Open AccessArticle
Sensors 2017, 17(2), 327;

Alternative cDEP Design to Facilitate Cell Isolation for Identification by Raman Spectroscopy

Department of Biological Engineering, Utah State University, Logan, UT 84322, USA
Author to whom correspondence should be addressed.
Academic Editors: Sebastian Wachsmann-Hogiu and Zachary J. Smith
Received: 1 December 2016 / Revised: 24 January 2017 / Accepted: 3 February 2017 / Published: 9 February 2017
(This article belongs to the Special Issue Applications of Raman Spectroscopy in Biosensors)
Full-Text   |   PDF [3517 KB, uploaded 9 February 2017]   |


Dielectrophoresis (DEP) uses non-uniform electric fields to cause motion in particles due to the particles’ intrinsic properties. As such, DEP is a well-suited label-free means for cell sorting. Of the various methods of implementing DEP, contactless dielectrophoresis (cDEP) is advantageous as it avoids common problems associated with DEP, such as electrode fouling and electrolysis. Unfortunately, cDEP devices can be difficult to fabricate, replicate, and reuse. In addition, the operating parameters are limited by the dielectric breakdown of polydimethylsiloxane (PDMS). This study presents an alternative way to fabricate a cDEP device allowing for higher operating voltages, improved replication, and the opportunity for analysis using Raman spectroscopy. In this device, channels were formed in fused silica rather than PDMS. The device successfully trapped 3.3 μm polystyrene spheres for analysis by Raman spectroscopy. The successful implementation indicates the potential to use cDEP to isolate and identify biological samples on a single device. View Full-Text
Keywords: contactless dielectrophoresis (cDEP); Raman spectroscopy; microfabrication contactless dielectrophoresis (cDEP); Raman spectroscopy; microfabrication

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material


Share & Cite This Article

MDPI and ACS Style

Hanson, C.; Vargis, E. Alternative cDEP Design to Facilitate Cell Isolation for Identification by Raman Spectroscopy. Sensors 2017, 17, 327.
