Search Results (35)

Circuit breakers are effectively utilized for the controlled switching technique to mitigate inrush current when energizing an unloaded transformer. The core of the controlled switching technique is to obtain the appropriate closing angle based on the residual flux after opening. For the prediction of residual flux, the voltage integration method faces the difficult problem of determining the integration upper limit, while the Jiles- Atherton (J-A) model has the advantages of clear physical meaning of parameters, accurate calculation, and the ability to iteratively solve residual magnetism. It has low dependence on the initial conditions and greatly avoids the influence of DC offset and noise on measurement results. Firstly, an improved particle-swarm optimization algorithm is proposed in this paper to address the problem of slow convergence speed and susceptibility to local optima in current particle-swarm optimization algorithms for extracting J-A model parameters. The problem of slow convergence speed and susceptibility to local optima in traditional particle-swarm optimization algorithms is solved by optimizing the velocity and position-update formulas of particles in this algorithm. This new algorithm not only accelerates convergence speed, but also balances the overall and local search capabilities. Then, based on the J-A model, residual flux prediction of the transformer is carried out, and a transformer no-load energization experimental platform is built. A simulation model combining the J-A model and classical transformer is constructed using PSCAD/EMTDC to predict the residual flux of the transformer at different closing angles. Finally, by combining simulation with actual experimental waveform data, the accuracy of residual flux prediction was verified by comparing the peak values of the inrush current. Full article

The Jiles–Atherton (J–A) model has seen extensive use for modelling the hysteresis behaviour of ferromagnetic materials due to its computational efficiency, simplicity of use, and small number of physically related parameters. However, in this work, the application of the J–A model to hysteresis curves obtained from experimental measurements for as-quenched and quenched-and-tempered engineering steels is considered. It has been demonstrated that the current form of the J–A model is not capable of representing certain observed features in the obtained hysteresis curves of these steels, in particular, the rapid narrowing of the loops seen for as-quenched steels and the sharp corners seen for quenched-and-tempered steels. This work has shown that a superior fit to the major loops for such steels can be obtained by applying Gaussian variations with respect to the applied magnetic field to the model parameters. The findings are supported by experimental results from engineering steels used in the oil and gas industry. Full article

Oil and gas pipelines are subject to soil corrosion and medium pressure factors, resulting in stress concentration and pipe rupture and explosion. Non-destructive testing technology can identify the stress concentration and defect corrosion area of the pipeline to ensure the safety of pipeline transportation. In view of the problem that the traditional pipeline inspection cannot identify the stress signal at the defect, this paper proposes a detection method using strong and weak magnetic coupling technology. Based on the traditional J-A (Jiles–Atherton) model, the pinning coefficient is optimized and the stress demagnetization factor is added to establish the defect of the ferromagnetic material. The force-magnetic relationship optimization model is used to calculate the best detection magnetic field strength. The force-magnetic coupling simulation of Q235 steel material is carried out by ANSYS 2019 R1 software based on the improved J-A force-magnetic model. The results show that the effect of the stress on the pipe on the magnetic induction increases first and then decreases with the increase in the excitation magnetic field strength, and the magnetic signal has the maximum proportion of the stress signal during the excitation process; the magnetic induction at the pipe defect increases linearly with the increase in the stress trend. Through the strong and weak magnetic scanning detection of cracked pipeline materials, the correctness of the theoretical analysis and the validity of the engineering application of the strong and weak magnetic detection method are verified. Full article

Hysteresis is a fundamental characteristic of magnetic materials. The Jiles–Atherton (J-A) hysteresis model, which is known for its few parameters and clear physical interpretations, has been widely employed in simulating hysteresis characteristics. To better analyze and compute hysteresis behavior, this study established a state space representation based on the primitive J-A model. First, based on the five fundamental equations of the J-A model, a state space representation was established through variable substitution and simplification. Furthermore, to address the singularity problem at zero crossings, local linearization was obtained through an approximation method based on the actual physical properties. Based on these, the state space model was implemented using the S-function. To validate the effectiveness of the state space model, the hysteresis loops were obtained through COMSOL finite element software and tested on a permalloy toroidal sample. The particle swarm optimization (PSO) method was used for parameter identification of the state space model, and the identification results show excellent agreement with the simulation and test results. Finally, a closed-loop control system was constructed based on the state space model, and trajectory tracking experiments were conducted. The results verify the feasibility of the state space representation of the J-A model, which holds significant practical implications in the development of magnetically shielded rooms, the suppression of magnetic interference in cold atom clocks, and various other applications. Full article

Accurately calculating the losses of ferromagnetic materials is crucial for optimizing the design and ensuring the safe operation of electrical equipment such as motors and power transformers. Commonly used loss calculation models include the Bertotti empirical formula and hysteresis models. In this paper, a new hybrid hysteresis model method is proposed to calculate losses—namely, the combination of the Jiles–Atherton hysteresis model (J–A) and the Fourier hysteresis model. The traditional Jiles–Atherton hysteresis model is mainly suitable for fitting the saturation hysteresis loop, but the fitting error is relatively large for internal minor hysteresis loops. In contrast, the Fourier hysteresis model is suitable for fitting the minor hysteresis loops because the corresponding magnetic induction strength or magnetic field is lower and the waveform distortion is small. Moreover, Fourier series expansion can be expressed with fewer terms, which is convenient for parameter fitting. Through examples, the results show that the hybrid hysteresis model can take advantage of the strengths of each model, not only reducing computational complexity, but also ensuring high fitting accuracy and loss calculation accuracy. Full article

As a typical intelligent device, magnetorheological (MR) dampers have been widely applied in vibration control and mitigation. However, the inherent hysteresis characteristics of magnetic materials can cause significant time delays and fluctuations, affecting the controllability and damping performance of MR dampers. Most existing mathematical models have not considered the adverse effects of magnetic hysteresis characteristics, and this study aims to consider such effects in MR damper models. Based on the magnetic circuit analysis of MR dampers, the Jiles–Atherton (J-A) model is adopted to characterize the magnetic hysteresis properties. Then, a weight adaptive particle swarm optimization algorithm (PSO) is introduced to the J-A model for efficient parameter identifications of this model, in which the differential evolution and the Cauchy variation are combined to improve the diversity of the population and the ability to jump out of the local optimal solution. The results obtained from the improved J-A model are compared with the experimental data under different working conditions, and it shows that the proposed J-A model can accurately predict the damping performance of MR dampers with magnetic hysteresis characteristics. Full article

Three-dimensional printing is a promising technology that offers increased freedom to create topologically optimised electrical machine designs with a much smaller layer thickness achievable with the current, laminated steel-sheet-based technology. These composite materials have promising magnetic behaviour, which can be competitive with the current magnetic materials. Accurately calculating the iron losses is challenging due to magnetic steels’ highly nonlinear hysteretic behaviour. Many numerical methodologies have been developed and applied in FEM-based simulations from the first introduced Steinmetz formulae. However, these old curve-fitting-based iron loss models are still actively used in modern finite-element solvers due to their simplicity and high computational demand for more-accurate mathematical methods, such as Preisach- or Jiles–Atherton-model-based calculations. In the case of 3D-printed electrical machines, where the printed material can have a strongly anisotropic behaviour and it is hard to define a standardised measurement, the applicability of the curve-fitting-based iron loss methodologies is limited. The following paper proposes an overview of the current problems and solutions for iron loss calculation and measurement methodologies and discusses their applicability in designing and optimising 3D-printed electrical machines. Full article

In response to the challenges of difficult energy supply and high costs in ocean wireless sensor networks, as well as the limited working cycle of chemical batteries, a cylindrical wave energy harvester with symmetrically distributed multi-cantilever beams was designed with Galfenol sheet as the core component. The dynamic equation of the device was established, and ANSYS transient dynamic simulations and Jiles-Atherton hysteresis model analysis were conducted to develop a mathematical model of the induced electromotive force of the Galfenol cantilever beam as a function of deformation. Experimental validation demonstrated that the simulated results of the cantilever beam deformation had an average error of less than 7% compared to the experimental results, while the average error between the theoretical and experimental values of the induced electromotive force of the device was around 15%, which preliminarily verifies the validity of the mathematical model of the device, and should be subject to further research and improvement. Full article

To achieve the nearly zero-field environment, demagnetization is an indispensable step for magnetic shields composed of high-permeability material, which adjusts the magnetization of the material to establish magnetic equilibrium with the environmental field and improve the shielding performance. The ideal demagnetization can make the high-permeability material on the anhysteretic magnetization curve to have a higher permeability than on the initial magnetization curve. However, inappropriate parameters of degaussing field cause the magnetization state to deviate from the anhysteretic magnetization curve. Therefore, this article proposes a new assessment criterion to analyze and evaluate the parameters of degaussing field based on the difference between the final magnetization state after demagnetization and theoretical anhysteretic state of the shielding material. By this way, the magnetization states after demagnetizations with different initial amplitude, frequency, period number and envelope attenuation function are calculated based on the dynamic Jiles–Atherton (J–A) model, and their magnetization curves under these demagnetization conditions are also measured and compared, respectively. The lower frequency, appropriate amplitude, sufficient period number and logarithmic envelope attenuation function can make the magnetization state after demagnetization closer to the ideal value, which is also consistent with the static magnetic-shielding performance of a booth-type magnetically shielded room (MSR) under different demagnetization condition. Full article

This paper proposes a multilevel three-dimensional constitutive model based on a microscopically phenomenological approach from the domain rotation mechanism, which is a fully coupled self-consistent homogenization scheme considering the interactions between elastic–inelastic strain and hysteresis. Considering the interactions among magnetic domains, grains, polycrystalline complexes, and macroscopic phenomenology, we predict the nonlinear magnetostrictive response of Terfenol-D under different types of external force loads and magnetic excitations in various thermal environments involving multi-fields of coupled magnetic, elastic, thermal, and mechanical phenomena. The average values of the mechanical bulk strains for different magnetization states are obtained at the grain scale utilizing Boltzmann functions and a self-consistent homogenization scheme. A Taylor series expansion of the Gibbs function concerning the field variables and an adapted Jiles–Atherton model are used to construct the hysteresis coupled constitutive relations at the macroscopic scale. The results associated with the experiments show that the established model can reasonably predict the magnetostrictive response under different external mixed stimuli. It can provide theoretical guidance for the precise control of nonlinear vibrations and the optimal design of the rotating giant magnetostrictive transducers at both microscopic and macroscopic multiple scales. Full article

This article presents the comparison of 3D and 2D finite element models of a power transformer designed for reactive power compensation stations. There is a lack of studies in the literature on internal electromagnetic phenomena in the active part of a transformer operated in these conditions. The results of numerical 2D and 3D calculations of no-load current and losses in the transformer core were obtained by using various methods and models. The impact of considering the hysteresis loop phenomenon on the calculation of core losses was investigated by using the Jiles–Atherton core losses model. The results obtained in the paper show that the model of the core must contain the areas representing the influence of overlappings on the no-load current and also on the flux density field in the core. The capacitive load of the transformer increases the flux density in the core limbs by several percent, so the power losses there must also increase accordingly. As a summary of the research, differences in the values of losses in each core element between the capacitive load and no-load conditions are presented. The results presented in this paper indicate that considering nonlinearity related to the magnetic hysteresis loop has a significant impact on the calculation of the core losses of power transformers. Full article

Direct current (DC) bias leads to increased vibration and noise in transformers. One of the main causes is the magnetostrictive effect of the transformer core. To address this phenomenon of magnetostriction, firstly, a transmission line model (TLM) of a single-phase transformer under DC bias is developed using transmission line theory and Jiles–Atherton (J–A) ferromagnetic hysteresis theory, taking into account the winding copper loss, core eddy current loss, and leakage effect. Secondly, the time-domain simulation of the single-phase transformer based on the Newton–Raphson iterative method is carried out, and the magnetostriction characteristics of the transformer under different DC and its variation law are analyzed. Finally, the results show that the DC bias results in magnetostrictive distortion and vibration acceleration curve distortion, the left and right wings of the magnetostrictive butterfly curve are no longer symmetrical, the slope of the vibration acceleration image increases significantly, and the degree of distortion is positively correlated with the magnitude of the DC. In addition, the peak values of the magnetostrictive deformation and vibration acceleration become larger under DC bias, leading to an increase in the vibration and noise of the transformer. The research object of this paper is the single-phase transformer, and the research method can also be applied to the study of three-phase transformers. Full article

There are several models for magnetic hysteresis. Their key purposes are to model magnetization curves with a history dependence to achieve hysteresis cycles without a frequency dependence. There are different approaches to handling history dependence. The two main categories are Duhem-type models and Preisach-type models. Duhem models handle it via a simple directional dependence on the flux rate, without a proper memory. While the Preisach type model handles it via memory of the point where the direction of the flux rate is changed. The most common Duhem model is the phenomenological Jiles–Atherton model, with examples of other models including the Coleman–Hodgdon model and the Tellinen model. Examples of Preisach type models are the classical Preisach model and the Prandtl–Ishlinskii model, although there are also many other models with adoptions of a similar history dependence. Hysteresis is by definition rate-independent, and thereby not dependent on the speed of the alternating flux density. An additional rate dependence is still important and often included in many dynamic hysteresis models. The Chua model is common for modeling non-linear dynamic magnetization curves; however, it does not define classical hysteresis. Other similar adoptions also exist that combine hysteresis modeling with eddy current modeling, similar to how frequency dependence is included in core loss modeling. Most models are made for scalar values of alternating fields, but there are also several models with vector generalizations that also consider three-dimensional directions. Full article

The incorporation of hysteresis models in computational electromagnetic software is of paramount importance for the accurate prediction of the ferromagnetic devices’ performance. The Preisach and Jiles-Atherton (J-A) models are frequently used for this purpose. The former is more accurate and can represent a broad range of magnetic materials, but it is computationally expensive. The latter is more efficient but can accurately model only soft ferromagnetic materials. In this paper, a recently proposed hysteresis model, referred to as the D’Aloia-Di Francesco-De Santis (D-D-D) model, is shown to have the best trade-off between accuracy and computational burden. For the first time, a numerical comparison between the Preisach, J-A and D-D-D models is provided for a large class of hysteresis loops including soft, semi-hard and hard ferromagnetic materials. Full article

Based on Jiles–Atherton theory and the quadratic law, a displacement model for giant magnetostrictive actuators (GMA) has been developed. The Runge–Kutta method is used to solve the nonlinear differential equation of the hysteresis model in a segmented magnetic field. Aiming at the problem that the model parameters are coupled with each other and difficult to estimate, a heuristic intelligent search algorithm-differential evolution algorithm (DE) is employed to implement parameter identification. In order to verify the effectiveness of the algorithm, comparative studies with the genetic algorithm (GA) and the particle swarm optimization (PSO) applied in parameter identification are performed. The simulation results demonstrate that the algorithm has the advantages of requiring few control variables, fast convergence speed, stable identified results, and excellent repeatability. Furthermore, the experimental results demonstrate that the output displacements calculated from the identified model are in great agreement with the measured values. Accordingly, the DE can identify the parameters of a displacement model for giant magnetostrictive actuators with satisfactory accuracy and reliability. Full article
