Open AccessArticle
Appl. Sci. 2018, 8(1), 51;

Omnidirectional Jump of a Legged Robot Based on the Behavior Mechanism of a Jumping Spider

Key Laboratory of Road Construction Technology and Equipment of MOE, Chang’an University, Xi’an 710064, China
State Key Laboratory of Fluid Power and Mechatronic Systems, Zhejiang University, Hangzhou 310028, China
Author to whom correspondence should be addressed.
Received: 14 November 2017 / Revised: 27 December 2017 / Accepted: 29 December 2017 / Published: 1 January 2018
(This article belongs to the Special Issue Bio-Inspired Robotics)
Full-Text   |   PDF [3865 KB, uploaded 2 January 2018]   |


To find a common approach for the development of an efficient system that is able to achieve an omnidirectional jump, a jumping kinematic of a legged robot is proposed based on the behavior mechanism of a jumping spider. To satisfy the diversity of motion forms in robot jumping, a kind of 4 degrees of freedom (4DoFs) mechanical leg is designed. Taking the change of joint angle as inspiration by observing the behavior of the jumping spider during the acceleration phase, a redundant constraint to solve the kinematic is obtained. A series of experiments on three types of jumping—vertical jumping, sideways jumping and forward jumping—is carried out, while the initial attitude and path planning of the robot is studied. The proposed jumping kinematic is verified on the legged robot experimental platform, and the added redundant constraint could be verified as being reasonable. The results indicate that the jumping robot could maintain stability and complete the planned task of jumping, and the proposed spider-inspired jumping strategy could easily achieve an omnidirectional jump, thus enabling the robot to avoid obstacles. View Full-Text
Keywords: jumping spider; jumping robot; omnidirectional jump; redundant DoF jumping spider; jumping robot; omnidirectional jump; redundant DoF

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
