Anchor Design of a Ring Joint Based on Reliability in a Precast Shear Wall Structure

by 1,2, 1,2,*, 1,2, 3 and 1,2
1
Key Lab of Structures Dynamic Behaviour and Control of the Ministry of Education, Harbin Institute of Technology, Harbin 150090, China
2
Key Lab of Smart Prevention and Mitigation of Civil Engineering Disasters of the Ministry of Industry and Information Technology, Harbin Institute of Technology, Harbin 150090, China
3
China Construction Seventh Engineering Division Corp. Ltd., Zhengzhou 450004, China
*
Author to whom correspondence should be addressed.
Appl. Sci. 2019, 9(16), 3361; https://doi.org/10.3390/app9163361
Received: 6 June 2019 / Revised: 10 August 2019 / Accepted: 12 August 2019 / Published: 15 August 2019
(This article belongs to the Section Civil Engineering)
Precast buildings have been widely used owing to its outstanding features. As these buildings consist of a combination of various components, the mechanical properties of the connections play a critical role in the overall performance of the structure, particularly the vertical connections in shear wall members. A new connection called ring joint is proposed for precast buildings, and test pieces were designed to analyze the anchor performance. The damage phenomena and test data were observed and recorded. The displacement, force, and strain were analyzed, and the results indicated that the anchor length was a key factor and the connection was safe and reliable under reasonable design. Numerical analysis was conducted to explore the mechanical mechanism, and a bearing capacity model was proposed combining the bond and dowel effects simultaneously. Anchor length was determined based on reliability analysis under various conditions, and other suggestions were proposed. All these could guarantee the mechanical properties of the connection, as well as safety and reliability, and promote the popularization and application. View Full-Text
Keywords: precast structure; ring joint; numerical analysis; bearing capacity model; reliability analysis precast structure; ring joint; numerical analysis; bearing capacity model; reliability analysis
Show Figures

Figure 1

MDPI and ACS Style

Zhou, J.; Zhi, X.; Fan, F.; Jiao, A.; Qian, H. Anchor Design of a Ring Joint Based on Reliability in a Precast Shear Wall Structure. Appl. Sci. 2019, 9, 3361.
