The increasing need for materials that are both lightweight and strong in the aerospace and automotive sectors has driven the extensive use of composite sandwich structures. This study examines the impact response of honeycomb sandwich composites fabricated using the vacuum-assisted resin transfer molding (VARTM) technique. Two configurations were analyzed, namely carbon–honeycomb–carbon (CHC) and carbon–Kevlar–honeycomb–Kevlar–carbon (CKHKC), to assess the effect of Kevlar reinforcement on impact resistance. Charpy impact testing was conducted to evaluate energy absorption, revealing that CKHKC composites exhibited significantly superior impact resistance compared to CHC composites. The CKHKC composite achieved an average impact strength of 70.501 KJ/m², which is approximately 73.8% higher than the 40.570 KJ/m² recorded for CHC. This improvement is attributed to Kevlar’s superior toughness and energy dissipation capabilities. A comparative assessment of impact energy absorption further highlights the advantages of hybrid Kevlar–carbon fiber composites, making them highly suitable for applications requiring enhanced impact performance. These findings provide valuable insights into the design and optimization of high-performance honeycomb sandwich structures for impact-critical environments. Full article

To address the issues of burr formation, structural deformation, and tearing in the conventional machining of Nomex honeycomb composites, this study aims to clarify the mechanisms by which ultrasonic vibration-assisted cutting enhances machining quality. A multi-scale analysis framework is developed to examine the effects of ultrasonic vibration on fiber distribution, cell-level shear response, and the overall cutting mechanics. At the microscale, analyses show that ultrasonic vibration mitigates stress concentrations, thereby shortening fiber length. At the mesoscale, elastic buckling and plastic yielding models show that ultrasonic vibration lowers shear strength and modifies the deformation. A macro-scale comparison of cutting behavior with and without ultrasonic vibration was conducted. The results indicate that the intermittent contact effect induced by vibration significantly reduces cutting force. Specifically, at an amplitude of 40 μm, the cutting force decreased by approximately 29.7% compared to the condition without ultrasonic vibration, with an average prediction error below 8.6%. Compared to conventional machining, which causes the honeycomb angle to deform to approximately 130°, ultrasonic vibration preserves the original 120° geometry and reduces burr length by 36%. These results demonstrate that ultrasonic vibration effectively reduces damage through multi-scale interactions, offering theoretical guidance for high-precision machining of fiber-reinforced composites. Full article

Machining Nomex honeycomb composite structures is crucial for manufacturing components that meet stringent industry requirements. However, the complex characteristics of this material require specialized machining techniques to avoid defects, ensure optimal surface quality, and preserve the integrity of the cutting tool. Thus, hybrid ultrasonic-vibration-assisted machining (HUSVAM) technology, using a CZ10 combined cutting tool, was introduced to overcome these limitations. To this end, a 3D numerical model based on the finite element method, developed using Abaqus/Explicit 2017 software, allows us to simulate the interaction between the cutting tool and the thin walls of the structure to be machined. The objective of this study was to validate a numerical model through experimental tests while quantifying the impact of critical machining parameters, including the rotation speed and tilt angle, on process performance, in terms of surface finish, tool wear, cutting force components and chip size. The numerical results demonstrated that HUSVAM technology allows for a significant reduction in the cutting force components, with a decrease of between 12% and 35%. Furthermore, this technology improves cutting quality by limiting the deformation and tearing of cell walls, while extending tool life through a significant reduction in wear. These improvements thus contribute to a substantial optimization of the overall efficiency of the machining process. Full article

Nomex honeycomb structures (NHCs) have currently experienced significant development, mainly in the aeronautics, aerospace, marine, and automotive sectors. This expansion raises noteworthy challenges related to the improvement of machining excellence, necessitating the use of particular cutting tools and adapted techniques. With this in mind, experimental studies were conducted to analyze the specificities of Nomex honeycomb cores milling by integrating longitudinal ultrasonic vibrations along the cutting tool rotation axis (UCK). However, the high tool speed and the unreachability of the tool-workpiece interface complicate the direct observation of the cutting process. To overcome these challenges, a 3D numerical model was developed to simulate the milling of composite honeycomb structures by integrating longitudinal and longitudinal–torsional ultrasonic vibrations. This model was developed by Abaqus/Explicit software, version 2017. The obtained results indicate that the integration of longitudinal–torsional vibrations allows a reduction in cutting forces by up to 28%, a reduction in the accumulation of material in front of the cutting tool, with a maximum reduction of 30%, and an improvement in the quality of the machined surface. Full article

The refinement of effective data generation methods has led to a growing interest in using artificial neural networks (ANNs) to solve modeling problems related to mechanical structures. This study investigates the modeling of composite sandwich structures, i.e., structures made up of two laminated composite face sheets sandwiching a lightweight honeycomb core. An ANN was utilized to predict structural deflection and face sheet stress with low computational cost. Initially, a three-point load mode was used to determine the flexural behavior of the composite sandwich structure before subsequently analyzing the sandwich structure using the Monte Carlo sampling tool. Various combinations of face sheet materials, face sheet layer numbers, core types, core thicknesses and load magnitudes were considered as design variables in data generation. The generated data were used to train a neural network. Subsequently, the predictions of the trained ANN were compared with the outcomes of a finite element model (FEM), and the comparison was extended to real structures by conducting experimental tests. A woven carbon-fiber-reinforced polymer (WCFRP) with a Nomex honeycomb core was tested to validate the ANN predictions. The predictions from the elaborated ANN model closely matched the FEM and experimental results. Therefore, this method offers a low-computational-cost technique for designing and optimizing sandwich structures in various engineering applications. Full article

Nomex honeycomb composites are widely recognized for their advanced structural applications in the aerospace, automotive and defense industries. These materials are distinguished by exceptional characteristics such as thin cell walls and a hexagonal structure, as well as layers made of phenolic resins and aramid fibers. However, complex machining and the maintenance of high quality at a large scale presents considerable challenges. This study provides a comprehensive review of the literature on the processing of Nomex composites, highlighting the design challenges related to processing technologies, the impact of conventional and ultrasonic processing methods, and the associated mechanical properties and microstructural topographies. Moreover, it reviews research advances in machining techniques, current challenges, and future perspectives, thereby providing valuable guidance to ensure the optimal cutting of Nomex honeycomb composite structures (NHCs). Full article

Composite materials are widely used in the new generation of aviation equipment due to their comprehensive performance. However, the part fixture is usually difficult during the machining of composites with soft and brittle characteristics, such as the Nomex honeycomb. Therefore, the holding method based on the false boss connection can be utilized due to its advantages of low cost, less pollution, and a short preparation period. In this study, the method to determine and optimize the critical parameters of the false boss design is proposed to address the issue that they previously relied heavily on the experience of engineers, which often results in much waste of materials. To determine the critical parameters, a simulation model is constructed for Nomex honeycomb core parts machining with a false boss holding. Based on the simulation model, the stability of the machining process is analyzed, and the weak link of the false boss between different milling areas is studied. Furthermore, the difference in the shape of different parts is considered, and the reasonable critical parameters of the false boss are obtained through analysis. Full article

Machining of Nomex honeycomb composite (NHC) structures is of critical importance in manufacturing parts to the specifications required in the aerospace industry. However, the special characteristics of the Nomex honeycomb structure, including its composite nature and complex geometry, require a specific machining approach to avoid cutting defects and ensure optimal surface quality. To overcome this problem, this research suggests the adoption of RUM technology, which involves the application of ultrasonic vibrations following the axis of revolution of the UCK cutting tool. To achieve this objective, a three-dimensional finite element numerical model of Nomex honeycomb structure machining is developed with the Abaqus/Explicit software, 2017 version. Based on this model, this research examines the impact of vibration amplitude on the machinability of this kind of structure, including cutting force components, stress and strain distribution, and surface quality as well as the size of the chips. In conclusion, the results highlight that the use of ultrasonic vibrations results in an important reduction in the components of the cutting force by up to 42%, improves the quality of the surface, and decreases the size of the chips. Full article

Nomex honeycomb composites (NHCs) are commonly used in various industrial sectors such as aerospace and automotive sectors due to their excellent material properties. However, when machining this type of structure, problems can arise due to significant cutting forces and unwanted cell vibrations. In order to remedy these shortcomings, this study proposes to integrate RUM (rotary ultrasonic machining) technology, which consists of applying ultrasonic vibrations along the axis of rotation of the cutter. To fully understand the milling process by ultrasonic vibrations of the NHC structure, a 3D numerical finite element model is developed using Abaqus/Explicit software. The results of the comparative analysis between the components of the simulated cutting forces and those from the experiment indicate a close agreement between the developed model and the experimental results. Based on the developed numerical model, this study comprehensively analyzes the influence of the ultrasonic vibration amplitude on various aspects, such as stress distribution in the cutting zone, chip size, the quality of the machined surface and the components of the cutting force. Ultimately, the results demonstrate that the application of ultrasonic vibrations leads to a reduction of up to 50% in the components of the cutting force, as well as an improvement in the quality of the machined surface and a reduction in the size of chips. Full article

A honeycomb structure is a sandwich structure widely used in fuselage, among which the hexagonal honeycomb core is the most widely used. The energy absorption characteristics and impedance ability of the structure are the main reasons that directly affect the energy absorption characteristics of the honeycomb sandwich structure. Therefore, it is necessary to study the out-of-plane mechanical properties of the composite honeycomb sandwich structure. Based on the numerical simulation results, the energy absorption characteristics of several composite honeycomb sandwich structures are verified by drop hammer impact experiments. The research shows that the transient energy absorption characteristics of the composite honeycomb sandwich structure are mainly related to the cell size of the honeycomb structure. The smaller the size of the front cell, the stronger the overall impact resistance; the strength of the composite honeycomb sandwich structure exceeds that of 7075 aluminum alloy-NOMEX and carbon fiber-NOMEX honeycomb sandwich structures. In this paper, the energy absorption characteristics of composite honeycomb sandwich structures under different impact energy are compared and studied. The displacement, force and energy curves of energy absorption characteristics related to time variables are analyzed. The difference in protective performance between the composite honeycomb sandwich structure and existing airframe structure is compared and studied. The optimal structural design parameters of composite honeycomb sandwich under low-speed impact of drop hammer are obtained. The maximum energy absorption per unit volume of the designed honeycomb sandwich structure is 171.7% and 229.8% higher than that of the NOMEX-AL and NOMEX-C structures. The 6.4 mm and 3 mm cell sizes show good characteristics in high-speed buffering and crashworthiness. The composite honeycomb sandwich airframe structure can improve the anti-damage performance of the UAV airframe structure, ensure the same thickness and lightweight conditions as the existing honeycomb sandwich airframe structure, and improve the single-core bearing mode of the existing airframe structure. Full article

Nomex honeycomb composite (NHC) cores have seen significant growth in recent years, particularly in the aeronautics, aerospace, naval and automotive industries. This development presents significant challenges in terms of improving machining quality, requiring the use of specialized cutting tools and favorable cutting techniques. In this context, experimental studies have been carried out to highlight the characteristics of the milling of NHCs by rotary ultrasonic machining (RUM). However, the rapid motion of the cutting tool and the inaccessibility of the tool/part interface prevent the visualization of the chip formation process. For this purpose, a three-dimensional numerical model for milling the NHC structure using RUM technology was developed by Abaqus Explicit software. On the basis of this model, the components of the cutting force, the quality of the machined surface and the chip accumulation in front of the cutting tool were analyzed. The numerical results agree with the experimental tests, demonstrating that the use of RUM technology effectively reduces the cutting force components. An in-depth analysis of the influence of feed component F_y on the quality of the generated surface was carried out, revealing that the surface quality improved with low values of feed component F_y. Furthermore, the impact of ultrasonic vibrations on the accumulation of chips in front of the cutting tool is particularly optimized, in particular for large amplitudes. Full article

Machining Nomex honeycomb composites (NHCs), which are widely-used materials in the aerospace industry, is an imperative process to obtain desired profiles. However, when machining NHCs to obtain a thin-edged surface, some problems can arise due to large cutting forces. To avoid these defects, a method of ultrasonic vibration machining with variable angles of the down milling disc cutter was proposed in this study. The processing principles and motion characteristics of this method were elaborated. A theoretical model of its cutting process was established. The principle of cutting force reduction was qualitatively analyzed based on the model, and an experimental validation was conducted. The results demonstrated that, due to a smaller swing angle in each pass, the proposed method could reduce the fractal dimension of the machined surface by 6.01% compared to 1° with 10° of angle in each pass. And severe machining defects were decreased. Additionally, comparing the process of the fixed 10° angle of ultrasonic vibration machining with the process of a 1° angle in a pass, cutting force can be significantly reduced by 33.5%, demonstrating the effectiveness of the proposed method which improved surface quality by reducing cutting forces. Full article

This research investigated potential fire hazards originating in hidden areas of pressurized sections of aircrafts. The objective was to establish a laboratory-scale flammability test method to predict the behavior of fire propagation under real fire conditions. A confined fire apparatus (CFA) was designed and constructed, and several tests were conducted to better understand the involved mechanisms and their consequences and to estimate flame spreading in hidden-zone fires. The experimental facility and flame-spreading results obtained for a typical material involved in hidden fires, specifically a ceiling panel, were presented and discussed. The experimental facility consisted of a narrow passage where a fire was initiated using a burner on a specimen exposed to a controlled heat flux. Experiments were conducted in the absence of forced airflow. Flame spreading was estimated through visual monitoring of fire development or temperature measurements at specific locations in the specimen. Both methods yielded similar results. The flame spread velocity in relation to the imposed heat flux allowed for the estimation of the critical heat flux for spreading ${\dot{q}}_{sp,cr}^{″}$ and for ignition ${\dot{q}}_{ig,cr}^{″}$; the corresponding temperatures, T_s,min and T_ig; and the flame spread parameter Φ. Full article

Nomex honeycomb composites are used extensively in aerospace, automotive, and other industries due to their superior material properties. However, the tool wear during their machining can compromise the processing accuracy and the stability of the whole machining process, thus studies on the tool wear and strengthening method are urgently needed. This study presents a radial difference calculation method (RDC) to evaluate the tool wear of the disc cutter quantitatively in both conventional cutting and ultrasonic assisted cutting. The morphology of the tool wear process and its characteristics were analyzed. Two different heat treatments (salt bath quenching and vacuum quenching) were carried out to strengthen the tool performance. The research results demonstrated that ultrasonic vibration could significantly reduce the tool wear of the disc cutter, by up to 36%, after the same machining time. Salt bath quenching and vacuum quenching can both strengthen the tool performance. Particularly, after vacuum quenching treatment, the disc cutter’s metallographic grains were refined, and the tool wear could be reduced by 64%, compared to the as-received disc cutter. The findings in this study could be instructive to obtain further understanding of the machining mechanism and to improve methods in ultrasonic assisted cutting of Nomex honeycomb composites. Full article

Honeycomb composites (HCs) are diversely employed in aerospace, national defense and other fields owing to their remarkable spatial geometry and excellent mechanical properties. Their complex hexagonal cell structure and heterogeneous material properties cause major problems when implementing high-quality processing. Surface defects generated by processing will reduce the capability and service lifespan of the honeycomb sandwich structure. Therefore, the high quality of HCs is a topic of close attention for researchers. In this paper, the consequences of different cutting parameters of rotary ultrasonic machining (RUM) on surface quality with an ultrasonic circular knife (UCK) were studied through multiple groups of single-factor and orthogonal experiments with two-factors/four-levels and one-factor/three-levels. The single factor experiment was used to explain the effect that the degree of cutting parameters has on surface quality, and the orthogonal experiments were applied to explain the interaction between the processing parameters and the influence law of each factor on surface quality. Therefore, the reasonable cutting parameters of HCs were determined through experimental results to provide guidance for the realization of the precise and efficient machining of HCs. This study can provide a basis for the subsequent comprehensive consideration of various factors to achieve high-quality machining of HCs. Full article
