Search Results (198)

In free space optical (FSO) communications, signals are affected by turbulence when transmitted through the atmosphere. Fluctuations in intensity caused by atmospheric turbulence lead to an increase in the bit error rate of FSO systems. Deep learning (DL), as a current research hotspot, offers a promising approach to improve the accuracy of signal detection. In this paper, we propose a signal detection method based on a bidirectional gated recurrent unit (BiGRU) neural network for FSO communications. The proposed detection method considers the temporal correlation of received signals due to the properties of the BiGRU neural network, which is not available in existing detection methods based on DL. In addition, the proposed detection method does not require channel state information (CSI) for channel estimation, unlike maximum likelihood (ML) detection technology with perfect CSI. Numerical results demonstrate that the proposed BiGRU-based detector achieves significant improvements in bit error rate (BER) performance compared with a multilayer perceptron (MLP)-based detector. Specifically, under weak turbulence conditions, the BiGRU-based detector achieves an approximate 2 dB signal-to-noise ratio (SNR) gain at a target BER of ${10}^{-6}$ compared to the MLP-based detector. Under moderate turbulence conditions, it achieves an approximate 6 dB SNR gain at the same target BER of ${10}^{-6}$. Under strong turbulence conditions, the proposed detector obtains a 6 dB SNR gain at a target BER of ${10}^{-4}$. Additionally, it outperforms conventional methods by more than one order of magnitude in BER under the same turbulence and SNR conditions. Full article

Wavefront aberrations caused by thermal flows or arising from the quality of optical components can significantly impair wireless communication links. Such aberrations may result in an increased error rate in the received signal, leading to data loss in laser communication applications. In this study, we explored a newly developed combined stochastic gradient descent optimization algorithm aimed at compensating for optical distortions. The algorithm we developed exhibits linear time and space complexity and demonstrates low sensitivity to variations in input parameters. Furthermore, its implementation is relatively straightforward and does not necessitate an in-depth understanding of the underlying system, in contrast to the Stochastic Parallel Gradient Descent (SPGD) method. In addition, a developed switch-mode approach allows us to use a stochastic component of the algorithm as a rapid, rough-tuning mechanism, while the gradient descent component is used as a slower, more precise fine-tuning method. This dual-mode operation proves particularly advantageous in scenarios where there are no rapid dynamic wavefront distortions. The results demonstrated that the proposed algorithm significantly enhanced the total collected power of the beam passing through the 10 μm diaphragm that simulated a 10 μm fiber core, increasing it from 0.33 mW to 2.3 mW. Furthermore, the residual root mean square (RMS) aberration was reduced from 0.63 μm to 0.12 μm, which suggests a potential improvement in coupling efficiency from 0.1 to 0.6. Full article

Free-space optical (FSO) communication systems face significant challenges from atmospheric turbulence, which induces time-correlated fading and burst errors that critically affect link reliability. This paper presents a comprehensive end-to-end CCSDS O3K simulation platform with detailed atmospheric channel and pointing error modeling, enabling realistic performance evaluation. The atmospheric channel model follows ITU-R P.1622-1 recommendations and incorporates amplitude scintillation with temporal correlation using Ornstein–Uhlenbeck processes, while the pointing error model captures beam misalignment effects inherent in satellite optical links. Through extensive Monte Carlo simulations, we investigate the impact of coherence time, and interleaving depth on system performance. Results show that deeper interleaving significantly improves reliability under realistic channel conditions, providing valuable design guidance for CCSDS-compliant optical communication systems. This study does not propose new algorithms or protocols; rather, it delivers the first end-to-end CCSDS-compliant simulation framework under realistically modeled turbulence and pointing errors. Accordingly, the results offer meaningful reference value and practical benchmarks for inter-satellite optical communication research and system design. Full article

The implementation of efficient free-space channels is fundamental for both classical and quantum free-space optical (FSO) communication. This can be challenging for fiber-coupled receivers, due to the time variant inhomogeneity of the refractive index that can cause strong fluctuations in the power coupled into the single-mode fiber (SMF), and requires the use of adaptive optics (AO) systems to correct the atmospheric-induced aberrations. In this work, we present two adaptive optic systems, one using a fast-steering prism (FSP) for the correction of tip-tilt and a second one based on a multi-actuator deformable lens (MAL), capable of correcting up to the third order of Zernike’s polynomials. We test both systems at telecom wavelength both with artificial turbulence in the laboratory and on a free-space channel, demonstrating their effectiveness in increasing the fiber coupling efficiency. Full article

The rapid growth of data traffic in modern communication networks has led to the development of advanced high-capacity multiplexing methods. Orbital angular momentum (OAM)–based mode division multiplexing (MDM) offers a promising scheme by utilizing the orthogonality of helical phase modes to transmit independent data streams simultaneously. In this work, we introduce a novel adjacent mode separation method exploiting OAM’s concentric intensity characteristics for free-space optical (FSO) spatial multiplexing. This method enables the detection of each OAM channel based on its distinctive ring-shaped intensity distribution, contrary to the conventional on-axis phase flattening approach. Two spatially multiplexed signals with different modes are separated by aligning its concentric intensity ring with the active area of an avalanche photodiode (APD), effectively suppressing crosstalk from adjacent modes. Experimental measurements demonstrate that our method achieves a bit-error-rate (BER) performance not exceeding the forward error correction (FEC) threshold, $3.8\times {10}^{-3}$, at up to 160 Mbps of data rate, while the conventional detection scheme fails beyond 5 Mbps. The analysis of the eye diagram confirms that our concentric-ring demultiplexing system achieves a high signal-to-noise ratio (SNR) and mode selectivity. These results support the feasibility of the proposed concentric intensity-based mode separation methodology for constructing compact, high-throughput OAM-multiplexed FSO links. Full article

The rapid development of intelligent high-speed railways (HSRs) has significantly improved the transportation efficiency of modern transit systems, while also imposing higher bandwidth demands on mobile communication systems. Free-space optical (FSO) communication technology, as a promising solution, can effectively meet the high-speed data transmission requirements in intelligent HSR scenarios. In this paper, we consider an intelligent HSR system based on beamwidth-adaptive FSO communication and investigate the coverage performance of the system. Different from the circular cells used in traditional radio frequency wireless communication systems, this paper focuses on the coverage problem of narrow-strip-shaped cells in HSR systems based on FSO communication. When the transmitter emits a wide beam, the channel gain includes geometric loss, atmospheric attenuation, and atmospheric turbulence. When the transmitter emits a narrow beam, the channel gain includes pointing error, atmospheric attenuation, and atmospheric turbulence. To adapt the width of the transmitter’s beam, we propose a beamwidth-adaptive HSR system and a beamwidth-adaptive method. Furthermore, we derive closed-form expressions of the edge coverage probability (ECP) and the percentage of cell coverage area (CCA), where the ECP is the probability that the received signal-to-noise ratio at the cell edge is greater than or equal to a given threshold, and the percentage of CCA dictates the percentage of locations within a cell that are not in outage. The accuracy of the derived theoretical expressions is validated through Monte-Carlo simulations. The average relative error of the ECP between theoretical and simulation results is only 0.035%, and the corresponding error of the percentage of CCA is 0.087%. In addition, the impacts of factors such as cell diameter, transmission power, signal-to-noise ratio threshold, and weather visibility on coverage performance are also discussed. Full article

Free-space optical (FSO) communications have emerged as a promising complement to conventional radio-frequency (RF) systems due to their high bandwidth, low interference, and license-free spectrum. Visible-light FSO communication, using laser diodes or LEDs, offers potential for short-range data links, but performance is highly wavelength-dependent under varying atmospheric conditions. This study presents an experimental evaluation of three visible laser diodes at 650 nm (red), 532 nm (green), and 405 nm (violet), focusing on their optical output power, quantum efficiency, and modulation behavior across a range of driving currents and frequencies. A custom laboratory testbed was developed using an Atmega328p microcontroller and a Visual Basic control interface, allowing precise control of current and modulation frequency. A silicon photovoltaic cell was employed as the optical receiver and energy harvester. The results demonstrate that the 650 nm red laser consistently delivers the highest quantum efficiency and optical output, with stable performance across electrical and modulation parameters. These findings support the selection of 650 nm as the most energy-efficient and versatile wavelength for short-range, cost-effective visible-light FSO communication. This work provides experimentally grounded insights to guide wavelength selection in the development of energy-efficient optical wireless systems. Full article

This paper proposes an intelligent power adaptation framework for Free-Space Optics (FSO) communication systems operating under different weather conditions exploiting a deep learning (DL) analysis of received eye diagram images. The system incorporates two Convolutional Neural Network (CNN) architectures, LeNet and Wide Residual Network (Wide ResNet) algorithms to perform regression tasks that predict received signal quality metrics such as the Quality Factor (Q-factor) and Bit Error Rate (BER) from the received eye diagram. These models are evaluated using Mean Squared Error (MSE) and the coefficient of determination (${\mathrm{R}}^2$ score) to assess prediction accuracy. Additionally, a custom CNN-based classifier is trained to determine whether the BER reading from the eye diagram exceeds a critical threshold of ${10}^{-4}$; this classifier achieves an overall accuracy of 99%, correctly detecting 194/195 “acceptable” and 4/5 “unacceptable” instances. Based on the predicted signal quality, the framework activates a dual-amplifier configuration comprising a pre-channel amplifier with a maximum gain of 25 dB and a post-channel amplifier with a maximum gain of 10 dB. The total gain of the amplifiers is adjusted to support the operation of the FSO system under all-weather conditions. The FSO system uses a 15 dBm laser source at 1550 nm. The DL models are tested on both internal and external datasets to validate their generalization capability. The results show that the regression models achieve strong predictive performance, and the classifier reliably detects degraded signal conditions, enabling the real-time gain control of the amplifiers to achieve the quality of transmission. The proposed solution supports robust FSO communication under challenging atmospheric conditions including dry snow, making it suitable for deployment in regions like Northern Europe, Canada, and Northern Japan. Full article

In response to the increasing demands for reliable, fast, and secure communications beyond 5G scenarios, the high-capacity networks have become a focal point. Quantum communication is at the forefront of this research, offering unmatched throughput and security. A free space optics (FSO) communication system integrated with fiber-end is designed and investigated using the Bennett–Brassard 1984 quantum key distribution (BB84-QKD) protocol. Simulation results show that reliable transmission can be achieved over a 10–15 km fiber length with a signal power of −19.54 dBm and high optical-to-signal noise of 72.28–95.30 dB over a 550 m FSO range under clear air, haze, fog, and rain conditions at a data rate of 1 Gbps. Also, the system using rectilinearly and circularly polarized signals exhibits a Stokes parameter intensity of −4.69 to −35.65 dBm and −7.7 to −35.66 dBm Stokes parameter intensity, respectively, over 100–700 m FSO range under diverse weather conditions. Likewise, for the same scenario, an FSO range of 100 m incorporating 2.5–4 mrad beam divergence provides the Stokes power intensity of −6.03 to −11.1 dBm and −9.04 to −14.12 dBm for rectilinearly and circularly polarized signals, respectively. Moreover, compared to existing works, this work allows faithful and secure signal transmission in free space, considering FSO–fiber link losses. Full article

This paper proposes a systematic ground experimental method to address the insufficient initial pointing accuracy of optical terminals in free space optical communication (FSO). By utilizing a multi-coordinate system transformation model combined with geodetic coordinates obtained from a Global Navigation Satellite System (GNSS), the elevation and azimuth angles of the optical terminal are calculated to achieve initial pointing. High-precision horizontal installation and true north direction calibration are accomplished using a GNSS dual-antenna system and a digital inclinometer to suppress mechanical installation errors. Furthermore, an iterative stellar calibration method is proposed, leveraging ephemeris to precompute stellar positions and optimize correction values through multiple observations, significantly improving pointing accuracy. In a 104.68 km span experiment conducted in the Qinghai Lake area, the azimuth and elevation angle errors of the optical terminal were reduced to −0.0293° and −0.0068°, respectively, with the uncertainty region narrowed to 0.0586°. These results validate the effectiveness of the proposed method in high-precision rapid link establishment, providing technical support for the engineering application of satellite-to-ground laser communication. Full article

Free-space optical (FSO) communication is a promising high-capacity solution for future wireless networks, particularly for backhaul and fronthaul links in 5G and emerging 6G systems. However, it remains highly vulnerable to environmental impairment, especially in arid regions prone to dust storms. While prior studies have addressed atmospheric effects such as fog and turbulence, the specific impact of dust on signal performance remains insufficiently explored. This work presents a probabilistic modeling framework for evaluating the performance of an intensity modulation/direct detection (IM/DD) FSO system under dust storm conditions. Using a controlled laboratory environment, we conducted measurements of the optical signal under dust-induced channel conditions using real-world dust samples collected from an actual dust storm. We identified the Beta distribution as the most accurate model for the measured signal fluctuations. Closed-form expressions were derived for average bit error rate (BER), outage probability, and channel capacity. The close agreement between the analytical, approximate, and simulated results validates the proposed model as a reliable tool for evaluating FSO system performance. The results show that the forward error correction (FEC) BER threshold of ${10}^{-3}$ is achieved at approximately 10.5 dB, and the outage probability drops below ${10}^{-3}$ at 10 dB average SNR. Full article

Free space optics (FSO) aims to perform as one of the best optical wireless channels to design a reliable, flexible, and cost-effective communication system. In FSO systems, mode-division multiplexing (MDM) transmission is a proven technique to expand transmission capacity per communication link. Thus, a 16 × 10 Gbps MDM-FSO system using fiber Bragg grating (FBG) sensors for the coexistence of communication and sensing, exploiting FSO links to transmit distinct Laguerre-Gaussian (LG) beams at a 1000–1900 m range, is proposed. The results illustrate that the system can transmit higher-order LG beams with sensor temperatures of 20–120 °C over a 1500 m range under clear air, drizzle, and moderate haze weather. Also, an improved performance is achieved in gamma–gamma compared to the log-normal distribution model for 10⁻⁶–10^−2.5 index modulation under weak-to-strong turbulence. The proposed system is capable of offering a high optical signal-to-noise ratio (OSNR) and gain of 113.39 and 15.43 dB, respectively, at an aggregate data rate of 160 Gbps under different atmospheric scenarios. Moreover, the proposed system achieves better system performance compared to existing works. Full article

To further enhance the stability and security of image transmission in FSO (Free Space Optics) aviation platforms, this paper proposes a communication transmission scheme that integrates a chaotic image encryption system with the HAP (high-altitude platform) environment. This scheme effectively combines the chaotic image encryption algorithm with the atmospheric turbulence channel transmission process, improving the anti-interference capabilities and security of HAP optical communication for image transmission. First, a five-dimensional hyperchaotic system with complex dynamic characteristics is introduced, and the system’s chaotic behaviors and dynamic properties are explored. The improved system model incorporates chaotic mapping and DNA coding techniques, forming a robust chaotic image encryption system, whose performance is experimentally validated. Next, the feasibility of integrating the chaotic image encryption system with HAP optical communication is discussed. A detailed description of the corresponding turbulence model and test conditions is provided. To verify the scheme’s feasibility, plaintext images of varying sizes are selected for experiments, comparing the transmission performance of both unencrypted and encrypted images under three turbulence levels: weak, medium, and strong. The impact on image communication quality is quantitatively analyzed using PSNR (Peak Signal-to-Noise Ratio) and SSIM (Structural Similarity Index measure). Finally, the effect of malicious interception attacks, caused by noise interference from different levels of atmospheric turbulence, is examined. The robustness and feasibility of the proposed scheme are validated, providing a promising approach for integrating HAP optical communication’s anti-turbulence capabilities with chaotic image encryption. Full article

Recently, free-space optical (FSO) communication systems utilizing unmanned aerial vehicle (UAV) relays have garnered significant attention. Integrating UAV relays into FSO communication and employing cooperative diversity techniques not only fulfill the need for long-distance transmission but also enable flexible adjustments of relay positions based on the actual environment. This paper investigates the performance of a parallel-UAV-relay-based FSO communication system. In the considered system, the channel fadings include atmospheric loss, atmospheric turbulence, pointing errors, and angle-of-arrival fluctuation. Using the established channel model, we derive a tractable expression for the probability density function of the total channel gain. Then, we derive closed-form expressions of the system outage probability (OP) and average bit error rate (ABER). Moreover, we also derive the asymptotic OP and ABER for a high-optical-intensity regime. Our numerical results validate the accuracy of the derived theoretical expressions. Additionally, the effects of the number of relay nodes, the field of view, the direction deviation, the signal-to-noise ratio threshold, the atmospheric turbulence intensity, the transmit power, and the transmission distance on the system’s performance are also discussed. Full article

Free-Space Optical (FSO) communication systems operating in arid regions, especially those envisioned for current and future 5G/6G networks, are significantly affected by dust storms, which cause signal attenuation and service disruptions. While previous studies have proposed deterministic models to characterize attenuation in both controlled and real environments, probabilistic modeling approaches remain largely unexplored, particularly for capturing the variability of FSO signal attenuation under dust conditions. This study proposes a probabilistic model for FSO signal attenuation developed from experiments conducted in a repeatable and well-characterized controlled dust chamber. The chamber-based setup allowed precise manipulation of dust visibility levels and consistent data collection, serving as a benchmark for statistical modeling. We analyzed the measurements to fit appropriate probability distributions for modeling the signal attenuation as a random variable. The empirical data were fitted to several candidate distributions, and the Johnson SB distribution consistently achieved superior performance with $R^2\ge 0.95$ and RMSE and MAE values close to zero across all dust conditions. The results offer a foundational framework for modeling dust-induced attenuation as a random process, providing statistical bounds for FSO link planning in desert environments. Full article
