Aimed at the problems of severe layover, interferometric phase aliasing and phase jumps caused by dense urban features, which lead to difficulties in phase unwrapping and insufficient automation and intelligence in building areas under complex scenes, this paper proposes a phase reconstruction and unwrapping method for interferometric synthetic aperture radar (InSAR) building layover areas in complex scenarios integrated with YOLOv11. Based on a self-constructed dedicated dataset, the YOLOv11 object detection network is trained to identify and locate building layover areas in synthetic aperture radar (SAR) images and extract their original interferometric phases. On this basis, by integrating the building facade interferometry model and the interferometric phase gradient model, regions dominated by facade scattering are effectively identified, and their interferometric phases are reconstructed to reduce scattering interference from non-relevant areas. Finally, the reconstructed phase is unwrapped using a quality-guided phase unwrapping method. Experimental results demonstrate that the proposed method can automatically and intelligently achieve phase unwrapping in building areas under complex scenes, providing reliable technical support for urban deformation monitoring and 3D reconstruction. Full article

Time-series interferometric synthetic aperture radar (TS-InSAR) has become a widely used technique for monitoring surface deformation with high spatial and temporal resolution. The recent rise in cloud-based InSAR platforms has significantly accelerated the production of interferograms. However, the accuracy of deformation inversion remains limited by fundamental issues affecting interferogram quality, including temporal and spatial decorrelation and phase unwrapping errors. These degrading effects are most pronounced in vegetated, desert, and snow-covered terrains, which are common in active tectonic zones and thereby exert a major impact on the quality of the unwrapped phase. Traditional quality control methods are inefficient or inadequate for large-scale analysis, and discarding low-quality data reduces the inversion accuracy. To address these limitations, we developed a deep learning-based approach to automatically assess interferogram quality and integrate it into the time-series InSAR inversion workflow. We utilized Sentinel-1 interferograms generated by the COMET-LiCSAR system as the primary data source. Based on this dataset, we developed a multi-stage selection strategy for interferogram quality control, integrating loop phase closure analysis, statistical indicators (including coherence and phase standard deviation), and manual verification. As a result, we constructed a high-quality labeled dataset comprising approximately 20,000 samples. An improved ConvNeXt-InSAR model was designed and trained to automatically quantify the quality of each pixel in individual interferograms. The model generates pixel-wise quality maps, which are then incorporated as weight constraints in the time-series InSAR network inversion. The proposed method was applied to the interseismic deformation reconstruction in the central-southern Tibetan Plateau region. This study highlights the potential of deep learning-based interferogram quality assessment in facilitating large-scale, automated time-series InSAR processing. Full article

High-intensity mining activities in coal mining areas have produced large-gradient surface deformation, posing severe challenges to deformation monitoring using Interferometric Synthetic Aperture Radar (InSAR) techniques based on C-band Synthetic Aperture Radar (SAR) data. This study systematically evaluated the applicability of L-band LuTan-1 SAR (L-SAR) data versus C-band Sentinel-1A data for monitoring mining-induced surface deformation, using the Guqiao Coal Mine in Huainan as the study area. Based on 10 ascending-track and 13 descending-track L-SAR images and 42 Sentinel-1A images, deformation retrievals were performed using Differential InSAR (DInSAR) and the Small Baseline Subset (SBAS) InSAR approach, respectively, and the results were validated against independent levelling measurements. Results indicate that the mean coherence of descending- and ascending-track L-SAR interferometric pairs are 0.42 and 0.45, respectively, substantially higher than Sentinel-1A’s 0.25. In the DInSAR analysis along profile A–A′, the maximum line-of-sight (LOS) displacement obtained from descending- and ascending-track L-SAR are −0.40 m and −0.43 m, respectively, compared with −0.25 m from Sentinel-1A. In the SBAS-InSAR time-series analysis, descending- and ascending-track L-SAR yield 209,418 and 228,388 coherent points, respectively, clearly revealing the temporal evolution of surface deformation; their maximum LOS deformation rates are approximately −1.54 m·yr⁻¹ and −2.0 m·yr⁻¹, respectively. By contrast, Sentinel-1A selects only 81,669 coherent points, with severe loss of coherence in the subsidence center and a maximum LOS deformation rate of about −0.48 m·yr⁻¹. Accuracy validation shows that the Root Mean Square Error (RMSE) of vertical displacements obtained from DInSAR monitoring results based on descending and ascending L-SAR data is 16.1 mm, satisfying the requirement of centimeter-level accuracy for mining area surface subsidence monitoring. The study demonstrates the pronounced advantages of L-SAR for monitoring large-gradient, nonlinear deformation in mining environments. L-band data outperform C-band Sentinel-1A across coherence preservation, deformation sensitivity, and monitoring accuracy, providing a scientific basis for the broader application of domestic L-band SAR satellites in disaster risk assessment and long-term time-series monitoring of mining-induced subsidence. Full article

Phase unwrapping in interferometric synthetic aperture radar (InSAR) aims to recover a continuous phase field from wrapped observations, which enable accurate topographic reconstruction and surface deformation measurements. With the recent advances in deep learning (DL), several DL-based unwrapping approaches have shown promising performance. However, deep learning networks suffer from inconsistent feature representations between encoder and decoder stages. This leads to incompatible skip connections that provide limited benefits and even degrade reconstruction quality. To overcome this limitation, we propose ResUCTransNet that integrates residual learning with transformer-based feature modeling. The network employs a multi-scale residual backbone derived from Res_UNet to extract stable deep features. Then, to replace conventional skip connections, a channel transformer (CTrans) module is introduced that composed of channel-wise cross fusion transformer (CCT) and channel-wise cross attention (CCA). This design effectively reduces the semantic gap in different network stages, which allows adaptive integration of local CNN features and global transformer representations. Experiments on the public InSAR-DLPU dataset demonstrate that ResUCTransNet effectively reduces model complexity and achieves substantial improvements over existing deep learning models and classical unwrapping algorithms. Specifically, the proposed method attains the best performance in terms of RMSE and SSIM (RMSE = 1.6247, SSIM = 0.7741). Compared with the second-best model, Res_Unet (RMSE = 2.8409, SSIM = 0.7733), ResUCTransNet achieves an approximately 42.8% reduction in RMSE while maintaining nearly identical structural similarity. The proposed method provides higher reconstruction accuracy and better structural fidelity, while maintaining strong robustness and generalization in complex terrain or severe noise conditions. Full article

This study proposes a feature-level fusion method that integrates Differential Interferometric Synthetic Aperture Radar (D-InSAR) and Unmanned Aerial Vehicle photogrammetry (UAV-P) for monitoring mining-induced subsidence basin (MSB). The method begins by extracting key subsidence characteristics based on the patterns of coal-mining-related surface displacement; the centimeter-level subsidence boundary is determined from D-InSAR data, while the meter-scale deformation at the subsidence center is derived from UAV-P. These extracted features are then used to invert the parameters of the probability integral method (PIM). The subsidence basin predicted by the inverted parameters serves as a criterion to select the superior dataset between the D-InSAR and UAV-derived results. Finally, the selected subsidence data are fused to generate a composite subsidence map. The proposed method was applied to the 2S201 panel in the Wangjiata Coal Mine using eight Sentinel-1A images and two UAV surveys. The fusion results were evaluated for their regional and overall accuracy against 30 ground control points measured by total station and GPS. The results demonstrate that the fusion method not only accurately extracts large-scale deformations in the mining area, with a maximum subsidence of 2.5 m and a root mean square error (RMSE) of 0.277 m in the subsidence center area, but also precisely identifies the subsidence boundary region with an accuracy of 0.039 m. The fused subsidence basin exhibits an overall accuracy of 0.182 m, which represents a significant improvement of 83.6% and 27.8% over the results obtained using D-InSAR and UAV alone, respectively. This method effectively reconstructs the complete morphology of the mining-induced subsidence basin, confirming its feasibility for practical applications. Full article

This study examines residual low-order (linear and constant) phase errors in interferometric synthetic aperture radar (InSAR) when compact, high-frequency radar sensors are mounted on commercial uncrewed aerial vehicles (UAVs). Although higher carrier frequencies and shorter standoff ranges enable fine-resolution interferometry, the same characteristics—together with UAV platform instability—make the system highly vulnerable to motion-induced phase errors, which can significantly degrade or even invalidate DEM reconstruction. This paper first quantifies the admissible motion-error bounds for reliable multi-baseline phase-gradient estimation, and then introduces a post-autofocus correction scheme that estimates the residual linear term from the interferometric fringe frequency and refines it via an FFT-based correlation objective, while the constant term is calibrated using ground control points (GCPs). The method is validated through simulations of a 24 GHz UAV demonstrator. To the best of our knowledge, this work provides the first post-autofocus demonstration of linear-and-constant residual-error mitigation for UAV-based high-frequency multi-baseline InSAR. In the considered K-band setting, the proposed approach reduces the DEM error from 42 m to 0.2 m (≈98% improvement). Full article

This study presents the first integrated quantification of mud diapirism susceptibility in the Membrillal sector of Cartagena de Indias, Colombia, through a multidisciplinary approach combining geospatial, geotechnical, hydrogeochemical, and socio-structural analyses. Using GIS-based multicriteria modeling, household surveys (n = 240), and temporal satellite imagery from 2013 to 2024, the research identifies spatial and temporal dynamics of active mud volcano reactivation. Field sampling of vent waters and gases followed ISO/IEC 17025 and APHA–AWWA–WEF standards, revealing high-salinity fluids (TDS = 13,220 mg/L; EC = 20.4 mS/cm; pH = 8.0) with elevated chloride (6996 mg/L) and low sulfate (1.67 mg/L) under reducing conditions, though a significant charge-balance discrepancy (Na⁺ = 8 mg/L) indicates either sample dilution during the collection or presence of unmeasured cationic species, and low free-gas flux constrained by high-density brine sealing. Principal component analysis of 240 georeferenced dwelling surveys yielded dimension-specific reliability (α = 0.68–0.76) and strong spatial correlation (Spearman ρ = 0.61–0.87) between vent proximity and structural damage—46.9% of dwellings exhibited visible cracking, with 27.2% severe (width > 1.5 mm). Satellite differencing documented 233% increase in active vents (3→10) and 35% vegetation reduction correlated with informal settlement expansion into moderate-to-high susceptibility zones. Weighted overlay GIS modeling (validated Kappa = 0.82) classified four hazard classes; high-susceptibility zones (18% of the study area) encompassed all ten active vents. Findings underscore anthropogenic pressurization drivers—primarily surface loading from settlement densification—and the need for continuous InSAR deformation monitoring, piezometric observation, complete hydrogeochemical characterization (including alkalinity and unmeasured cations), and establishing early-warning thresholds for community risk mitigation. Full article

Land subsidence induced by excessive groundwater abstraction has emerged as a major geo-environmental hazard in arid oasis regions, calling for reproducible methods to quantitatively assess the abstraction-reduction–subsidence response and to support zoned management. This study integrates Sentinel-1A PS-InSAR deformation data with groundwater-level measurements to develop and calibrate a MODFLOW-SUB model that couples three-dimensional groundwater flow and one-dimensional skeletal compaction. The InSAR deformation field is used to constrain the conceptual model and key parameters. Four abstraction-reduction scenarios (20%, 40%, 60%, and 80%) are designed to characterize response curves using indicators such as maximum cumulative subsidence, annual subsidence rate, and the area exceeding specified thresholds. In addition, a multi-criteria composite index integrating driving forces, geological susceptibility, and exposure is applied for hazard zoning and scenario comparison. The results show that PS-InSAR constraints improve the spatial agreement of the simulations. The time-series RMSE between simulated and InSAR-derived deformation is approximately 20 mm, and the end-of-period cumulative subsidence error is within 10 mm. From 2019 to 2020, the maximum cumulative subsidence reached 166 mm, and the peak subsidence rate reached 101 mm/a. A clear lag between groundwater-level fluctuations and subsidence is observed, with the maximum correlation occurring at ~35 days for ACJ-1 and ~59–83 days for ACJ-2. This spatial variability is associated with the thickness and permeability of clay layers. Forecasts for 2021–2028 indicate that, under business-as-usual abstraction, maximum subsidence may reach 695 mm. Across scenarios, subsidence mitigation exhibits diminishing marginal returns with increasing abstraction reduction. Under the adopted model settings, a 20% reduction in abstraction yields substantial decreases in maximum subsidence and high-hazard area, representing a practical trade-off between mitigation benefits and water-use costs. Overall, the integrated workflow of monitoring, inversion, coupled modeling, scenario analysis, and zoning, together with the resulting zoned management recommendations, provides decision support for land-subsidence mitigation and water-allocation planning in arid oasis regions. Full article

With the rapid expansion of airport construction projects in China, high-fill airports are frequently built under complex geological conditions, where the high risk of surface stability may significantly affect flight safety and operational costs. In this study, 17 high-fill airports and 11 non-high-fill airports across China, all characterized by high subsidence risks, were selected to investigate vertical ground deformation. Utilizing multi-temporal Sentinel-1A radar imagery spanning from 2017 to 2024, Small Baseline Subset InSAR (SBAS-InSAR) was employed to retrieve the annual average deformation velocities and time-series cumulative displacements. The results revealed that among the selected sites, only 25% were relatively stable, while the others exhibited significant deformation characteristics. Notably, high-fill airports demonstrated greater deformation magnitudes compared to those in plain areas, especially in the area of prevalent slope subsidence. In addition, significantly positive correlation was found between fill height and deformation magnitude, while differential settlement was widespread in runway zones. Furthermore, foundations involving special ground conditions manifested continuedly and distinct deformation patterns despite ground treatments. This study demonstrates the limitations of current engineering approaches in completely eliminating airport deformation, and offers valuable insights for the site selection, engineering design, and maintenance of high-fill airports. Full article

The latest advances in remote sensing play a central role in providing Earth observation (EO) data for numerous applications in the scope of reaching environmentally sustainable goals. However, over tropical rainforests, optical imaging is often hindered by extensive cloud coverage, which means that analysis-ready images are mostly restricted to the dry season. In this study, we propose combining radar features extracted from short time series of Sentinel-1 Interferometric Wide Swath (IW) data with a deep learning-based classification scheme to continuously monitor the state of forests. The proposed methodology is based on the joint use of SAR backscatter and interferometric coherences at different temporal baselines to perform pixel-wise classification of land cover classes of interest. However, we show that for a sequence of Sentinel-1 time series, different land cover classes exhibit particular seasonal-dependent variations. Another challenge in performing short-term predictions stems from the fact that ground truths are usually available only on a yearly basis. To address these challenges, we propose a seasonal sampling of the training data, masked by potential deforestation, along with a classification based on a modified U-Net model. The classification results show that overall accuracies above 90% can be achieved throughout the whole year with the proposed method, emerging as a potential tool for mapping rainforests with unprecedented temporal resolution. Full article

Leveraging the complementary advantages of InSAR and GNSS, this study proposes a refined method for monitoring mining-induced surface subsidence by integrating both technologies. The method begins with calculating the time-series cumulative subsidence basin from InSAR. Subsequently, a constraint condition is established to identify large-gradient deformations, thereby distinguishing the subsidence edge from the subsidence center. For the subsidence edge with minor deformation, the InSAR results are retained. For the large-gradient subsidence center, the subsidence basin around the mining panel is reconstructed by integrating InSAR and GNSS models. Continuous surface deformation information in a geographic coordinate system is then obtained through spatial interpolation, ultimately yielding comprehensive surface subsidence results across the mining area. Taking a mining area in Shanxi Province as the study region, the feasibility and accuracy of the proposed method were validated using 35 SAR images acquired between April 2016 and September 2017, along with leveling measurement data from the mining panel. The maximum surface subsidence rate of the settlement basin obtained from the solution is −186.68 mm/year, and the maximum surface subsidence amount is 248 mm. Compared with the InSAR monitoring results, the root mean square error of the data collaborative monitoring is reduced by 96.8%, and it is reduced by 64.4% compared with the GNSS probability integral method. The results demonstrate that the proposed method can achieve subsidence results consistent with the actual situation. Its monitoring capability is significantly superior to that of using either InSAR or GNSS alone, effectively compensating for the limitations inherent in each individual technology when applied to mining subsidence monitoring. Consequently, this integrated approach provides more accurate and reliable information on surface subsidence in mining areas. Full article

Land subsidence poses a persistent challenge to Tianjin, a major coastal city in China, with implications for urban infrastructure and sustainable development. This study examines the spatiotemporal evolution of ground subsidence in Tianjin from 2003 to 2024 using multi-source SAR observations from Envisat ASAR (C-band), ALOS PALSAR (L-band), and Sentinel-1 (C-band). Surface deformation was derived using SBAS-InSAR with atmospheric phase correction. Due to limitations in data availability, SAR observations are temporally discontinuous; therefore, the long-term subsidence evolution was reconstructed by integrating multi-sensor deformation rates through a model-based time-series fitting approach. The results show pronounced subsidence during 2003–2010 in inland districts such as Wuqing, Beichen, Jinnan, and Jinghai, with maximum rates exceeding 50 mm/yr. After 2017, regional subsidence rates generally declined, while localized deformation became increasingly concentrated in coastal reclamation areas of the Binhai New Area, particularly around Dongjiang Port and Fuzhuang. Spatial and temporal patterns of subsidence exhibit clear correspondence with changes in groundwater use intensity and phases of urban construction and land reclamation. These observations suggest a transition in dominant subsidence controls over time. The results provide a long-term observational perspective on subsidence evolution in Tianjin and offer a geospatial basis for land-use planning and infrastructure risk assessment in coastal cities. Full article

Monitoring urban subsidence over ultra-long periods using time-series Interferometric synthetic aperture radar (InSAR) technology is critically important. Conventional approaches, however, face two main limitations: significant atmospheric phase residuals in complex urban settings, and discontinuous temporal time-series with short temporal coverage due to single-platform data constraints. To address these limitations, this study presents a new method for estimating ultra-long-term subsidence time series in urban areas, which combines Interferometric Subset Stacking (ISS) with multi-platform data fusion (DF). The methodology firstly processes TerraSAR-X and Sentinel-1A datasets through differential interferometry and applies ISS for atmospheric phase suppression. Next, bilinear interpolation unifies the spatial resolution and aligns the spatial reference frames of the two datasets. Subsequently, joint modeling derives subsidence velocities. Finally, temporal integration via linear interpolation and moving averaging produces a unified spatio-temporal deformation sequence. Applied to the Beijing region, China, this approach generated a 12-year ultra-long-term subsidence time series result (2012–2024), revealing maximum cumulative subsidence of 1100 mm spatially correlated with groundwater extraction patterns. Validation against Global Navigation Satellite System (GNSS) data showed strong agreement (correlation coefficient: 0.94, Root Mean Square Error (RMSE): 6.3 mm). The method achieved substantial atmospheric reduction—67.7% for Sentinel-1A and 24.1% for TerraSAR-X—representing approximately 15–20% accuracy improvement over conventional Generic Atmospheric Correction Online Service (GACOS) for InSAR. By effectively utilizing multi-platform data, this approach makes fuller use of the available phase information and compensates for the temporal gaps inherent in single-satellite datasets. It thus offers a valuable framework for long-term urban deformation monitoring. Full article

Transportation infrastructure is vulnerable to heterogeneous deformation, yet such deformation remains insufficiently monitored and characterized in metropolitan regions due to the lack of high-resolution deformation gradient products and comparison with industrial standards. Here, we generated a 45 m resolution interferometric synthetic aperture radar (InSAR) surface displacement time series across the Beijing Plain using Sentinel-1 SAR imagery acquired between 2014 and 2024, and calculated deformation gradients along all ring roads, major expressways, and airport runways. These deformation gradients are compared with national standards to evaluate their structural risks. Our analysis shows that (1) subsidence in the Beijing Plain is concentrated in the northern, eastern, and southern regions, where the northeastern region has been uplifting since 2018 due to the groundwater recovery in Beijing; (2) all ring roads, expressways, and airport runways are relatively stable during our observation period of 2015–2021, except for the central runway of Beijing Capital International Airport, which has accumulated a deformation gradient of 1.9‰ during 2015–2021, exceeding the safety limit of 1.5‰, indicating structural risks. These results demonstrate the effectiveness of high-resolution InSAR time series for monitoring deformation and pinpointing potential structural risks. Full article

Frequent extreme rainfall events in northwestern China have made loess–mudstone composite slopes highly susceptible to progressive failure, posing serious threats to infrastructure and public safety. This study investigates the deformation–failure mechanisms and evolutionary characteristics of such slopes under rainfall infiltration by integrating indoor physical model tests with long-term SBAS-InSAR time-series deformation monitoring. The physical model experiments reveal pronounced hydro-mechanical heterogeneity within the composite slope: surface fissures act as preferential flow paths, the mudstone interface exerts a significant water-blocking effect, and hydrological responses differ markedly between shallow and deep layers. The wetting front exhibits a distinct dual-layer migration pattern, characterized by rapid lateral expansion in the shallow layer and delayed advancement in the deep layer. Rainfall infiltration induces a progressive failure process, evolving from toe infiltration softening and mid-slope local erosion to differential crest erosion and ultimately overall sliding, forming a typical failure pattern of frontal creeping, central shearing, and rear tensile deformation. SBAS-InSAR results indicate that the natural landslide experienced a similar long-term progressive evolution, developing from shallow, localized deformation to deep-seated and slope-wide acceleration under multi-year rainfall. Despite differences in spatial deformation patterns influenced by natural microtopography, the failure stages and dominant deformation zones identified by both approaches show strong consistency. The combined results demonstrate that rainfall-induced suction decay, interface softening, pore water pressure accumulation, and stress redistribution jointly control the progressive instability of loess–mudstone slopes. This study highlights the effectiveness of integrating physical modeling and InSAR monitoring for elucidating rainfall-induced landslide mechanisms and provides scientific insights for hazard assessment and mitigation in composite-structure slopes. Full article
