Membranes 2018, 8(1), 14; https://doi.org/10.3390/membranes8010014

Preparation and Characterization of TiO2/g-C3N4/PVDF Composite Membrane with Enhanced Physical Properties

1
School of Environmental Engineering, Nanjing Institute of Technology, Nanjing 211167, China
2
Jiangsu Huijin Environmental Protection Technology Co., Ltd., Wuxi 214241, China
*
Author to whom correspondence should be addressed.
Received: 11 January 2018 / Revised: 12 February 2018 / Accepted: 14 February 2018 / Published: 5 March 2018
(This article belongs to the Special Issue Composite Membranes: Synthesis and Characterization)
Full-Text   |   PDF [1679 KB, uploaded 5 March 2018]   |

Abstract

TiO2/g-C3N4/PVDF composite membranes were prepared by a phase inversion method. A comparison of the performance and morphology was carried out among pure PVDF, g-C3N4/PVDF, TiO2/PVDF and TiO2/g-C3N4/PVDF composite membranes. The results of permeability and instrumental analysis indicated that TiO2 and g-C3N4 organic-inorganic composites obviously changed the performance and structure of the PVDF membranes. The porosity and water content of 0.75TiO2/0.25g-C3N4/PVDF composite membranes were 97.3 and 188.3 L/(m2·h), respectively. The porosity and water content of the 0.75TiO2/0.25g-C3N4 membranes were increased by 20.8% and 27.4%, respectively, compared with that of pure PVDF membranes. This suggested that the combination of organic-inorganic composite with PVDF could remarkably improve UTS, membrane porosity and water content. View Full-Text
Keywords: g-C3N4; PVDF membrane; TiO2; characterization g-C3N4; PVDF membrane; TiO2; characterization
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
