The conventional Structural Health Monitoring (SHM) framework focuses on individual structures. However, preliminary studies are required at a large territorial scale to effectively identify the most vulnerable elements. This becomes particularly challenging in urban settings, where numerous buildings of varied shapes, ages, and structural conditions are closely spaced from one another. A twofold task is therefore required: the automated identification and differentiation of various structures, coupled with a ranking system based on perceived structural risk, here assumed to be linked to their deformation patterns. It integrates displacement measurements acquired through the Differential Synthetic Aperture Radar Interferometry (DInSAR) technique, specifically employing the full-resolution Small Baseline Subset (SBAS) approach coupled with Hierarchical Clustering. The effectiveness of this method is successfully demonstrated and validated in two selected areas of Rome, Italy, serving as case studies. The results of this vast-area scale monitoring can be used to select the constructions that need a more in-depth assessment. Full article

The goal of this study was to develop a model describing the relationship between the ground-displacement-caused tremors induced by underground mining, and mining and geological factors using the Random Forest Regression machine learning method. The Rudna mine (Poland) was selected as the research area, which is one of the largest deep copper ore mines in the world. The SAR Interferometry methods, Differential Interferometric Synthetic Aperture Radar (DInSAR) and Small Baseline Subset (SBAS), were used in the first case to detect line-of-sight (LOS) displacements, and in the second case to detect cumulative LOS displacements caused by mining tremors. The best-prediction LOS displacement model was characterized by R² = 0.93 and RMSE = 5 mm, which proved the high effectiveness and a high degree of explanation of the variation of the dependent variable. The identified statistically significant driving variables included duration of exploitation, the area of the exploitation field, energy, goaf area, and the average depth of field exploitation. The results of the research indicate the great potential of the proposed solutions due to the availability of data (found in the resources of each mine), and the effectiveness of the methods used. Full article

The Upper Silesian coal basin (USCB) in Poland faces significant ground deformation issues resulting from mining activities conducted without backfill, which can persist for years. These activities can cause damage to surface structures and phenomena such as induced seismicity. Ground deformations can be monitored using differential synthetic aperture radar interferometry (DInSAR). However, various DInSAR approaches have their own advantages and limitations, particularly regarding accuracy and atmospheric filtering. This is especially important for high-frequency displacement signals associated with seismic activity, which can be filtered out. Therefore, this study aims to assess the detectability of mining-induced seismic events using interferometric techniques, focusing on the USCB area. In this experiment, we tested two InSAR approaches: conventional DInSAR without atmospheric filtering and the small baseline subset (SBAS) approach, where the atmospheric phase screen was estimated and removed using high-pass and low-pass filtering. The results indicate that, in most cases, post-seismic ground displacement is not detectable using both methods. This suggests that mining-related seismic events typically do not cause significant post-seismic ground displacement. Out of the 17 selected seismic events, only two were clearly visible in the DInSAR estimated deformation, while for four other events, some displacement signals could neither be definitively confirmed nor negated. Conversely, only one seismic event was clearly detectable in the SBAS displacement time series, with no evidence of induced tremors found for the other events. DInSAR proved to be more effective in capturing displacement signals compared to SBAS. This could be attributed to the small magnitude of the tremors and, consequently, the small size of the seismic sources. Throughout the investigated period, all registered events had magnitudes less than 4.0. This highlights the challenge of identifying any significant influence of low-magnitude tremors on ground deformation, necessitating further investigations. Moreover, SBAS techniques tend to underestimate mining displacement rates, leading to smoothed deformation estimates, which may render post-seismic effects invisible for events with low magnitudes. However, after an in-depth analysis of the 17 seismic events in the USCB, DInSAR was found to be more effective in capturing displacement signals compared to SBAS. This indicates the need for significant caution when applying atmospheric filtering to high-frequency displacement signals. Full article

Tropical peatlands in Southeast Asia have experienced widespread subsidence due to forest clearance and drainage for agriculture, oil palm and pulp wood production, causing concerns about their function as a long-term carbon store. Peatland drainage leads to subsidence (lowering of peatland surface), an indicator of degraded peatlands, while stability/uplift indicates peatland accumulation and ecosystem health. We used the Advanced Pixel System using the Intermittent SBAS (ASPIS-DInSAR) technique with biophysical and geographical data to investigate the impact of peatland drainage and agriculture on spatial patterns of subsidence in Selangor, Malaysia. Results showed pronounced subsidence in areas subjected to drainage for agricultural and oil palm plantations, while stable areas were associated with intact forests. The most powerful predictors of subsidence rates were the distance from the drainage canal or peat boundary; however, other drivers such as soil properties and water table levels were also important. The maximum subsidence rate detected was lower than that documented by ground-based methods. Therefore, whilst the APSIS-DInSAR technique may underestimate absolute subsidence rates, it gives valuable information on the direction of motion and spatial variability of subsidence. The study confirms widespread and severe peatland degradation in Selangor, highlighting the value of DInSAR for identifying priority zones for restoration and emphasising the need for conservation and restoration efforts to preserve Selangor peatlands and prevent further environmental impacts. Full article

Ground deformation is one of the crucial issues threatening many cities in both societal and economic aspects. Interferometric synthetic aperture radar (InSAR) has been widely used for deformation monitoring. Recently, there has been an increasing availability of massive archives of SAR images from various satellites or sensors. This paper introduces Multi-Satellite SBAS that exploits complementary information from different SAR data to generate integrated long-term ground displacement time series. The proposed method is employed to create the vertical displacement maps of Almokattam City in Egypt from 2000 to 2020. The experimental results are promising using ERS, ENVISAT ASAR, and Sentinel-1A displacement integration. There is a remarkable deformation in the vertical direction along the west area while the mean deformation velocity is −2.32 mm/year. Cross-validation confirms that the root mean square error (RMSE) did not exceed 2.8 mm/year. In addition, the research findings are comparable to those of the previous research in the study area. Consequently, the proposed integration method has great potential to generate displacement time series based on multi-satellite SAR data; however, it still requires further evaluation using field measurements. Full article

The analysis of the degree of surface deformation can be a relevant aspect in the study of surface stability conditions, as it provides added value in the construction of risk management plans. This analysis provides the opportunity to establish the behaviors of the internal dynamics of the earth and its effects on the surface as a prediction tool for possible future effects. To this end, this study was approached through the analysis of Synthetic Aperture Radar (SAR) images using the Differential Interferometry (DInSAR) technique, which, in turn, is supported by the Small Baseline Subset (SBAS) technique to take advantage of the orbital separation of the Sentinel-1 satellite images in ascending and descending trajectory between the years 2014 and 2021. As a result, a time series was obtained in which there is a maximum uplift of 117.5 mm (LOS-ascending) or 49.3 mm (LOS-descending) and a maximum subsidence of −86.2 mm (LOS-ascending) or −71.5 mm (LOS-descending), with an oscillating behavior. These deformation conditions are largely associated with the kinematics of the Bucaramanga Fault, but a recurrent action of deep seismic activity from the Bucaramanga Seismic Nest was also observed, generating a surface deformation of ±20 mm for the period evaluated. These deformations have a certain degree of impact on the generation of mass movements, evaluated by the correlation with the LOS-descending images. However, their action is more focused as an inherent factor of great weight, which makes it possible to respond to early care and allows real-time follow-up, giving positive feedback to the system. Full article

Coal mining leads to surface subsidence, landslides, soil erosion and other problems that seriously threaten the life and property safety of residents in mining areas, and it is urgent to obtain mining subsidence information using high-frequency, high-precision and large-scale monitoring methods. Therefore, this paper mainly studies the deformation monitoring of the Datong mining area using Lutan-1 monostatic and bistatic SAR data. Firstly, the latest Lutan-1 bistatic data are used to reconstruct the DSM, and the interferometric calibration method is used to improve the accuracy of the DSM. Then, the surface deformation monitoring of the mining area is implemented by using DInSAR, SBAS-InSAR and Stacking-InSAR with the reconstructed DSM data and Lutan-1 monostatic SAR data. Finally, the deformation monitoring results are compared with the surface deformation results based on the TanDEM data, and both the results are evaluated using the filed leveling data. Taking 20 images covering the Datong mining area as the data sources, the surface deformation results obtained using different InSAR methods in the mining area were quantitatively evaluated and analyzed. The results indicated that: (1) the DSM obtained using the Lutan-1 bistatic SAR data was assessed and demonstrated with the ICESat laser altimetry data an error of 2.8 m, which meets the Chinese 1:50,000 scale DEM cartographic accuracy standard, and the difference analysis with the TanDEM data shows that the terrain changes are mainly distributed in mountainous areas; (2) Due to the improvement in resolution, the registration accuracy of the SAR images and LT-DSM is higher than that of the TanDEM data in the range direction and azimuth direction; (3) Via evaluation with the filed leveling data, it is found that the surface deformation measurement results based on LT-DSM are less affected by terrain, and the accuracy of LT-DSM-SBAS and LT-DSM-DInSAR is improved by 11.5% and 16.3%, respectively, compared with TanDEM-SBAS and TanDEM-DInSAR, which demonstrates the effectiveness of the Lutan-1 bistatic and monostatic data for mine deformation monitoring. Full article

Over-exploitation of coal mines leads to surface subsidence, surface cracks, collapses, landslides, and other geological disasters. Taking a mining area in Nalintaohai Town, Ejin Horo Banner, Ordos City, Inner Mongolia Autonomous Region, as an example, Sentinel-1A data from January 2018 to October 2019 were used as the data source in this study. Based on the high interference coherence of the permanent scatterer (PS) over a long period of time, the problem of the manual selection of ground control points (GCPs) affecting the monitoring results during refinement and re-flattening is solved. A DInSAR-PS-Stacking method combining the PS three-threshold method (the coherence coefficient threshold, amplitude dispersion index threshold, and deformation velocity interval) is proposed as a means to select ground control points for refinement and re-flattening, as well as a means to obtain time-series deformation by weighted stacking processing. A SBAS-PS-InSAR method combining the PS three-threshold method to select PS points as GCPs for refinement and re-flattening is also proposed. The surface deformation results monitored by the DInSAR-PS-Stacking and SBAS-PS-InSAR methods are analyzed and verified. The results show that the subsidence location, range, distribution, and space–time subsidence law of surface deformation results obtained by DInSAR-PS-Stacking, SBAS-PS-InSAR, and GPS methods are basically the same. The deformation results obtained by these two InSAR methods have a good correlation with the GPS monitoring results, and the MAE and RMSE are within the acceptable range. The error showed that the edge of the subsidence basin was small and that the center was large. Both methods were found to be able to effectively monitor the coal mine, but there were also shortcomings. DInSAR-PS-Stacking has a strong ability to monitor the settlement center. SBAS-PS-InSAR performed well in monitoring slow and small deformations, but its monitoring of the settlement center was insufficient. Considering the advantages of these two InSAR methods, we proposed fusing the time-series deformation results obtained using these two InSAR methods to allow for more reliable deformation results and to carry out settlement analysis. The results showed that the automatic two-threshold (deformation threshold and average coherence threshold) fusion was effective for monitoring and analysis, and the deformation monitoring results are in good agreement with the actual situation. The deformation information obtained by the comparison, and fusion of multiple methods can allow for better monitoring and analysis of the mining area surface deformation, and can also provide a scientific reference for mining subsidence control and early disaster warning. Full article

The largest earthquake (Mw 6.4) in northwestern Croatia ruptured the faults near the city of Petrinja on 29 December 2020, at 11:19 UTC. The epicenter was located ~3 km southwest of Petrinja, ~40 km southeast of Zagreb, the capital of the Republic of Croatia. Here we investigated the geometric and kinematic properties of the 2020 Mw 6.4 Petrinja earthquake using a joint inversion of ascending and descending interferograms from three tracks of Sentinel-1 Single-Look Complex (SLC) images. The coseismic and early postseismic surface displacements associated with the Petrinja earthquake were imaged using standard DInSAR and SBAS time-series InSAR methods, respectively. The distributed slip model was inverted based on the ground surface displacements with maximum slip patch in 5 km depth. The early postseismic deformation occurred on the northwestern extent of coseismic slip, and it cannot be well modeled by the coseismic model. We thus suggested that the postseismic deformation was caused by a combined effect of the postseismic afterslips and aftershocks occurring in this area. Based on the inverted slip model, we calculated the Coulomb stress change in the region, and found a good correlation between positive Coulomb failure stress ∆CFS and the distribution of aftershocks. Based on these results, we identified which faults are more active, and then better estimated the seismic hazards in the region. Full article

This paper proposes a geo-hazard risk assessment technique to analyze the impacts of surface subsidence monitored in a major coal mine in Nigeria. In many developing countries, disaster risk management schemes have mainly focused on traditional singular hazard assessment, vulnerability assessment, or risk assessment. However, it is difficult to use a singular application to adequately address hazard assessment due to the variation in data requirements, factors associated with the hazards, and the various elements at risk. Most times, hazard assessment schemes heavily rely on data and techniques from different global organizations that collate data on disasters, using various scales and objectives to make informed decisions. Several challenges seemingly arise from total reliance on these kinds of data due to standardization, the exact number of potential victims, and the purpose of the data collection. This makes disaster information collected at the local level unique and assessment schemes more complete; however, the coverage is limited worldwide. The proposed approach combines the spatial relationship between vulnerability assessment and elements at risk to highlight the grave consequences of potential disasters. Thus, the aim is to underscore the importance of integrating local-level inputs in analyzing risk factors and vulnerability indicators for hazard assessment. This study was conducted at the Onyeama coal mine in South East Nigeria. This area has experienced severe negative impacts of subsidence over the years. We exploit data from Sentinel-1 Synthetic Aperture Radar (SAR) Satellites and Small-Baseline Subset Differential Interferometric Synthetic Aperture Radar (SBAS-DInSAR) technique to map the study area. The results generate an elements-at-risk database with a particular focus on population density, road networks, and building networks identified as indices for loss estimation. Full article

Satellite interferometry has recently developed as a powerful tool for monitoring displacements on structures for structural health monitoring (SHM), as it allows obtaining information on past deformation and performing back analysis on structural behavior. Despite the increasing literature on this subject, the lack of protocols for applying and interpreting interferometric data for structural assessment prevents these techniques from being employed alongside conventional SHM. This paper proposes a methodology for exploiting satellite interferometric data aiming at remotely detecting displacements and buildings’ criticalities at different levels of analysis, i.e., urban scale and single-building scale. Moreover, this research exploits the capability of satellite monitoring for damage diagnosis, comparing the millimeter scale displacements to information derived from on-site inspections. Different data-driven algorithms were applied to detect seasonal and irreversible components of displacements, such as statistical models for damage identification derived from traditional on-site monitoring. Thus, the proposed methodology was applied to a XVI-century case study located in the city center of Rome (Italy), Palazzo Primoli, and two stocks of COSMO-SkyMed (CSK) images processed through the Small BAseline Subset Differential Interferometry (SBAS-DInSAR) technique were used to assess displacements for an eight-year-long (between 2011 and 2019) monitoring period. Full article

Different interferometric approaches have been developed over the past few decades to process SAR data and recover surface deformation, and each approach has advantages and limitations. Finding an accurate and reliable interval for preparing mean deformation rate maps (MDRMs) remains challenging. The primary purpose of this paper is to implement an application consisting of three unsupervised clustering algorithms (UCAs) for determining the best interval from SAR-derived deformation data, which can be used to interpret long-term deformation processes, such as subsidence, and identify displacement patterns. Considering Port Harcourt (in the Niger Delta) as the study area, it was essential to remove the sources of error in extracting deformation signals from SAR data, spatially ionospheric and tropospheric delays, before using UCAs to obtain its characteristics and real deformation data. Moreover, another purpose of this paper is to implement the advanced integration method (AIM) for atmospheric phase screen (APS) correction to enhance deformation signals obtained through different SAR processing approaches, including interferometric SARs (two-pass interferometry, InSAR) and multitemporal interferometry SARs (n-pass interferometry, DInSAR; permanent scatterer interferometry (PSI); and small baseline subset (SBAS)). Two methods were chosen to evaluate and find the best technique with which to create an MDRM: The first one was to compare the signals corrected by the AIM and the vertical component of the GPS station, which showed the AIM providing 58%, 42%, and 28% of the matching with GNSS station outputs for InSAR, PSI, and SBAS, respectively. Secondly, similarity measures and Davies–Bouldin index scores were implemented to find an accurate and reliable interval in which the SBAS technique with the unsupervised K-medians method has been chosen. Based on GNSS vertical deformation in a 500 m radius around the station, the SBAS K-medians technique expressed up to 5.5% better deformation patterns than the map of SAR processing techniques. Full article

The damage to pipeline infrastructures caused by reactive soils has been a critical challenge for asset owners. Sustainable backfilling materials have recently gained interest to stabilize highly reactive zones as a pre-emptive approach towards sustainability. In this study, two adjacent sections of a sewer pipeline trench in Melbourne, Australia were backfilled with two blends of 100% recycled aggregates. The sites were monitored for ground deformations during October 2020–February 2022 (17 months) using surveying techniques. Interferometric synthetic aperture radar (InSAR) techniques and algorithms were also employed to estimate the ground movements of the sites and surrounding regions. The cross-validation of deformation results achieved from both techniques enabled an in-depth analysis of the effectiveness of the recycled aggregates to address reactive soil issues in urban developments. Observational deformation data and their spatiotemporal variation in the field were satisfactorily captured by the InSAR techniques: differential InSAR (DInSAR), persistent scatterer interferometry (PSI), and small baseline subset (SBAS). The SBAS estimations were found to be the closest to field measurements, primarily due to the analysis of zones without well-defined geometries. This study’s contribution to existing knowledge defines the spatiotemporal influence of sustainable backfill in areas with reactive soil through field data and satellite imaging. The relationship between InSAR techniques and actual field behavior of sustainable backfill can be a baseline for the growing construction that may be challenging to perform field monitoring due to resource constraints. Full article

This article presents an investigation of ground movement measurements based on a combination of TerraSAR-X and Sentinel-1 data, in opposite tracks, aiming to detect ground de-formation of the remaining dikes of Germano mine, after the Fundão dam collapse. The differential interferometry technique SBAS (Small Baseline Subset) was applied to obtain the deformation of the surface in different Line of Sight (LoS), in order to carry out the vector decomposition and generate the deformation measurements in the vertical and horizontal directions. A set of 37 single-look complex (SLC) images of TerraSAR-X (TSX), acquired during the period from 19 February 2016 to 15 May 2017, and 37 SLC images of Sentinel-1, acquired from 8 February 2016 to 15 May 2017, were used to perform this investigation. For the TerraSAR-X interferometric processing, a coherence threshold of 40%, 4 looks in range and 2 looks in azimuth, 1200 m of atmospheric filter, and 10 % of max normal baseline of the critical were used. For the Sentinel-1 interferometric processing a coherence threshold of 26%, 8 looks in range and 2 looks in azimuth, 1200 m of atmospheric filter, and 20% of the of max normal baseline of the critical were used. For both sensors a digital elevation model generated by Pleiades 1-A was used for removing the topographic phase component. The final results were consistent with the topographic in situ measurements, providing key information to make crucial decisions regarding risks, or even mitigation, repairs or emergency response, as well as for a better understanding of the on-going instability phenomena affecting the dikes and dams. Full article

This paper develops a low-cost web application system for monitoring geometrical impacts of surface subsidence. In many of the developing countries, the method of extraction of minerals such as coal is often impractical and uneconomical, especially with surface mining. With global warming, rapid population growth, and fast-growing urbanization with a disregard for sustainability, the overall subsidence risk has significantly increased. Despite the maturity of Differential Interferometric Synthetic Aperture Radar (DInSAR) for timely monitoring of subsidence hazards, the potential of SAR constellations has been under-exploited, as most applications focus mainly on mapping unstable areas. The developed web application system exploits Sentinel-1 SAR constellation and Small-BAseline Subset (SBAS-DInSAR) technique, to provide new streamlines of information for monitoring solutions and improve disaster risk decision making. We illustrate the model by investigating and measuring potential surface subsidence caused by underground hard coal mining activities and exponential urban population growth within a major coalmine in Nigeria. Results of the yearly cumulative amount of horizontal and vertical deformation between 2016 and 2020 range from −25.487 mm to −50.945 mm and −24.532 mm to −57.161 mm, for high and low risks, respectively. Under the influence of external factors such as rising poverty and fast-growing urbanization, the destruction of in situ stress distributions will likely increase nonlinear deformations. Full article
