The Combined Cycle Combined Heat and Power (CCCHP) systems are an effective way to improve energy efficiency and reduce emissions. This paper examines the energy and environmental impact of CCCHP combustion using waste biomass like the biomass of spent wash (SW), waste crankcase oil (WCO), and bagasse (BA) using an advanced Ebsilon Professional 16 software simulation model. The simulations were designed to achieve 150 MW total power output and 25 MW heating energy. Simulation results indicate that the minimum fuel feed requirement of a 10.762 kg/s flow rate was recorded at the highest calorific value (CV) fuel briquette of 1:8 ratio BA–WCO. The BA–WCO system demonstrates a significantly higher heat recovery capacity in the heat recovery steam generator (HRSG) compared to the BA–SW system. At a 1:8 ratio, it recovers 1463 kJ/kg versus 583 kJ/kg, and 1391 kJ/kg versus 498 kJ/kg at a 1:3 ratio. The CCCHP efficiency was much higher for BA–WCO than those developed from spent wash–bagasse, yielding up to 41.1% compared to a maximum of 26.71%. Furthermore, the BA–WCO system showed a better result than the BA–SW CCCHP system by emitting a low amount of flue gas with low temperature. Full article

This paper aims to evaluate the feasibility and performances of a novel hybrid solar–gas system, which provides electric power and cooling. By using Ebsilon (V15.0) software, the operation, advanced exergic and economic analyses of this hybrid system are conducted. The analysis results show that the total electric power and energy efficiency of the hybrid system are 96.0 MW and 45.8%. The solar energy system contributes an electric power of 9.0 MW. The maximum cooling load is 69.66 MW. The exergic loss and exergic efficiency of the whole hybrid system are 119.1 MW and 44.6%. The combustion chamber (CC) has the maximum exergic loss (56.5 MW). The exergic loss and exergic efficiency of the solar direct steam generator (SDSG) are 28.5 MW and 36.2%. For the air compressor (AC), CC, heat recovery steam generator (HRSG) and refrigeration system (CSS), a considerable part of the exergic loss is exogenous. The avoidable exergic loss of the CC is 11.69 MW. For the SDSG, there is almost no avoidable exergic loss. Economic analysis shows that for the hybrid system, the levelized cost of energy is 0.08125 USD/kWh, and the dynamic recycling cycle is 5.8 years, revealing certain economic feasibility. The results of this paper will contribute to the future research and development of solar–gas hybrid utilization technology to a certain extent. Full article

The use of renewables in heat production requires methods to overcome the issue of asynchronous heat load and energy production. The most effective method for analyzing the intricate thermal dynamics of an existing building is through transient simulation, utilizing real-world weather data. This approach offers a far more nuanced understanding than static calculations, which often fail to capture the dynamic interplay of environmental factors and building performance. Transient simulations, by their nature, model the building’s thermal behavior over time, reflecting the continuous fluctuations in temperature, solar radiation, and wind speed. Leveraging actual meteorological data enables the simulation model to faithfully capture system dynamics under realistic operational scenarios. This is crucial for evaluating the effectiveness of heating, ventilation, and air conditioning (HVAC) systems, identifying potential energy inefficiencies, and assessing the impact of various energy-saving measures. The simulation can reveal how the building’s thermal mass absorbs and releases heat, how solar gains influence indoor temperatures, and how ventilation patterns affect heat losses. In this paper, a household heating system consisting of an air source heat pump, PV, and buffer tank is simulated and analyzed. The 3D model accurately represents the building’s geometry and thermal properties. This virtual representation serves as the basis for calculating heat losses and gains, considering factors such as insulation levels, window characteristics, and building orientation. The approach is based on the calculation of building heat load based on a 3D model and EN ISO 52016-1 standard. The heat load is modeled based on air temperature and sun irradiance. The heating system is modeled in EBSILON professional 16.00 software for the calculation of transient 10 min time step heat production during the heating season. The results prove that a buffer tank with the right heat production control system can efficiently increase the auto consumption of self-produced PV electric energy, leading to a reduction in environmental effects and higher economic profitability. Full article

The material in the mold of the injection-molding machine releases significant latent heat of solidification during the cooling process. The efficient recovery and utilization of this waste heat is crucial for improving energy efficiency. A novel integrated energy management system for mold cooling/heat pump/material preheating is proposed in this paper. Taking the symmetrical thermodynamic performance of the heat pump components as the basis and optimizing the system configurations, four system configurations were investigated: MC/BHP/MPCC, MC/RHP/MPCC, MC/HP/MP-IEMS, and MC/DCHP/MP-IEMS, utilizing EBSILON software. The performance of the systems was evaluated through the coefficient of performance (COP) and whole cycle energy efficiency (η). The T-q, T-s, and P-h diagrams were analyzed. It was found that, under comparative operating conditions, both the MC/HP/MP-IEMS and MC/DCHP/MP-IEMS systems exhibited significantly higher COP and η than the MC/BHP/MPCC and MC/RHP/MPCC systems. MC/HP/MP-IEMS achieves a COP of 13.66 and η of 22.09. Similarly, MC/DCHP/MP-IEMS achieves a COP of 14.00 and η of 22.53. The paper optimizes the other three systems using MC/BHP/MPCC as the comparison condition. Optimal cycle performances are achieved with COP and η values of 9, 16, 16, and 9, 26, 25, respectively. A comparison of the thermodynamic performance of five different refrigerants revealed that R123 and R245fa have superior overall performance. This study provides theoretical support for the engineering implementation of integrated energy management systems for injection-molding machines. Full article

Combined Cycle Combined Heat and Power (CCCHP) systems enhance energy efficiency and reduce emissions by simultaneously generating electricity and heat. This study presents the energy and exergy performance, environmental impact, and efficiency optimization of CCCHP combustion systems using Ebsilon Professional 16 software simulation. Three fuel combustion CCCHP systems of coal, biomass, and coal–biomass cofiring were simulated for 150 MW of total power output with 125 MW of electrical power and 25 MW of a heating energy system. The sensitivity analysis was performed for 16 different systems with the fuel moisture content varying from 10% to 40% (w/w) to identify the energy and environmental effect on simulated CCCHP systems. The simulation results indicate that increasing biomass moisture content enhanced flue gas energy and improved the Rankine cycle performance. The energy efficiency of biomass and coal–biomass combustion CCCHP systems increased from 56.90% to 67.22% and 56.94% to 62.37, with the moisture content rising from 10% to 30% (w/w) and 10% (w/w) to 25.56% (w/w), respectively, but declined beyond these. Moreover, the exergy efficiency showed a similar pattern peaking at 50.06% in biomass samples and 50.10% in the cofiring sample. Furthermore, the environmental impact, CO₂ and SO₂ emission concentrations reduced from 22.42% (w/w) to 20.77 (w/w) and 0.66% to 0.61%, respectively, with an increase in fuel moisture content from 10% to 25.56% in a biomass cofired combustion CCCHP system. Full article

To address China’s small coal power units facing shutdown and retirement, which urgently need life cycle extension and renovation, a complete solar thermal storage simulation power generation system based on the original site of a decommissioned thermal power unit is developed using Ebsilon software in this study. The operational characteristics of the simulated system are studied in depth to build a system with integrity and stability that can carry out economic and stable power production. The results of simulation tests on the solar collector system and the thermal storage subsystem show that the energy storage rate of the energy storage subsystem is affected by light intensity and significantly increases at approximately 8:00 a.m. The annual power generation capacity of the system is influenced by the energy storage hours set by the energy storage subsystem, and the annual power generation capacity increases more significantly when the energy storage hours are controlled within the range of 5–8 h. The operating efficiency of the corresponding subsystem can be improved by selecting a suitable location for the light intensity required and controlling the effective reflectivity of the mirror field and the energy storage hours, which can ensure the system’s stable operation. The research results provide theoretical guidance for reusing and transforming retired thermal power units. Full article

This study quantitatively analysed the influence of cooling water parameters on the performance of a modular high-temperature gas-cooled reactor (MHTGR) nuclear power plant (NPP). The secondary circuit system and cold-end system were modelled using EBSILON software, version 16.0. The influence of cooling water inlet temperature and mass flow rate on the thermal performance of the secondary circuit system was analysed over the full power range with the goal of optimising net power. Under 100% rated condition, for each 1 °C increase in cooling water inlet temperature between 10 and 33 °C, the net power and cycle efficiency decreased by 0.67 MW and 0.14%, respectively, whereas the heat consumption rate increased by 28.72 kJ/(kW·h). The optimal cooling water mass flow rates corresponding to cooling water inlet temperatures of 16 °C and 33 °C were obtained. The optimal cooling water mass flow rate decreased nonlinearly with decreasing power levels. At a cooling water inlet temperature of 33 °C, an increase in cooling water mass flow rate from the designed value (7697.61 kg/s) to the optimal value (10,922.14 kg/s) resulted in a 1.03 MW increase in net power. These findings provide guidelines for MHTGR NPP operation optimisation and economic improvement, especially under high-temperature weather conditions. Full article

The present study investigates low-grade heat utilization in ejector refrigeration systems under hot climatic conditions. A variable area ejector is used to maximize the harvested heat from the generator of the solar system at peak times. Exergy, economic, and exergoeconomic analyses are conducted to evaluate the performance of the system. A thermodynamic model of the system has been developed using Ebsilon Professional software. Available experimental and theoretical data validate the results. The effects of properties of the working fluids, ejector geometry, and operation conditions are also evaluated. It was found that the coefficient of performance of the system reached 0.45 at a generator pressure of 3 bars. Furthermore, it was noticed that the overall exergy efficiency could be increased for a fixed generator temperature while increasing the ejector area ratio. A value of 21% exergetic efficiency was calculated for the system. The exergoeconomic analysis of the system demonstrated that heat exchangers are required to be improved thermodynamically at the expense of the capital investment cost. Full article

Thermal water desalination is one of the most important techniques to solve the water scarcity problem in many regions of the world. Out of around 7.8 billion people in the world, only about 6 billion of them have access to clean water; notably, climate change plays a major role in accelerating the evaporation rate of water from water bodies, which in turn increases the scarcity. Multi-stage flash, recognized to have a high rate of water production in comparison with other available technologies, accounts for 35% of water desalination facilities worldwide. This paper presents a detailed Excel model to evaluate the amount of energy required to drive 16 stages of multi-stage flash. This model aims to design and evaluate the amount of thermal energy required for such projects and optimize their performance by calibrating the governing parameters. Furthermore, the 16 stages were simulated via the Ebsilon 13.02 software package to match the results and evaluate the fulfillment of the plant requirements. The temperature drop of the brine stream was 2.34 °C/stage. The top brine temperature was 130 °C. The results show that 29.5 kg/s of superheated steam is required to desalinate 162 kg/s of 2500 kg/s influent mass flow of brine. The effect of water intake temperature was also examined by using Ebsilon. The performance ratio decreased from 5.49 to 2.66 when the water intake temperature decreased from 30 °C to 5 °C. Full article

The development of district heating systems results in a search for alternative heat sources. One of these is low-enthalpy geothermic energy, more available than traditional geothermal energy. However, utilization of these resources is difficult, due to the low quality of the produced heat. To utilize them, the heat pump system can be used. Such a system was designed for this case study of a city in a region of the Polish Lowlands. The data necessary for the design came from the project of the borehole and operational parameters of the existing heating plant. Four heat pump-cycle designs were proposed, modeled, and simulated using Ebsilon software. Afterward, the designs were optimized to achieve maximum coefficient of performance (COP) value. As a result of the simulation, the efficiency of each design was determined and the seasonal COP value was calculated with the annual measured heat demand of the plant. The system based on the cascade design proved the most efficient, with a seasonal COP of 7.19. The seasonal COP for the remaining basic, subcooling, and regenerator variants was 5.61, 3.73, and 5.60, respectively. The annual heat production of the designed system (22,196 MWh) was calculated based on the thermal power of the designed system and historical demand data. This paper presents a simulation methodology for assessment of the efficiency and feasibility of a heat pump system in district heating. Full article

Waste-to-energy (WtE) incineration is an important technique in waste management systems and waste hierarchy. It is used to treat approximately 63% of the waste in European countries. The flue gas volumetric rate and its composition are essential to determine and monitor the emissions from waste incineration plants. This paper presents two methodologies used to evaluate the emissions from incinerators during the design phase. The first consists of a set of equations applicable in Excel (calculation model), while the second is the built-in components in Ebsilon 13.2 software which simulates the emissions from a furnace. This paper also proposes a comprehensive flue gas cleaning system for a simulated waste incineration plant in Jordan. According to Ebsilon, the results showed that for a 25 kg/s loading rate, there was 258,514 mg/Nm³, 749.90 mg/Nm³, 890.20 mg/Nm³, and 717 mg/Nm³ of CO₂, NO₂, SO₂, and HCL, respectively. It was noted that these values relate to 1.5 of excess air ratio, where the effect of excess air ratio as the main driver for any combustion process was examined. The calculation method (set of equations) evaluated the flue gas volumetric rate, the CO₂ emissions, and N₂O and SO₂ levels. Ebsilon allows for simulation of the treatment stages and calculates the amount of materials required. Selective non-catalytic reduction (SNCR) (a built-in component in the Ebsilon library) was used to treat the NO₂ emissions. For 1.5 of excess air ratio, those emissions were reduced from 749 mg/Nm³ to 180 mg/Nm³, while the Ca(OH)₂ injector used to treat the SO₂ and HCL emissions reduced emissions from 890.20 mg/Nm³ and 717 mg/Nm³ to 44 mg/Nm³ and 7.16 mg/Nm³, respectively. Regarding the reduction in CO₂, the spherical carbon absorption concept was simulated using 9.4 kg/s of carbon which was adequate to verify a 91% reduction rate of CO₂. Furthermore, the calculation model was validated and approved as a valuable model to predict the flue gas volume, the oxygen required, and flue gas emissions at the design stage. Full article

The article presents results of thermodynamic analysis using a zero-dimensional mathematical models of a negative CO₂ emission power plant. The developed cycle of a negative CO₂ emission power plant allows the production of electricity using gasified sewage sludge as a main fuel. The negative emission can be achieved by the use this type of fuel which is already a “zero-emissive” energy source. Together with carbon capture installation, there is a possibility to decrease CO₂ emission below the “zero” level. Developed models of a novel gas cycle which use selected codes allow the prediction of basic parameters of thermodynamic cycles such as output power, efficiency, combustion composition, exhaust temperature, etc. The paper presents results of thermodynamic analysis of two novel cycles, called PDF0 and PFD1, by using different thermodynamic codes. A comparison of results obtained by three different codes offered the chance to verify results because the experimental data are currently not available. The comparison of predictions between three different software in the literature is something new, according to studies made by authors. For gross efficiency (54.74%, 55.18%, and 52.00%), there is a similar relationship for turbine power output (155.9 kW, 157.19 kW, and 148.16 kW). Additionally, the chemical energy rate of the fuel is taken into account, which ultimately results in higher efficiencies for flue gases with increased steam production. A similar trend is assessed for increased CO₂ in the flue gas. The developed precise models are particularly important for a carbon capture and storage (CCS) energy system, where relatively new devices mutually cooperate and their thermodynamic parameters affect those devices. Proposed software employs extended a gas–steam turbine cycle to determine the effect of cycle into environment. First of all, it should be stated that there is a slight influence of the software used on the results obtained, but the basic tendencies are the same, which makes it possible to analyze various types of thermodynamic cycles. Secondly, the possibility of a negative CO₂ emission power plant and the positive environmental impact of the proposed solution has been demonstrated, which is also a novelty in the area of thermodynamic cycles. Full article

This study investigates the hybridization scenario of a single-flash geothermal power plant with a biomass-driven sCO₂-steam Rankine combined cycle, where a solid local biomass source, olive residue, is used as a fuel. The hybrid power plant is modeled using the simulation software EBSILON^®Professional. A topping sCO₂ cycle is chosen due to its potential for flexible electricity generation. A synergy between the topping sCO₂ and bottoming steam Rankine cycles is achieved by a good temperature match between the coupling heat exchanger, where the waste heat from the topping cycle is utilized in the bottoming cycle. The high-temperature heat addition problem, common in sCO₂ cycles, is also eliminated by utilizing the heat in the flue gas in the bottoming cycle. Combined cycle thermal efficiency and a biomass-to-electricity conversion efficiency of 24.9% and 22.4% are achieved, respectively. The corresponding fuel consumption of the hybridized plant is found to be 2.2 kg/s. Full article

In order to solve the existing problems of large mean heat transfer temperature differences of regenerative air heaters and high superheat degrees of regenerative extraction steam in double reheat coal-fired power generation systems, two new design schemes of ultra-supercritical double reheat cycles are proposed, which can realize the deep boiler-turbine coupling among the heat transfer processes of air, feeding water and regeneration extraction steam on the base of the principle of energy level matching. A typical 1000 MW ultra-supercritical double reheat cycle system is selected as the reference system and the overall system model is built by using the Ebsilon simulation software. The performances of two new systems are analyzed by using both the exergy method and energy equilibrium method. The results show that net output powers of both new systems 1 and 2 increase by 6.38 MW and 6.93 MW, respectively, and the standard coal consumptions of power generation decrease by 1.65 g/kWh and 1.79 g/kWh, respectively. The off-design performances of new systems and the reference system are analyzed, and the results show that performances of two new systems are better than that of the reference system. The system flow of the new system 2 is more complex compared with that of the new system 1. Generally speaking, the performance of new system 1 is better than that of new system 2. On the basis of new system 1, new system 3 is further optimized and its full operating condition performance characteristics are analyzed. The standard coal consumption rate of new system 3 is reduced about 1 g/kWh at higher load, and around 0.2 g/kWh at low load. Full article

In this paper, the simulation software EBSILON is used to simulate the reheat units, and the reheat temperature control mode is deeply explored. In the benchmark system, the influence of different load intermediate point temperature on the flue gas recirculation (FGR) is analyzed. Then, the effects of load, coal quality, excess air factor, and feed water temperature on FGR are studied under the premise of intermediate point temperature as design value, and the cause for FGR change is analyzed by comparing the cutoff bypass flue (CBF) system. The results show that under any load, the FGR decreases with the increase of the intermediate point temperature, while under low load, the change of the intermediate point temperature has a greater impact on the FGR rate. When the intermediate point temperature remains constant, the FGR plunge has an increase of load at low load and is almost unchanged at high load; the FGR rate of coal with low calorific value and high moisture content is low and the coal with low volatile and high ash content has great influence on reheat steam temperature; and the excess air factor and feed water temperature are inversely proportional to the flue gas recirculation rate. In the CBF system, the change trend is similar to the reference system, but under the same working condition, the FGR rate is higher than the latter. Full article
