Electron. Mater., Volume 3, Issue 1 (March 2022) – 13 articles

Cover Story (view full-size image): The use of earth-abundant, non-toxic, and low-cost semiconductors on cheap substrates for the realization of electronic devices is becoming increasingly important due to the scarcity of elements such as In, Ga, etc. I-VII γ-cuprous halides such as CuCl, CuBr, and CuI are p-type semiconductors with a zinc blende crystal structure and direct band-gaps of ⁓3.0 eV that are optically transparent, capable of light emission, and also have lattice constants close to that of Si. On the other hand, Cu3N has been described as a defect-tolerant semiconductor that is attractive for energy conversion and storage. Here, it is shown that γ-CuI may be obtained from Cu3N at room temperature by exposure to iodine, which in turn allows the fabrication of p–n heterojunction diodes directly on glass which exhibit rectifying current–voltage characteristics. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Select all
Export citation of selected articles as:
18 pages, 4030 KiB
Article
Copper-Content Dependent Structural and Electrical Properties of CZTS Films Formed by “Green” Colloidal Nanocrystals
by Volodymyr Dzhagan, Oleksandr Selyshchev, Serhiy Kondratenko, Nazar Mazur, Yevhenii Havryliuk, Oleksandra Raievska, Oleksandr Stroyuk and Dietrich R. T. Zahn
Electron. Mater. 2022, 3(1), 136-153; https://doi.org/10.3390/electronicmat3010013 - 20 Mar 2022
Cited by 2 | Viewed by 2523
Abstract
Thin films of colloidal CZTS nanocrystals (NCs) synthesized using a “green” approach in water with a variation of the copper-to-tin ratio are investigated by Raman scattering, mid-infrared (molecular vibrations) and near-infrared (free carrier) absorption, X-ray photoemission spectroscopy (XPS), electrical conductivity, and conductive atomic [...] Read more.
Thin films of colloidal CZTS nanocrystals (NCs) synthesized using a “green” approach in water with a variation of the copper-to-tin ratio are investigated by Raman scattering, mid-infrared (molecular vibrations) and near-infrared (free carrier) absorption, X-ray photoemission spectroscopy (XPS), electrical conductivity, and conductive atomic force microscopy (cAFM). We determined the effect of the actual Cu content on the phonon spectra, electrical conductivity, and spectral parameters of the plasmon band. An increase in the electrical conductivity of the NC films upon annealing at 220 °C is explained by three factors: formation of a CuxS nanophase at the CZTS NC surface, partial removal of ligands, and improved structural perfection. The presence of the CuxS phase is concluded to be the determinant factor for the CZTS NC film conductivity. CuxS can be reliably detected based on the analysis of the modified Auger parameter of copper, derived from XPS data and corroborated by Raman spectroscopy data. Partial removal of the ligand is concluded from the agreement of the core-level XPS and vibrational IR spectra. The degree of lattice perfection can be conveniently assessed from the Raman data as well. Further important information derived from a combination of photoelectron and optical data is the work function, ionization potential, and electron affinity of the NC films. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials II)
Show Figures

Figure 1

12 pages, 1904 KiB
Article
Investigation of Elastic Properties of WO3 Thin Films Supported on Quartz in Surface Acoustic Wave Sensing Devices
by Madjid Arab, Véronique Madigou, Virginie Chevallier, Christian Turquat and Christine Leroux
Electron. Mater. 2022, 3(1), 124-135; https://doi.org/10.3390/electronicmat3010012 - 17 Mar 2022
Cited by 2 | Viewed by 2237
Abstract
This study aims to discuss the combined theoretical and experimental results of elastic properties of tungsten trioxide films supported on Quartz (YX)/45°/10° resonator to form surface acoustic wave (SAW) devices. The SAW systems with different thicknesses of WO3 thin films were imaged [...] Read more.
This study aims to discuss the combined theoretical and experimental results of elastic properties of tungsten trioxide films supported on Quartz (YX)/45°/10° resonator to form surface acoustic wave (SAW) devices. The SAW systems with different thicknesses of WO3 thin films were imaged and structurally characterized by X-ray diffraction, atomic force, and transmission electron microscopy. The deposited WO3 films (100, 200, and 300 nm of thickness) crystallized in a single monoclinic phase. The acoustoelectric properties of the SAW system were obtained by combining theoretical simulations with experimental measurements. The modeling of the SAW devices has been performed by the finite element and boundary element methods (FEM/BEM). The elastic constants of the films at room temperature were assessed via electrical admittances experiments in light of theoretical calculations. The gravimetric effect of the deposited layers is observed by a shift of the resonance frequency to lower values as the thickness of the films increases. Moreover, the acoustic losses are affected by the dielectric losses of the WO3 films while the resonant frequency decreases almost linearly. SAW devices revealed strong displacement fields with low acoustic losses as a function of WO3 thicknesses. For all the deposited layers, the measured Young’s moduli and Poisson’s ratios are 8 GPa and 0.5, respectively. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials II)
Show Figures

Figure 1

9 pages, 3098 KiB
Review
Majority and Minority Charge Carrier Traps in n-Type 4H-SiC Studied by Junction Spectroscopy Techniques
by Ivana Capan and Tomislav Brodar
Electron. Mater. 2022, 3(1), 115-123; https://doi.org/10.3390/electronicmat3010011 - 14 Mar 2022
Cited by 7 | Viewed by 3199
Abstract
In this review, we provide an overview of the most common majority and minority charge carrier traps in n-type 4H-SiC materials. We focus on the results obtained by different applications of junction spectroscopy techniques. The basic principles behind the most common junction spectroscopy [...] Read more.
In this review, we provide an overview of the most common majority and minority charge carrier traps in n-type 4H-SiC materials. We focus on the results obtained by different applications of junction spectroscopy techniques. The basic principles behind the most common junction spectroscopy techniques are given. These techniques, namely, deep-level transient spectroscopy (DLTS), Laplace DLTS (L-DLTS), and minority carrier transient spectroscopy (MCTS), have led to recent progress in identifying and better understanding the charge carrier traps in n-type 4H-SiC materials. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials II)
Show Figures

Figure 1

14 pages, 4671 KiB
Article
Vis and NIR Diffuse Reflectance Study in Disordered Bismuth Manganate—Lead Titanate Ceramics
by Andrzej Molak, Anna Z. Szeremeta and Janusz Koperski
Electron. Mater. 2022, 3(1), 101-114; https://doi.org/10.3390/electronicmat3010010 - 25 Feb 2022
Cited by 4 | Viewed by 2124
Abstract
This work shows a correlation between light reflectance, absorption, and morphologies of series of bismuth manganate–lead titanate, (1 − x) BM–x PT, (x = 0.00, 0.02, 0.04, 0.08, 0.12, 0.16, 0.24, 1.00) ceramics composite. Low reflectance in the Vis-NIR range [...] Read more.
This work shows a correlation between light reflectance, absorption, and morphologies of series of bismuth manganate–lead titanate, (1 − x) BM–x PT, (x = 0.00, 0.02, 0.04, 0.08, 0.12, 0.16, 0.24, 1.00) ceramics composite. Low reflectance in the Vis-NIR range corresponds to ‘black mirror’ features. The modified Kubelka-Munk function applied to measured visible-near infrared (Vis-NIR) diffuse reflectance enabled the estimation of the energy gaps magnitude of the order of 1.0–1.2 eV for BM-PT. Histograms of grains, obtained using a scanning electron microscope, enabled finding the correlation between grains size, reflectance magnitude, and PT content. The magnitude of energy gaps was attributed to electronic structure bands modified by crystal lattice disorder and oxygen vacancies. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

8 pages, 1344 KiB
Article
25,000 fps Computational Ghost Imaging with Ultrafast Structured Illumination
by Hongxu Huang, Lijing Li, Yuxuan Ma and Mingjie Sun
Electron. Mater. 2022, 3(1), 93-100; https://doi.org/10.3390/electronicmat3010009 - 24 Feb 2022
Cited by 5 | Viewed by 2546
Abstract
Computational ghost imaging, as an alternative photoelectric imaging technology, uses a single-pixel detector with no spatial resolution to capture information and reconstruct the image of a scene. Due to its essentially temporal measurement manner, improving the image frame rate is always a major [...] Read more.
Computational ghost imaging, as an alternative photoelectric imaging technology, uses a single-pixel detector with no spatial resolution to capture information and reconstruct the image of a scene. Due to its essentially temporal measurement manner, improving the image frame rate is always a major concern in the research of computational ghost imaging technology. By taking advantage of the fast switching time of LED, an LED array was developed to provide a structured illumination light source in our work, which significantly improves the structured illumination rate in the computational ghost imaging system. The design of the LED array driver circuit presented in this work makes full use of the LED switching time and achieves a pattern displaying rate of 12.5 MHz. Continuous images with 32 × 32 pixel resolution are reconstructed at a frame rate of 25,000 fps, which is approximately 500 times faster than what a universally used digital micromirror device can achieve. The LED array presented in this work can potentially be applied to other techniques requiring high-speed structured illumination, such as fringe 3D profiling and array-based LIFI. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

11 pages, 2350 KiB
Article
Magnetization of Magnetically Inhomogeneous Sr2FeMoO6-δ Nanoparticles
by Gunnar Suchaneck, Nikolai Kalanda, Marta Yarmolich, Evgenii Artiukh, Gerald Gerlach and Nikolai A. Sobolev
Electron. Mater. 2022, 3(1), 82-92; https://doi.org/10.3390/electronicmat3010008 - 08 Feb 2022
Cited by 1 | Viewed by 2153
Abstract
In this work, we describe the magnetization of nanosized SFMO particles with a narrow size distribution around ca. 70 nm fabricated by the citrate-gel technique. The single-phase composition and superstructure ordering degree were proved by X-ray diffraction, the superparamagnetic behavior by magnetization measurements [...] Read more.
In this work, we describe the magnetization of nanosized SFMO particles with a narrow size distribution around ca. 70 nm fabricated by the citrate-gel technique. The single-phase composition and superstructure ordering degree were proved by X-ray diffraction, the superparamagnetic behavior by magnetization measurements using zero-field cooled and field-cooled protocols, as well as by electron magnetic resonance. Different contributions to the magnetic anisotropy constant and the temperature dependence of the magnetocrystalline anisotropy are discussed. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

17 pages, 3454 KiB
Review
Passive Intermodulation at Contacts of Rough Conductors
by Amir Dayan, Yi Huang and Alex Schuchinsky
Electron. Mater. 2022, 3(1), 65-81; https://doi.org/10.3390/electronicmat3010007 - 03 Feb 2022
Cited by 11 | Viewed by 3372
Abstract
Passive intermodulation (PIM) is a niggling phenomenon that debilitates the performance of modern communications and navigation systems. PIM products interfere with information signals and cause their nonlinear distortion. The sources and basic mechanisms of PIM have been studied in the literature but PIM [...] Read more.
Passive intermodulation (PIM) is a niggling phenomenon that debilitates the performance of modern communications and navigation systems. PIM products interfere with information signals and cause their nonlinear distortion. The sources and basic mechanisms of PIM have been studied in the literature but PIM remains a serious problem of signal integrity. In this paper, the main sources and mechanisms of PIM generation by joints of good conductors are discussed. It is shown that the passive electrical, thermal and mechanical nonlinearities are intrinsically linked despite their distinctively different time scales. The roughness of the contact surfaces plays an important role in PIM generation by conductor joints. A review of the PIM phenomenology at the contacts of the good conductors suggests that novel multiphysics models are necessary for the analysis and reliable prediction of PIM products generated by several concurrent nonlinearities of a diverse physical nature. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

2 pages, 147 KiB
Editorial
Acknowledgment to Reviewers of Electronic Materials in 2021
by Electronic Materials Editorial Office
Electron. Mater. 2022, 3(1), 63-64; https://doi.org/10.3390/electronicmat3010006 - 25 Jan 2022
Cited by 1 | Viewed by 1698
Abstract
Rigorous peer-reviews are the basis of high-quality academic publishing [...] Full article
10 pages, 1755 KiB
Article
Modulation in Electric Conduction of PVK and Ferrocene-Doped PVK Thin Films
by Hari Chandra Nayak, Shivendra Singh Parmar, Rajendra Prasad Kumhar and Shailendra Rajput
Electron. Mater. 2022, 3(1), 53-62; https://doi.org/10.3390/electronicmat3010005 - 14 Jan 2022
Cited by 2 | Viewed by 2427
Abstract
In this article, the dielectric properties of poly (9-vinylcarbazole) (PVK) and ferrocene-doped PVK thin films are studied. The thin films were grown by the isothermal solution casting technique. Dielectric properties of grown films were studied as function of ferrocene concentration, frequency, and temperature. [...] Read more.
In this article, the dielectric properties of poly (9-vinylcarbazole) (PVK) and ferrocene-doped PVK thin films are studied. The thin films were grown by the isothermal solution casting technique. Dielectric properties of grown films were studied as function of ferrocene concentration, frequency, and temperature. The relative permittivity (ε′) is increased with increasing ferrocene percentage (~1%) due to the free charge carriers. The relative permittivity decreases for higher ferrocene percentage (~2%). However, the relative permittivity of PVK and ferrocene-doped PVK samples remains almost constant for studied temperature range (313–413 K). The frequency dependence of tan δ for all samples is studied. The frequency dependence of dielectric parameter exhibits frequency dispersion behavior, which suggests all types of polarization present in the lower frequency range. The loss tangent (tanδ) values are larger at higher temperatures in the low frequency region. However, the tan δ values at different temperatures are almost similar in the high frequency region. It is observed that the relative permittivity is maximum, dielectric loss is minimum, and AC conductivity is minimum for 1% ferrocene doped PVK as compared to pure PVK and 2% ferrocene doped PVK samples. Full article
Show Figures

Figure 1

12 pages, 6427 KiB
Article
Synthesis and Physical Properties of Iridium-Based Sulfide Ca1−xIr4S6(S2) [x = 0.23–0.33]
by Michael Vogl, Martin Valldor, Roman Boy Piening, Dmitri V. Efremov, Bernd Büchner and Saicharan Aswartham
Electron. Mater. 2022, 3(1), 41-52; https://doi.org/10.3390/electronicmat3010004 - 11 Jan 2022
Viewed by 2317
Abstract
We present the synthesis and characterization of the iridium-based sulfide Ca1−xIr4S6(S2). Quality and phase analysis were conducted by means of energy-dispersive X-ray spectroscopy (EDXS) and powder X-ray diffraction (XRD) techniques. Structure analysis reveals a [...] Read more.
We present the synthesis and characterization of the iridium-based sulfide Ca1−xIr4S6(S2). Quality and phase analysis were conducted by means of energy-dispersive X-ray spectroscopy (EDXS) and powder X-ray diffraction (XRD) techniques. Structure analysis reveals a monoclinic symmetry with the space group C 1 2/m 1 (No. 12), with the lattice constants a = 15.030 (3) Å, b = 3.5747 (5) Å and c = 10.4572 (18) Å. Both X-ray diffraction and EDXS suggest an off-stoichiometry of calcium, leading to the empirical composition Ca1−xIr4.0S6(S2) [x = 0.23–0.33]. Transport measurements show metallic behavior of the compound in the whole range of measured temperatures. Magnetic measurements down to 1.8 K show no long range order, and Curie–Weiss analysis yields θCW = −31.4 K, suggesting that the compound undergoes a magnetic state with short range magnetic correlations. We supplement our study with calculations of the band structure in the framework of the density functional theory. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

14 pages, 4196 KiB
Article
Defect- and H-Free Stoichiometric Silicon Carbide by Thermal CVD from the Single Source Precursor Trisilacyclohexane
by Alain E. Kaloyeros, Jonathan Goff and Barry Arkles
Electron. Mater. 2022, 3(1), 27-40; https://doi.org/10.3390/electronicmat3010003 - 10 Jan 2022
Cited by 6 | Viewed by 2526
Abstract
Stoichiometric silicon carbide (SiC) thin films were grown using thermal chemical vapor deposition (TCVD) from the single source precursor 1,3,5-trisilacyclohexane (TSCH) on c-Si (100) substrates within an optimized substrate temperature window ranging from 650 to 850 °C. X-ray photoelectron spectroscopy (XPS) and Fourier [...] Read more.
Stoichiometric silicon carbide (SiC) thin films were grown using thermal chemical vapor deposition (TCVD) from the single source precursor 1,3,5-trisilacyclohexane (TSCH) on c-Si (100) substrates within an optimized substrate temperature window ranging from 650 to 850 °C. X-ray photoelectron spectroscopy (XPS) and Fourier transform infrared spectroscopy (FTIR) analyses revealed that the as-deposited films consisted of a Si-C matrix with a Si:C ratio of ~1:1. FTIR and photoluminescence (PL) spectrometry studies showed that films deposited ≥ 750 °C were defect- and H-free within the detection limit of the techniques used, while ellipsometry measurements yielded an as-grown SiC average refractive index of ~2.7, consistent with the reference value for the 3C-SiC phase. The exceptional quality of the films appears sufficient to overcome limitations associated with structural defects ranging from failure in high voltage, high temperature electronics to 2-D film growth. TSCH, a liquid at room temperature with good structural stability during transport and handling as well as high vapor pressure (~10 torr at 25 °C), provides a viable single source precursor for the growth of stoichiometric SiC without the need for post-deposition thermal treatment. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1

12 pages, 3173 KiB
Article
p-Type Iodine-Doping of Cu3N and Its Conversion to γ-CuI for the Fabrication of γ-CuI/Cu3N p-n Heterojunctions
by Argyris Tilemachou, Matthew Zervos, Andreas Othonos, Theodoros Pavloudis and Joseph Kioseoglou
Electron. Mater. 2022, 3(1), 15-26; https://doi.org/10.3390/electronicmat3010002 - 10 Jan 2022
Cited by 8 | Viewed by 3466
Abstract
Cu3N with a cubic crystal structure is obtained in this paper by the sputtering of Cu under N2 followed by annealing under NH3: H2 at 400 °C, after which it was doped with iodine at room temperature [...] Read more.
Cu3N with a cubic crystal structure is obtained in this paper by the sputtering of Cu under N2 followed by annealing under NH3: H2 at 400 °C, after which it was doped with iodine at room temperature resulting into p-type Cu3N with hole densities between 1016 and 1017 cm−3. The Cu3N exhibited distinct maxima in differential transmission at ~2.01 eV and 1.87 eV as shown by ultrafast pump-probe spectroscopy, corresponding to the M and R direct energy band gaps in excellent agreement with density functional theory calculations, suggesting that the band gap is clean and free of mid-gap states. The Cu3N was gradually converted into optically transparent γ-CuI that had a hole density of 4 × 1017 cm−3, mobility of 12 cm2/Vs and room temperature photoluminescence at 3.1 eV corresponding to its direct energy band gap. We describe the fabrication and properties of γ-CuI/TiO2/Cu3N and γ-CuI/Cu3N p-n heterojunctions that exhibited rectifying current-voltage characteristics, but no photogenerated current attributed to indirect recombination via shallow states in Cu3N and/or deep states in the γ-CuI consistent with the short (ps) lifetimes of the photoexcited electrons-holes determined from transient absorption–transmission spectroscopy. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Graphical abstract

14 pages, 1060 KiB
Article
Attaining Low Lattice Thermal Conductivity in Half-Heusler Sublattice Solid Solutions: Which Substitution Site Is Most Effective?
by Rasmus Tranås, Ole Martin Løvvik and Kristian Berland
Electron. Mater. 2022, 3(1), 1-14; https://doi.org/10.3390/electronicmat3010001 - 05 Jan 2022
Cited by 1 | Viewed by 2833
Abstract
Low thermal conductivity is an important materials property for thermoelectricity. The lattice thermal conductivity (LTC) can be reduced by introducing sublattice disorder through partial isovalent substitution. Yet, large-scale screening of materials has seldom taken this opportunity into account. The present study aims to [...] Read more.
Low thermal conductivity is an important materials property for thermoelectricity. The lattice thermal conductivity (LTC) can be reduced by introducing sublattice disorder through partial isovalent substitution. Yet, large-scale screening of materials has seldom taken this opportunity into account. The present study aims to investigate the effect of partial sublattice substitution on the LTC. The study relies on the temperature-dependent effective potential method based on forces obtained from density functional theory. Solid solutions are simulated within a virtual crystal approximation, and the effect of grain-boundary scattering is also included. This is done to systematically probe the effect of sublattice substitution on the LTC of 122 half-Heusler compounds. It is found that substitution on the three different crystallographic sites leads to a reduction of the LTC that varies significantly both between the sites and between the different compounds. Nevertheless, some common criteria are identified as most efficient for reduction of the LTC: The mass contrast should be large within the parent compound, and substitution should be performed on the heaviest atoms. It is also found that the combined effect of sublattice substitution and grain-boundary scattering can lead to a drastic reduction of the LTC. The lowest LTC of the current set of half-Heusler compounds is around 2 W/Km at 300 K for two of the parent compounds. Four additional compounds can reach similarly low LTC with the combined effect of sublattice disorder and grain boundaries. Two of these four compounds have an intrinsic LTC above ∼15 W/Km, underlining that materials with high intrinsic LTC could still be viable for thermoelectric applications. Full article
(This article belongs to the Special Issue Feature Papers of Electronic Materials)
Show Figures

Figure 1
