Search Results (17)

Over the past two decades, Light Detection and Ranging (LiDAR) technology has evolved from early National Aeronautics and Space Administration (NASA)-led airborne laser altimetry into commercially mature systems that now underpin vegetation remote sensing across scales. Continuous advancements in laser engineering, signal processing, and complementary technologies—such as Inertial Measurement Units (IMU) and Global Navigation Satellite Systems (GNSS)—have yielded compact, cost-effective, and highly sophisticated LiDAR sensors. Concurrently, innovations in carrier platforms, including uncrewed aerial systems (UAS), mobile laser scanning (MLS), Simultaneous Localization and Mapping (SLAM) frameworks, have expanded LiDAR’s observational capacity from plot- to global-scale applications in forestry, precision agriculture, ecological monitoring, Above Ground Biomass (AGB) modeling, and wildfire science. This review synthesizes LiDAR’s cross-domain capabilities for the following: (a) quantifying vegetation structure, function, and compositional dynamics; (b) recent sensor developments encompassing ALS discrete-return ${(ALS}_D)$, and ALS full-waveform $\left({ALS}_{FW}\right)$, photon-counting LiDAR (PCL), emerging multispectral LiDAR (MSL), and hyperspectral LiDAR (HSL) systems; and (c) state-of-the-art data processing and fusion workflows integrating optical and radar datasets. The synthesis demonstrates that many LiDAR-derived vegetation metrics are inherently transferable across domains when interpreted within a unified structural framework. The review further highlights the growing role of artificial-intelligence (AI)-driven approaches for segmentation, classification, and multitemporal analysis, enabling scalable assessments of vegetation dynamics at unprecedented spatial and temporal extents. By consolidating historical developments, current methodological advances, and emerging research directions, this review establishes a comprehensive state-of-the-art perspective on LiDAR’s transformative role and future potential in monitoring and modeling Earth’s vegetated ecosystems. Full article

Hyperspectral LiDAR (HSL) is a promising active detection technique for underwater positioning and remote sensing, enabling the simultaneous acquisition of three-dimensional topographic and spectral information of underwater targets. This study presents an advanced underwater hyperspectral LiDAR (UDHSL) system with a spectral range of 450–700 nm, adjustable spectral bandwidth of 10–300 nm, and tunable repetition frequency of 50 kHz to 1 MHz. The system achieves high precision with a laser divergence angle of ≤1 mrad, pulse width of 7 ns, laser energy of 7.5 µJ, ranging resolution of 1.13 cm and ranging accuracy of 1.02 m@distance of 27 m. Hyperspectral point clouds spanning 11 bands (450–650 nm) are generated during 3D pool experiments. The distance-colored point clouds precisely align with the geometric characteristics of targets, the normalized intensity-colored point clouds across spectral bands exhibit discriminative capabilities for target identification, and the color-composite point clouds approximate the true colors of targets, collectively validating the system’s ability to concurrently acquire spectral and topographic data. These results underscore the potential of this technology for underwater exploration and positioning applications. Full article

Hyperspectral LiDAR (HSL) has been utilized as an efficacious technique in object classification and recognition based on its unique capability to obtain ranges and spectra synchronously. Different kinds of HSL prototypes with varied structures have been promoted and measured its performance. However, almost all of these HSL prototypes employ complex and large spectroscopic devices, such as an Acousto-Optic Tunable Filter and Liquid-Crystal Tunable Filter, which makes this HSL system bulky and expensive, and then hinders its extensive application in many fields. In this paper, a smart and smaller spectroscopic component, an intergraded optical filter (IOF), is promoted to miniaturize these HSL systems. The system calibration, range precision, and spectral profile experiments were carried out to test the HSL prototype. Although the IOF employed here only covered a wavelength range of 699–758 nm with a six-channel passband and showed a transmittance of less than 50%, the HSL prototype showed excellent performance in ranging and spectral profile collecting. The spectral profiles collected are well in accordance with those acquired based on the AOTF. The spectral profiles of the fruits, vegetables, plants, and ore samples collected by the HSL based on an IOF can effectively reveal the status of the plants, the component materials, and ore species. Finally, we also showed the integrated design of the HSL based on a three-dimensional IOF and combined with a detector. The performance and designs of this HSL system based on an IOF show great potential for miniaturizing in some specific applications. Full article

The hyperspectral full-waveform LiDAR (HSL) system based on the supercontinuum laser can obtain spatial and spectral information of the target synchronously and outperform traditional LiDAR or imaging spectrometers in target classification and other applications. However, low detection efficiency caused by the detection of useless background points (ULBG) hinders its practical applications, especially when the target is small compared with the large field of view (FOV) of the HSL system. A novel vision-aided hyperspectral full-waveform LiDAR system (V-HSL) was proposed to solve the problem and improve detection efficiency. First, we established the framework and developed preliminary algorithms for the V-HSL system. Next, we experimentally compared the performance of the V-HSL system with the HSL system. The results revealed that the proposed V-HSL system could reduce the detection of ULBG points and improve detection efficiency with enhanced detection performance. The V-HSL system is a promising development direction, and the study results will help researchers and engineers develop and optimize their design of the HSL system and ensure high detection efficiency of spatial and spectral information of the target. Full article

Advanced remote sensing techniques for estimating crop nitrogen (N) are crucial for optimizing N fertilizer management. Hyperspectral LiDAR (HSL) data, with both spectral and spatial information of the targets, can extract more plant properties than traditional LiDAR and hyperspectral imaging systems. In this study, we tested the ability of HSL in terms of estimating maize N concentration at the leaf-level by using spectral indices and partial least squares regression (PLSR) methods. Subsequently, the N estimation was scaled up to the plant-level based on HSL point clouds. Biomass, extracted with structural proxies, was utilized to exhibit its supplemental effect on N concentration. The results show that HSL has the ability to extract N concentrations at both the leaf-level and the canopy-level, and PLSR showed better performance (R² > 0.6) than the single spectral index (R² > 0.4). In comparison to the stem height and maximum canopy width, the plant height had the strongest ability (R² = 0.88) to estimate biomass. Future research should utilize larger datasets to test the viability of using HSL to monitor the N concentration of crops, which is beneficial for precision agriculture. Full article

High-throughput measurement of plant photosynthesis ability presents a challenge for the breeding process aimed to improve crop yield. As a novel technique, hyperspectral lidar (HSL) has the potential to characterize the spatial distribution of plant photosynthesis traits under less confounding factors. In this paper, HSL reflectance spectra of maize leaves were utilized for estimating the maximal velocity of Rubisco carboxylation (V_cmax) and maximum rate of electron transport at a specific light intensity (J) based on both reflectance-based and trait-based methods, and the results were compared with the commercial Analytical Spectral Devices (ASD) system. A linear combination of the Lambertian model and the Beckmann law was conducted to eliminate the angle effect of the maize point cloud. The results showed that the reflectance-based method (R² ≥ 0.42, RMSE ≤ 28.1 for J and ≤4.32 for V_cmax) performed better than the trait-based method (R² ≥ 0.31, RMSE ≤ 33.7 for J and ≤5.17 for V_cmax), where the estimating accuracy of ASD was higher than that of HSL. The Lambertian–Beckmann model performed well (R² ranging from 0.74 to 0.92) for correcting the incident angle at different wavelength bands, so the spatial distribution of photosynthesis traits of two maize plants was visually displayed. This study provides the basis for the further application of HSL in high-throughput measurements of plant photosynthesis. Full article

In precision agriculture, efficient fertilization is one of the most important pursued goals. Vegetation spectral profiles and the corresponding spectral parameters are usually employed for vegetation growth status indication, i.e., vegetation classification, bio-chemical content mapping, and efficient fertilization guiding. In view of the fact that the spectrometer works by relying on ambient lighting condition, hyperspectral/multi-spectral LiDAR (HSL/MSL) was invented to collect the spectral profiles actively. However, most of the HSL/MSL works with the wavelength specially selected for specific applications. For precision agriculture applications, a more feasible HSL capable of collecting spectral profiles at wide-range spectral wavelength is necessary to extract various spectral parameters. Inspired by this, in this paper, we developed a hyperspectral LiDAR (HSL) with 10 nm spectral resolution covering 500~1000 nm. Different vegetation leaf samples were scanned by the HSL, and it was comprehensively assessed for wide-range wavelength spectral profiles acquirement, spectral parameters extraction, vegetation classification, and the laser incident angle effect. Specifically, three experiments were carried out: (1) spectral profiles results were compared with that from a SVC spectrometer (HR-1024, Spectra Vista Corporation); (2) the extracted spectral parameters from the HSL were assessed, and they were employed as the input features of a support vector machine (SVM) classifier with multiple labels to classify the vegetation; (3) in view of the influence of the laser incident angle on the HSL reflected laser intensities, we analyzed the laser incident angle effect on the spectral parameters values. The experimental results demonstrated the developed HSL was more feasible for acquiring spectral profiles with wide-range wavelength, and spectral parameters and vegetation classification results also indicated its great potentials in precision agriculture application. Full article

Hyperspectral LiDAR (HSL) is a new remote sensing detection method with high spatial and spectral information detection ability. In the process of laser scanning, the laser echo intensity is affected by many factors. Therefore, it is necessary to calibrate the backscatter intensity data of HSL. Laser incidence angle is one of the important factors that affect the backscatter intensity of the target. This paper studied the radiometric calibration method of incidence angle effect for HSL. The reflectance of natural surfaces can be simulated as a combination of specular reflection and diffuse reflection. The linear combination of the Lambertian model and Beckmann model provides a comprehensive theory that can be applied to various surface conditions, from glossy to rough surfaces. Therefore, an adaptive threshold radiometric calibration method (Lambertian–Beckmann model) is proposed to solve the problem caused by the incident angle effect. The relationship between backscatter intensity and incident angle of HSL is studied by combining theory with experiments, and the model successfully quantifies the difference between diffuse and specular reflectance coefficients. Compared with the Lambertian model, the proposed model has higher calibration accuracy, and the average improvement rate to the samples in this study was 22.67%. Compared with the results before calibration with the incidence angle of less than 70°, the average improvement rate of the Lambertian–Beckmann model was 62.26%. Moreover, we also found that the green leaves have an obvious specular reflection effect near 650–720 nm, which might be related to the inner microstructure of chlorophyll. The Lambertian–Beckmann model was more helpful to the calibration of leaves in the visible wavelength range. This is a meaningful and a breakthrough exploration for HSL. Full article

Terrestrial hyperspectral LiDAR (HSL) sensors could provide not only spatial information of the measured targets but also the backscattered spectral intensity signal of the laser pulse. The raw intensity collected by HSL is influenced by several factors, among which the range, incidence angle and sub-footprint play a significant role. Further studies on the influence of the range, incidence angle and sub-footprint are needed to improve the accuracy of backscatter intensity data as it is important for vegetation structural and biochemical information estimation. In this paper, we investigated the effects on the laser backscatter intensity and developed a practical correction method for HSL data. We established a laser ratio calibration method and a reference target-based method for HSL and investigated the calibration procedures for the mixed measurements of the effects of the incident angle, range and sub-footprint. Results showed that the laser ratio at the red-edge and near-infrared laser wavelengths has higher accuracy and simplicity in eliminating range, incident angle and sub-footprint effects and can significantly improve the backscatter intensity discrepancy caused by these effects. Full article

Hyperspectral light detection and ranging (LiDAR) (HSL) combines the characteristics of hyperspectral imaging and LiDAR techniques into a single instrument without any data registration. It provides more information than hyperspectral imaging or LiDAR alone in the extraction of vegetation physiological and biochemical parameters. However, the laser pulse intensity is affected by the incident angle, and its effect on HSL has not yet been fully explored. It is important for employing HSL to investigate vegetation properties. The aim of this paper is to study the incident angle effect of leaf reflectance with HSL and build a model about this impact. In this paper, we studied the angle effect of leaf reflectance from indoor HSL measurements of individual leaves from four typical tree species in Beijing. We observed that (a) the increasing of incident angle decreases the leaf reflectance; (b) the leaf spectrum observed by HSL from 650 to 1000 nm with 10 nm spectral resolution (36 channels) are consistent with those that measured by Analytica Spectra Devices (ASD) spectrometer (R² = 0.9472 ~ 0.9897); (c) the specular reflection is significant in the red bands, and clear non-Lambertian characteristics are observed. In the near-infrared, there is little specular reflection, but it follows the Lambert-scattering law. We divided the whole band (650–1000 nm) into six bands and established an empirical model to correct the influence of angle effect on the reflectance of the leaf for HSL applications. In the future, the calibration of HSL measurements applied for other targets will be studied by rigorous experiments and modelling. Full article

Hyperspectral LiDAR (HSL) has been widely discussed in recent years, which attracts increasing attention of the researchers in the field of electronic information technology. With the application of supercontinuum laser source, it is now possible to develop an HSL system, which can collect spectral and spatial information of targets simultaneously. Meanwhile, eye-safety and miniature HSL device with multiple spectral bands are given more priorities in on-site applications. In this paper, we tempt to investigate how to select spectral bands with a selection method. The proposed method consists of three steps: first, the variances among the classes based on hyperspectral feature parameters, termed inter-class variances, are calculated; second, the channels are sorted based on corresponding variances in descending order, and those with the two highest values are adopted as the initial input of classification; finally, the channels are selected successively from the rest of the sorted sequence until the classification accuracy reaches 100%. To test the performance of the proposed method, we collect 91/71-channel hyperspectral measurements of four different categories of materials with 5 nm spectral resolution using an acousto-optic tunable filter (AOTF) based HSL. Experimental results demonstrate that the proposed method could achieve higher classification accuracy than a random band selection method with different classifiers (naïve Bayes (NB) and support vector machine (SVM)) regardless of classification feature parameters (echo maximum and reflectance). To reach 100% accuracy, it demands 8–9 channels on average by echo maximum and 4–5 channels on average by reflectance based on NB classifier; these figures are 3–4 by echo maximum and 2–3 by reflectance with SVM classifier. The proposed method can complete classification task much faster than the random selection method. We further confirm the specific channels for the classification of different materials, and find that the optimal channels vary with different materials. The experimental results prove that the optimal band selection of HSL system for classification is reliable. Full article

Spectra of reflectance (S_r) and fluorescence (S_f) are significant for crop monitoring and ecological environment research, and can be used to indicate the leaf nitrogen content (LNC) of crops indirectly. The aim of this work is to use the S_r-S_f features obtained with hyperspectral and laser-induced fluorescence LiDAR (HSL, LIFL) systems to construct novel combined spectral indices (NCI_H-F) for multi-year rice LNC estimation. The NCI_H-F is in a form of FWs* $\mathsf{\Phi }$ + GSIs* $\mathsf{\Phi }$ , where $\mathsf{\Phi }$ is the S_r-S_f features, and FWs and GSIs are the feature weights and global sensitive indices for each characteristic band. In this study, the characteristic bands were chosen in different ways. Firstly, the S_r-S_f characteristics which can be the intensity or derivative variables of spectra in 685 and 740 nm, have been assigned as the $\mathsf{\Phi }$ value in NCI_H-F formula. Simultaneously, the photochemical reflectance index (PRI) formed with 531 and 570 nm was modified based on a variant spectral index, called PRI_fraction, with the S_f intensity in 740 nm, and then compared its potential with NCI_H-F on LNC estimation. During the above analysis, both NCI_H-F and PRI_fraction values were utilized to model rice LNC based on the artificial neural networks (ANNs) method. Subsequently, four prior bands were selected, respectively, with high FW and GSI values as the ANNs inputs for rice LNC estimation. Results show that FW- and GSI-based NCI_H-F are closely related to rice LNC, and the performance of previous spectral indices used for LNC estimation can be greatly improved by multiplying their FWs and GSIs. Thus, it can be included that the FW- and GSI-based NCI_H-F constitutes an efficient and reliable constructed form combining HSL (S_r) and LIFL (S_f) data together for rice LNC estimation. Full article

Huizhou-style ancient architecture was one of the most important genres of architectural heritage in China. The architecture employed bricks, woods, and stones as raw materials, and timber frames were significant structures. Due to the drawback that the timbers were vulnerable to moisture and atmospheric agents, ancient timber buildings needed frequent protective interventions to maintain its good condition. Such interventions unavoidably disrupted the consistency between the original timber components. Besides this, the modifications brought about difficulty in correctly analysing and judging the state of existing ancient buildings, which, in current preservation practices, mainly rely on the expertise of skilled craftsmen to classify wood species and to identify the building-age of the timber components. Therefore, the industry and the research community urgently need a technique to rapidly and accurately classify wood materials and to discriminate building-age. In the paper, we designed an eye-safe 81-channel hyperspectral LiDAR (HSL) to tackle these issues. The HSL used an acousto-optic tunable filter (AOTF) as a spectral bandpass filter, offering the HSL measurements with 5 nm spectral resolution. Based on the HSL measurements, we analysed the relationship between the surface and cross-section spectral profiles of timber components from different ancient architectures built in the early Qing dynasty (~300 years), late Qing dynasty (~100 years), and nowadays, and confirmed the feasibility of using surface spectra of timber components for classification purpose. We classified building-ages and wood species with multiple Naive Bayes (NB) and support vector machine (SVM) classifiers by the surface spectra of timber components; this also unveiled the possibility of classifying gnawed timber components from its spectra for the first time. The encouraging experimental results supported that the AOTF-HSL is feasible for historic timber building preservation. Full article

Non-contact and active vegetation or plant parameters extraction using hyperspectral information is a prospective research direction among the remote sensing community. Hyperspectral LiDAR (HSL) is an instrument capable of acquiring spectral and spatial information actively, which could mitigate the environmental illumination influence on the spectral information collection. However, HSL usually has limited spectral resolution and coverage, which is vital for vegetation parameter extraction. In this paper, to broaden the HSL spectral range and increase the spectral resolution, an Acousto-optical Tunable Filter based Hyperspectral LiDAR (AOTF-HSL) with 10 nm spectral resolution, consecutively covering from 500–1000 nm, was designed. The AOTF-HSL was employed and evaluated for vegetation parameters extraction. “Red Edge” parameters of four different plants with green and yellow leaves were extracted in the lab experiments for evaluating the HSL vegetation parameter extraction capacity. The experiments were composed of two parts. Firstly, the first-order derivative of the spectral reflectance was employed to extract the “Red Edge” position (REP), “Red Edge” slope (RES) and “Red Edge” area (REA) of these green and yellow leaves. The results were compared with the referenced value from a standard SVC^© HR-1024 spectrometer for validation. Green leaf parameter differences between HSL and SVC results were minor, which supported that notion the HSL was practical for extracting the employed parameter as an active method. Secondly, another two different REP extraction methods, Linear Four-point Interpolation technology (LFPIT) and Linear Extrapolation technology (LET), were utilized for further evaluation of using the AOTF-HSL spectral profile to determine the REP value. The differences between the plant green leaves’ REP results extracted using the three methods were all below 10%, and the some of them were below 1%, which further demonstrated that the spectral data collected from HSL with this spectral range and resolution settings was applicable for “Red Edge” parameters extraction. Full article

True-color three-dimensional (3D) imaging exploits spatial and spectral information and can enable accurate feature extraction and object classification. The existing methods, however, are limited by data collection mechanisms when realizing true-color 3D imaging. We overcome this problem and present a novel true-color 3D imaging method based on a 32-channel hyperspectral LiDAR (HSL) covering a 431–751 nm spectral range. We conducted two experiments, one with nine-color card papers and the other with seven different colored objects. We used the former to investigate the effect of true-color 3D imaging and determine the optimal spectral bands for compositing true-color, and the latter to explore the classification potential based on the true-color feature using polynomial support vector machine (SVM) and Gaussian naive Bayes (NB) classifiers. Since using all bands of HSL will cause color distortions, the optimal spectral band combination for better compositing the true-color were selected by principal component analysis (PCA) and spectral correlation measure (SCM); PCA emphasizes the amount of information in band combinations, while SCM focuses on correlation between bands. The results show that the true-color 3D imaging can be realized based on HSL measurements, and three spectral bands of 466, 546, and 626 nm were determined. Comparing reflectance of the three selected bands, the overall classification accuracy of seven different colored objects was improved by 14.6% and 8.25% based on SVM and NB, respectively, classifiers after converting spectral intensities into true-color information. Overall, this study demonstrated the potential of HSL system in retrieving true-color and facilitating target recognition, and can serve as a guide in developing future three-channel or multi-channel true-color LiDAR. Full article
