Verification of Automotive Monopost Seat Strength through Dynamic and Quasi-Static Simulations
Abstract
:1. Introduction
2. Monopost Seat
3. Safety Performance Standard
Regulation Name | EUR ECE R14 [12] | North America FMVSS 210/207 [13,14] | ||
---|---|---|---|---|
Loading angle | 10 ± 5° | 10 ± 5° | ||
Load | 3-POINT | SHOULDER | 13,500 ± 200 N | 13,345 N |
LAP | 13,500 ± 200 N | 13,345 N | ||
Inertial load | Seat weight × 20 | Seat weight × 20 | ||
Holding time for load | >0.2 s | >10 s |
