In-Plane and Out-of-Plane MEMS Piezoresistive Cantilever Sensors for Nanoparticle Mass Detection
Abstract
:1. Introduction
2. Materials and Methods
2.1. ElectroThermal Piezoresistive Cantilever Sensor (EtPCS)
2.2. Atomic Force Microscopy Micro-Cantilever Sensor (AFM-MCS)
2.3. Nanoparticles Generation
3. Result and Discussion
3.1. EtPCS Cantilever Performance
3.2. AFM-MCS Cantilever Performance
4. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
