Ligand Selectivity in the Recognition of Protoberberine Alkaloids by Hybrid-2 Human Telomeric G-Quadruplex: Binding Free Energy Calculation, Fluorescence Binding, and NMR Experiments
by
Nanjie Deng 1,*, Junchao Xia 2, Lauren Wickstrom 3, Clement Lin 4
, Kaibo Wang 4, Peng He 5, Yunting Yin 1 and Danzhou Yang 4,*
Nanjie Deng 1,*, Junchao Xia 2, Lauren Wickstrom 3, Clement Lin 4, Kaibo Wang 4, Peng He 5, Yunting Yin 1 and Danzhou Yang 4,*
1
Department of Chemistry and Physical Sciences, Pace University, New York, NY 10038, USA
2
Department of Mathematics and Department of Research Computing, Princeton University, Princeton, NJ 08544, USA
3
Department of Science, Borough of Manhattan Community College, the City University of New York, New York, NY 10007, USA
4
Department of Medicinal Chemistry and Molecular Pharmacology, College of Pharmacy, Purdue University, West Lafayette, IN 47907, USA
5
James Frank Institute, and Institute for Biophysical Dynamics, The University of Chicago, Chicago, IL 60637, USA
*
Authors to whom correspondence should be addressed.
Molecules 2019, 24(8), 1574; https://doi.org/10.3390/molecules24081574
Received: 15 March 2019 / Revised: 15 April 2019 / Accepted: 19 April 2019 / Published: 21 April 2019
(This article belongs to the Special Issue G-Quadruplex Ligands and Cancer)
The human telomeric G-quadruplex (G4) is an attractive target for developing anticancer drugs. Natural products protoberberine alkaloids are known to bind human telomeric G4 and inhibit telomerase. Among several structurally similar protoberberine alkaloids, epiberberine (EPI) shows the greatest specificity in recognizing the human telomeric G4 over duplex DNA and other G4s. Recently, NMR study revealed that EPI recognizes specifically the hybrid-2 form human telomeric G4 by inducing large rearrangements in the 5′-flanking segment and loop regions to form a highly extensive four-layered binding pocket. Using the NMR structure of the EPI-human telomeric G4 complex, here we perform molecular dynamics free energy calculations to elucidate the ligand selectivity in the recognition of protoberberines by the human telomeric G4. The MM-PB(GB)SA (molecular mechanics-Poisson Boltzmann/Generalized Born) Surface Area) binding free energies calculated using the Amber force fields bsc0 and OL15 correlate well with the NMR titration and binding affinity measurements, with both calculations correctly identifying the EPI as the strongest binder to the hybrid-2 telomeric G4 wtTel26. The results demonstrated that accounting for the conformational flexibility of the DNA-ligand complexes is crucially important for explaining the ligand selectivity of the human telomeric G4. While the MD-simulated (molecular dynamics) structures of the G-quadruplex-alkaloid complexes help rationalize why the EPI-G4 interactions are optimal compared with the other protoberberines, structural deviations from the NMR structure near the binding site are observed in the MD simulations. We have also performed binding free energy calculation using the more rigorous double decoupling method (DDM); however, the results correlate less well with the experimental trend, likely due to the difficulty of adequately sampling the very large conformational reorganization in the G4 induced by the protoberberine binding.
View Full-Text
Keywords:
G-quadruplex; protoberberine; NMR; molecular dynamics simulation; binding free energy; MM-PB(GB)SA; NMR titration
▼
Show Figures
Figure 1
This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited
MDPI and ACS Style
Deng, N.; Xia, J.; Wickstrom, L.; Lin, C.; Wang, K.; He, P.; Yin, Y.; Yang, D. Ligand Selectivity in the Recognition of Protoberberine Alkaloids by Hybrid-2 Human Telomeric G-Quadruplex: Binding Free Energy Calculation, Fluorescence Binding, and NMR Experiments. Molecules 2019, 24, 1574.
