Search Results (19)

Due to the development of power semiconductors and the increase in digital loads, DC microgrids are receiving attention, and their application scope is rapidly expanding. As the technological stability of high-voltage direct current (HVDC) continues to rise, the potential of low-voltage direct current (LVDC) distribution systems is becoming increasingly intriguing. Many researchers are actively conducting safety and efficiency research on DC distribution systems and power grids. In LVDC distribution systems, small-scale DC microgrids are formed by renewable energy sources supplying DC power. This paper analyzes the efficiency improvement that can be achieved by integrating a fire protection system into a DC microgrid. This research analyzed the changes when fire protection systems such as receivers, transmitters, fire alarms, emergency lighting, and evacuation guidance, which have traditionally used AC power, were converted to DC circuits. As a result, the power supply infrastructure within the DC microgrid can be simplified, energy loss can be reduced, and the stability of the power system can be improved. The research results of this paper suggest that DC circuit-based fire protection facilities can positively impact future smart grid and renewable energy goals. Full article

This paper deals with the operation method of an intelligent fault isolation device (IFID), which can detect and estimate faults in rapid and accurate ways considering the slope characteristics of fault currents with distribution line constants. Namely, the proposed operation method in IFID calculates the slope of the fault current with distribution line constants, and reduces its operation time by comparing the calculated slope value to the setting value to detect and evaluate the fault condition. Moreover, this paper implements the DC 400 V, 10 kW scaled IFID consisting of hardware (H/W) and software (S/W) sections based on the proposed operation method. The H/W section is composed of main and current limit switches, a current limit resistor, voltage and current sensors, and switching mode power supply (SMPS). Also, the S/W section consists of a control board and code composer studio (CCS) to calculate the slope characteristics of the fault current and control the semiconductor device. From the test results based on the proposed operation method, it was found that the IFID considering the slope characteristics of fault currents can detect and evaluate the fault condition and limit the fault current faster than the existing method to consider the fault current only. Full article

DC smart grids are a promising solution for the efficient integration of renewable energy sources and loads. Still, their widespread adoption is hindered by significant challenges related to fault response, identification, and clearance. The traditional DC fault analysis method is a useful tool for straightforwardly understanding the behaviour of fault current contributions from DC converters in LVDC networks during a fault. However, when a system with multiple converters and non-negligible fault impedance need to be considered, its accuracy is severely limited due to the assumptions included in the problem solution, thus leading to the following: (a) the dependency of the results’ reliability on fault impedance values and/or other converter fault current contributions; (b) the inaccuracy of the diode current estimation; and (c) the inaccuracy of the conductor joule integral. Thus, these results’ data may be unreliable for designing protection systems for one converter or for an entire network. In order to overcome these issues, this paper proposes an innovative, simple numerical approach to DC fault current evaluation, which can be adopted when the number of converters become significant, or the network is complex. This method arises from the primary interest in solving the circuit to extract the indicators (current peak value and time, joule integral, etc.) necessary for designing circuit protections. This approach proved to grant two main advantages over traditional methods: (a) it provides accurate results, with no need to introduce any specific assumption; (b) it can be structured to manage an arbitrary number of converters; and (c) it reduces the computational processing times and resources necessary to simulate an entire DC network in comparison to other circuit solution software. Full article

Low-voltage direct current (LVDC) systems have been increasingly studied as new efficient power systems. However, existing studies have primarily focused on power conversion designs, control, and operation, and research on ground configurations of LVDC systemsis insufficient. Consideration of the installation criteria of protective equipment and grounding systems is crucial because ground configurations in general households for end users are highly associated with the risk of human electrocution. Therefore, we investigate a mid-point grounding system using capacitors to ensure electrical safety in a mono-polar LVDC system that a general end user can directly experience in a household. MATLAB/Simulink is used to analyze the fault characteristics of the mid-point grounding system using capacitors by considering the effects of DC on the human body based on the International Electrical Code (IEC). Consequently, this paper suggests the minimum required values of the capacitors and resistors to operate the DC residual current detector (DC RCD), and the operation of the DC RCD was confirmed. By confirming the applicability of DC RCD in a household LVDC system with a mid-point grounding system using capacitors and resistors, unnecessary power loss in a mid-point grounding system and electrical accidents, such as electric shocks and fires, could be minimized. Full article

Fault detection and isolation are important tasks to improve the protection system of low voltage direct current (LVDC) networks. Nowadays, there are challenges related to the protection strategies in the LVDC systems. In this paper, two proposed methods for fault detection and isolation of the faulty segment through the line and bus voltage measurement were discussed. The impacts of grid fault current and the characteristics of protective devices under pre-fault normal, under-fault, and post-fault conditions were also discussed. It was found that within a short time after fault occurrence in the network, this fault was quickly detected and the faulty line segment was efficiently isolated from the grid, where this grid was restored to its normal operating conditions. For analysing the fault occurrence and its isolation, two algorithms with their corresponding MATLAB/SIMULINK platforms were developed. The findings of this paper showed that the proposed methods would be used for microgrid protection by successfully resolving the fault detection and grid restoration problems in the LVDC microgrids, especially in rural villages. Full article

Low-voltage dc distribution offers high efficiency for grid integration of dc-based technologies such as photovoltaic and battery storage systems and new loads such as charging stations for electric vehicles due to reduced number of conversion stages. However, the selection of protection devices, protection coordination and selectivity is still subject to research. This work proposes to use a two-layer protection technique utilizing the control capability of power converters in case of a short-circuit fault at branch level of a low voltage dc feeder. The first layer is limiting the bus current using a virtual resistance in the droop control to avoid tripping of the grid-forming converter. The second layer implements a soft fuse tripping technique for selectivity. The control concept is presented and the system stability is analyzed using impedance-based stability analysis. Experimental results on a hardware-in-the-loop setup verify the findings. Full article

Owing to the increasing penetration level of distributed energy resources (DER) and direct current (DC) load, the usage of low-voltage direct current (LVDC) systems has expanded to achieve efficient operations. However, because the LVDC system reaches the peak fault current at a faster rate than the alternating current (AC) system, a solution that protects the system components is necessary to maintain system integrity. It is required by the low-voltage ride-through (LVRT) that the DERs maintain their interconnections with the LVDC system and support fault recovery. In this study, a method is proposed to allow the application of the superconducting fault current limiter (SFCL) to reduce the fault current and enhance the LVRT capability. However, when the DER maintain a connection to support fault recovery, the conventional resistive-type SFCL must withstand the burden of high-temperature superconducting (HTSC) operation during fault state dependence on LVRT. Therefore, this study proposes a trigger-type SFCL to reduce the burden of the HTSC element and enhance the LVRT capability. The voltage sag related to the LVRT was improved owing to the SFCL. The proposed solution was confirmed using PSCAD/EMTDC, which is a commercial software. Full article

The demand for a low voltage direct current (LVDC) microgrid is increasing by the increase of DC-based digital loads and renewable resources and the rapid development of power electronics technology. For the stable operation of an LVDC microgrid, it is necessary to develop a protection method. In this paper, the new protection scheme considering the fault section is proposed using wavelet transform (WT) in an LVDC microgrid. The fault sections are classified into DC side of the alternating current (AC)/DC converter, DC/DC converter connected to photovoltaic (PV) system, DC line, and DC bus. The characteristics of fault current at each fault section are analyzed. Based on these analyses, the new protection scheme including the fault section estimation is proposed using WT. The proposed scheme estimates the fault section using the detail component after performing WT and sends the trip signal to each circuit breaker according to the fault section. The proposed protection scheme is verified through various simulations according to the fault region and fault current using electromagnetic transient program (EMTP)/ATPDraw and MATLAB. The simulation results show that the fault section is accurately determined, and the corresponding circuit breaker (CB) operations are performed. Full article

The demand for low voltage DC (LVDC) distribution systems is increasing due to the rapid development of power conversion technology, the increase of DC-based digital loads, and the expansion of DC-based distributed generation (DG). For the stable operation of the LVDC distribution system, it is necessary to develop a protection method. In this paper, the fault section is estimated using wavelet transform (WT) in LVDC distribution system. The fault section is classified into a DC line and a DC bus. The characteristics of fault current at each fault section part are analyzed in simple and actual LVDC system. Based on this analysis, the algorithm for fault section estimation is proposed using the detail component after performing WT. The results of fault section estimations are verified through various simulations using EMTP and MATLAB. The fault section estimation can be utilized in the development of protection schemes in LVDC distribution system. Full article

This study examines various low voltage levels applied to a direct current residential nanogrid (DC-RNG) with respect to the efficiency and component cost of the system. Due to the significant increase in DC-compatible loads, on-site Photovoltaic (PV) generation, and local battery storage, DC distribution has gained considerable attention in buildings. To provide an accurate evaluation of the DC-RNG’s efficiency and component cost, a one-year load profile of a conventional AC-powered house is considered, and AC appliances’ load profiles are scaled to their equivalent available DC appliances. Based on the modified load profiles, proper wiring schemes, converters, and protection devices are chosen to construct a DC-RNG. The constructed DC-RNG is modeled in MATLAB software and simulations are completed to evaluate the efficiency of each LVDC level. Four LVDC levels—24 V, 48 V, 60 V, and 120 V—are chosen to evaluate the DC-RNG’s efficiency and component cost. Additionally, impacts of adding a battery energy storage unit on the DC-RNG’s efficiency are studied. The results indicate that 60 V battery-less DC-RNG is the most efficient one; however, when batteries are added to the DC-RNG, the 48 V DC distribution becomes the most efficient and cost-effective option. Full article

Grounding fault analysis is of vital importance for low voltage direct current (LVDC) supply and utilization systems. However, the existing DC grounding fault model is inappropriate for LVDC supply and utilization system. In order to provide an appropriate assessment model for the DC grounding fault impact on the LVDC supply and utilization system, an LVDC supply and utilization system grounding fault model is proposed in this paper. Firstly, the model is derived by utilizing capacitor current and voltage as the system state variable, which considers the impact of the converter switch state on the topology of the fault circuit. The variation of system state parameters under various fault conditions can be easily obtained by inputting system state data in normal conditions as the initial value. Then, a model solution algorithm for the proposed model is utilized to calculated the maximum fault current, the system maximum fault current with different grounding resistance is simple to acquired based on the solution algorithm. The calculation results demonstrate that grounding resistance and structure of LVDC supply and utilization system have remarkable impacts on the transient current. The effectiveness of the proposed model is verified in PSCAD/EMTDC. The simulation results indicate that the proposed method is appropriate for the system fault analysis under various fault conditions with different grounding resistance and the proposed model can offer theoretical guidance for system fault protection. Full article

Series arc faults are challenging to detect in low-voltage dc (LVDC) distribution systems because, unlike other fault types, series arc faults result in only small changes in the current and voltage waveforms. Though there have been several approaches proposed to detect series arc faults, each approach has its requirements and limitations. A step change in the current and voltage waveforms at the arc inception is one of the characteristic signatures of these faults that can be extracted without requiring one to sample the waveforms at a very high frequency. This characteristic feature is utilized to present a novel approach based on voltage differential protection to detect series arc faults in LVDC systems. The proposed method is demonstrated using an embedded controller and experimental data that emulate a hardware-in-the-loop (HIL) test environment. The successful detection of series arc faults on two sets of series arc fault experimental data validated the approach. The results presented also illustrate the computational feasibility in implementing the approach in a real-time environment using an embedded controller. In addition, the paper discusses the robustness of the approach to load changes and loss of time synchronization between measurements at the two terminals of the line. Full article

The low voltage direct current (LVDC) distribution networks are connected with too many kinds of loads and sources, which makes them prone to failure. Due to the small damping value in the DC lines, the fault signal propagates so fast that the impact current with the wave front of millisecond and the transient voltage pose great challenges for fault detection. Even worse, some faults with small currents are difficult to detect and the communication is out of sync, resulting in protection misoperation. These problems have severely affected the new energy utilization. In view of this, a DC fault current limiter (FCL) composed of inductance, resistance, and power electronic switch was designed in this paper. The rising speed of fault current can be decreased by the series inductance and the peak value of the fault current can be limited by series impedance, thus in this way the running time can be gained for fault detection and protection. For distributed energy access, by deducing the short circuit fault characteristic expression of LVDC distribution network, the feasibility of FCL was verified. Based on the structure of the bridge-type alternating current (AC) current limiter, the structure and parameters of the DC FCL were determined according to the fault ride-through target. Then, a low voltage ride-through strategy based on DC FCL was proposed for the bipolar short-circuit fault of LVDC distribution network. Finally, MATLAB/Simulink simulation was used to verify the rationality of the proposed FCL and its ride-through strategy. Full article

As the application of low-voltage-direct-current system increases, fault analysis in the low-voltage-direct-current system has essential because the fault response has different from the conventional AC distribution system. Especially, the fault current by the discharge current of the capacitor in the low-voltage-direct-current distribution system has very large compared with the conventional AC distribution system. Therefore, this paper proposed the application of the superconducting fault current limiter for limiting the fault current on the low-voltage-direct-current system. As one of the protected methods against fault current, the superconducting fault current limiter which could quickly limit the fault current has been noticed as an attractive method. However, the protection relay may malfunction such as over current relay, selective protection relay due to limiting fault current by applying superconducting fault current limiter. Therefore, in this paper proposed a solution to malfunction problem of the protection relay using the voltage components of the high temperature superconductivity. This paper verified the effect of the proposed method through test modelling and PSCAD/EMTDC. Full article

This paper describes the design and field application of a high-efficiency single-phase AC/DC converter that is suitable for distribution lines. First, an appropriate AC/DC converter was designed in consideration of the environment of the application system. In order to ensure high efficiency and high reliability, we designed an optimum switching element and capacitor suitable for the converter, and the protection element of the AC/DC converter was designed based on these elements. The control function for the power converter suitable for an LVDC distribution system is proposed for highly reliable operation. The AC/DC converter was manufactured based on the design and its performance was verified during application in an actual low-voltage DC (LVDC) distribution grid through tests at the demonstration site. The application to a DC distribution system in an actual grid is very rare and it is expected that it will contribute to the expansion of LVDC distribution. Full article
