Acoustic Field Characterization of Medical Array Transducers Based on Unfocused Transmits and Single-Plane Hydrophone Measurements

1
Computer-Assisted Applications in Medicine, ETH Zurich, 8092 Zurich, Switzerland
2
Institute of Dynamics and Vibration Research, Leibniz University Hannover, 30167 Hannover, Germany
3
Institute of Diagnostic and Interventional Radiology, University Hospital Zurich, Rämistrasse 100, 8091 Zurich, Switzerland
4
Swiss Federal Laboratories for Materials Science and Technology, Empa, 8600 Dübendorf, Switzerland
*
Authors to whom correspondence should be addressed.
These authors contributed equally to this work.
Received: 1 February 2019 / Revised: 15 February 2019 / Accepted: 16 February 2019 / Published: 19 February 2019
(This article belongs to the Special Issue Ultrasound Transducers)
  |
PDF [1421 KB, uploaded 19 February 2019]
  |

Abstract

Medical ultrasonic arrays are typically characterized in controlled water baths using measurements by a hydrophone, which can be translated with a positioning stage. Characterization of 3D acoustic fields conventionally requires measurements at each spatial location, which is tedious and time-consuming, and may be prohibitive given limitations of experimental setup (e.g., the bath and stage) and measurement equipment (i.e., the hydrophone). Moreover, with the development of new ultrasound sequences and modalities, multiple measurements are often required to characterize each imaging mode to ensure performance and clinical safety. Acoustic holography allows efficient characterization of source transducer fields based on single plane measurements. In this work, we explore the applicability of a re-radiation method based on the Rayleigh–Sommerfeld integral to medical imaging array characterization. We show that source fields can be reconstructed at single crystal level at wavelength resolution, based on far-field measurements. This is herein presented for three practical application scenarios: for identifying faulty transducer elements; for characterizing acoustic safety parameters in focused ultrasound sequences from 2D planar measurements; and for estimating arbitrary focused fields based on calibration from an unfocused sound field and software beamforming. The results experimentally show that the acquired pressure fields closely match those estimated using our technique. View Full-Text
Keywords: ultrasound; acoustic holography; hydrophone measurements; Rayleigh–Sommerfeld; medical transducers; near field; safety index; plane wave; elastography ultrasound; acoustic holography; hydrophone measurements; Rayleigh–Sommerfeld; medical transducers; near field; safety index; plane wave; elastography
