Searching for Orbits for a Mission to the Asteroid 2001SN263 Considering Errors in the Physical Parameters
Abstract
1. Introduction
2. The Triple Asteroid 2001SN263
3. Description of the Problem
4. Equations of Motion
5. Results
5.1. A Good Option to Observe Alpha and Gamma
5.2. A Good Option to Observe Beta
5.3. An Option to Observe All the Three Bodies of the System
6. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
- Belton, M.J.S.; Veverka, J.; Thomas, P.; Helfenstein, P.; Simonelli, D.; Chapman, C.; Davies, M.E.; Greeley, R.; Greenberg, R.; Head, J.; et al. Galileo Encounter with 951 Gaspra: First pictures of an asteroid. Science 1992, 257, 1647. [Google Scholar] [CrossRef] [PubMed]
- Belton, M.J.; Chapman, C.R.; Klaasen, K.P.; Harch, A.P.; Thomas, P.C.; Veverka, J.; McEwen, A.S.; Pappalardo, R.T. Galileo’s Encounter with 243 Ida: Overview of the imaging experiment. Icarus 1996, 120, 1–19. [Google Scholar] [CrossRef]
- Binzel, R.P.; Rivkin, A.; Bus, S.J.; Sunshine, J.; Burbine, T.H. MUSES-C target asteroid (25143) 1998 SF36: A reddened ordinary chondrite. Meteorit. Planet. Sci. 2001, 36, 1167–1172. [Google Scholar] [CrossRef]
- Veverka, J.; Farquhar, B.B.; Robinson, M.J.; Thomas, P.C.; Murchie, S.; Harch, A.P.; Antreasian, P.G.; Chesley, S.R.; Miller, J.K.; Owen, W.M.; et al. The landing of the Near-Shoemaker spacecraft on asteroid 433 Eros. Nature 2001, 413, 390–393. [Google Scholar] [CrossRef]
- Miller, J.K.; Konopliv, A.S.; Antreasian, P.G.; Bordi, J.J.; Chesley, S.; Helfrich, C.E.; Owen, W.M.; Wang, T.C.; Williams, B.G.; Yeomans, D.K.; et al. Determination of shape, gravity and rotational state of asteroid 433 Eros. Icarus 2002, 155, 3–17. [Google Scholar] [CrossRef]
- Broschart, S.B.; Scheeres, D.J. Control of hovering spacecraft near small bodies: Application to asteroid 25143 Itokawa. J. Guid. Control Dyn. 2005, 28, 343–354. [Google Scholar] [CrossRef]
- Huntress, W.; Stetson, D.; Farquhar, R.; Zimmerman, J.; Clark, B.; O’Neil, W.; Bourke, R.; Foing, B. The next steps in exploring deep space—A cosmic study by the IAA. Acta Astronaut. 2006, 58, 304–377. [Google Scholar] [CrossRef]
- Yoshikawa, M.; Fujiwara, A.; Kawaguchi, J. Hayabusa and its adventure around the tiny asteroid Itokawa. Proc. Int. Astron. Union 2006, 2, 323–324. [Google Scholar] [CrossRef]
- Brum, A.G.V.D.; Hetem, A., Jr.; Rêgo, I.D.S.; Francisco, C.P.F.; Fenili, A.; Madeira, F.; Da Cruz, F.C.; Assafin, M. Preliminary development plan of the ALR, the laser rangefinder for the Aster deep space mission to the 2001 SN263 asteroid. J. Aerosp. Tehchnol. Manag. 2011, 3, 331–338. [Google Scholar] [CrossRef]
- Jones, T.; Bellerose, J.; Lee, P.; Prettyman, T.; Lawrence, D.; Smith, P.; Gaffey, M.; Nolan, M.; Goldsten, J.; Thomas, P.; et al. Amor: Investigating The Triple Asteroid System 2001 SN263. AAS/Div. Planet. Sci. Meet. Abstr. #42 2010, 42, 49. Available online: https://ui.adsabs.harvard.edu/abs/2010DPS....42.4929J (accessed on 23 August 2022).
- Müller, T.G.; Ďurech, J.; Hasegawa, S.; Abe, M.; Kawakami, K.; Kasuga, T.; Kinoshita, D.; Kuroda, D.; Urakawa, S.; Okumura, S.; et al. Thermo-physical properties of 162173 (1999 JU3), a potential flyby and rendezvous target for interplanetary missions. Astron. Astrophys. 2011, 525, A145. [Google Scholar] [CrossRef]
- Tardivel, S.; Michel, P.; Scheeres, D.J. Deployment of a lander on the binary asteroid (175706) 1996 FG3, potential target of the European MarcoPolo-R sample return mission. Acta Astronaut. 2013, 89, 60–70. [Google Scholar] [CrossRef]
- Tsuda, Y.; Yoshikawa, M.; Abe, M.; Minamino, H.; Nakazawa, S. System design of the Hayabusa 2—Asteroid sample return mission to 199 JU3. Acta Astronaut. 2013, 91, 356–362. [Google Scholar] [CrossRef]
- Chesley, S.R.; Farnocchia, D.; Nolan, M.C.; Vokrouhlický, D.; Chodas, P.W.; Milani, A.; Spoto, F.; Rozitis, B.; Benner, L.A.; Bottke, W.F.; et al. Orbit and bulk density of the OSIRIS-REx target Asteroid (101955) Bennu. Icarus 2014, 235, 5–22. [Google Scholar] [CrossRef]
- Bottke, W.F.; Vokrouhlický, D.; Walsh, K.J.; Delbo, M.; Michel, P.; Lauretta, D.S.; Campins, H.; Connolly, H.C.; Scheeres, D.J.; Chelsey, S.R. In search of the source of asteroid (101955) Bennu: Applications of the stochastic YORP model. Icarus 2015, 247, 191–217. [Google Scholar] [CrossRef]
- NASA. Available online: https://www.nasa.gov/osiris-rex (accessed on 25 April 2017).
- Surovik, D.A.; Scheeres, D.J. Autonomous maneuver planning at small bodies via mission objective reachability analysis. In Proceedings of the 2014 AIAA/AAS Astrodynamics Specialist Conference, San Diego, CA, USA, 4–7 August 2014. [Google Scholar]
- Werner, R.A. The gravitational potential of a homogeneous polyhedron or don’t cut corners. Celest. Mech. Dyn. Astron. 1994, 59, 253–278. [Google Scholar] [CrossRef]
- Scheeres, D.J. Dynamics about uniformly rotating triaxial ellipsoids: Application to asteroids. Icarus 1994, 121, 225–238. [Google Scholar] [CrossRef]
- Scheeres, D.J. Orbital Motion in Strongly Perturbed Environments; Springer: Boulder, CO, USA, 2012; ISBN 978-3-642-03255-4. [Google Scholar]
- Scheeres, D.J. Orbit mechanics about asteroids and comets. J. Guid. Control Dyn. 2012, 35, 987–997. [Google Scholar] [CrossRef]
- Scheeres, D.J. Orbital mechanics about small bodies. Acta Astronaut. 2012, 72, 1–14. [Google Scholar] [CrossRef]
- Rossi, A.; Marzari, F.; Farinella, P. Orbital evolution around irregular bodies. Earth Planets Space 1999, 51, 1173–1180. [Google Scholar] [CrossRef]
- Scheeres, D.J.; Hu, W. Secular motion in a 2nd degree and order gravity field with no rotation. Celest. Mech. Dyn. Astron. 2001, 79, 183–200. [Google Scholar] [CrossRef]
- Bartczakk, P.; Breiter, S.; Jusiel, P. Ellipsoids, material points and material segments. Celest. Mech. Dyn. Astron. 2006, 96, 31–48. [Google Scholar] [CrossRef]
- Byram, S.M.; Scheeres, D.J. Stability of Sun-Synchronous Orbits in the Vicinity of a Comet. J. Guid. Control Dyn. 2009, 32, 1550–1559. [Google Scholar] [CrossRef][Green Version]
- Shang, H.; Wu, X.; Cui, P. Periodic orbits in the doubly synchronous binary asteroid systems and their applications in space missions. Astrophys. Space Sci. 2014, 355, 69–87. [Google Scholar] [CrossRef]
- Yang, H.; Gong, S.; Baoyin, H. Two-impulse transfer orbits connecting equilibrium points of irregular-shaped asteroids. Astrophys. Space Sci. 2015, 357, 66. [Google Scholar] [CrossRef]
- Zeng, X.; Baoyin, H.; Li, J. Updated Rotating Mass Dipole with Oblateness of One Primary (II): Out-of-plane Equilibria and Their Stability. Astrophys. Space Sci. 2016, 361, 15. [Google Scholar] [CrossRef]
- Chanut, T.G.G.; Aljbaae, S.; Prado, A.F.B.A.; Carruba, V. Dynamics in the vicinity of (101955) Bennu: Solar radiation pressure effects in equatorial orbits. Mon. Not. R. Astron. Soc. 2017, 470, 2687–2701. [Google Scholar] [CrossRef]
- Almeida, A.K., Jr.; Oliveira, G.M.C.; Prado, A.F.B.A. Artificial equilibrium points and bi-impulsive maneuvers to observe 243 Ida. Chin. J. Aeronaut. 2021, 34, 410. [Google Scholar] [CrossRef]
- Araújo, R.A.N. O Sistema Triplo de Asteroides 2001SN263: Dinâmica Orbital e Estabilidade. Doctorate. Degree Thesis, INPE—National Institute for Space Research, São José dos Campos, Brazil, 2011. [Google Scholar]
- Fang, J.; Margot, J.L.; Brozovic, M.; Nolan, M.C.; Benner, L.A.M.; Taylor, P.A. Orbits of near-earth asteroid triple 2001SN263 and 1994 CC: Properties, origin, and evolution. Astron. J. 2011, 141, 154. [Google Scholar] [CrossRef]
- Araújo, R.A.N.; Winter, O.C.; Prado, A.F.B.A. Stable retrograde orbits around the triple system 2001 SN263. Mon. Not. R. Astron. Soc. 2015, 449, 4404. [Google Scholar] [CrossRef]
- Masago, B.Y.P.L.; Prado, A.; Chiaradia, A.P.M.; Gomes, V.M. Developing the Precessing Inclined Bi-Elliptical Four-Body Problem with Radiation Pressure” to search for orbits in the triple asteroid 2001SN263. Adv. Space Res. 2016, 57, 962–982. [Google Scholar] [CrossRef]
- Sanchez, D.M.; Prado, A.F.B.A. Searching for Less-Disturbed Orbital Regions Around the Near-Earth Asteroid 2001 SN263. J. Spacecr. Rocket. 2019, 56, 1775–1785. [Google Scholar] [CrossRef]
- Cavalca, M.P.O.; Gomes, V.M.; Sanchez, D.M. Mid-range natural orbits around the triple asteroid 2001SN263. Eur. Phys. J. Spéc. Top. 2020, 229, 1557–1572. [Google Scholar] [CrossRef]
- Valvano, G.; Winter, O.C.; Sfair, R.; Oliveira, R.M.; Borderes-Motta, G. 2001 SN263—The contribution of their irregular shapes on the neighbourhood dynamics. Mon. Not. R. Astron. Soc. 2022, 515, 606–616. [Google Scholar] [CrossRef]
- Brum, A.G.V.D.; Schuindt, C.M. A Proposal of Optical Navigation for Deep Space Mission ASTER to Explore NEA 2001-SN263. J. Aerosp. Technol. Manag. 2022, 14. [Google Scholar] [CrossRef]
- Deienno, R.; Sanchez, D.M.; de Almeida Prado, A.F.B.; Smirnov, G. Satellite de-orbiting via controlled solar radiation pressure. Celest. Mech. Dyn. Astron. 2016, 126, 433–459. [Google Scholar] [CrossRef]
- Holman, M.J.; Wiegert, P.A. Long-term Stability of Planets in Binary Systems. Astron. J. 1999, 117, 621–628. [Google Scholar] [CrossRef]
- Hu, W.; Scheeres, D.J. Numerical determination of stability regions for orbital motion in uniformly rotating second degree and order gravity fields. Planet. Space Sci. 2004, 52, 685–692. [Google Scholar] [CrossRef]
- Mudryk, L.R.; Wu, Y. Resonance Overlap is Responsible for Ejecting Planets in Binary Systems. Astrophys. J. Lett. 2006, 639, 423–431. [Google Scholar] [CrossRef][Green Version]
- Nolan, M.C.; Howell, E.S.; Benner, L.A.M.; Ostro, S.J.; Giorgini, J.D.; Busch, M.W.; Carter, L.M.; Anderson, R.F.; Magri, C.; Campbell, D.B.; et al. Arecibo Radar Imaging of 2001SN263: A near-Earth triple asteroid system. Asteroids Comets Meteors 2008, 1405, 8258. [Google Scholar]
- de Almeida, A.K., Jr.; Prado, A.F.B.A. Comparisons between the circular restricted three-body and bi-circular four body problems for transfers between the two smaller primaries. Sci. Rep. 2022, 12, 4148. [Google Scholar] [CrossRef] [PubMed]
- Fieseler, P.D. A method for Solar Sailing in a low Earth Orbit. Acta Astronaut. 1988, 43, 531–541. [Google Scholar] [CrossRef]
Body | Central Body | a | e | i | Period | Radius (km) | Mass (× 1010 kg) [33] |
---|---|---|---|---|---|---|---|
Alpha | Sun | 1.99 AU | 0.48 | 6.7° | 2.80 years | 1.30 | |
Beta | Alpha | 16.633 km | 0.015 | 0.00° | 6.23 days | 0.39 | |
Gamma | Alpha | 3.804 km | 0.016 | 13.87° | 0.69 days | 0.29 |
Scenario | Symbol | Nomenclature |
---|---|---|
1 | (+) (+) | mβ + error, mγ + error |
2 | (+) (0) | mβ + error, mγ without error |
3 | (+) (−) | mβ + error, mγ − error |
4 | (0) (+) | mβ without error, mγ + error |
5 | (0) (0) | mβ without error, mγ without error |
6 | (0) (−) | mβ without error, mγ − error |
7 | (−) (+) | mβ − error, mγ + error |
8 | (−) (0) | mβ − error, mγ without error |
9 | (−) (−) | mβ − error, mγ − error |
Orbits with the Spacecraft Starting in the Periapsis (Same Side Orbits) |
---|
-2: Orbit internal to Gamma in resonance 3:4 |
-3: Orbit internal to Gamma in resonance 4:5 |
-4: Orbit external to Gamma in resonance 3:1 |
Orbits with the spacecraft starting in the apoapsis (same side orbits) |
-5: Orbit internal to Beta in resonance 1:2 |
-12: Orbit external to Gamma in resonance 4:3 |
-15: Orbit external to Gamma in resonance 7:5 |
Orbit with the spacecraft starting in the periapsis (opposite side orbits) |
-18: Orbit internal to Gamma in resonance 5:6 |
Orbit with the spacecraft starting in the apoapsis (opposite side orbits) |
-20: Orbit external to Gamma in resonance 6:5 |
Orbit with the spacecraft starting in the periapsis (same side orbits with i = 13.87°) |
-22: Orbit internal to Gamma in resonance 3:4 |
Orbits with the spacecraft starting in the apoapsis (same side orbits with i = 13.87°) |
-25: Orbit internal to Beta in resonance 1:2 |
-27: Orbit internal to Beta in resonance 3:5 |
-31: Orbit external to Gamma in resonance 7:2 |
Orbit with the spacecraft starting in the periapsis (same side orbits with i = 90°) |
-38: Orbit internal to Gamma in resonance 3:4 |
Orbit with the spacecraft starting in the apoapsis (same side orbits with i = 90°) |
-42: Orbit internal to Beta in resonance 2:3 |
-52: Orbit external to Gamma in resonance 8:5 |
Orbits with the spacecraft starting in the apoapsis (same side orbits with i = 180°) |
-59: Orbit internal to Beta in resonance 3:5 |
-60: Orbit internal to Beta in resonance 4:7 |
-61: Orbit internal to Beta in resonance 5:9 |
Family 1—Positive Errors in the Mass of Beta | ||||||
---|---|---|---|---|---|---|
Observation Times (Days) | ||||||
Positive Errors in the Mass of Gamma | No Errors in the Mass of Gamma | Negative Errors in the Mass of Gamma | ||||
Orbit | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° |
2 | ||||||
R1 | 6.95 | 9.62 | 18.57 | 18.57 | 10.23 | 10.23 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 5.88 | 8.47 | 13.20 | 13.20 | 6.98 | 6.98 |
3 | ||||||
R1 | 3.53 | 6.72 | 62.50 | 62.50 | 10.44 | 14.76 |
R2 | 1.49 | 0.84 | 0 | 0 | 0 | 0 |
R3 | 7.21 | 5.67 | 43.07 | 43.06 | 8.06 | 12.72 |
4 | ||||||
R1 | 6.50 | 6.48 | 4.94 | 6.02 | 13.34 | 4.72 |
R2 | 0 | 0 | 0 | 1.36 | 0 | 0.62 |
R3 | 7.87 | 5.62 | 6.74 | 6.99 | 15.84 | 5.93 |
5 | ||||||
R1 | 0 | 0 | 0 | 0 | 0 | 0 |
R2 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 |
R3 | 0 | 0 | 0 | 0 | 0 | 0 |
12 | ||||||
R1 | 3.55 | 3.61 | 25.86 | 25.87 | 12.62 | 16.51 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 4.65 | 4.96 | 30.07 | 30.07 | 13.85 | 18.22 |
15 | ||||||
R1 | 6.34 | 7.19 | 18.65 | 15.36 | 6.16 | 13.41 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 6.64 | 5.60 | 21.73 | 18.28 | 6.70 | 9.60 |
18 | ||||||
R1 | 28.54 | 25.41 | 11.83 | 12.44 | 20.68 | 17.55 |
R2 | 0.87 | 0 | 0 | 0 | 0 | 0 |
R3 | 9.25 | 8.46 | 8.13 | 8.45 | 17.10 | 11.56 |
20 | ||||||
R1 | 52.40 | 52.41 | 51.78 | 51.71 | 14.55 | 14.55 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 12.77 | 12.76 | 15.32 | 15.36 | 5.51 | 5.50 |
22 | ||||||
R1 | 1.86 | 1.86 | 62.50 | 62.50 | 6.03 | 6.03 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 1.45 | 1.45 | 43.31 | 43.33 | 4.04 | 4.04 |
25 | ||||||
R1 | 0 | 0 | 7.50 | 1.65 | 0.09 | 0 |
R2 | 1.84 | 1.84 | 2.65 | 2.66 | 2.48 | 2.77 |
R3 | 0 | 0 | 7.71 | 0.46 | 0.41 | 0.48 |
27 | ||||||
R1 | 10.56 | 7.06 | 1.87 | 13.37 | 11.29 | 1.66 |
R2 | 1.48 | 4.33 | 2.65 | 1.75 | 2.21 | 5.65 |
R3 | 9.93 | 7.94 | 2.79 | 14.84 | 11.85 | 2.55 |
31 | ||||||
R1 | 0 | 0 | 0 | 1.33 | 0.09 | 0.09 |
R2 | 2.01 | 2.01 | 6.68 | 6.32 | 1.92 | 1.92 |
R3 | 3.16 | 3.17 | 1.33 | 2.35 | 1.21 | 1.21 |
38 | ||||||
R1 | 5.78 | 5.78 | 7.07 | 7.07 | 6.32 | 6.32 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 2.64 | 2.64 | 3.23 | 3.23 | 3.36 | 3.36 |
42 | ||||||
R1 | 0.90 | 0.93 | 1.91 | 1.66 | 1.62 | 1.61 |
R2 | 0.71 | 0.31 | 0.46 | 0.30 | 0.33 | 0.34 |
R3 | 1.16 | 1.95 | 1.95 | 1.59 | 1.46 | 1.38 |
52 | ||||||
R1 | 8.09 | 11.34 | 12.86 | 13.03 | 14.36 | 12.06 |
R2 | 0.78 | 0 | 0.49 | 0.47 | 0.16 | 0.43 |
R3 | 6.94 | 9.56 | 10.41 | 10.08 | 10.78 | 9.79 |
59 | ||||||
R1 | 0.79 | 0.79 | 1.16 | 1.16 | 0.66 | 0.69 |
R2 | 0.97 | 0.99 | 0.88 | 0.88 | 1.00 | 1.00 |
R3 | 0.71 | 0.57 | 1.32 | 0.95 | 0.70 | 0.60 |
60 | ||||||
R1 | 0.11 | 0.11 | 0.10 | 0.10 | 0.09 | 0.09 |
R2 | 0.17 | 0.17 | 0.16 | 0.16 | 0.17 | 0.17 |
R3 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 |
61 | ||||||
R1 | 0.14 | 0.14 | 0.14 | 0.14 | 0.13 | 0.13 |
R2 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 | 0.16 |
R3 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 | 0.24 |
Family 2—No Errors in the Mass of Beta | ||||||
---|---|---|---|---|---|---|
Observation Times (Days) | ||||||
Positive Errors in the Mass of Gamma | No Errors in the Mass of Gamma | Negative Errors in the Mass of Gamma | ||||
Orbit | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° |
2 | ||||||
R1 | 3.52 | 2.91 | 25.13 | 40.69 | 10.22 | 10.22 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 3.75 | 3.02 | 18.50 | 25.02 | 6.97 | 6.97 |
3 | ||||||
R1 | 3.42 | 3.41 | 62.50 | 62.50 | 4.43 | 4.43 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 3.51 | 3.22 | 43.07 | 43.07 | 2.66 | 2.66 |
4 | ||||||
R1 | 21.18 | 6.60 | 6.86 | 18.00 | 1.53 | 1.53 |
R2 | 0 | 0 | 0 | 0 | 2.27 | 2.63 |
R3 | 20.63 | 7.60 | 5.92 | 20.61 | 1.98 | 1.98 |
5 | ||||||
R1 | 0 | 0 | 0 | 0 | 0 | 0 |
R2 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 |
R3 | 0 | 0 | 0 | 0 | 0 | 0 |
12 | ||||||
R1 | 2.74 | 3.02 | 25.83 | 25.82 | 7.26 | 8.80 |
R2 | 0 | 1.14 | 0 | 0 | 0 | 0 |
R3 | 4.67 | 5.04 | 30.39 | 30.40 | 7.05 | 8.59 |
15 | ||||||
R1 | 5.96 | 9.52 | 24.27 | 24.26 | 11.90 | 42.46 |
R2 | 0 | 0 | 0 | 0 | 0.24 | 0 |
R3 | 5.03 | 7.56 | 27.15 | 27.15 | 12.79 | 31.33 |
18 | ||||||
R1 | 9.66 | 12.08 | 35.73 | 11.36 | 6.19 | 6.19 |
R2 | 0 | 0 | 0.69 | 0 | 0 | 0 |
R3 | 5.36 | 5.83 | 16.51 | 5.99 | 2.64 | 2.64 |
20 | ||||||
R1 | 52.19 | 52.20 | 36.18 | 35.00 | 32.56 | 24.10 |
R2 | 0 | 0 | 0.43 | 0 | 0 | 0 |
R3 | 12.33 | 12.32 | 12.61 | 11.63 | 12.65 | 12.39 |
22 | ||||||
R1 | 1.86 | 1.86 | 62.50 | 62.50 | 6.03 | 6.03 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 1.46 | 1.46 | 43.03 | 43.02 | 4.06 | 4.05 |
25 | ||||||
R1 | 2.71 | 2.73 | 6.86 | 2.40 | 2.36 | 2.33 |
R2 | 1.42 | 0.99 | 0.88 | 0 | 0.55 | 0.55 |
R3 | 1.48 | 1.43 | 7.58 | 1.71 | 1.25 | 2.68 |
27 | ||||||
R1 | 0 | 0 | 5.51 | 5.64 | 0 | 0 |
R2 | 2.22 | 2.20 | 4.58 | 4.55 | 2.32 | 2.32 |
R3 | 0.51 | 0.50 | 4.27 | 5.06 | 0.32 | 0.32 |
31 | ||||||
R1 | 4.55 | 10.91 | 4.32 | 5.39 | 1.62 | 11.24 |
R2 | 5.80 | 1.15 | 1.59 | 2.23 | 4.48 | 1.38 |
R3 | 5.08 | 8.69 | 5.17 | 5.65 | 3.31 | 11.43 |
38 | ||||||
R1 | 6.61 | 6.61 | 8.12 | 8.13 | 6.71 | 6.71 |
R2 | 0 | 0 | 0.32 | 0.37 | 0 | 0 |
R3 | 3.05 | 3.05 | 4.43 | 4.40 | 3.81 | 3.80 |
42 | ||||||
R1 | 1.87 | 1.87 | 2.16 | 2.18 | 1.88 | 1.88 |
R2 | 0.69 | 0.69 | 0.34 | 0.34 | 0.78 | 0.78 |
R3 | 1.06 | 1.04 | 0.88 | 1.01 | 1.34 | 1.34 |
52 | ||||||
R1 | 6.53 | 5.57 | 9.15 | 5.00 | 13.73 | 11.90 |
R2 | 0.34 | 0.44 | 0 | 0 | 0 | 0.31 |
R3 | 4.57 | 4.31 | 8.23 | 4.03 | 9.84 | 9.57 |
59 | ||||||
R1 | 2.39 | 2.39 | 1.88 | 1.86 | 2.14 | 2.14 |
R2 | 2.55 | 2.56 | 2.68 | 2.68 | 2.89 | 2.93 |
R3 | 2.83 | 2.83 | 2.62 | 2.61 | 3.57 | 3.55 |
60 | ||||||
R1 | 2.65 | 2.67 | 2.27 | 1.65 | 0.69 | 0.69 |
R2 | 1.01 | 0.64 | 1.53 | 1.07 | 0.35 | 0.35 |
R3 | 2.08 | 1.97 | 2.35 | 1.34 | 0.54 | 0.54 |
61 | ||||||
R1 | 0.69 | 0.80 | 2.48 | 2.52 | 0.15 | 0.15 |
R2 | 2.58 | 2.66 | 1.39 | 1.33 | 0.17 | 0.17 |
R3 | 2.79 | 2.75 | 1.52 | 1.90 | 0.25 | 0.25 |
Family 3—Negative Errors in the Mass of Beta | ||||||
---|---|---|---|---|---|---|
Observation Times (Days) | ||||||
Positive Errors in the Mass of Gamma | No Errors in the Mass of Gamma | Negative Errors in the Mass of Gamma | ||||
Orbit | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° | True Anomaly 0° | True Anomaly 180° |
2 | ||||||
R1 | 2.85 | 2.98 | 18.55 | 18.55 | 10.22 | 10.22 |
R2 | 0.65 | 0.72 | 0 | 0 | 0 | 0 |
R3 | 2.46 | 2.49 | 13.17 | 13.17 | 6.97 | 6.96 |
3 | ||||||
R1 | 5.59 | 3.82 | 62.50 | 62.50 | 4.42 | 4.41 |
R2 | 1.44 | 0 | 0 | 0 | 0 | 0 |
R3 | 5.61 | 3.95 | 43.06 | 43.07 | 2.65 | 2.64 |
4 | ||||||
R1 | 2.59 | 24.33 | 22.45 | 3.60 | 5.97 | 4.85 |
R2 | 0 | 0 | 0 | 0.68 | 0.51 | 0.57 |
R3 | 3.10 | 23.88 | 22.49 | 5.25 | 5.53 | 5.24 |
5 | ||||||
R1 | 0 | 0 | 0 | 0 | 0 | 0 |
R2 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 | 62.50 |
R3 | 0 | 0 | 0 | 0 | 0 | 0 |
12 | ||||||
R1 | 1.97 | 3.05 | 25.80 | 25.78 | 22.53 | 4.16 |
R2 | 0.49 | 0.49 | 0 | 0 | 0 | 1.65 |
R3 | 3.22 | 5.37 | 30.39 | 30.37 | 23.71 | 5.23 |
15 | ||||||
R1 | 3.84 | 3.84 | 23.95 | 23.95 | 18.00 | 17.38 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 4.08 | 4.08 | 26.53 | 26.53 | 17.25 | 17.99 |
18 | ||||||
R1 | 7.27 | 6.48 | 10.67 | 27.67 | 45.54 | 9.66 |
R2 | 0 | 0 | 0.24 | 0 | 0 | 0 |
R3 | 3.76 | 2.98 | 5.98 | 18.11 | 20.09 | 5.58 |
20 | ||||||
R1 | 52.27 | 52.27 | 51.56 | 51.57 | 52.55 | 51.72 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 12.79 | 12.80 | 14.95 | 14.95 | 17.37 | 18.03 |
22 | ||||||
R1 | 1.86 | 1.86 | 62.50 | 62.50 | 6.02 | 6.02 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 1.46 | 1.46 | 42.82 | 42.83 | 4.10 | 4.09 |
25 | ||||||
R1 | 0.39 | 0.75 | 1.87 | 2.21 | 0.99 | 1.04 |
R2 | 1.60 | 1.89 | 0.62 | 0.45 | 2.44 | 2.47 |
R3 | 1.89 | 1.95 | 2.55 | 2.28 | 1.65 | 1.66 |
27 | ||||||
R1 | 0 | 0 | 0 | 0 | 0 | 0 |
R2 | 1.68 | 2.11 | 1.62 | 1.62 | 1.34 | 1.34 |
R3 | 0.43 | 0.43 | 0.36 | 0.36 | 0.35 | 0.35 |
31 | ||||||
R1 | 0.99 | 2.45 | 7.28 | 6.89 | 7.26 | 7.26 |
R2 | 0.57 | 2.12 | 2.13 | 4.45 | 1.40 | 1.40 |
R3 | 1.60 | 2.33 | 5.30 | 5.31 | 4.40 | 4.40 |
38 | ||||||
R1 | 7.97 | 7.97 | 8.49 | 8.27 | 8.14 | 8.14 |
R2 | 0 | 0 | 0.09 | 0 | 0 | 0 |
R3 | 4.38 | 4.38 | 4.27 | 4.02 | 5.02 | 5.03 |
42 | ||||||
R1 | 1.79 | 1.78 | 2.20 | 2.42 | 1.58 | 1.58 |
R2 | 1.45 | 1.44 | 0.69 | 0.52 | 0.03 | 0.04 |
R3 | 0.70 | 0.85 | 1.01 | 0.94 | 0.11 | 0.11 |
52 | ||||||
R1 | 1.81 | 1.81 | 7.33 | 5.76 | 18.28 | 18.36 |
R2 | 0 | 0 | 0 | 0 | 0 | 0 |
R3 | 1.68 | 1.68 | 7.53 | 5.46 | 13.27 | 13.98 |
59 | ||||||
R1 | 0.78 | 0.77 | 0.31 | 0.31 | 0.25 | 0.25 |
R2 | 3.05 | 3.05 | 2.84 | 2.84 | 2.68 | 2.68 |
R3 | 2.96 | 2.97 | 2.93 | 2.93 | 2.76 | 2.76 |
60 | ||||||
R1 | 3.11 | 3.21 | 3.11 | 3.02 | 2.65 | 2.64 |
R2 | 2.97 | 2.82 | 2.99 | 2.92 | 3.13 | 3.14 |
R3 | 2.85 | 2.99 | 3.17 | 3.11 | 2.99 | 2.99 |
61 | ||||||
R1 | 3.14 | 3.15 | 2.55 | 2.51 | 2.82 | 2.82 |
R2 | 1.62 | 1.48 | 1.61 | 1.71 | 2.09 | 2.08 |
R3 | 2.80 | 2.86 | 2.41 | 2.40 | 2.40 | 2.58 |
Scenario | Observational Times (Days) | ||
---|---|---|---|
True Anomaly 0° | True Anomaly 180° | ||
(+) (+) | R1 | 52.40 | 52.41 |
R3 | 12.77 | 12.76 | |
(+) (0) | R1 | 51.78 | 51.71 |
R3 | 15.32 | 15.36 | |
(+) (−) | R1 | 14.55 | 14.55 |
R3 | 5.51 | 5.50 | |
(0) (+) | R1 | 52.19 | 52.20 |
R3 | 12.33 | 12.32 | |
(0) (0) | R1 | 36.18 | 35.00 |
R3 | 12.61 | 11.63 | |
(0) (−) | R1 | 32.56 | 24.10 |
R3 | 12.65 | 12.39 | |
(−) (+) | R1 | 52.27 | 52.27 |
R3 | 12.79 | 12.80 | |
(−) (0) | R1 | 51.56 | 51.57 |
R3 | 14.95 | 14.95 | |
(−) (−) | R1 | 52.55 | 51.72 |
R3 | 17.37 | 18.03 |
Scenario (+) (+) | R1 | 0.79 | 0.79 |
R2 | 0.97 | 0.99 | |
R3 | 0.71 | 0.57 | |
Scenario (+) (0) | R1 | 1.16 | 1.16 |
R2 | 0.88 | 0.88 | |
R3 | 1.32 | 0.95 | |
Scenario (+) (−) | R1 | 0.66 | 0.69 |
R2 | 1.00 | 1.00 | |
R3 | 0.70 | 0.60 | |
Scenario (0) (+) | R1 | 2.39 | 2.39 |
R2 | 2.55 | 2.56 | |
R3 | 2.83 | 2.83 | |
Scenario (0) (−) | R1 | 2.14 | 2.14 |
R2 | 2.89 | 2.93 | |
R3 | 3.57 | 3.55 | |
Scenario (−) (+) | R1 | 0.78 | 0.77 |
R2 | 3.05 | 3.05 | |
R3 | 2.96 | 2.97 | |
Scenario (−) (0) | R1 | 0.31 | 0.31 |
R2 | 2.84 | 2.84 | |
R3 | 2.93 | 2.93 | |
Scenario (−) (−) | R1 | 0.25 | 0.25 |
R2 | 2.68 | 2.68 | |
R3 | 2.76 | 2.76 |
Publisher’s Note: MDPI stays neutral with regard to jurisdictional claims in published maps and institutional affiliations. |
© 2022 by the authors. Licensee MDPI, Basel, Switzerland. This article is an open access article distributed under the terms and conditions of the Creative Commons Attribution (CC BY) license (https://creativecommons.org/licenses/by/4.0/).
Share and Cite
de Almeida Junior, A.K.; Mescolotti, B.Y.P.M.; Chiaradia, A.P.M.; Gomes, V.M.; de Almeida Prado, A.F.B. Searching for Orbits for a Mission to the Asteroid 2001SN263 Considering Errors in the Physical Parameters. Symmetry 2022, 14, 1789. https://doi.org/10.3390/sym14091789
de Almeida Junior AK, Mescolotti BYPM, Chiaradia APM, Gomes VM, de Almeida Prado AFB. Searching for Orbits for a Mission to the Asteroid 2001SN263 Considering Errors in the Physical Parameters. Symmetry. 2022; 14(9):1789. https://doi.org/10.3390/sym14091789
Chicago/Turabian Stylede Almeida Junior, Allan Kardec, Bruna Yukiko Pinheiro Masago Mescolotti, Ana Paula Marins Chiaradia, Vivian M. Gomes, and Antonio Fernando Bertachini de Almeida Prado. 2022. "Searching for Orbits for a Mission to the Asteroid 2001SN263 Considering Errors in the Physical Parameters" Symmetry 14, no. 9: 1789. https://doi.org/10.3390/sym14091789
APA Stylede Almeida Junior, A. K., Mescolotti, B. Y. P. M., Chiaradia, A. P. M., Gomes, V. M., & de Almeida Prado, A. F. B. (2022). Searching for Orbits for a Mission to the Asteroid 2001SN263 Considering Errors in the Physical Parameters. Symmetry, 14(9), 1789. https://doi.org/10.3390/sym14091789
