National Mineral Waste Databases as an Information Source for Assessing Material Recovery Potential from Mine Waste, Tailings and Metallurgical Waste
Abstract
:1. Introduction
2. Materials and Methods
2.1. Defining Key Mine Waste Valorisation Data Parameters
2.2. Review and Assessment of National Mine Waste Inventories
3. Results and Discussion
4. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
- Coulson, M. The History of Mining: The Events, Technology and People Involved in the Industry that Forged the Modern World; Harriman House Ltd.: Hampshire, UK, 2012. [Google Scholar]
- Mudd, G.M. The Sustainability of Mining in Australia: Key Production Trends and Their Environmental Implications for the Future; Research Report No. RR5; Department of Civil Engineering, Monash University: Monash, Australia, 2009. [Google Scholar]
- Habashi, F. Metallurgy, History of. In Reference Module in Materials Science and Materials Engineering; Saleen, H., Ed.; Elsevier: Oxford, UK, 2017; pp. 1–6. [Google Scholar]
- Zepf, V.; Simmons, J.; Reller, A.; Rennie, C.; Ashfield, M. Materials Critical to the Energy Industry. An Introduction, 2nd ed.; British Petroleum: London, UK, 2014. [Google Scholar]
- Endangered Elements. Available online: https://www.acs.org/content/acs/en/greenchemistry/research-innovation/endangered-elements.html (accessed on 23 April 2020).
- The 2017 List of Critical Raw Materials for the EU. Available online: https://eur-lex.europa.eu/legal-content/EN/TXT/?uri=CELEX:52017DC0490 (accessed on 27 April 2020).
- Lemière, B. Mining the waste: Prospecting valuable residues optimising processes with modern technology, sustainably remediating legacy sites. In Proceedings of the conference 2nd Eurasia—MENA Mining Summit, Istanbul, Turkey, 16–17 June 2012. [Google Scholar]
- Binnemans, K.; Pontikes, Y.; Jones, P.T.; Van Gerven, T.; Blanpain, B. Recovery of rare earths from industrial waste residues: A concise review. In Proceedings of the Third International Slag Valorization Symposium, Leuven, Belgium, 19–20 March 2013; Malfliet, A., Jones, P.T., Binnemans, K., Cizer, Ö., Fransaer, J., Yan, P., Pontikes, Y., Guo, M., Blanpain, B., Eds.; 2013; pp. 191–205. [Google Scholar]
- Falagán, C.; Grail, B.M.; Johnson, B. New approaches for extracting and recovering metals from mine tailings. Min. Eng. 2017, 106, 71–78. [Google Scholar] [CrossRef]
- Matinde, E.; Simate, G.S.; Ndlovu, S. Mining and metallurgical wastes: A review of recycling and re-use practices. J. S. Afr. Inst. Min. Metall. 2018, 118, 825–844. [Google Scholar] [CrossRef]
- Valderrama, I.; Santander, M.; Paiva, M.; Rubio, J. Modified-three-product-column (3PC) flotation of copper-gold particles in a rougher feed and tailings. Min. Eng. 2011, 24, 1397–1401. [Google Scholar] [CrossRef]
- Sapsford, D.J.; Cleall, P.J.; Harbottle, M.J. In situ resource recovery from waste repositories: Exploring the potential for mobilisation and capture of metals from anthropogenic ores. J. Sustain. Metall. 2017, 3, 375–392. [Google Scholar] [CrossRef][Green Version]
- Peppicelli, C.; Harbottle, M.J.; Sapsford, D.J.; Cleall, P.J. Changes in metal speciation and mobility during electrokinetic treatment of industrial wastes: Implications for remediation and resource recovery. Sci. Total Environ. 2018, 624, 1488–1503. [Google Scholar] [CrossRef] [PubMed]
- Bellenfant, G.; Guezennec, A.G.; Bodenan, F.; D’Hugues, P.; Cassard, D. Re-processing of mining waste: Combining environmental management and metal recovery? In Mine Closure 2013, Proceedings of the Eighth International Seminar on Mine Closure, Vina del Mar, Chile, 5–7 December 2013; Fourie, A.B., Tibbett, M., Eds.; Australian Centre for Geomechanics: Perth, Australia, 2013; pp. 571–582. [Google Scholar]
- Ndlovu, S.; Simate, G.S.; Matinde, E. Waste Production and Utilization in the Metal Extraction Industry; CRC Press: Boca Raton, FL, USA, 2017; p. 512. [Google Scholar]
- Directive 2006/21/EC of the European Parliament and of the Council of 15 March 2006 on the Management of Waste from Extractive Industries and Amending Directive 2004/35/EC—Statement by the European Parliament, the Council and the Commission. Available online: https://eur-lex.europa.eu/legal-content/EN/TXT/?uri=CELEX%3A32006L0021 (accessed on 24 April 2020).
- Grimalt, J.O.; Ferrer, M.; Macpherson, E. The mine tailing accident in Aznalcollar. Sci. Total Environ. 1999, 242, 3–11. [Google Scholar] [CrossRef]
- McDermott, R.K.; Sibley, J.M. The Aznalcóllar tailings dam accident—A case study. Min. Resour. Eng. 2000, 9, 101–118. [Google Scholar] [CrossRef]
- Report of the International Task Force for Assessing the Baia Mare Accident; ICPDR: Brussels, Belgium, 2000; Available online: https://reliefweb.int/report/hungary/report-international-task-force-assessing-baia-mare-accident (accessed on 5 February 2019).
- The Raw Materials Initiative—Meeting Our Critical Needs for Growth and Jobs in Europe. Available online: https://eur-lex.europa.eu/LexUriServ/LexUriServ.do?uri=COM:2008:0699:FIN:en:PDF (accessed on 24 April 2020).
- Panagiotopoulou, C.; Gaki, A.; Balomenos, E.; Taxiarchou, M.; Panias, D.; Paspaliaris, I.; Aggelopoulos, P. Valorisation of Extractive Industries’ Wastes. In Proceedings of the OPMR2016—Opportunities in Processing of Metal Resources in South East Europe, Budapest, Hungary, 28–30 November 2016; pp. 201–211. [Google Scholar]
- Garbarino, E.; Orveillon, G.; Saveyn, H.; Barthe, P.; Eder, P. Best Available Techniques (BAT) Reference Document for the Management of Waste from Extractive Industries in Accordance with Directive 2006/21/EC; Report No. EUR 28963 EN; Publication Office of the European Union: Luxembourg, 2018; p. 692.
- Blengini, G.A.; Mathieux, F.; Mancini, L.; Nyberg, M.; Cavaco Viegas, H.M. (Eds.) Recovery of Critical and Other Raw Materials from Mining Waste and Landfills: State of Play on Existing Practices; EUR 29744 EN; Publications Office of the European Union: Luxembourg, 2019.
- Bodenan, F.; Guezennec, A.G.; Beaulieu, M.; Bellenfant, G.; Lemière, B.; Catherine, L.; Save, M. Re-Processing of mine tailings: Discussion on case studies. In Proceedings of the 13th SGA Biennal Meeting, Nancy, France, 24–27 August 2015. [Google Scholar]
- Dino, G.A.; Rossetti, P.; Biglia, G.; Sapino, M.L.; Di Mauro, F.; Sarkka, H.; Coulon, F.; Gomes, D.; Parejo-Bravo, L.; Aranda, P.Z.; et al. Smart Ground Project: A New Approach to Data Accessibility and Collection for Raw Materials and Secondary Raw Materials in Europe. Environ. Eng. Manag. J. 2017, 16, 1673–1684. [Google Scholar] [CrossRef]
- Management of Mining, Quarrying and Ore Processing Waste in the European Union. Study Made for DG Environment, European Commission. BRGM/RP-50319-FR. December 2001. Available online: https://ec.europa.eu/environment/waste/studies/mining/0204finalreportbrgm.pdf (accessed on 5 February 2019).
- International Reporting Template for the Public Reporting of Exploration Targets, Exploration Results, Mineral Resources and Mineral Reserves. November 2019. Available online: http://www.crirsco.com/templates/CRIRSCO_International_Reporting_Template_November_2019.pdf (accessed on 5 February 2019).
- Australasian Code for Reporting of Exploration Results, Mineral Resources and Ore Reserves (The JORC Code 2012 Edition). Available online: http://www.jorc.org/docs/JORC_code_2012.pdf (accessed on 5 February 2019).
- PERC Reporting Standard. Pan-European Standard for Reporting of Exploration Results, Mineral Resources and Reserves (“The PERC Reporting Standard”). 2017. Available online: http://www.vmine.net/PERC/documents/PERC%20REPORTING%20STANDARD%202017.pdf (accessed on 5 February 2019).
- United Nations Framework Classification for Fossil Energy and Mineral Reserves and Resources 2009 Incorporating Specifications for Its Application; ECE Energy Series; No. 42; UN: New York, NY, USA, 2014; Available online: https://doi.org/10.18356/a9e6af6c-en (accessed on 5 February 2019).
- GEODERIS. Propositions Méthodologiques sur les Conditions de Mise en Oeuvre de la Démarche D’interprétation de L’état des Milieux au Contexte D’après-Mine; Report N2015/014DE—15NAT24080; GEODERIS: Metz, France, 2015. (In French)
- GEODERIS. Suites Données à L’inventaire DDIE Actualisation Méthodologique Introduction de la Catégorisation des Secteurs; Report N2016/025DE—16NAT24010; GEODERIS: Metz, France, 2017. (In French)
- Charles, N.; Dupuy, J.-J.; Christmann, P.; Galin, R.; Guillon, D. Industrie Minérale et Activité Minière en France. Collection «La Mine en France». Tome 1, 25p, 5 figures, 2 tables. 2017. Available online: http://www.mineralinfo.fr/sites/default/files/upload/tome_01_industrie_mineraleactivite_miniere_final24032017.pdf (accessed on 10 May 2020).
- Jiménez, A.M.; Vadillo, L.; Rodríguez Pacheco, R.L.; Fernández Naranjo, F.J.; Arranz-González, J.C.; Alberruche, E.; Rodriguez Gomez, V. Metodología Para la Realización de un Inventario de Instalaciones de Residuos Mineros Cerradas o Abandonadas; Instituto Geológico y Minero de España (IGME): Madrid, Spain, 2014; p. 206. [Google Scholar]
- Serra, M.; Andrisani, M.G. Inventario Nazionale delle Strutture di Deposito di Rifiuti Estrattivi, Chiuse o Abbandonate di Tipo A; Report No. GEO 2017/RA/01; ISPRA: Rome, Italy, 2017. Available online: http://www.isprambiente.gov.it/files/miniere/Inventario_Aggiornamento_2017.pdf (accessed on 5 February 2019).
- Cameron, D.G. Use Guide for the BRITPITS GIS Dataset; Open Report OR/13/016; British Geological Survey: Keyworth, UK, 2012. [Google Scholar]
- Palumbo-Roe, B.; Colman, T. The Nature of Waste Associated with Closed Mines in England and Wales; Open Report OR/10/14; British Geological Survey: Keyworth, UK, 2010. [Google Scholar]
- Palumbo-Roe, B.; Linley, K.; Cameron, D.; Mankelow, J. Inventory of Closed Mine Waste Facilities in Northern Ireland, Phase 2, Assessment; Report CR/14/031N; British Geological Survey: Nottingham, UK, 2014. [Google Scholar]
- Inventory of Closed Mining Waste Facilities, Version 2 (UK Environment Agency). Available online: https://assets.publishing.service.gov.uk/government/uploads/system/uploads/attachment_data/file/288582/LIT_6797_7d390c.pdf (accessed on 5 February 2019).
- Inventory of Closed Mining Waste Facilities (Scottish Government). Available online: https://www.gov.scot/binaries/content/documents/govscot/publications/advice-and-guidance/2015/01/closed-mining-waste-facilities-list/documents/fe847c5d-896f-4d92-8c11-ab1341538a90/fe847c5d-896f-4d92-8c11-ab1341538a90/govscot:document/ (accessed on 5 February 2019).
- Kiss, J.; Jordán, G. Inventory and Risk Classification of Closed Mine Waste Facilities for Hungary; Version No. 2; MBFH–ELGI–MÁFI: Budapest, Hungary, 2012. [Google Scholar]
- Gosar, M.; Šajn, R.; Miler, M. Izdelava Popisa Zaprtih Objektov za Ravnanje z Odpadki iz Rudarskih in Drugih Dejavnosti Izkoriščanja Mineralnih Surovin—Poročilo 1. Faze Projekta; Geological Survey of Slovenia: Ljubljana, Slovenia, 2013. (In Slovene) [Google Scholar]
- Gosar, M.; Šajn, R.; Miler, M. Izdelava Popisa Zaprtih Objektov za Ravnanje z Odpadki iz Rudarskih in Drugih Dejavnosti Izkoriščanja Mineralnih Surovin—Poročilo 2. Faze Projekta; Geological Survey of Slovenia: Ljubljana, Slovenia, 2013. (In Slovene) [Google Scholar]
- Gosar, M.; Šajn, R.; Miler, M. Izdelava Popisa Zaprtih Objektov za Ravnanje z Odpadki iz Rudarskih in Drugih Dejavnosti Izkoriščanja Mineralnih Surovin—Poročilo 3. Faze Projekta; Geological Survey of Slovenia: Ljubljana, Slovenia, 2014. (In Slovene) [Google Scholar]
- Crane, R.A.; Sinnett, D.E.; Cleall, P.J.; Sapsford, D.J. Physicochemical composition of wastes and co-located landscape designations at legacy mine sites in south west England and Wales: Implications on resource potential. Resour. Conserv. Recycl. 2017, 123, 117–134. [Google Scholar] [CrossRef]
- Méthodologie Nationale de Gestion des Sites et Sols Pollués. Ministère de l’Environnement, de l’Energie et de la Mer. Available online: http://ssp-infoterre.brgm.fr/sites/default/files/upload/documents/methodo_ssp_2017.pdf (accessed on 5 February 2019).
Country | Abbreviations | Name | Reference | Total No. of Sites | No, of Sites with Detailed Assessment | Measured Substances |
---|---|---|---|---|---|---|
France | GEODERIS | GEODERIS | [31,32,33] | 3144 | 200 | Pb, Zn, As, Cd, Cr, Hg, Cu, V, Mo, Co, Ni, Se, Sb, Tl |
Spain | IGME | Instituto Geológico y Minero de España | [34] | 370 | 370 | Pb, Zn, As, Cd, Cr, Hg, Cu, V, Mo, Co, Ni, Se |
Italy | ISPRA | Istituto Superiore per la Protezione e la Ricerca Ambientale | [35] | 650 | 220 | Asbestos, Ag, As, Cd, Cr, Co, Cu, Hg, Mn, Pb, Ni, Tl, Zn, Sb, Sn, Be, V, CN, Fluoride, Aromatic compounds, TPH C > 12 |
* UK | BGS | British Geological Survey | [36,37,38,39,40] | 404 | 0 | Harmful substances are measured in downstream water and not in waste material |
EA | Environment Agency (England and Wales) | |||||
Scottish Government | ||||||
NIDoE | Northern Ireland Department of Environment | |||||
Hungary | MBFSZ | Magyar Bányászati és Földtani Szolgálat | [41] | 1046 | 71 | Ag, Au, As, Be, Cd, Cr, Cu, Hg, Mo, Ni, Pb, Sb, Se, Sn, Th, Tl, U, Zn |
Slovenia | ARSO | Agencija Republike Slovenije za okolje | [42,43,44] | 173 | 78 | As, Ba, Cd, Co, Cr, Cu, Hg, Mo, Ni, Pb, Zn |
Portugal | DGEG, EDM | Direcção Geral de Energia e Geologia | No references | 199 | 39 | Cd, Cu, Ni, Pb, Zn, Cr total, Cr6+, Hg, Co, Mo, As |
Parameter ID | Short Description | Sub Division | |
---|---|---|---|
Basic Valorisation Parameters | B1 | Location, history, mining and processing technology of the site | |
B2 | Volume, area and structure of the existing waste deposits | ||
B3 | Reason for which the mine was abandoned | ||
B4 | Homogeneity of the tailings | ||
B5 | Methodology of data collection | ||
B6.1 | Environmental impacts of mine waste deposit | Actual physical | |
B6.2 | Potential physical | ||
B6.3 | Actual chemical | ||
B6.4 | Potential chemical | ||
B6.5 | Need for remediation | ||
B6.6 | Remediation costs | ||
B7.1 | Site extractability | Possibility for safe extraction and waste relocation | |
B7.2 | Revegetation status | ||
B8.1 | Site accessibility | Ownership | |
B8.2 | Special permits required | ||
B8.3 | Land use restrictions | ||
B8.4 | Other legislative barriers | ||
B9.1 | Data availability | Data managing authority | |
B9.2 | Language(s) | ||
Metal-Centric Valorisation Parameters | M10.1 | Chemical and mineralogical composition | Matrix |
M10.2 | Commodity elements | ||
M10.3 | Trace elements | ||
M11.1 | Physico-chemical properties | Grain size distribution | |
M11.2 | Moisture content | ||
M11.3 | Redox state at different pH | ||
Material-Centric Valorisation Parameters | C10.1 | Chemical and mineralogical composition | Type and content of alkali ions |
C10.2 | Type and content of alkaline earth ions | ||
C10.3 | Type and content of silicon | ||
C10.4 | Type and content of potentially toxic elements (PTEs) | ||
C10.5 | Type and content of organic substance | ||
C11.1 | Physico-chemical properties | Moisture | |
C11.2 | Grain size distribution | ||
C12.1 | Potential final products specifications | Mechanical properties | |
C12.2 | Thermal properties |
Pa. | France | Spain | Italy | UK | Hungary | Slovenia | Portugal |
---|---|---|---|---|---|---|---|
B1 | AV only for some sites | AV as short description | AV for most of the sites, detailed for some | AV (1) | AV only in mine closure reports | AV as short description of history of mining site | AV as short description of history of mining site |
B2 | AV, data quality depends on potential risk | AV | AV if provided by Regional Geological Survey | NA in inventory, but in various publications | Estimation, AV in technical operation plans or individual survey reports | Estimation | AV |
B3 | NAS | AV for larger mines | NA | NA | NA | AV for high risk sites | AV in selected sites |
B4 | AV for high risk sites with ongoing remediation | NA | NA | NA in inventory, but in various publications | NA | NA | Visual estimation |
B5 | AV for high-risk sites (2) | AV (3) | AV for deposits investigated with ARAGNA method (Sardinia) | AV as part of the methodology report | NA | AV | AV for remediated sites |
B6.1 | AV for potential high-risk sites | AV | AV | AV, based on risk assessment (4) | AV | AV for high risk sites | AV for active mines and remediated sites |
B6.2 | AV for high risk sites with ongoing remediation | AV | AV | AV, based on risk assessment (4) | AV | AV for high risk sites | AV for active mines and remediated sites |
B6.3 | AV for potential high-risk sites | AV | AV | AV, based on risk assessment (4) | AV | AV for high risk sites | AV for active mines and remediated sites |
B6.4 | AV for high risk sites with ongoing remediation | AV | AV | AV, based on risk assessment (4) | AV | AV for high risk sites | AV for active mines and remediated sites |
B6.5 | AV for potential high-risk sites | AV | AV | AV, based on risk assessment (4) | AV | AV for highly risk sites | AV for risk sites |
B6.6 | AV for high risk sites with ongoing remediation | NAS | AV for specific sites within the remediation projects | Based on risk assessment (4) | NAS | NAS | AV, but possibly confidential |
B7.1 | AV for high risk sites with ongoing remediation | NAS | NAS | NA | AV for selected deposits | NAS | NAS |
B7.2 | NA | AV | AV | NA | AV | AV for risk sites | AV for risk sites |
B8.1 | AV for sites with no responsible owner | NAS | Data in the environmental protection and land use plans | NA, but held in BRITPITS and/or the Land Registry | AV for operating mines | Information is AV in land register | AV |
B8.2 | According to Mining legislation | NAS | Depending on land use restrictions and site hazard characterisation, involving local and national authorities | Mineral extraction is subject to planning – likely to be complicated as may fall under environmental regulation | According to Mining legislation | Depending on land use restrictions and site hazard characterisation, involving local and national authorities | Mine waste are not classified as waste in the Portuguese environmental law |
B8.3 | According to Mining legislation | NAS | Depending on land use restrictions and site hazard characterisation, involving local and national authorities | There may be land use restrictions which could include cultural or ecological designations associated with past mining | According to Mining legislation | Determined in national and municipality spatial plans | Determined in national and municipality spatial plans |
B8.4 | If reprocessing includes activities outside the scope of mining regulations | NAS | Depending on land use restrictions and site hazard characterisation, involving local and national authorities | Waste management and pollution control regulations as well as those protecting the natural environment and cultural assets | If reprocessing includes activities outside the scope of mining regulations | Depending on land use restrictions and site hazard characterisation, involving local and national authorities | If reprocessing includes activities outside the scope of mining regulations |
B9.1 | Data in Table 1 | ||||||
B9.2 | National | National | National | National | National and English | National | National |
Pa. | France | Spain | Italy | UK | Hungary | Slovenia | Portugal |
---|---|---|---|---|---|---|---|
M10.1 | AV for high risk sites with ongoing remediation | AV, not public | AV for investigated sites | NA, but AV for a limited number of mines in other documents | AV | AV | AV for active sites and selected remediated sites |
M10.2 | AV | AV, not public | AV for investigated sites | NA, as above | NA, only for specific sites in other reports | AV for high risk sites | AV for active and selected remediated sites |
M10.3 | AV for high risk sites with ongoing remediation | AV, not public | AV for investigated sites | NA, as above | AV for red mud tailings and for other sites containing PTEs | AV for high risk sites | AV for active and selected remediated sites |
M11.1 | AV for high risk sites with ongoing remediation | AV, not public | AV for investigated sites | NA, as above | AV | Visual estimation for some sites | AV for active and selected remediated sites |
M11.2 | AV for high risk sites with ongoing remediation | NAS | AV for investigated sites | NA, as above | NAS | NAS | AV for active sites |
M11.3 | AV for high risk sites with ongoing remediation | pH and electrical conductivity only, not public | AV for investigated sites | NA, as above | NAS | NAS | AV for active sites |
Pa. | France | Spain | Italy | UK | Hungary | Slovenia | Portugal |
---|---|---|---|---|---|---|---|
C10.1 | NAS | NAS | AV as potential residues | NA, but AV for a limited number of mines in other documents | NAS | NAS | NAS |
C10.2 | NAS | NAS | AV as potential residues | NA, as above | NAS | NAS | NAS |
C10.3 | NAS | NAS | AV as potential residues | NA, as above | NAS | NAS | NAS |
C10.4 | NAS | AV, not public | AV as potential residues | NA, as above | AV for larger waste sites | AV for high risk sites | NAS |
C10.5 | NAS | NAS | AV as potential residues | NA, as above | NAS | Visual estimation for some sites | NAS |
C11.1 | AV for high risk sites with ongoing remediation | NAS | AV for investigated sites | NA, as above | NAS | NAS | NAS |
C11.2 | AV for high risk sites with ongoing remediation | AV, not public | AV for investigated sites | NA, as above | NAS | Visual estimation for some sites | NAS |
C12.1 | NAS | NAS | AV for investigated sites | NA, as above | NAS | NAS | NAS |
C12.2 | NAS | NAS | AV for investigated sites | NA, as above | NAS | NAS | NAS |
