Journal of Marine Science and Engineering

A series of laboratory experiments were conducted in a wave-current flume to investigate the scour evolution and scour morphology around tripod in combined waves and current. The tripod model was made using the 3D printing technology, and it was installed in seabed with three installation angles α = 0°, 90°and 180° respectively. In the present study, the scour evolution and scour characteristic were first analyzed. Then, the equilibrium scour depth S_eq was investigated. Furthermore, a parametric study was carried out to study the effects of Froude number F_r and Euler number E_u on equilibrium scour depth S_eq respectively. Finally, the effects of tripod’s structural elements on S_eq were discussed. The results indicate that the maximum scour hole appeared underneath the main column for installation angle α = 0°, 90° and 180°. The S_eq for α = 90° was greater than the case of α = 0° and α = 180°, implying the tripod suffered from more severe scour for α = 90°. When KC was fixed, the dimensionless time scale T* for α = 90° was slightly larger than the case of α = 0° and α = 180° and the T* was linearly correlated with U_cw in the range of 0.347 < U_cw < 0.739. The higher F_r and E_u both resulted in the greater scour depth for tripod in combined waves and current. The logarithmic formula can depict the general trend of S_eq and F_r (E_u) for tripod in combined waves and current. Full article

The Upper Indus Basin, in Pakistan’s western Salt Range, is home to the Zaluch Gorge. The sedimentary rocks found in this Gorge, belonging to the Chhidru Formation, were studied in terms of sedimentology and stratigraphy, and provide new insights into the basin paleogeographic evolution from the Precambrian to the Jurassic period. Facies analysis in the Chhidru Formation deposits allowed the recognition of three lithofacies (the limestone facies—CF1, the limestone with clay interbeds facies—CF2, and the sandy limestone facies—CF3) with five microfacies types (mudstone biomicrite—MF-1, wackestone-biomicrite—MF-2, wackestone-biosparite—MF-3, pack-stone-biomicrite—MF-4, and packstone-biosparite—MF-5), as well as their depositional characteristics. The identified carbonate and siliciclastic formations display various facies in a shallow marine environment, with different lithologies, sedimentary features, and energy conditions. It is thought that the depositional characteristics of these microfacies are closer to those of the middle to outer shelf. Because of the progressively coarsening outcrop sequence, this formation seems to be at the very top of the high stand system tract (HST). A modified dynamic depositional model of the Chhidru Formation is further built using outcrop data, facies information, and stratigraphy. According to this concept, the formation was deposited in the middle to inner shelf area of the shallow marine environment, during the Late-Permian period. The Permo-Triassic Boundary (PTB), which is the end of the type-1 series, is marked by this formation’s top. Full article

With a plan to achieve a target of 5.7 GW offshore wind power capacity in 2025, Taiwan anticipates building a 36-billion USD industry, which makes Taiwan a center of attention in the global marketplace of civil engineering construction. Aimed at Taiwan’s underwater foundations industries, this study is the first to develop an investment evaluation model (IEM) by applying FPR to obtain risk factor weights and calculate the overall investment risk value with a numerical scoring method. In a context where no precedent exists for reference, this study provides auxiliary and supportive tools to help builders to make the decision, based on objective indicators, whether to undertake an investment. To date, no research has been conducted to introduce a reasonable mathematical model that discusses the issue of partner selection in the field of offshore wind power. This study is the first paper to construct a SWARA-FTOPSIS partner selection model, which enables underwater foundations builders to take specific Taiwanese characteristics into account in their selection of the best partners to meet transportation, construction, and installation requirements. Finally, the study uses the case of the Taipower Offshore Wind Power Project (2nd phase) to verify the feasibility of this model. Full article

After collisions at sea, situation evaluation and analysis are very important to follow-up rescue operations. At present, there are few ways give weights in the current situational safety evaluation methods after collisions of marine ships. Most safety evaluation models ignore the blurred boundaries of evaluation grades. To solve these issues, this paper identifies the safety evaluation indicator system and evaluation standards, and establishes an after-collisions safety evaluation model of maritime ships based on the extension cloud theory. This model combines the extension cloud model, the analytic hierarchy process, the entropy weight method, and game theory. Using this model, the situation safety of two collisions was evaluated. The evaluation results reflect the effectiveness of the model. In order to ensure the safety of the lives and property of marine personnel, suggestions have been made to strengthen crew training, improve ship’s self-rescue ability at sea, and establish a complete marine emergency response rescue system. Full article

Numerical simulations were performed to study the long-distance evolution of irregular waves in deep water. It was observed that some solitons, which are the theoretical solutions of the nonlinear Schrödinger equation, emerged spontaneously as irregular wave trains propagated in deep water. The solitons propagated approximately at a speed of the linear group velocity. All the solitons had a relatively large amplitude and one detected soliton’s height was two times larger than the significant wave height of the wave train, therefore satisfying the rogue wave definition. The numerical results showed that solitons can persist for a long distance, reaching about 65 times the peak wavelength. By analyzing the spatial variations of these solitons in both time and spectral domains, it is found that the third-and higher-order resonant interactions and dispersion effects played significant roles in the formation of solitons. Full article

Caulerpa, a (sub) tropical seaweed, is a notorious taxonomic group and an invasive seaweed worldwide. Similar to several species that have been introduced to benthic habitats through aquariums, Caulerpa sertularioides has also been introduced into Korean aquariums, although it is not native to the region. Thus, it is necessary to evaluate the potential of this species for invading domestic macroalgal habitats. Therefore, an indoor mesocosm experiment was conducted to examine the ecophysiological invasion risk of non-native seaweed C. sertularioides under various climate conditions and exposure to three future climate scenarios: acidification (doubled CO₂), warming (5 °C increase from ambient temperature), and greenhouse (GR: combination of acidification and warming); additionally, we compared the invasion risk between future and present climates (control: 20 °C and 470 µatm CO₂). High CO₂ concentrations and increased temperatures positively affected the photosynthesis and growth of C. sertularioides. Photosynthesis and growth were more synergistically increased under GR conditions than under acidification and warming. Consequently, the performance of this potentially invasive species in the native macroalgal Korean habitat will be higher in the future in coastal environments. Therefore, proper management is required to prevent the geographic expansion of C. sertularioides in the Korean coastal ocean. Full article

A drogue is used to stabilise and straighten seismic arrays so that seismic waves can be well-received. To embed the effect of a cone-shaped drogue into the numerical modelling of the deep-towed seismic survey system, one surrogate model that maps the relationship between the hydrodynamic characteristics of the drogue and towing conditions was obtained based on data-driven simulations. The sample data were obtained by co-simulation of the commercial software RecurDyn and Particleworks, and the modelling parameters were verified by physical experiments. According to the Morison formula, the rotational angle, angular velocity, angular acceleration, towing speed, and towing acceleration of the drogue were selected as the design variables and drag forces and aligning torque were selected as the research objectives. The sample data of more than 8500 sets were obtained from virtual manoeuvres. Subsequently, both polynomial and neural network regression algorithms were used to study these data. Finally, analysis results show that the surrogate model obtained by machine learning has good performance in predicting research objectives. The results also reveal that the neural network regression algorithm is superior to the polynomial regression algorithm, its largest error of mean square is less than 0.8 (N²/N² mm²), and its R-squared is close to 1. Full article

Cavitation characteristics in the wake of a circular cylinder, which contains multiscale vortices, are numerically investigated via Large Eddy Simulation (LES) in this paper. The Reynolds number is 9500 based on the inlet velocity, the cylinder diameter and the kinematic viscosity of the noncavitation liquid. The Schneer–Sauer (SS) model is applied to cavitation simulation because it is more sensitive to vapor–liquid two-phase volume fraction than the Zwart–Gerber–Belamri (ZGB) model, according to theoretical analyses. The wake is quasiperiodic, with an approximate frequency of 0.2. It is found that the cavitation of vortices could inhibit the vortex shedding. Besides, the mutual aggregation of small-scale vortices in the vortex system or the continuous stripping of small-scale vortices at the edge of large-scale vortices could induce the merging or splitting of cavities in the wake. Full article

To reduce the risk of collision in territorial sea areas, including trade ports and entry waterways, and to enhance the safety and efficiency of ship passage, the International Maritime Organization requires the governing body of every country to establish and operate a vessel traffic service (VTS). However, previous studies on risk prediction models did not consider the locations of near collisions and actual collisions and only employed a combined collision risk index in surveillance sea areas. In this study, we propose a regional collision risk prediction system for a collision area considering spatial patterns using a density-based spatial clustering of applications with noise (DBSCAN). Furthermore, a fuzzy inference system based on a near collision (FIS-NC) and long short-term memory (LSTM) is adopted to help a vessel traffic service operator (VTSO) make timely optimal decisions. In the local spatial pattern stage, the ship trajectory was determined by identifying the actual-collision and near-collision locations simultaneously. Finally, the system was developed by learning a sequence dataset from the extracted trajectory of the ship when a collision occurred. The proposed system can recommend an action faster than the fuzzy inference system based on the near-collision location. Therefore, using the developed system, a VTSO can quickly predict ship collision risk situations and make timely optimal decisions at dangerous surveillance sea areas. Full article

As the technical and theoretical research of floating breakwaters is becoming increasingly mature, the floating breakwaters are now being utilized, especially in offshore reefs. Therefore, it is of practical significance to study the hydrodynamic performance of a multi-module floating breakwater system under the influence of reefs. In this study, a 3D model experiment was carried out on a system consisting of eight three-cylinder floating breakwater modules under the influence of reefs. A wave attenuation mesh cage was incorporated at the bottom of the model. The floating breakwater system was slack-moored in its equilibrium position, and each module was connected by elastic connectors. The reefs were modeled on a bathymetric map of existing reefs in the East China Sea. In this experiment, the wave transmission coefficients, motion responses, and mooring forces of the floating breakwater system were measured. The results showed that the three-cylinder floating breakwater in the beam waves (β = 90°) has excellent wave attenuating performance under the influence of reefs, especially for short-period waves. However, under the influence of the reef reflection wave and the shallow water effect, the motion responses in the three main stress directions of the floating breakwater were large, and there was some surge and pitch motion. Under the influence of the aggregation and superposition of reflected waves on both sides of the reefs, the peak mooring forces in the middle position of the floating breakwater system were the largest at large wave height. The three-cylinder floating breakwater exhibited satisfactory hydrodynamic performance under the influence of reefs. It has broad application prospects in offshore reefs. Full article

Due to the impact of natural and artificial influence, such as waves, tides, and artificial dewatering, the small-strain shear modulus of soils may vary with the water content of soil, causing deformation of excavations and other earth structures. The present study used a resonant column device to investigate the effects of water content, void ratio, and confining pressure on the small-strain shear modulus of a silt extracted from an excavation site near Qiantang River in Hangzhou, China. The test results revealed that the effects of the three factors are not coupled and can be characterized by three individual equations. In particular, the small-strain shear modulus decreases with increasing water content under otherwise similar conditions, which can be characterized by a power function. The classical Hardin’s equation is modified to consider the effect of water content by introducing an additional function of water content. Full article

In the background of global warming and climate change, nuisance flooding is only caused by astronomical tides, which could be modulated by the nodal cycle. Therefore, much attention should be paid to the variation in the amplitude of the nodal cycle. In this paper, we utilize the enhanced harmonic analysis method and the independent point scheme to obtain the time-dependent amplitudes of the 8.85-year cycle of N₂ tide and the 4.42-year cycle of 2N₂ tide based on water level records of four tide gauges in the Gulf of Maine. Results indicate that the long-term trends of N₂ and 2N₂ tides vary spatially, which may be affected by the sea-level rise, coastal defenses, and other possible climate-related mechanisms. The comparison between Halifax and Eastport reveals that the topography greatly influences the amplitudes of those cycles. Moreover, a quasi 20-year oscillation is obvious in the 8.85-year cycle of N₂ tide. This oscillation probably relates to a 20-year mode in the North Atlantic Ocean. Full article

Starry flounder (Platichthys stellatus) is a commercially important cold-water fish. Our aim was to investigate the effects of fluctuating water temperature on flounders after periods of starvation and feeding. Fish were divided into starvation and feeding groups. The water temperature was increased stepwise in experiment 1; more focused variations, based on the results of experiment 1, were studied in experiment 2. At temperatures ≤27 °C, there was no significant difference observed in survival. At 28 °C, mortality increased, survival was lower (21%) in the starvation group than in the feeding group (46%), and weight loss was the highest (15%) in the starvation group. In experiment 2, survival was ≥86%, and there was no significant difference between the starvation/feeding groups. However, when the water temperature was increased to 27 °C after being decreased to 12 °C, weight loss was the highest (11%). Glucose, cortisol, superoxide dismutase (SOD), catalase (CAT), and glutathione (GSH) levels increased with increasing water temperature, and then gradually decreased. Glutamic pyruvic transaminase (GPT)/glutamic oxaloacetic transaminase (GOT) levels showed large variations among individuals. Triglyceride, cholesterol, and protein levels gradually decreased with long-term starvation. Survival was not affected by water temperature drop ≤27 °C after starvation/feeding. These results indicate that 27 °C is the upper limit of tolerable water temperature for the survival of starry flounders. Therefore, aquaculture farms should ensure maintaining water temperatures at ≤27 °C during high-temperature periods. Full article

The instability of the no-load working condition of the pump turbine directly affects the grid connection of the unit, and will cause vibration and damage to the components of the unit in severe cases. In this paper, a three-dimensional full flow numerical model including the runner gap and the pressure-balance pipe was established. The method SST k-ω model was used to predict the internal flow characteristics of the pump turbine. The pressure pulsation of the runner under different operating conditions during the no-load process was compared. Because the rotation speed, flow rate, and guide vane opening of the unit change in a small range during the no-load process, the pressure pulsation characteristics of the runner are basically the same. Therefore, a working condition was selected to analyze the transient characteristics of the flow field, and it was found that there was a high-speed ring in the vaneless zone, and a stable channel vortex was generated in the runner flow passage. Analyzing the axial water thrust of each part of the runner, it was found that the axial water thrust of the runner gap was much larger than the axial water thrust of the runner blades, and it changed with time periodically. It was affected by rotor stator interaction. The main frequency was expressed as a multiple of the number of guide vanes, that is, vanes passing frequency, 22f_n. During the entire no-load process, the axial water thrust of the runner changed slowly with time and fluctuated slightly. Full article

Aiming at the problem of unsteady cavitation during a projectile’s vertical water-exit process, scaled model experiments were carried out based on the self-designed underwater launch platform and high-speed cameras, which focus on changes in cavitation shape and projectile posture. In this paper, the general process of the cavitation evolution and projectile’s movement is described; the relationship between the re-entry jet, local cavitation number and cavitation stability is discussed. Meanwhile, the effect of head forms and launch speeds on the cavitation evolution and movement characteristics is analyzed, including 60° cone, 90° cone and hemispherical head with velocity of 16.8 m/s, 18.5 m/s and 20.0 m/s, whose launch cavitation number is 0.714, 0.589 and 0.504. The results show that the attached cavities fall off from the bottom up under the influence of the end-re-entry jet and the shedding frequency declines when the launch cavitation number decreases. The cavitation growth of 60° cone is easily disturbed by the air mass near the launcher, the cavitation development of 90° cone is characterized by small-scale and high-frequency growth and shedding, while the hemispherical head is not prone to cavitation. Moreover, increasing the speed can improve the stability of cavitation development and the projectile’s movement. Full article

Nonlinear ultrasonic testing is highly sensitive to micro-defects and can be used to detect hidden damage and defects inside materials. At present, most tests are carried out on specimens, and there are few nonlinear ultrasonic tests for fatigue damage of compressor blades. A vibration fatigue test was carried out on compressor blade steel KMN, and blade specimens with different damage degrees were obtained. Then, the nonlinear coefficients of blade specimens were obtained by nonlinear ultrasonic testing. The results showed that the nonlinear coefficient increased with the increase in the number of fatigue cycles in the early stage of fatigue, and then the nonlinear coefficient decreased. The microstructures were observed by scanning electron microscopy (SEM). It was proven that the nonlinear ultrasonic testing can be used for the detection of micro-cracks in the early stage of fatigue. Through the statistical analysis of the size of the micro-cracks inside the material, the empirical formula of the nonlinear coefficient β and the equivalent crack size were obtained. Combined with the β–S–N three-dimensional model, an evaluation method based on the nonlinear ultrasonic testing for the early fatigue damage of the blade was proposed. Full article

Tuna fish school detection provides information on the fishing decisions of purse seine fleets. Here, we present a recognition system that included fish shoal image acquisition, point extraction, point matching, and data storage. Points are a crucial characteristic for images of free-swimming tuna schools, and point algorithm analysis and point matching were studied for their applications in fish shoal recognition. The feature points were obtained by using one of the best point algorithms (scale invariant feature transform, speeded up robust features, oriented fast and rotated brief). The k-nearest neighbors (KNN) algorithm uses ‘feature similarity’ to predict the values of new points, which means that new data points will be assigned a value based on how closely they match the points that exist in the database. Finally, we tested the model, and the experimental results show that the proposed method can accurately and effectively recognize tuna free-swimming schools. Full article

Nowadays, system-based simulation is one of the main methods for ship manoeuvring prediction. Great efforts are usually devoted to the determination of hydrodynamic derivatives as required for the mathematical models used for such methods. System identification methods can be applied to determine hydrodynamic derivatives. The purpose of this work is to present a parameter identification study based on least-squares support-vector machines (LS-SVMs) to obtain hydrodynamic derivatives for an Abkowitz-type model. An approach for constructing training data is used to reduce parameter drift. In addition, wavelet threshold denoising is applied to filter out the noise from the sample data during data pre-processing. Most of the resulting derivatives are very close to the original ones—especially for linear derivatives. Although the errors of high-order derivatives seem large, the final predicted results of the turning circle and zigzag manoeuvres agree pretty well with the reference ones. This indicates that the used methods are effective in obtaining manoeuvring hydrodynamic derivatives. Full article

Revetment elements and protective facilities on a breakwater can effectively weaken the impact of waves. In order to resist storm surges, there is a plan to build a breakwater on the northern shore of Meizhou Bay in Putian City, China. To better design it, considering different environmental conditions, physical and numerical experiments were carried out to accurately study the effects of the breakwater and its auxiliary structures on wave propagation. In the experiments, the influence of the wave type, initial water depth, and the structure of the fence plate are considered. The wave run-up and dissipation, the wave overtopping volume, and the structure stability are analyzed. The results indicate that the breakwater can effectively resist the wave impact, reduce the wave run-up and overtopping, and protect the rear buildings. In addition, under the same still water depth and significant wave height, the amount of overtopped water under regular waves is larger than that under irregular waves. With the increase of the still water depth and significant wave height, the overtopped water increases, which means that when the storm surge occurs, damage on the breakwater under the high tide level is greater than that under the low tide level. Besides, the fence plate can effectively dissipate energy and reduce the overtopping volume by generating eddy current in the cavity. Considering the stability and the energy dissipation capacity of the fence plate, it is suggested that a gap ratio of 50% is reasonable. Full article
