Article

Using Plane Strain Compression Test to Evaluate the Mechanical Behavior of Magnesium Processed by HPT

1
Department of Mechanical Engineering, Universidade Federal de Minas Gerais, Av. Antônio Carlos 6627, Belo Horizonte 30270-901, MG, Brazil
2
Department of Materials Engineering and Civil Construction, Universidade Federal de Minas Gerais, Av. Antônio Carlos 6627, Belo Horizonte 30270-901, MG, Brazil
3
Graduate Program in Metallurgical, Materials and Mining Engineering, Universidade Federal de Minas Gerais, Av. Antônio Carlos 6627, Belo Horizonte 30270-901, MG, Brazil
4
Department of Metallurgical and Materials Engineering, Universidade Federal de Minas Gerais, Av. Antônio Carlos 6627, Belo Horizonte 30270-901, MG, Brazil
5
Materials Research Group, Department of Mechanical Engineering, University of Southampton, Southampton SO17 1BJ, UK
*
Author to whom correspondence should be addressed.
Academic Editors: Andriy Ostapovets and Marcello Cabibbo
Metals 2022, 12(1), 125; https://doi.org/10.3390/met12010125
Received: 16 December 2021 / Revised: 4 January 2022 / Accepted: 6 January 2022 / Published: 9 January 2022
There is a great interest in improving mechanical testing of small samples produced in the laboratory. Plane strain compression is an effective test in which the workpiece is a thin sheet. This provides great potential for testing samples produced by high-pressure torsion. Thus, a custom tool was designed with the aim to test 10 mm diameter discs processed by this technique. Finite element analysis is used to evaluate the deformation zone, stress and strain distribution, and the accuracy in the estimation of stress–strain curves. Pure magnesium and a magnesium alloy processed by high-pressure torsion are tested using this custom-made tool. The trends observed in strength and ductility agree with trends reported in the literature for these materials. View Full-Text
Keywords: magnesium; severe plastic deformation; mechanical properties; mechanical testing; finite element modeling magnesium; severe plastic deformation; mechanical properties; mechanical testing; finite element modeling
Show Figures

Figure 1
