Robotics

30 pages, 10077 KiB

Open AccessArticle

Design and Experimental Evaluation of Multiple 3D-Printed Reduction Gearboxes for Wearable Exoskeletons

by Riccardo Bezzini, Giulia Bassani, Carlo Alberto Avizzano and Alessandro Filippeschi

Robotics 2024, 13(11), 168; https://doi.org/10.3390/robotics13110168 - 19 Nov 2024

Viewed by 538

The recent advancements in wearable exoskeletons have highlighted their effectiveness in assisting humans for both rehabilitation and augmentation purposes. These devices interact with the user; therefore, their actuators and power transmission mechanisms are crucial for enhancing physical human–robot interaction (pHRI). The advanced progression [...] Read more.

The recent advancements in wearable exoskeletons have highlighted their effectiveness in assisting humans for both rehabilitation and augmentation purposes. These devices interact with the user; therefore, their actuators and power transmission mechanisms are crucial for enhancing physical human–robot interaction (pHRI). The advanced progression of 3D printing technology as a valuable method for creating lightweight and efficient gearboxes enables the exploration of multiple reducer designs. However, to the authors’ knowledge, only sporadic implementations with relatively low reduction ratios have been reported, and the respective experimental validations usually vary, preventing a comprehensive evaluation of different design and implementation choices. In this paper, we design, develop, and examine experimentally multiple 3D-printed gearboxes conceived for wearable assistive devices. Two relevant transmission ratios (1:30 and 1:80) and multiple designs, which include single- and double-stage compact cam cycloidal drives, compound planetary gearboxes, and cycloidal and planetary architectures, are compared to assess the worth of 3D-printed reducers in human–robot interaction applications. The resulting prototypes were examined by evaluating their weight, cost, backdrivability, friction, regularity of the reduction ratio, gear play, and stiffness. The results show that the developed gearboxes represent valuable alternatives for actuating wearable exoskeletons in multiple applications. Full article

(This article belongs to the Special Issue AI for Robotic Exoskeletons and Prostheses)

► Show Figures

Figure 1

20 pages, 9893 KiB

Open AccessArticle

Context-Specific Navigation for ‘Gentle’ Approach Towards Objects Based on LiDAR and URF Sensors

by Claudia Álvarez-Aparicio, Beáta Korcsok, Adrián Campazas-Vega, Ádám Miklósi, Vicente Matellán and Bence Ferdinandy

Robotics 2024, 13(11), 167; https://doi.org/10.3390/robotics13110167 - 19 Nov 2024

Viewed by 448

Abstract

Navigation skills are essential for most social and service robotics applications. The robots that are currently in practical use in various complex human environments are generally very limited in their autonomous navigational abilities; while they can reach the proximity of objects, they are [...] Read more.

Navigation skills are essential for most social and service robotics applications. The robots that are currently in practical use in various complex human environments are generally very limited in their autonomous navigational abilities; while they can reach the proximity of objects, they are not efficient in approaching them closely. The new solution described in this paper presents a system to solve this context-specific navigation problem. The system handles locations with differing contexts based on the use of LiDAR and URF sensors, allowing for the avoidance of people and obstacles with a wide margin, as well as for approaching target objects closely. To quantify the efficiency of our solution we compared it with the ROS contextless standard navigation (move_base) in two different robot platforms and environments, both with real-world tests and simulations. The metrics selected were (1) the time the robot needs to reach an object, (2) the Euclidean distance, and (3) the orientation between the final position of the robot and the defined goal position. We show that our context-specific solution is superior to the standard navigation both in time and Euclidean distance. Full article

(This article belongs to the Section Sensors and Control in Robotics)

► Show Figures

Figure 1

29 pages, 27816 KiB

Open AccessArticle

Trajectory Aware Deep Reinforcement Learning Navigation Using Multichannel Cost Maps

by Tareq A. Fahmy, Omar M. Shehata and Shady A. Maged

Robotics 2024, 13(11), 166; https://doi.org/10.3390/robotics13110166 - 17 Nov 2024

Viewed by 465

Abstract

Deep reinforcement learning (DRL)-based navigation in an environment with dynamic obstacles is a challenging task due to the partially observable nature of the problem. While DRL algorithms are built around the Markov property (assumption that all the necessary information for making a decision [...] Read more.

Deep reinforcement learning (DRL)-based navigation in an environment with dynamic obstacles is a challenging task due to the partially observable nature of the problem. While DRL algorithms are built around the Markov property (assumption that all the necessary information for making a decision is contained in a single observation of the current state) for structuring the learning process; the partially observable Markov property in the DRL navigation problem is significantly amplified when dealing with dynamic obstacles. A single observation or measurement of the environment is often insufficient for capturing the dynamic behavior of obstacles, thereby hindering the agent’s decision-making. This study addresses this challenge by using an environment-specific heuristic approach to augment the dynamic obstacles’ temporal information in observation to guide the agent’s decision-making. We proposed Multichannel Cost Map Observation for Spatial and Temporal Information (M-COST) to mitigate these limitations. Our results show that the M-COST approach more than doubles the convergence rate in concentrated tunnel situations, where successful navigation is only possible if the agent learns to avoid dynamic obstacles. Additionally, navigation efficiency improved by 35% in tunnel scenarios and by 12% in dense-environment navigation compared to standard methods that rely on raw sensor data or frame stacking. Full article

(This article belongs to the Section AI in Robotics)

► Show Figures

Figure 1

18 pages, 6281 KiB

Open AccessArticle

Mechanical Design, Manufacturing, and Testing of a Soft Pneumatic Actuator with a Reconfigurable Modular Reinforcement

by Michele Gabrio Antonelli, Pierluigi Beomonte Zobel, Enrico Mattei and Nicola Stampone

Robotics 2024, 13(11), 165; https://doi.org/10.3390/robotics13110165 - 12 Nov 2024

Viewed by 653

Abstract

Soft actuators have enabled the growth of soft robotics, overcoming several drawbacks of rigid robotics by providing devices with many degrees of freedom and the ability to grasp, bend, move, jump, and more. The reconfiguration of the workspace is still a limitation of [...] Read more.

Soft actuators have enabled the growth of soft robotics, overcoming several drawbacks of rigid robotics by providing devices with many degrees of freedom and the ability to grasp, bend, move, jump, and more. The reconfiguration of the workspace is still a limitation of these actuators. Indeed, once the actuator is designed and developed, it is used for a specific task. This work presents a reconfigurable soft pneumatic actuator with a novel reconfigurable modular reinforcement. The latter is wrapped around an inner tube in silicone rubber and is made of components whose assembly can be configured based on the task. A formulation is identified by a hybrid approach based on finite element analysis and response surface methodology for predicting and designing the behavior of the actuator. The prototyping revealed the ease of fabrication and reconfigurability as the strength of this new actuator. The experimental tests demonstrated the feasibility of adopting the actuator as a finger in a gripper for handling and moving objects of different shapes, masses, and stiffness. Furthermore, the evaluated performance shows a good trade-off between mass, developed force, implementation time, easy reconfigurability, and cost-effectiveness. Full article

(This article belongs to the Special Issue Advanced Grasping and Motion Control Solutions, Edition II)

► Show Figures

Figure 1

21 pages, 5673 KiB

Open AccessArticle

HaptiScan: A Haptically-Enabled Robotic Ultrasound System for Remote Medical Diagnostics

by Zoran Najdovski, Siamak Pedrammehr, Mohammad Reza Chalak Qazani, Hamid Abdi, Sameer Deshpande, Taoming Liu, James Mullins, Michael Fielding, Stephen Hilton and Houshyar Asadi

Robotics 2024, 13(11), 164; https://doi.org/10.3390/robotics13110164 - 10 Nov 2024

Viewed by 865

Abstract

Medical ultrasound is a widely used diagnostic imaging modality that provides real-time imaging at a relatively low cost. However, its widespread application is hindered by the need for expert operation, particularly in remote regional areas where trained sonographers are scarce. This paper presents [...] Read more.

Medical ultrasound is a widely used diagnostic imaging modality that provides real-time imaging at a relatively low cost. However, its widespread application is hindered by the need for expert operation, particularly in remote regional areas where trained sonographers are scarce. This paper presents the development of HaptiScan, a state-of-the-art telerobotic ultrasound system equipped with haptic feedback. The system utilizes a commercially available robotic manipulator, the UR5 robot from Universal Robots, integrated with a force/torque sensor and the Phantom Omni haptic device. This configuration enables skilled sonographers to remotely conduct ultrasound procedures via an internet connection, addressing both the geographic and ergonomic limitations faced in traditional sonography. Key innovative features of the system include real-time force feedback, ensuring that sonographers can precisely control the ultrasound probe from a remote location. The system is further enhanced by safety measures such as over-force sensing, patient discomfort monitoring, and emergency stop mechanisms. Quantitative indicators of the system’s performance include successful teleoperation over long distances with time delays, as demonstrated in simulations. These simulations validate the system’s control methodologies, showing stable performance with force feedback under varying time delays and distances. Additionally, the UR5 manipulator’s precision, kinematic, and dynamic models are mathematically formulated to optimize teleoperation. The results highlight the effectiveness of the proposed system in overcoming the technical challenges of remote ultrasound procedures, offering a viable solution for real-world telemedicine applications. Full article

(This article belongs to the Special Issue Development of Biomedical Robotics)

► Show Figures

Figure 1

20 pages, 27274 KiB

Open AccessArticle

Subtask-Based Usability Evaluation of Control Interfaces for Teleoperated Excavation Tasks

by Takumi Nagate, Hikaru Nagano, Yuichi Tazaki and Yasuyoshi Yokokohji

Robotics 2024, 13(11), 163; https://doi.org/10.3390/robotics13110163 - 9 Nov 2024

Viewed by 646

Abstract

This study aims to experimentally determine the most suitable control interface for different subtasks in the teleoperation of construction robots in a simulation environment. We compare a conventional lever-based rate control interface (“Rate-lever”) with two alternative methods: rate control (“Rate-3D”) and position control [...] Read more.

This study aims to experimentally determine the most suitable control interface for different subtasks in the teleoperation of construction robots in a simulation environment. We compare a conventional lever-based rate control interface (“Rate-lever”) with two alternative methods: rate control (“Rate-3D”) and position control (“Position-3D”), both using a 3D positional input device. In the experiments, participants operated a construction machine in a virtual environment and evaluated the control interfaces across three tasks: sagittal plane excavation, turning, and continuous operation. The results revealed that “Position-3D” outperformed others for sagittal excavation, while both “Rate-lever” and “Rate-3D” were more effective for turning. Notably, “Position-3D” and “Rate-3D” can be implemented on the same input device and are easily integrated. This feature offers the possibility of a hybrid-type interface suitable for operators to obtain optimized performance in sagittal and horizontal tasks. Full article

(This article belongs to the Special Issue Robot Teleoperation Integrating with Augmented Reality)

► Show Figures

Figure 1

24 pages, 2730 KiB

Open AccessArticle

Robust and Adaptive Control of a Soft Continuum Manipulator for Minimally Invasive Surgery

by Liujia Wang, Kaiwen Chen and Enrico Franco

Robotics 2024, 13(11), 162; https://doi.org/10.3390/robotics13110162 - 7 Nov 2024

Viewed by 700

Abstract

This article investigates the model-based control in configurations space of a soft continuum manipulator for minimally invasive surgery. The main control challenges for these types of systems are the presence of model uncertainties and nonlinearities. To this end, a sliding-mode controller, a Lyapunov [...] Read more.

This article investigates the model-based control in configurations space of a soft continuum manipulator for minimally invasive surgery. The main control challenges for these types of systems are the presence of model uncertainties and nonlinearities. To this end, a sliding-mode controller, a Lyapunov redesign controller, and an adaptive controller have been designed and compared by means of simulations and experiments on a prototype. The results indicate that the adaptive controller yields better accuracy but a slower transient. Conversely, the sliding-mode controller and Lyapunov redesign yield a faster response but can result in chattering or steady-state errors. Full article

(This article belongs to the Special Issue Adaptive and Nonlinear Control of Robotics)

► Show Figures

Figure 1

12 pages, 2009 KiB

Open AccessArticle

The Effectiveness of a Robotic Workstation Simulation Implementation in the Automotive Industry Using a Closed-Form Solution of the Absolute Orientation Problem

by Wojciech Andrzej Szulc and Piotr Czop

Robotics 2024, 13(11), 161; https://doi.org/10.3390/robotics13110161 - 30 Oct 2024

Viewed by 533

Abstract

This paper provides an in-depth analysis of a novel methodology to enhance the commissioning processes of robotic production lines in the automotive sector, with a particular emphasis on the implementation of offline programming (OLP) methods. The proposed innovative methodology, verified within the automotive [...] Read more.

This paper provides an in-depth analysis of a novel methodology to enhance the commissioning processes of robotic production lines in the automotive sector, with a particular emphasis on the implementation of offline programming (OLP) methods. The proposed innovative methodology, verified within the automotive industry, introduces a systematic, iterative process for calibrating and aligning the local user coordinate system (UCS) with high-precision external measurements, ensuring minimal discrepancy between simulated and actual robot paths. A significant contribution of this study is an original adjustment of the numerical algorithm applying a closed-form solution to the absolute orientation problem where unit quaternions are used to establish a UCS and evaluate positioning errors. The experimental validation study draws from 485 measurement datasets gathered across more than 300 robot stations, with each dataset comprising at least six measured point pairs, using readings from both internal robot positioning systems and a Leica AT403 laser tracker, aligned with nominal tooling values. This approach addresses discrepancies between simulated and actual environments, and our findings show an 83.51% success rate for direct implementation of simulated robot path programs. This result underscores the effectiveness of the proposed method and demonstrates the accuracy of the developed numerical algorithm, providing a reliable measure of real OLP implementation effectiveness in the automotive sector. This method further streamlines multi-robot station setup through centralized UCS alignment, significantly reducing commissioning time and enhancing efficiency in both the assembly and commissioning stages of robotized production lines. The proposed methodology facilitates precise alignment in the commissioning stage and highlights the need for synchronized simulation updates, robust offline programming practices, and regular kinematic error verification to further enhance OLP accuracy. Full article

(This article belongs to the Special Issue Integrating Robotics into High-Accuracy Industrial Operations)

► Show Figures

Figure 1

17 pages, 1170 KiB

Open AccessArticle

Telepresence Robots in the Context of Dementia Caregiving: Caregivers’ and Care Recipients’ Perspectives

by Shabnam FakhrHosseini, Lauren Cerino, Lisa D’Ambrosio, Lexi Balmuth, Chaiwoo Lee, Mengke Wu and Joseph Coughlin

Robotics 2024, 13(11), 160; https://doi.org/10.3390/robotics13110160 - 30 Oct 2024

Viewed by 872

Abstract

As a result of a rapidly aging population and the increasing prevalence of dementia among older adults, technological solutions are increasingly being considered to facilitate caregiving. This research investigates the perspectives of 20 caregiving dyads on VGo, a telepresence social robot with features [...] Read more.

As a result of a rapidly aging population and the increasing prevalence of dementia among older adults, technological solutions are increasingly being considered to facilitate caregiving. This research investigates the perspectives of 20 caregiving dyads on VGo, a telepresence social robot with features designed to support caregiving. Care recipients (CRs), aged 65 and older, diagnosed with Alzheimer’s disease and related dementias, along with their primary caregivers (CGs), evaluated the robot through an online interview study. The interviews integrated informative videos showcasing VGo’s features and functions. Insights from the interviews revealed diverse expectations, interests, and reservations. The majority of CGs and their CRs perceived the robot’s features as beneficial. In particular, the voice command capability was appreciated as an alternative to using smartphones and as a way to manage home appliances. The community feature, however, did not align well with many participants’ lifestyles, and participants had a number of suggestions to enhance the robot’s notification function. Based on the interview results, the study offers a set of design recommendations for telepresence social robots in home caregiving contexts. This investigation highlights the promise of social robots in caregiving contexts and underscores the need for further improvements to ensure they fit users’ needs. Full article

(This article belongs to the Special Issue Social Robots for the Human Well-Being)

► Show Figures

Figure 1

22 pages, 9800 KiB

Open AccessArticle

Arduino-Based Mobile Robotics for Fostering Computational Thinking Development: An Empirical Study with Elementary School Students Using Problem-Based Learning Across Europe

by Rolando Barradas, José Alberto Lencastre, Salviano Pinto Soares and António Valente

Robotics 2024, 13(11), 159; https://doi.org/10.3390/robotics13110159 - 29 Oct 2024

Viewed by 972

Abstract

The present article explores the impact of educational robotics on fostering computational thinking and problem-solving skills in elementary school students through a problem-based learning approach. This study involved the creation of a framework which includes a robot and two eBooks designed for students [...] Read more.

The present article explores the impact of educational robotics on fostering computational thinking and problem-solving skills in elementary school students through a problem-based learning approach. This study involved the creation of a framework which includes a robot and two eBooks designed for students and teachers. The eBooks serve as a guide to the construction and programming of a small Arduino-based robot. Through integration with gamification elements, the model features a narrative with three characters to boost a student’s engagement and motivation. Through iteration of heuristic evaluations and practical tests, we refined the initial theoretical framework. An empirical study was conducted in two phases involving 350 students. The first empirical test involved a small group of 21 students, similar to end users, from five European schools. With a 100% completion rate for the tasks, 73.47% of these tasks were solved optimally. Later, we conducted a larger validation study which involved 329 students in a Portuguese school. This second phase of the study was conducted during the 2022–2023 and 2023–2024 school years with three study groups. The results led to a 91.13% success rate in problem-solving activities, and 56.99% of those students achieved optimal solutions. Advanced statistical techniques, including ANOVA, were applied to account for group differences and ensure the robustness of the findings. This study demonstrates that the proposed model which integrates educational robotics with problem-based learning effectively promotes computational thinking and problem-solving skills, which are essential for the 21st century. These findings support the inclusion of robotics into primary school curricula and provide a validated framework for educators. Full article

(This article belongs to the Special Issue Advances and Challenges in Educational Robotics, Volume III)

► Show Figures

Figure 1

24 pages, 4188 KiB

Open AccessArticle

Methodology for Integrated Design Optimization of Actuation Systems for Exoskeletons

by Daniel Greve and Christian Kreischer

Robotics 2024, 13(11), 158; https://doi.org/10.3390/robotics13110158 - 25 Oct 2024

Viewed by 723

Abstract

The engineering of actuation systems for active exoskeletons presents a significant challenge due to the stringent demands for mass reduction and compactness, coupled with complex specifications for actuator dynamics and stroke length. This challenge is met with a model-based methodology. Models for human [...] Read more.

The engineering of actuation systems for active exoskeletons presents a significant challenge due to the stringent demands for mass reduction and compactness, coupled with complex specifications for actuator dynamics and stroke length. This challenge is met with a model-based methodology. Models for human body, exoskeleton and parametric actuation systems are derived and coupled. Beginning with an inverse dynamics human body simulation, loads in human joints are estimated, and the corresponding support torques are derived. Under the assumption of a control law ensuring these support torques, an optimization problem is stated to determine actuation system parameters such as the number of stator coils and number of battery cells. Lastly, results from the optimization are validated using sophisticated models. The methodology is applied to an exemplary exoskeleton and compared to an approach derived from previous studies. Full article

(This article belongs to the Section Neurorobotics)

► Show Figures

Figure 1

19 pages, 8123 KiB

Open AccessArticle

Towards a Unified Framework for Software-Hardware Integration in Evolutionary Robotics

by Edgar Buchanan, Léni K. Le Goff, Matthew F. Hale, Emma Hart, Agoston E. Eiben, Matteo De Carlo, Mike Angus, Robert Woolley, Jon Timmis, Alan F. Winfield and Andy M. Tyrrell

Robotics 2024, 13(11), 157; https://doi.org/10.3390/robotics13110157 - 25 Oct 2024

Viewed by 922

Abstract

The discrepancy between simulated and hardware experiments, the reality gap, is a challenge in evolutionary robotics. While strategies have been proposed to address this gap in fixed-body robots, they are not viable when dealing with populations and generations where the body is in [...] Read more.

The discrepancy between simulated and hardware experiments, the reality gap, is a challenge in evolutionary robotics. While strategies have been proposed to address this gap in fixed-body robots, they are not viable when dealing with populations and generations where the body is in constant change. The continual evolution of body designs necessitates the manufacturing of new robotic structures, a process that can be time-consuming if carried out manually. Moreover, the increased manufacturing time not only prolongs hardware experimental durations but also disrupts the synergy between hardware and simulated experiments. Failure to effectively manage these challenges could impede the implementation of evolutionary robotics in real-life environments. The Autonomous Robot Evolution project presents a framework to tackle these challenges through a case study. This paper describes the main three contributions of this work: Firstly, it analyses the different reality gap experienced by each different robot or the heterogenous reality gap. Secondly, it emphasizes the importance of automation in robot manufacturing. And thirdly, it highlights the necessity of a framework to orchestrate the synergy between simulated and hardware experiments. In the long term, integrating these contributions into evolutionary robotics is envisioned to enable the continuous production of robots in real-world environments. Full article

(This article belongs to the Special Issue Progress and Prospects of Evolutionary Robotics)

► Show Figures

Figure 1

21 pages, 8060 KiB

Open AccessArticle

Total Least Squares In-Field Identification for MEMS-Based Inertial Measurement Units

by Massimo Duchi and Edoardo Ida’

Robotics 2024, 13(11), 156; https://doi.org/10.3390/robotics13110156 - 23 Oct 2024

Viewed by 1657

Abstract

Inertial Measurement Units are widely used in various applications and, hardware-wise, they primarily consist of a tri-axial accelerometer and a tri-axial gyroscope. For low-end commercial employments, the low cost of the device is crucial: this makes MEMS-based sensors a popular choice in this [...] Read more.

Inertial Measurement Units are widely used in various applications and, hardware-wise, they primarily consist of a tri-axial accelerometer and a tri-axial gyroscope. For low-end commercial employments, the low cost of the device is crucial: this makes MEMS-based sensors a popular choice in this context. However, MEMS-based transducers are prone to significant, non-uniform and environmental-condition-dependent systematic errors, that require frequent re-calibration to be eliminated. To this end, identification methods that can be performed in-field by non-expert users, without the need for high-precision or costly equipment, are of particular interest. In this paper, we propose an in-field identification procedure based on the Total Least Squares method for both tri-axial accelerometers and gyroscopes. The proposed identification model is linear and requires no prior knowledge of the parameters to be identified. It enables accelerometer calibration without the need for specific reference surface orientation relative to Earth’s gravity and allows gyroscope calibration to be performed independently of accelerometer data, without requiring the sensor’s sensitive axes to be aligned with the rotation axes during calibration. Experiments conducted on NXP sensors FXOS8700CQ and FXAS21002 demonstrated that using parameters identified by our method reduced cross-validation standard deviations by about two orders of magnitude compared to those obtained using manufacturer-provided parameters. This result indicates that our method enables the effective calibration of IMU sensor parameters, relying only on simple 3D-printed equipment and significantly improving IMU performance at minimal cost. Full article

(This article belongs to the Special Issue Recent Trends and Advances on Robotics and Mechatronics within the IFToMM Technical Committee on Robotics and Mechatronics)

► Show Figures

Figure 1

15 pages, 1731 KiB

Open AccessArticle

Kinematic Reliability of Manipulators Based on an Interval Approach

by Fabian Andres Lara-Molina and Rogério Sales Gonçalves

Robotics 2024, 13(11), 155; https://doi.org/10.3390/robotics13110155 - 23 Oct 2024

Viewed by 508

Abstract

Robotic manipulators inevitably experience the impact of uncertainties and errors, such as dimensional tolerances and joint clearances. Therefore, this paper proposes a novel method based on an interval approach to evaluate the kinematic reliability of manipulators. Kinematic reliability quantifies the probability of positioning [...] Read more.

Robotic manipulators inevitably experience the impact of uncertainties and errors, such as dimensional tolerances and joint clearances. Therefore, this paper proposes a novel method based on an interval approach to evaluate the kinematic reliability of manipulators. Kinematic reliability quantifies the probability of positioning errors that fall within allowable boundaries. As a result, reliability evaluates the probability that the interval end-effector error produced by dimensional tolerances exceeds an acceptable rate. The proposed reliability index is based on the interval error that conveys an alternative approach to the kinematic reliability methods based on probabilistic frameworks reported in the literature based on probabilistic approaches. The obtained numerical results demonstrate the viability of the proposed methodology by evaluating the reliability of a serial manipulator subjected to joint clearances and a parallel manipulator with dimensional tolerances. Full article

(This article belongs to the Special Issue Selected Papers from MEDER 2024: Advances in Mechanism Design for Robotics)

► Show Figures

Figure 1
