This study introduces a controlled laboratory setup for hyperspectral longwave infrared (LWIR) imaging of soils, designed to bridge the gap between laboratory measurements and remote sensing observations. A Fourier-transform hyperspectral LWIR imaging spectrometer (Telops Hyper-Cam LW) was employed, together with a specialized heating plate, rigorous calibration protocols, and a Spatial Averaging Before Blackbody Fitting (SABBF) method to enable accurate LWIR indoor measurements. Unlike established laboratory techniques that measure reflectance and calculate emissivity indirectly, this setup enables direct passive measurement of soil emissivity, replicating airborne and spaceborne LWIR measurements of the surface. The emissivity spectra of 12 variable soil samples obtained with the lab setup were compared and validated based on LWIR Hyper-Cam LW spectra acquired under outdoor conditions, then were subsequently analyzed to determine the mineral composition of each sample. Spectral features and indices were used to estimate the relative content of quartz, clay minerals, and carbonates, from the most to least abundant. The results demonstrate that the laboratory-based setup preserves spectral fidelity while offering improved repeatability, scheduling flexibility, and reduced dependence on weather. Beyond replicating outdoor measurements, this controlled setup is easy to install and provides a reproducible framework for LWIR soil spectroscopy that could be considered for standard laboratory protocols, enabling reliable mineral identification, calibration/validation of airborne and satellite LWIR data, and broader applications in soil monitoring and environmental remote sensing. Full article

Fourier transform spectrometers (FTSs) are cornerstone instruments in Earth observation space missions, effectively monitoring atmospheric gases in missions such as Michelson Interferometer for Passive Atmospheric Sounding (MIPAS), and Infrared Atmospheric Sounding Interferometer (IASI). It will also be the core instrument of Meteosat Third Generation—Sounding (MTG-S) and the future Earth Explorer (EE) mission Far-infrared Outgoing Radiation Understanding and Monitoring (FORUM). Building on this legacy, the European Space Agency (ESA) has developed an FTS instrument and an inverse model designed to estimate the radiometric and spectral performance from a set of instrumental parameters. The model and its validation using in-flight measurements of the FTS instrument Gimballed Limb Observer for Radiance Imaging of the Atmosphere (GLORIA)-Lite are described in this paper. The results indicate that the difference between the model predictions and the measured signal is less than 2% relative to the average of the measurements. Moreover, we can correctly predict the instrument’s radiometric gain and offset and reconstruct a scientific science spectrum. This model can be utilised effectively to evaluate the radiometric performance of future FTS missions. Full article

To determine the long-term effect of Australian bushfires on the upper tropospheric composition in the South Pacific, we investigated the variation in CO and hydrocarbon species in the South Pacific according to the extent of Australian bushfires (2004–2020). We conducted analyses using satellite data on hydrocarbon and CO from the Atmospheric Chemistry Experiment Fourier Transform Spectrometer (ACE-FTS), and on fire (fire count, burned area, and fire radiative power) from the Moderate Resolution Imaging Spectroradiometer (MODIS). Additionally, we compared the effects of bushfires between Northern and Southeastern Australia (N_Aus and SE_Aus, respectively). Our analyses show that Australian bushfires in austral spring (September to November) result in the largest increase in CO and hydrocarbon species in the South Pacific and even in the west of South America, indicating the trans-Pacific transport of smoke plumes. In addition to HCN (a well-known wildfire indicator), CO and other hydrocarbon species (C₂H₂, C₂H₆, CH₃OH, HCOOH) are also considerably increased by Australian bushfires. A unique finding in this study is that the hydrocarbon increase in the South Pacific mostly relates to the bushfires in N_Aus, implying that we need to be more vigilant of bushfires in N_Aus, although the severe Australian bushfire in 2019–2020 occurred in SE_Aus. Due to the surface conditions in springtime, bushfires on grassland in N_Aus during this time account for most Australian bushfires. All results show that satellite data enables us to assess the long-term effect of bushfires on the air composition over remote areas not having surface monitoring platforms. Full article

A wide band range can cover more of the characteristic spectral lines of substances, and thus analyze the structure and composition of substances more accurately. In order to broaden the band range of spectral instruments, an ultra-wide-band Fourier transform infrared spectrometer is designed. The incident light of the spectrometer is constrained by a secondary imaging scheme, and switchable light sources and detectors are set to achieve an ultra-wide band coverage. A compact and highly stable double-moving mirror swing interferometer is adopted to generate optical path difference, and a controller is used to stabilize the swing of the moving mirrors. A distributed design of digital system integration and analog system integration is adopted to achieve a lightweight and low-power-consumption spectrometer. High-speed data acquisition and a transmission interface are applied to improve the real-time performance. Further, a series of experiments are performed to test the performance of the spectrometer. Finally, the experimental results show that the spectral range of the ultra-wide-band Fourier transform infrared spectrometer covers 0.770–200 μm, with an accurate wave number, a spectral resolution of 0.25 cm⁻¹, and a signal-to-noise ratio better than 50,000:1. Full article

The accurate monitoring of greenhouse gas (GHG) concentrations is crucial in mitigating global warming. The imaging Fourier transform spectrometer (IFTS) is an effective tool for measuring GHG concentrations, offering high throughput and a wide spectral measurement range. In order to address the issue of spectral inconsistency during the detection process of the target gas, which is influenced by external environmental factors, making it difficult to achieve high-precision gas concentration inversion, this paper proposes a multi-scale feature attention (MDISE) model. The model uses a multi-scale dilated convolution (MD) module to retain both global and local shallow features of the spectra; introduces the one-dimensional Inception (1D Inception) module to further extract multi-scale deep features; and incorporates the channel attention mechanism (SE) module to enhance attention to important spectral wavelengths, suppressing redundant and interfering information. A target gas detection system was built in the laboratory, and the proposed model was tested on gas samples collected by two channels of a short and medium-wavelength infrared imaging Fourier transform spectrometer (SMWIR-IFTS). The experimental results show that the MDISE model reduces the root mean square error (RMSE) in both channels by 79.14%, 76.59%, and 69.80%, and 81.45%, 82.65%, and 74.01%, respectively, compared to the partial least squares regression (PLSR), support vector regression (SVR), and conventional one-dimensional convolutional neural network (1D-CNN) models. Additionally, the MDISE model achieved average coefficient of determination (R²) values of 0.997 and 0.995 for the concentration intervals in both channels. The MDISE model demonstrates excellent performance and significantly improves the accuracy of GHG concentration inversion. Full article

A new spectral super-resolution technique was proposed by combining the Fabry–Perot interferometer (FPI) with Temporally and Spatially Modulated Fourier Transform Imaging Spectrometer (TSMFTIS). This study uses the multi-beam interference of the FPI to modulate the target spectrum periodically, and it acquires the modulated interferogram through TSMFTIS. The combined interference of the two techniques overcomes the limitations of the maximum optical path difference (OPD) on spectral resolution. FPI is used to encode high-frequency interference information into low-frequency interference information, proposing an inversion algorithm to recover high-frequency information, studying the impact of FPI optical defects on the system, and proposing targeted improvement algorithms. The simulation results indicate that this method can achieve multi-component joint interference imaging, improving spectral resolution by twofold. This technology offers advantages such as high throughput, stability, simple and compact structure, straightforward principles, high robustness, and low cost. It provides new insights into TSMFTIS spectral super-resolution research. Full article

Highly sensitive infrared photodetectors are needed in numerous sensing and imaging applications. In this paper, we report on extended short-wave infrared (e-SWIR) avalanche photodiodes (APDs) capable of operating at room temperature (RT). To extend the detection wavelength, the e-SWIR APD utilizes a higher indium (In) composition, specifically In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures. The detection cut-off wavelength is successfully extended to 2.6 µm at RT, as verified by the Fourier Transform Infrared Spectrometer (FTIR) detection spectrum measurement at RT. The In_0.3Ga_0.7As_0.25Sb_0.75/GaSb heterostructures are lattice-matched to GaSb substrates, ensuring high material quality. The noise current at RT is analyzed and found to be the shot noise-limited at RT. The e-SWIR APD achieves a high multiplication gain of $M~190$ at a low bias of $V_{bias}=-2.5\mathrm{V}$ under illumination of a distributed feedback laser (DFB) with an emission wavelength of 2.3 µm. A high photoresponsivity of $\mathfrak{R}>140\mathrm{A}/\mathrm{W}$ is also achieved at the low bias of $V_{bias}=-2.5\mathrm{V}$. This type of highly sensitive e-SWIR APD, with a high internal gain capable of RT operation, provides enabling technology for e-SWIR sensing and imaging while significantly reducing size, weight, and power consumption (SWaP). Full article

This study utilized an infrared spotlight Hyperspectral infrared Atmospheric Sounder (HIRAS) and the Medium Resolution Spectral Imager (MERSI) mounted on FY3D cloud products from the National Satellite Meteorological Center of China to obtain methane profile information. Methane inversion channels near 7.7 μm were selected based on the different distribution of methane weighting functions across different seasons and latitudes, and the selected retrieval channels had a great sensitivity to methane but not to other parameters. The optimization method was employed to retrieve methane profiles using these channels. The ozone profiles, temperature, and water vapor of the European Centre for Medium-Range Weather Forecasts (ECMWF) fifth-generation reanalysis data (ERA5) were applied to the retrieval process. After validating the methane profile concentrations retrieved by HIRAS, the following conclusions were drawn: (1) compared with Civil Aircraft for the Regular Investigation of the Atmosphere Based on an Instrument Container (CARIBIC) flight data, the average correlation coefficient, relative difference, and root mean square error were 0.73, 0.0491, and 18.9 ppbv, respectively, with lower relative differences and root mean square errors in low-latitude regions than in mid-latitude regions. (2) The methane profiles retrieved from May 2019 to September 2021 showed an average error within 60 ppbv compared with the Fourier transform infrared spectrometer (FTIR) station observations of the Infrared Working Group (IRWG) of the Network for the Detection of Atmospheric Composition Change (NDACC). The errors between the a priori and retrieved values, as well as between the retrieved and smoothed values, were larger by around 400–500 hPa. Apart from Toronto and Alzomoni, which had larger peak values in autumn and spring respectively, the mean column averaging kernels typically has a larger peak in summer. Full article

To improve the accuracy of infrared radiation characteristics measurement in the aviation field, an infrared Fourier transform imaging spectrometer based on a double-swing solid angle reflector was designed. This imaging spectrometer operates in the 3–5 μm wavelength range and has a field of view of 1.7° × 1.7°. This article presents a comprehensive analysis of the system’s stray light and also studies the impact of external stray light on the imaging quality, along with the influence of internal stray light on the interference effects and the spectral resolution. It also present the design of a hood that suppresses the point source transmittance of the external stray light down to the order of 10⁻⁴. Based on this, we propose a method that incorporates the introduction of wedge and inclination angles. Additionally, a numerical range is provided for the addition of these angles on the beam splitter mirror and compensation plate. This ensures the effective suppression of any internal stray light. This study fills the gap in the knowledge about Fourier transform imaging spectrometers operating in the mid-infrared band for aviation applications, and proposes a suppression method suitable for interference systems, which is also suitable for Fourier transform imaging spectrometers based on other types of interferometers. This study broadens the application field of Fourier transform imaging spectrometers in stray light, and has great significance to promote the development of Fourier transform imaging spectrometer. Full article

The use of a dual-interference channels static Fourier transform imaging spectrometer based on stepped micro-mirror (D-SIFTS) for environmental gas monitoring has the advantages of high throughput, a compact structure, and a stable performance. It also has the characteristics of both a broad spectral range and high spectral resolution. However, its unique structural features also bring many problems for subsequent data processing, mainly including the complex distribution of the interference data, the low signal-to-noise ratio (SNR) of infrared scene images, and a unique inversion process of material information. To this end, this paper proposes a method of image and spectra information processing and gas concentration inversion. A multiscale enhancement algorithm for infrared images incorporating wavelet denoising is used to obtain high-quality remote sensing scene images, and spectral reconstruction optimization algorithms, such as interference intensity sequence resampling, are used to obtain accurate spectral information; the quantitative calibration model of the detected gas concentration is established to achieve high-precision inversion of gas concentration, and its distribution is visualized in combination with the scene image. Finally, the effectiveness and accuracy of the data processing algorithm are verified through the use of several experiments, which provide essential theoretical guidance and technical support for the practical applications of D-SIFTS. Full article

Models of particle acceleration in solar eruptive events suggest that roughly equal energy may go into accelerating electrons and ions. However, while previous solar X-ray spectroscopic imagers have transformed our understanding of electron acceleration, only one resolved image of γ-ray emission from solar accelerated ions has ever been produced. This paper outlines a new satellite instrument concept—the large imaging spectrometer for solar accelerated nuclei (LISSAN)—with the capability not only to observe hundreds of events over its lifetime, but also to capture multiple images per event, thereby imaging the dynamics of solar accelerated ions for the first time. LISSAN provides spectroscopic imaging at photon energies of 40 keV–100 MeV on timescales of ≲10 s with greater sensitivity and imaging capability than its predecessors. This is achieved by deploying high-resolution scintillator detectors and indirect Fourier imaging techniques. LISSAN is suitable for inclusion in a multi-instrument platform such as an ESA M-class mission or as a smaller standalone mission. Without the observations that LISSAN can provide, our understanding of solar particle acceleration, and hence the space weather events with which it is often associated, cannot be complete. Full article

A novel channel-modulated static birefringent Fourier transform imaging spectropolarimeter (CSBFTIS) is introduced, which is based on a double Wollaston prism (DWP). With an adjustable air gap (AG), the spectral resolution can be adjusted by changing the AG. The CSBFTIS combines the channel-modulated imaging spectropolarimeter and the slit-free static birefringent Fourier transform imaging spectrometer technology with adjustable spectral resolution. The device is compact and robust, with a wide spectral range and a large luminous flux. Compared with various previous spectropolarimeters, it can greatly reduce the size of the spectral image data to adapt to different application requirements. A prototype is built, and simulation and experiments are carried out, and the results prove the effectiveness of the method. Full article

Infrared imaging spectrometers detect and identify targets by collecting spectral and image information. However, when detecting small temperature differences and dynamic targets, the accuracy of infrared detection is reduced, the traditional scanning structure detection time is longer, the real-time performance is poor and it is easy to introduce motion artifacts. This paper proposes an infrared polarization snapshot spectral imaging system (PSIFTIS) based on a polarizer array, a lens array and a roof-shaped stepped micromirror. Polarized light can solve the problem of small-temperature-difference target recognition by characterizing the surface properties of materials. Lens arrays utilize multi-aperture imaging to achieve snapshot detection of targets. The system can obtain 4D data information, including polarization, in a single measurement cycle. This study completed the overall optical design of a PSIFTIS and an optical simulation experiment using it. Finally, a system prototype was built in the laboratory and a polarization spectrum detection experiment was carried out. The experimental results show that the PSIFTIS could accurately obtain the polarization spectrum information for the target, the spectral resolution reached 7.8 cm⁻¹ and the Stokes measurement error was less than 5%. Full article

The optical displacement calculation formula for the dual Wollaston prism is derived for any incident plane and angle using the wave normal tracing method. The validity of the calculation is confirmed by comparing it with captured photographs. The relationship between the maximum incident aperture, incident angle, and incident surface angle is given when plane and spherical waves incident on the prism group. The aperture utilization of a novel static birefringent Fourier transform imaging spectrometer based on dual Wollaston prisms is also analyzed. The relationship of aperture utilization with the incident surface angle, incident angle, and prisms’ air gap thickness is given. The results provide a theoretical foundation for fully describing the optical transmission characteristics of the dual Wollaston prism group and developing a high-performance spatio-tempo hybrid modulated birefringent spectral zoom Fourier transform imaging spectrometer. Full article

It is important to obtain information on an instantaneous target. A high-speed camera can capture a picture of an immediate scene, but spectral information about the object cannot be retrieved. Spectrographic analysis is a key tool for identifying chemicals. Detecting dangerous gas quickly can help ensure personal safety. In this paper, a temporally and spatially modulated long-wave infrared (LWIR)-imaging Fourier transform spectrometer was used to realize hyperspectral imaging. The spectral range was 700~1450 cm⁻¹ (7~14.5 μm). The frame rate of infrared imaging was 200 Hz. The muzzle-flash area of guns with calibers of 5.56 mm, 7.62 mm, and 14.5 mm were detected. LWIR images of muzzle flash were obtained. Spectral information on muzzle flash was obtained using instantaneous interferograms. The main peak of the spectrum of the muzzle flash appeared at 970 cm⁻¹ (10.31 μm). Two secondary peaks near 930 cm⁻¹ (10.75 μm) and 1030 cm⁻¹ (9.71 μm) were observed. Radiance and brightness temperature were also measured. The spatiotemporal modulation of the LWIR-imaging Fourier transform spectrometer provides a new method for rapid spectral detection. The high-speed identification of hazardous gas leakage can ensure personal safety. Full article
