Analysis of the Sieve Unit Inclination Angle in the Cleaning Process of Oat Grain in a Rotary Cleaning Device

1
Department of Mechanical Engineering and Automatics, University of Life Sciences in Lublin, 20-612 Lublin, Poland
2
Department of Horticulture Machinery and Tools, University of Life Sciences in Lublin, 20-612 Lublin, Poland
3
Faculty of Technical Sciences, Department of Heavy Duty Machines and Research Methodology, University of Warmia and Mazury in Olsztyn, 10-719 Olsztyn, Poland
4
Department of Mechanics and Mechanical Engineering, Faculty of Transport and Computer Science, University of Economics and Innovation, 20-209 Lublin, Poland
5
Department of Automation, Lublin University of Technology, 20-618 Lublin, Poland
*
Author to whom correspondence should be addressed.
Processes 2020, 8(3), 346; https://doi.org/10.3390/pr8030346
Received: 29 January 2020 / Revised: 11 March 2020 / Accepted: 16 March 2020 / Published: 18 March 2020
(This article belongs to the Special Issue Sustainable Food Processing Processes)
The article presents some of the research on the wider work related to testing and improving a new rotary cleaning device. The new cereal grain cleaning and separation device can support the development of sustainable agriculture in terms of seed purity and quality. This device is especially useful for small and medium-sized farms. This device has the characteristics of a multi-stage screen aided by an air stream (i.e., by pneumoseparation). The prototype was constructed at the University of Life Sciences in Lublin. The research was conducted at a test stand, which allowed changes in the operating parameters of the cleaner and their measurement. The scope of the tests included determining the influence of the inclination angle of the sieve unit (α) on the effectiveness and efficiency of oat grain cleaning. The experiment was carried out using two rotational spindle speeds: 5 and 75 rpm. The quality of the separation and cleaning of oat grains was evaluated using six cleaning process parameters: plump grain mass separation coefficient (Spg), fine grain separation coefficient (Sfg), fine impurities separation coefficient (Sfi), chaff separation coefficient (Sch), total coefficient of cleaning effectiveness (E), plump grain cleaning efficiency (qpg). Results showed the significant effect of the sieve drum inclination angle on the efficiency and effectiveness of oat grain cleaning. View Full-Text
Keywords: rotary cleaning device; grain separation; oat grain; conical sieve rotary cleaning device; grain separation; oat grain; conical sieve
Show Figures

Figure 1

MDPI and ACS Style

Krzysiak, Z.; Samociuk, W.; Zarajczyk, J.; Kaliniewicz, Z.; Pieniak, D.; Bogucki, M. Analysis of the Sieve Unit Inclination Angle in the Cleaning Process of Oat Grain in a Rotary Cleaning Device. Processes 2020, 8, 346.
