LED lighting plays a pivotal role in the illumination landscape owing to its substantial energy efficiency, prolonged operational lifespan, environmental advantages, superior light quality, and its capacity for advanced lighting control. Flicker in led lighting systems has emerged as a substantial concern and is appropriate to its potential opposing impacts on human health and visual comfort. Hence, this paper presents a comprehensive analysis, design, and mitigation strategy for flicker in a DC-DC led driver that incorporates a valley fill circuit. The initial stage of this investigation involves an analysis of a conventional cuk converter. However, it is noted that this converter produces an inverting output and experiences high current stress on the semiconductor switch. Consequently, to address these limitations, a non-inverting cuk converter (NICC) is introduced, resulting in a positive output, reduced voltage and current ripple and increased efficiency. To surmount these challenges, the implementation of a valley fill circuit is proposed. This addition facilitates the rapid attainment of a steady state, increases efficiency, and substantially reduces the output voltage and current ripple. An in-depth analysis of the stress imposed on the switch is conducted, leading to the development of a circuit designed to extend the operational life of the LED driver. Therefore, this paper compares the topologies of three different DC-DC cuk power converters. These converters include conventional cuk, non-inverting cuk (NICC), and non-inverting cuk with valley-fill. The performance metrics are examined and compared for all three topologies. The findings of this study affirm that the proposed driver circuit is highly effective in mitigating flicker, thereby enhancing the user experience and elevating the quality of led lighting, all while maintaining energy efficiency. The MATLAB simulations of these converters are performed to validate the theoretical results. Full article

This article reviews converter circuits with power factor correction considering issues that arise in implementing such circuits. The Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) procedure are employed for the review. Six topologies with power factor correction were considered including boost, buck, buck-boost, Cük, dual boost, and totem pole bridgeless. The main findings highlight various implementation alternatives for these converters, taking into account complexity, performance, control strategies, and applications. Additionally, the review identified studies based on simulation and hardware implementation. Several alternatives exist for research to improve energy conversion circuits using conventional techniques such as PI controllers or novel controllers using artificial intelligence techniques such as neural networks. Finally, it should be noted that converter circuits with power factor correction are crucial for developing various electrical and electronic devices in domestic and industrial applications. Full article

Electric Vehicles (EV) significantly contribute to reducing carbon emissions and promoting sustainable transportation. Among EV technologies, hybrid energy storage systems (HESS), which combine fuel cells, power batteries, and supercapacitors, have been widely adopted to enhance energy density, power density, and system efficiency. Bidirectional DC-DC converters are pivotal in HESS, enabling efficient energy management, voltage matching, and bidirectional energy flow between storage devices and vehicle systems. This paper provides a comprehensive review of bidirectional DC-DC converter topologies for EV applications, which focuses on both non-isolated and isolated designs. Non-isolated topologies, such as Buck-Boost, Ćuk, and interleaved converters, are featured for their simplicity, efficiency, and compactness. Isolated topologies, such as dual active bridge (DAB) and push-pull converters, are featured for their high voltage gain and electrical isolation. An evaluation framework is proposed, incorporating key performance metrics such as voltage stress, current stress, power density, and switching frequency. The results highlight the strengths and limitations of various converter topologies, offering insights into their optimization for EV applications. Future research directions include integrating wide-bandgap devices, advanced control strategies, and novel topologies to address challenges such as wide voltage gain, high efficiency, and compact design. This work underscores the critical role of bidirectional DC-DC converters in advancing energy-efficient and sustainable EV technologies. Full article

In a tristate converter the basic circuit topology is extended by an additional electronic switch and an additional diode. Three modes follow each other within one switching period. During the first mode M1, both electronic switches are on and both diodes are off. In the second mode M2, only the second switch is on and the first diode is conducting, and in mode M3, only the second diode is conducting. The voltage transformation ratio is a function of the two duty cycles of the electronic switches. In a typical tristate converter, the current flows through the second switch during the first two modes. In the converters treated here, the current is flowing through the second switch only during the second mode, so the losses are reduced compared to the normal tristate converter. This is shown for the Buck, the Buck–Boost, the Boost, the Zeta, the Cuk, the Super Boost, the quadratic Buck, and a reduced-duty cycle converter. The voltage transformation ratios are depicted in diagrams. As an example the reduced loss tristate Buck is used to demonstrate the derivation of the large and the small signal models. The transfer functions are also calculated and Bode plots are shown for an operating point. The voltage and the current stress of the converters are analyzed and the results are summarized in tables. The considerations are proved by simulations with the help of LTSpice. Full article

The Cuk power factor correction (PFC) converter with an input inductor operating discontinuous conduction mode (DCM) is widely utilized for its advantages of continuous input and output currents, low output voltage ripple, and simple control. However, the conventional Cuk PFC converter encounters issues such as the inability to achieve high power factor (PF) because of input current distortion and high intermediate capacitor voltage, especially at high input voltage. To achieve high PF, high efficiency, and low intermediate capacitor voltage simultaneously, by operating the output inductor at critical conduction mode (CRM) and adjusting input inductance from 170 µH to 930 µH within the half-line cycle dynamically with the transient rectified input voltage, a DCM-CRM Cuk PFC converter utilizing variable inductor control is proposed in this paper. The topology operational principle, control strategy, and key characteristics of the proposed converter have been studied. A 108 W experimental prototype was built and tested to validate the proposed converter. According to the comparative experimental results between the conventional converter and the proposed converter, it can be concluded that the proposed converter utilizing variable inductor control can enhance the PF and efficiency and reduce the intermediate capacitor voltage and total harmonic distortion (THD) of input current with universal 90~240 Vac input voltage range. Full article

Fuel cells (FCs) offer several operational advantages when integrated as a power source in electric vehicles (EVs). Since the voltage of these cells is typically low, usually less than 1 V, the power conversion system requires a DC–DC converter capable of providing a high voltage conversion ratio to match the input voltage of the motor propulsion system, which can exceed 400 V and reach up to 800 V. The modular DC–DC boost converter proposed in this paper is designed to achieve a high voltage step-up ratio for the input FC voltages through the use of isolated series-connecting boosting submodules connected. The power electronic topology employed in the submodules (SMs) is designed to provide a flexible output voltage while maintaining a continuous input current from the fuel cells with minimal current ripple to improve the FC’s performance. The proposed step-up modular converter provides several benefits including scalability, better controllability, and improved reliability, especially in the presence of partial faults. Computer simulations using MATLAB/SIMULINK^® software (R2024a) have been used to study the feasibility of the proposed converter when connected to a permanent magnet synchronous motor (PMSM). Also, experimental results using a 1 kW prototype composed of four SMs have been obtained to validate the performance of the proposed converter. Full article

A step-up DC/DC converter is required to match the fuel cell’s stack voltage with the DC-link capacitor of the propulsion system in fuel cell-based electric vehicles (FCEVs). Typically, the nominal voltage of a single fuel cell ranges from 0.5 V to 1 V, and the DC-link voltage usually lies between 400 V and 800 V. This article proposes a new modular step-up DC/DC converter capable of providing a wide voltage-boosting range from the input to the output side using series-connected isolated boosting submodules (SMs). Modified versions of boost and Cuk converters are designed and used as the SMs to deliver a flexible output voltage, combining the voltage-boosting capability with the ability to embed a medium/high-frequency transformer, which provides both galvanic isolation and an additional degree of voltage boosting while drawing a continuous input current from the fuel cell with minimal ripple, enhancing performance. The proposed modular converter offers the advantages of improved controllability, scalability, and greater reliability, particularly during partial faults. The feasibility of the proposed converter is demonstrated through computer simulations conducted using MATLAB/SIMULINK^® R2024a software where a DC link of 400 V is created from 50 V input sources. Additionally, a 1 kW small-scale prototype is designed and controlled using a TMS320F28335 digital signal processor to validate the mathematical analysis and simulation results, where the SMs are controlled to create a DC link of 100 V from four 25 V input sources with an electrical efficiency of approximately 95%. Full article

In this article, a multipurpose embedded system for testing organic photovoltaic modules is presented. It is designed to include all the features for real-time monitoring, data acquisition, and power conversion based on a Ćuk converter, providing useful data for scientific investigation of the outdoor operation of organic photovoltaic modules. The embedded system allows both the scan of the I–V curve and the continuous operation of the organic photovoltaic module, such as at its maximum power. Voltage and current at the terminals of the organic photovoltaic module under test and up to four temperatures are continuously measured and stored on a Secure Digital card. The communication interface allows the embedded system to connect with other instruments, such as irradiance sensors, with digital serial output. The embedded system is designed both for laboratory and in-the-field use: it can be powered either by the AC electrical grid or a battery, which can also operate as a backup battery. Galvanic isolation divides the embedded system into the field-side and the logic-side functional sections, providing improved noise immunity and safe operation. The main power distribution system within the embedded system is a +9 V bus; ultra-low-noise linear low dropout regulators provide the +3.3 V and +5 V regulated voltages to supply the analog and digital circuits within the logic-side section, and a flyback converter supplies the field-side section of the board. The proposed embedded solution is validated using an experimental setup built at SolarTechLab, Politecnico di Milano. The experimental results report the feasibility of the proposed embedded system. Full article

In order to address the energy imbalance issue of a series-connected lithium-iron battery pack, this paper proposes an active equalization method based on a reduced-order solving strategy for the Hanoi Tower problem. The proposed scheme utilizes a combined structure of a switching-network circuit and a bidirectional Cuk converter and leverages an ultracapacitor cell as the energy-transfer carrier. Simulation and comparison demonstrate that the exchange of unbalanced energy within the battery pack can be achieved. The proposed approach can effectively achieve various balancing modes such as cell-to-cell, cell-to-string, string-to-cell, and string-to-string with a relatively fast balancing speed. Full article

This study introduces an innovative version of a recently studied converter. A Double Dual Ćuk Converter was recently studied with advantages like the possibility of designing it for achieving a low-input current ripple. The proposed converter, called the Improved Double Dual Ćuk Converter, maintains the advantages of the former one, and it is characterized by requiring one less capacitor and inductor than its predecessor. This allows addressing the challenge of optimizing the topology to reduce component count without compromising the operation; this work proposes an efficient design methodology based on theoretical analysis and experimental validation. Results demonstrate that the improved topology not only retains the advantages of the previous version, including high efficiency and robustness, but also enhances power density by reducing the number of components. These advancements open new possibilities for applications requiring compact and efficient power converters, such as renewable energy systems, electric vehicles, and portable power supply systems. This work underscores the importance of continuous innovation in power converter design and lays the groundwork for future research aimed at optimizing converter topologies. A detailed discussion of the operating principles and modeling of the converter is provided. Furthermore, simulation outcomes highlighting differences in steady-state duration, output voltage, input current ripple, and operational efficiency are shared. The results from an experimental test bench are also presented to corroborate the efficacy of the improved converter. Full article

Renewable energy sources play a great role in the sustainability of natural resources and a healthy environment. Among these, solar photovoltaic (PV) systems are becoming more economically viable. However, as the utility of solar energy conversion systems is limited by the availability of sunlight, they need to be integrated with electrical energy storage systems to be more sustainable. This paper aims to improve the control performance of a hybrid energy storage system (HESS) with PV power generation as the primary power source. HESSs stabilize DC microgrid systems by compensating for demand generation mismatches. Batteries and supercapacitors are chosen as energy storage elements; batteries have a high energy density and are capable of supplying and absorbing energy over a long duration, while supercapacitors can store and deliver energy very quickly. To enhance the stability of the system, each storage element is connected to the DC bus using a bidirectional Ćuk converter, which offers high efficiency, a continuous current, and minimal switching losses. This study proposes a proportional–integral (PI) controller combined with the fast nonsingular integral terminal sliding mode control (FNITSMC) for HESSs to adjust the power balance in a DC microgrid. FNITSMC has the advantage of enhancing the system states to reach the equilibrium point of a long sliding surface with a fast convergence rate. The reference current for FNITSMC is obtained using a PI controller combined with a low-pass filter (LPF), which eliminates the peaking current spikes on the battery and diverts them towards the supercapacitor. The effectiveness of the proposed control scheme is validated through the real-time hardware-in-the-loop (HIL) simulations on Typhoon™ HIL-402 with added uncertainties, including load variations at various temperatures and irradiances. Full article

The main contribution of the paper concerns the use of an LCL trap filter with a PFC isolated Ćuk converter. Further, SiC MOSFET is used with a PFC isolated Ćuk converter designed for 50 W with 42 kHz in DCM. A small-signal model of the converter is cascaded with the filter model to investigate the effect of the filter on the whole system. Moreover, large-signal and small-signal models of the converter are compared to investigate the requirement of the small-signal analysis. In addition, an LTspice simulation using SiC MOSFET of the system is conducted and the results are compared by the applications for both LC and LCL trap filters with respect to different loading conditions. Further, the LCL trap filter is compared with the LC filter regarding the PF, THD, and efficiency. Controller design considering the filter is also presented. In addition, the converter is operated and compared using linear and nonlinear loads for each filter. Parametric variation in the filter components is investigated. As a result of the simulation and applications, the THD of the grid current is 4.83% and the PF is 0.998, meeting the standards, and the overall efficiency of the system is 85% with the LCL trap filter. It can be concluded that the presented filter provides better results than the LC filter. Full article

This paper presents a theoretical analysis of steady-state operation, control-oriented modeling for voltage control, and the experimental results of a DC–DC bidirectional converter based on a Cuk converter using a voltage-doubler concept. Due to the voltage-doubler concept, the voltage stress across semiconductors is reduced when compared with the conventional Cuk converter; this allows for the use of semiconductors with reduced drain–source on-resistance. Moreover, due to the input and output current source characteristics, the converter presents advantages, such as draining/injecting currents on both sides with low-ripple currents. Furthermore, the theoretical analysis is verified by experimental results obtained from a proof-of-concept prototype designed with a 250 V input voltage, a 360 V output voltage, 2 kW rated power, and 100 kHz switching frequency. Full article

In this paper, a control strategy of a cell-based multi-agent system is proposed to solve the problem of inconsistency of series lithium-ion battery packs. The bidirectional Cuk converter is utilized as an equalizing circuit serving for balancing adjacent cells in a pack. A SOC-based consensus control with a time-triggered mechanism (TTM) is proposed. In order to reduce the actuator updates, the control method is ameliorated by altering TTM to an event-triggered mechanism (ETM). Adjustable balancing currents are designed in both TTM and ETM methods for the acceleration of the equalization process. The cases in dynamic environments under externally imposed charging/discharging currents by adopting TTM and ETM methods are investigated in detail. By comparison, the simulations and hardware-in-the-loop (HIL) experiments with a Typhoon real-time simulator are illustrated to show that, both in standby or external charging/discharging conditions, the proposed ETM algorithms are superior to TTM’s in terms of equalization time and adaptability to the external environment. Full article

Small-signal models of dc-dc converters are often designed using a state-space averaging approach. This design can help discuss and derive the control-oriented and other frequency-domain attributes, such as input or output impedance parameters. This paper aims to model the dc-dc converters for PV application by employing a capacitor on the input side. The modeling, design, and analysis of the dc-dc converters regarding the input capacitor is limited in the literature. Five dc-dc converters, including buck, boost, buck-boost, ĆUK, and SEPIC converters, are designed and implemented using the state-space average modeling approach in MATLAB/Simulink. The circuit topology of each converter and the state-space matrices are derived considering every constraint. A rigorous and compelling analysis of the dc-dc converters is carried out to compare system stability and, ultimately, the dynamic performance. The output of the resulting small-signal models has been demonstrated in the time-domain against topology simulations. All the converters are exposed to unpredictable weather conditions and the simulations are carried out in the PSIM software. The perturb and observe (P&O) maximum power point tracking (MPPT) algorithm is applied in all the converters to ensure maximum power point (MPP) achievement. The results showcase that the boost converter outperforms all other converters in terms of stability, settling time, and overshoot. Full article
