Open AccessArticle
Remote Sens. 2018, 10(2), 215; https://doi.org/10.3390/rs10020215

Permafrost Distribution along the Qinghai-Tibet Engineering Corridor, China Using High-Resolution Statistical Mapping and Modeling Integrated with Remote Sensing and GIS

1
State Key Laboratory of Frozen Soils Engineering, Northwest Institute of Eco-Environment and Resources, Chinese Academy of Sciences, Lanzhou 730000, China
2
South China Institute of Geotechnical Engineering, School of Civil Engineering and Transportation, South China University of Technology, Guangzhou 510006, China
*
Authors to whom correspondence should be addressed.
Received: 18 October 2017 / Revised: 5 December 2017 / Accepted: 30 January 2018 / Published: 1 February 2018
(This article belongs to the Special Issue Remote Sensing of Dynamic Permafrost Regions)
Full-Text   |   PDF [6621 KB, uploaded 1 February 2018]   |

Abstract

Permafrost distribution in the Qinghai-Tibet Engineering Corridor (QTEC) is of growing interest due to the increase in infrastructure development in this remote area. Empirical models of mountain permafrost distribution have been established based on field sampled data, as a tool for regional-scale assessments of its distribution. This kind of model approach has never been applied for a large portion of this engineering corridor. In the present study, this methodology is applied to map permafrost distribution throughout the QTEC. After spatial modelling of the mean annual air temperature distribution from MODIS-LST and DEM, using high-resolution satellite image to interpret land surface type, a permafrost probability index was obtained. The evaluation results indicate that the model has an acceptable performance. Conditions highly favorable to permafrost presence (≥70%) are predicted for 60.3% of the study area, declaring a discontinuous permafrost distribution in the QTEC. This map is useful for the infrastructure development along the QTEC. In the future, local ground-truth observations will be required to confirm permafrost presence in favorable areas and to monitor permafrost evolution under the influence of climate change. View Full-Text
Keywords: statistical model; permafrost map; remote sensing; Qinghai-Tibet Plateau statistical model; permafrost map; remote sensing; Qinghai-Tibet Plateau
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
