Erosion-Corrosion of Gathering Pipeline Steel in Oil-Water-Sand Multiphase Flow
Abstract
1. Introduction
2. Materials and Methods
2.1. Materials and Solution
2.2. Pipe Flow Loop Setup
2.3. Testing Methods
3. Results and Discussion
3.1. Influence of Velocity on Erosion-Corrosion Performance
3.2. Influence of Sand Concentrations on Erosion-Corrosion
3.3. Performance of Erosion-Corrosion at Different Angle Positions of a Pipe Section
3.4. Erosion-Corrosion Synergism
3.5. Observation of Corrosion Morphology
4. Conclusions
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
