Water 2018, 10(4), 437; https://doi.org/10.3390/w10040437

Groundwater Quality Assessment: An Improved Approach to K-Means Clustering, Principal Component Analysis and Spatial Analysis: A Case Study

1
CONACYT-Instituto Potosino de Investigación Científica y Tecnológica, A.C. División de Geociencias Aplicadas, Camino a la Presa San José 2055, Col. Lomas 4ta Sección, San Luis Potosí CP. 78216, San Luis Potosí, Mexico
2
Área Académica de Química, Universidad Autónoma del Estado de Hidalgo, Carretera Pachuca-Tulancingo Km. 4.5, Mineral de la Reforma CP. 42184, Hidalgo, Mexico
3
CONACYT-Centro de Investigación en Materiales Avanzados, S.C. Calle CIMAV 110, Ejido Arroyo Seco, Col. 15 de mayo (Tapias), Durango CP. 34147, Durango, Mexico
4
Postgrado en Hidrociencias, Colegio de Postgraduados, Carr. Fed. Mexico-Texcoco km. 36.5, Montecillo, Texcoco CP. 56230, Estado de Mexico, Mexico
5
Colegio Mexicano de Especialistas en Recursos Naturales, Callejón de las flores No. 8, Texcoco CP. 56220, Estado de Mexico, Mexico
*
Author to whom correspondence should be addressed.
Received: 7 January 2018 / Revised: 31 March 2018 / Accepted: 2 April 2018 / Published: 6 April 2018
(This article belongs to the Section Water Resources Management and Governance)
Full-Text   |   PDF [6328 KB, uploaded 3 May 2018]   |

Abstract

K-means clustering and principal component analysis (PCA) are widely used in water quality analysis and management. Nevertheless, numerous studies have pointed out that K-means with the squared Euclidean distance is not suitable for high-dimensional datasets. We evaluate a methodology (K-means based on PCA) for water quality evaluation. It is based on the PCA method to reduce the dataset from high dimensional to low for the improvement of K-means clustering. For this, a large dataset of 28 hydrogeochemical variables and 582 wells in the coastal aquifer are classified with K-means clustering for high dimensional and K-means clustering based on PCA. The proposed method achieved increased quality cluster cohesion according to the average Silhouette index. It ranged from 0.13 for high dimensional k-means clustering to 5.94 for K-means based on PCA and the practical spatial geographic information systems (GIS) evaluation of clustering indicates more quality results for K-means clustering based on PCA. K-means based on PCA identified three hydrogeochemical classes and their sources. High salinity was attributed to seawater intrusion and the mineralization process, high levels of heavy metals related to domestic-industrial wastewater discharge and low heavy metals concentrations were associated with industrial wastewater punctual discharges. This approach allowed the demarcation of natural and anthropogenic variation sources in the aquifer and provided greater certainty and accuracy to the data classification. View Full-Text
Keywords: K-means clustering; PCA; spatial analysis; water quality; hydrogeochemical; coastal aquifer K-means clustering; PCA; spatial analysis; water quality; hydrogeochemical; coastal aquifer
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
