A Simplified Sablik’s Approach to Model the Effect of Compaction Pressure on the Shape of Hysteresis Loops in Soft Magnetic Composite Cores

Faculty of Electrical Engineering; Częstochowa University of Technology, 42-201 Częstochowa, Poland
*
Author to whom correspondence should be addressed.
Materials 2020, 13(1), 170; https://doi.org/10.3390/ma13010170
Received: 1 December 2019 / Revised: 20 December 2019 / Accepted: 23 December 2019 / Published: 1 January 2020
A novel approach to take into account the effect of compaction pressure on the shape of modeled hysteresis curves of self-developed soft magnetic composite cores is presented. The description relies on the introduction of an additional term in the so-called effective field, which is assumed proportional to the compaction pressure. The proposed model bears some resemblance to the Sablik’s extension of the Jiles–Atherton model, readily used in the studies of the magnetoelastic effect. Verification of the description is carried out using measurement data from self-developed iron-based composite cores. View Full-Text
Keywords: soft magnetic composites; magnetic properties; Jiles–Atherton model; Sablik model soft magnetic composites; magnetic properties; Jiles–Atherton model; Sablik model
Show Figures

Figure 1
