Radar waveform design is an important approach to radar system performance enhancement. For a long time, synthetic aperture radar (SAR) systems have utilized linear frequency modulation (LFM) waveforms as transmitted signals and have relied on window functions to suppress sidelobes. However, this approach significantly degrades system signal-to-noise ratio (SNR) and resolution. Nonlinear frequency modulation (NLFM) waveforms can suppress sidelobes without SNR loss and have been widely applied in the SAR field in recent years. Nonetheless, they still cannot completely avoid resolution loss. To address this, this article, based on an advanced High-Freedom Parameterized Frequency Modulation (HFPFM) coding model, constructs a waveform sidelobe optimization model constrained by mainlobe widening and solves it using a gradient descent method. Through detailed experiments, we found that the optimized waveform, compared to the LFM waveform, can reduce sidelobes by more than 9 dB without widening the mainlobe, thereby simultaneously avoiding the resolution and SNR losses caused by window function weighting. In addition, this optimization method can efficiently and rapidly optimize all parameters simultaneously using only matrix multiplication and fast Fourier transform (FFT)/inverse fast Fourier transform (IFFT). The SAR point target imaging simulation results verify that the optimized waveform can clearly image weak targets near strong targets, which proves the effectiveness of the proposed method. Full article

Nonlinear frequency modulated (NLFM) signals can be used to enhance the resolution, anti-jamming capability, and imaging quality of synthetic aperture radar (SAR) systems through optimized design, demonstrating substantial application potential. However, in a SAR system using NLFM signals, the non-start–stop effect, caused by the continuous motion of the platform during pulse transmission and reception, introduces significant errors, resulting in target defocusing. To tackle this problem, this paper proposes a general numerical error compensation method dedicated to NLFM signals. First, the error model is correspondingly derived from the non-start–stop assumption. Then, a phase compensation method is designed through numerical calculations. Simulation experiments are performed to validate the effectiveness of the proposed method. This method provides a robust error compensation framework for high-resolution SAR systems using NLFM signals. Full article

Pulse compression enhances the signal-to-noise ratio (SNR) in distributed fiber optic acoustic sensing (DAS) by increasing pulse energy through cross-correlation, while maintaining spatial resolution. In DAS systems, linear frequency modulation (LFM) pulses are commonly used; however, their limited sidelobe suppression (SLR) results in increased noise, limiting improvements in SNR and fading noise mitigation. To overcome these limitations, we propose an adaptable NLFM pulse design methodology that optimizes SLR based on specific application requirements. This approach significantly enhances pulse energy injection while reducing system noise, thereby improving overall sensing performance. Additionally, dual-carrier frequency-division multiplexing is employed to maximize energy utilization and mitigate fading effects. The experimental results demonstrate that, compared to the LFM-based detection pulse system, the optimized NLFM pulse improves the SNR by 10 dB. Under identical conditions, the NLFM system also enhances its performance in suppressing fading noise. Furthermore, the use of dual carriers effectively reduces the hardware resource consumption of the sensing system, highlighting the great potential of NLFM pulses in the field of fiber optic sensing. Full article

In this paper, a fast method to generate a constant-modulus (CM) waveform for a multiple-input, multiple-output, (MIMO) radar is proposed. To simplify the optimization process, the design of the transmit waveform is decoupled from the design of transmit beamformers (TBs) and subpulses. To further improve the computational efficiency, the TBs’ optimization is conducted in parallel, and a linear programming model is proposed to match the desired beampattern. Additionally, we incorporate the perturbation vectors into the TBs’ optimization so that the TBs can be adjusted to satisfy the CM constraint. To quickly generate the CM subpulses with the desired range-compression (RC) performance, the classical linear frequency modulation (LFM) signal and non-LFM (NLFM) are adopted as subpulses. Meanwhile, to guarantee the RC performance of the final angular waveform, the selection of LFM signal parameters is analyzed to achieve a low cross-correlation between subpulses. Numerical simulations verify the transmit beampattern performance, RC performance, and computational efficiency of the proposed method. Full article

Synthetic aperture radar (SAR) is a high-resolution imaging radar. With the deteriorating electromagnetic environment, SAR systems are susceptible to various forms of electromagnetic interference, including deception jamming. This jamming notably impacts SAR signal processing and subsequently worsens the quality of acquired images. Chaotic frequency modulation (CFM) signals could effectively counteract deception jamming. Nevertheless, due to the inadequate band-limited performance of CFM signals, higher oversampling factors are needed for achieving optimal low sidelobe levels, leading to increased system costs and excessively high data rates. Additionally, not all chaotic sentences meet the CFM signal requirements. In response, this paper proposes a novel signal modulation method called chaotic-nonlinear frequency modulation (C-NLFM) that enhances band-limited performance. The optimum parameters for C-NLFM signals are selected using the particle swarm optimization (PSO) algorithm. In this way, C-NLFM signals attain ideal low sidelobe levels even when faced with reduced oversampling factors. Meanwhile, this chaotic coding mode retains its capability to effectively suppress deception jamming. Moreover, C-NLFM signals demonstrate versatility in adapting to various chaotic sequences, thereby enhancing their flexibility to modify the signals as required. Through comprehensive simulations, data analysis, and a semi-physical experiment, the effectiveness and superiority of this proposed method have been confirmed. Full article

In the domain of optical fiber distributed acoustic sensing, the persistent challenge of extending sensing distances while concurrently improving spatial resolution and frequency response range has been a complex endeavor. The amalgamation of pulse compression and frequency division multiplexing methodologies has provided certain advantages. Nevertheless, this approach is accompanied by the drawback of significant bandwidth utilization and amplified hardware investments. This study introduces an innovative distributed optical fiber acoustic sensing system aimed at optimizing the efficient utilization of spectral resources by combining compressed pulses and frequency division multiplexing. The system continuously injects non-linear frequency modulation detection pulses spanning various frequency ranges. The incorporation of non-uniform frequency division multiplexing augments the vibration frequency response spectrum. Additionally, nonlinear frequency modulation adeptly reduces crosstalk and enhances sidelobe suppression, all while maintaining a favorable signal-to-noise ratio. Consequently, this methodology substantially advances the spatial resolution of the sensing system. Experimental validation encompassed the multiplexing of eight frequencies within a 120 MHz bandwidth. The results illustrate a spatial resolution of approximately 5 m and an expanded frequency response range extending from 1 to 20 kHz across a 16.3 km optical fiber. This achievement not only enhances spectral resource utilization but also reduces hardware costs, making the system even more suitable for practical engineering applications. Full article

This study introduces an innovative phase-sensitive optical time-domain reflectometer (φ-OTDR) technology based on orthogonal frequency-division multiplexing (OFDM) and nonlinear frequency modulation (NLFM) pulse modulation sequences. The proposed approach addresses the inherent trade-offs among spatial resolution, frequency response range, and sensing distance that conventional φ-OTDR systems encounter. This method optimizes spatial resolution and sensing distance by modulating both the frequency and phase of optical pulses. Moreover, it enhances sidelobe suppression by adjusting the nonlinearity of frequency modulation, reducing interference between adjacent signals, and improving the signal-to-noise ratio (SNR). Additionally, orthogonal frequency-division multiplexing expands the frequency response range. This paper elucidates the fundamental principles and implementation of OFDM-NLFM time-domain pulse modulation techniques and designs, experimentally validates a φ-OTDR system based on this method, and conducts comprehensive testing and analysis of the system’s performance. The experimental results demonstrate that the proposed φ-OTDR system achieves an 11 m spatial resolution and a frequency response range of 1–10 kHz over a 16.3 km optical fiber, utilizing a 65 MHz frequency bandwidth with multiplexed signals across four frequencies. This innovative approach reduces hardware resource consumption, opening up promising prospects for various practical engineering applications in optical fiber sensing technology. Full article

Ultra-wideband (UWB) nonlinear frequency modulation (NLFM) waveforms have the advantages of low sidelobes and high resolution. By extending the frequency domain wideband synthesis method to the NLFM waveform, the synthetic bandwidth will be limited, and the grating lobe will grow as the number of subpulses increases at a fixed synthetic bandwidth. Aiming for the highly periodic grating lobes caused by equally spaced splicing and small subpulse time-bandwidth products (TxBW), a multisubpulse UWB NLFM waveform synthesis method is proposed in this paper. Random frequency hopping and spectral correction are utilized to disperse the energy of periodic grating lobes and optimize the matched filter of the subpulse, thereby reducing notches and Fresnel ripples in the synthesized spectrum. The results of the hardware-in-the-loop simulation experiment show that the peak sidelobe ratio (PSLR) and the integral sidelobe ratio (ISLR) of the NLFM synthetic wideband waveform (SWW) obtained by 50 subpulses with a bandwidth of 36 MHz are improved by 4.8 dBs and 4.5 dBs, respectively, when compared to the frequency domain wideband synthesis method, and that the grating lobe is suppressed by an average of 10.6 dBs. It also performs well in terms of point target resolution, and it has potential for 2D radar super-resolution imaging. Full article

Synthetic aperture radar (SAR) systems have the capacity for day-and-night and all-weather surveillance, which has become increasingly indispensable for military surveillance and global comprehensive environmental monitoring. With the development of the high-resolution SAR imaging technique, studies on SAR jamming have also received much interest. Traditional jamming methods are based on linear-frequency-modulated (LFM) signals, and this method can achieve high main-lobe jamming gain. However, its sidelobe jamming energy is very low. To solve this issue, a novel nonlinear frequency modulation (NLFM) waveform design method for SAR jamming is proposed in this paper. Compared with LFM waveforms, the designed waveforms have the same main-lobe jamming gain and very high sidelobes, which can significantly improve jamming performance. Moreover, detailed simulation experiments were carried out to verify the effectiveness of the newly proposed jamming scheme. Full article

Conventional radars commonly use a linear frequency-modulated (LFM) waveform as the transmitted signal. The LFM radar is a simple system, but its impulse-response function produces a −13.25 dB sidelobe, which in turn can make the detection of weak targets difficult by drowning out adjacent weak target information with the sidelobe of a strong target. To overcome this challenge, this paper presents a modeling and optimization method for non-linear frequency-modulated (NLFM) waveforms. Firstly, the time-frequency relationship model of the NLFM signal was combined by using the Legendre polynomial. Next, the signal was optimized by using a bio-inspired method, known as the Firefly algorithm. Finally, the numerical results show that the advantages of the proposed NLFM waveform include high resolution and high sensitivity, as well as ultra-low sidelobes without the loss of the signal-to-noise ratio (SNR). To the authors’ knowledge, this is the first study to use NLFM signals for target-velocity improvement measurements. Importantly, the results show that mitigating the sidelobe of the radar waveform can significantly improve the accuracy of the velocity measurements. Full article

A new approach to the estimation and classification of nonlinear frequency modulated (NLFM) signals is presented in the paper. These problems are crucial in electronic reconnaissance systems whose role is to indicate what signals are being received and recognized by the intercepting receiver. NLFM signals offer a variety of useful properties not available for signals with linear frequency modulation (LFM). In particular, NLFM signals can ensure the desired reduction of sidelobes of an autocorrelation (AC) function and desired power spectral density (PSD); therefore, such signals are more frequently used in modern radar and echolocation systems. Due to their nonlinear properties, the discussed signals are difficult to recognize and therefore require sophisticated methods of analysis, estimation and classification. NLFM signals with frequency content varying with time are mainly analyzed by time–frequency algorithms. However, the methods presented in the paper belong to time–chirp domain, which is relatively rarely cited in the literature. It is proposed to use polynomial approximations of nonlinear frequency and phase functions describing signals. This allows for applying the cubic phase function (CPF) as an estimator of phase polynomial coefficients. Originally, the CPF involved only third-order nonlinearities of the phase function. The extension of the CPF using nonuniform sampling is used to analyse the higher order polynomial phase. In this paper, a sixth order polynomial is considered. It is proposed to estimate the instantaneous frequency using a polynomial with coefficients calculated from the coefficients of the phase polynomial obtained by CPF. The determined coefficients also constitute the set of distinctive features for a classification task. The proposed CPF-based classification method was examined for three common NLFM signals and one LFM signal. Two types of neural network classifiers: learning vector quantization (LVQ) and multilayer perceptron (MLP) are considered for such defined classification problem. The performance of both the estimation and classification processes was analyzed using Monte Carlo simulation studies for different SNRs. The results of the simulation research revealed good estimation performance and error-free classification for the SNR range encountered in practical applications. Full article

The OFDM chirp signal is suitable for MIMO radar applications due to its large time-bandwidth product, constant time-domain, and almost constant frequency-domain modulus. Particularly, by introducing the time-frequency structure of the non-linear frequency modulation (NLFM) signal into the design of an OFDM chirp waveform, a new OFDM-NLFM waveform with low peak auto-correlation sidelobe ratio (PASR) and peak cross-correlation ratio (PCCR) is obtained. IN-OFDM is the OFDM-NLFM waveform set currently with the lowest PASR and PCCR. Here we construct the optimization model of the OFDM-NLFM waveform set with the objective function being the maximum of the PASR and PCCR. Further, this paper proposes an OFDM-NLFM waveform set design algorithm inspired by alternating optimization. We implement the proposed algorithm by the alternate execution of two sub-algorithms. First, we keep both the sub-chirp sequence code matrix and sub-chirp rate plus and minus (PM) code matrix unchanged and use the particle swarm optimization (PSO) algorithm to obtain the optimal parameters of the NLFM signal’s time-frequency structure (NLFM parameters). Next, we keep current optimal NLFM parameters unchanged, and optimize the sub-chirp sequence code matrix and sub-chirp rate PM code matrix using the block coordinate descent (BCD) algorithm. The above two sub-algorithms are alternately executed until the objective function converges to the optimal solution. The results show that the PASR and PCCR of the obtained OFDM-NLFM waveform set are about 5 dB lower than that of the IN-OFDM. Full article

In synthetic aperture radar (SAR) imaging, geometric resolution, sidelobe level (SLL) and signal-to-noise ratio (SNR) are the most important parameters for measuring the SAR image quality. The staring spotlight mode continuously transmits signals to a fixed area by steering the azimuth beam to acquire azimuth high geometric resolution, and its two-dimensional (2D) impulse response with the low SLL is usually obtained from the 2D weighted power spectral density (PSD) by the selected weighting window function. However, this results in the SNR reduction due to 2D amplitude window weighting. In this paper, the staring spotlight SAR with nonlinear frequency modulation (NLFM) signal and azimuth non-uniform sampling (ANUS) is proposed to obtain high geometric resolution SAR images with the low SLL and almost without any SNR reduction. The NLFM signal obtains non-equal interval frequency sampling points under uniform time sampling by adjusting the instantaneous chirp rate. Its corresponding PSD is similar to the weighting window function, and its pulse compression result without amplitude window weighting has low sidelobes. To obtain a similar Doppler frequency distribution for low sidelobe imaging in azimuth, the received SAR echoes are designed to be non-uniformly sampled in azimuth, in which the sampling sequence is dense in middle and sparse in both ends, and azimuth compression result with window weighting would also have low sidelobes. According to the echo model of the proposed imaging mode, both the back projection algorithm (BPA) and range migration algorithm (RMA) are modified and presented to handle the raw data of the proposed imaging mode. Both imaging results on simulated targets and experimental real SAR data processing results of a ground-based radar validate the proposed low sidelobe imaging mode. Full article

This paper presents a novel approach to fast and accurate non-linear pulse signal reconstruction dedicated for electromagnetic sensors and their applications such as ELectronic INTelligence (ELINT), electronic warfare (EW), electronic reconnaissance (ER) systems, as well as for passive bistatic radar purposes in which other pulse radars are used as a source of illumination. The method is based on the instantaneous chirp rate (CR) estimation in the time-frequency (TF) domain providing a calculation of the frequency rate between every two consecutive samples. Such a new method allows for the precise reconstruction of the non-linear frequency modulated (NLFM) signal to be carried out in significantly shorter time in comparison to methods known in the literature. The presented approach was tested and validated using both simulated and real-life radar signals proving the usability of the proposed solution in practical applications. The results were compared with the precise extended generalized chirp transform (EGCT) method as a reference technique, using optimal matched filtration as the main concept. Full article

Since the advent of “pulse compression” radar, the “chirp” signal (Linear Frequency Modulation, LFM) has been one of the most widely used radar waveforms. It is well known that, by changing its modulation into a Non-Linear Frequency Modulation (NLFM), better performance in terms of Peak-to-Sidelobes Ratio (PSLR) can be achieved to mitigate the masking effect of nearby targets and to increase the useful dynamic range. Adding an appropriate amplitude modulation, as occurs in Hybrid-NLFM (HNLFM), the PSLR can reach very low values (e.g., PSLR < −60 dB), comparable to the two-way antenna sidelobes in azimuth. On the other hand, modern solid-state power amplifier technology, using low-power modules, requires them to be combined at the Radio Frequency (RF) stage in order to achieve the desired transmitted power. Noise Radar Technology (NRT) represents a valid alternative to deterministic waveforms. It makes use of pseudo-random waveforms—realizations of a noise process. The higher its time-bandwidth (or BT) product, the higher the (statistical) PSLR. With practical BT values, the achievable PSLR using pure random noise is generally not sufficient. Therefore, the generated pseudorandom waveforms can be “tailored” (TPW: Tailored Pseudorandom Waveforms) at will through suitable algorithms in order to achieve the desired sidelobe level, even only in a limited range interval, as shown in this work. Moreover, the needed high BT, i.e., the higher time duration T having fixed the bandwidth B, matches well with the low power solid-state amplifiers of Noise Radar. Focusing the interest on (civil) surveillance radar applications, such as ATC (Air Traffic Control) and marine radar, this paper proposes a general review of the two classes of waveforms, i.e., HNLFM and TPW. Full article
