Al. With the selection of appropriate implantation conditions, the dual implantation of B and Al combined with the MWA technique shows promise for the fabrication of future p-channel SB-MOSFETs with a lower thermal budget. Full article
