Nowcasting Solar Irradiance Components Using a Vision Transformer and Multimodal Data from All-Sky Images and Meteorological Observations
Abstract
:1. Introduction
1.1. Solar Irradiance Nowcasting
1.2. Related Works
1.3. The Contributions of This Study
2. Dataset
2.1. Multimodal Data
2.1.1. Meteorological Measurements
2.1.2. ASIs
2.2. Data Preprocessing
3. Methodology
3.1. Baselines
3.1.1. Clear Sky Model
3.1.2. FFNN
3.1.3. Hybrid of FFNN and U-Net
3.2. Proposed Methodology
3.3. Implementation
4. Results
4.1. Cloud Detection
4.2. Performance Evaluation
4.3. “Hard” vs. “Easy” Scenarios
4.4. Ablation Study
4.5. Sensitivity Analysis
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
Nomenclature
AA | Solar azimuth angle [°] |
AI | Artificial intelligence |
ASI | All-sky image |
AT | Ambient temperature [°C] |
BSRN | Baseline Surface Radiation Network |
CC | Cloud cover [%] |
CNN | Convolutional neural network |
COP | Conference of Parties |
CSL | Clear sky library |
CS DHI | Clear sky diffuse horizontal irradiance [W/m2] |
CS DNI | Clear sky direct normal irradiance [W/m2] |
CS GHI | Clear sky global horizontal irradiance [W/m2] |
DHI | Diffuse horizontal irradiance [W/m2] |
DIY | Do-it-yourself |
DN | Day number from January 1 |
DNI | Direct normal irradiance [W/m2] |
DP | Dew point temperature [°C] |
FFNN | Feedforward neural network |
GHI | Global horizontal irradiance [W/m2] |
hh | Hour of the day |
Measured solar irradiance components | |
IoU | Intersection over union |
Predicted solar irradiance components | |
LSTM | Long short-term memory |
MAE | Mean absolute error |
MLP | Multilayer perceptron |
mm | Minute of the hour |
MSE | Mean square error |
Number of predicted and measured pairs of solar irradiance components | |
NWP | Numerical weather prediction |
PAR | Photosynthetically active radiation [W/m2] |
PCA | Principal component analysis |
PV | Photovoltaic |
RBR | Red–blue ratio |
ReLU | Rectified linear unit |
RH | Relative humidity [%] |
RMSE | Root mean square error |
UNFCCC | United Nations Framework Convention on Climate Change |
ViT | Vision transformer |
VP | Vapor pressure [hpa] |
VRE | Variable renewable energy |
WD | Wind direction [°] |
WMO | World Meteorological Organization |
WS | Wind speed [m/s] |
WSISEG | Whole-Sky Image Segmentation |
ZA | Solar zenith angle [°] |
