In this study, an unsteady vortex element method is applied to the analysis of a horizontal wing in order to investigate its propulsive performance when operating as a biomimetic thruster. The foil undergoes a combined heaving and pitching motion at the same frequency, in a uniform inflow condition, due to its advance at a constant speed. The numerical results are presented and compared to experimental measurements for the propulsion thrust coefficient and the efficiency of the system over a range of motion parameters. The results indicate the significance of 3D effects and show that the present technique can serve for the design of this kind of propulsive system with optimized performance. In the next stage, the wing is examined in a horizontal T-foil arrangement at the bow of a ship as an efficient propulsion system, and its performance in irregular head waves, characterized by a frequency spectrum, is also studied using experiments in a towing tank. In the test cases, a 30% damping of the ship responses in waves is observed with a simultaneous decrease in the total resistance by 5%. The numerical results are compared with data obtained from tank experiments, revealing good agreement, demonstrating the applicability of the present method to the preliminary design of this system for the augmentation of ship propulsion in waves. Full article

A unique flow control approach, blow suction combined jet (BSCJ), was presented to enhance the hydrodynamic performance of hydrofoils without the need of external energy resources. Utilizing the three-dimensional (3D) NACA0015 (National Advisory Committee for Aeronautics, NACA) foil as a case study, the orthogonal design methodology is employed to enhance the design of geometric and flow parameters, including the suction/blow point and the jet momentum coefficient. The fluid dynamics of the BSCJ foil at various angles of attack were numerically assessed using the large eddy simulation (LES) approach. The flow structures, encompassing vortex formations, pressure coefficients, and the impact of boundary layer velocity, were presented and evaluated to elucidate the control mechanism and influence of BSCJ. The simulation results indicate that the BSCJ primarily enhances the separation point of the rear wing surface by eliminating low-momentum fluid from the hydrofoil’s suction surface, thereby substantially augmenting the pressure differential across the hydrofoil and ultimately enhancing its hydrodynamic performance. The jet momentum coefficient is the primary determinant influencing the hydrodynamic performance of the hydrofoil, with best conditions attained when the suction slot is positioned at 0.25 C from the leading edge, the blowing slot at 0 C from the trailing edge, and the jet momentum coefficient is 0.1. The conclusions derived from the current study can offer theoretical advice for the future application of the BSCJ approach in underwater vehicles. Full article

A flapping foil, which mimics the flapping wings of birds and the locomotion of aquatic organisms, is an alternative to a conventional turbine for the harvesting of renewable energy from ubiquitous flows in the atmosphere, oceans, and rivers. In this work, the energy harvesting performance of flapping foils with attached flaps at the trailing edge is numerically studied by using an immersed boundary–lattice Boltzmann method (IB-LBM) at a Reynolds number of 1100. Three different configurations are considered, namely, a clean NACA0015 foil, a NACA0015 foil with a single flap, and a NACA0015 foil with two symmetric flaps. The results show that the flap attached to the trailing edge is able to enhance the energy harvesting efficiency, and the two symmetric flaps can achieve more enhancements than its single-flap counterpart. The mechanism of such enhancements is attributed the separation of the interactions of vortexes generated at the upper and bottom surfaces of the foil. To further obtain the optimal configurations of the two symmetric flaps, the angle between the two flaps ($\alpha$) and the length ($l_f$) of the flap are systematically studied. The results show that the optimal energy harvesting performance is achieved at $\alpha ={60}^{\circ }$ and $l_f=0.1c$ (c denotes the chord length of the foil). Compared with the baseline case, namely, the clean NACA foil, the optimal configuration can achieve an improvement of efficiency up to 19.94%. This study presents a strategy by adding two symmetric flaps at the trailing edge of the foil to enhance the energy harvesting performance of a flapping foil, which contributes to advancing the development of simple and efficient clean energy harvesting by using a flapping foil. Full article

Ice accumulation on lift-generating surfaces, such as rotor blades or wings, degrades aerodynamic performance and increases various risks. Active measures to counteract surface icing are energy-consuming and should be replaced by passive anti-icing surfaces. Two major categories of surface treatments—coating and structuring—already show promising results in the laboratory, but none fulfill the current industry requirements for performance and durability. In this paper, we show how femtosecond laser structuring of stainless steel (1.4301) combined with a hydrocarbon surface treatment or a vacuum treatment leads to superhydrophobic properties. The anti-ice performance was investigated in an icing wind tunnel under glaze ice conditions. Therefore, flexible steel foils were laser-structured, wettability treated and attached to NACA 0012 air foil sections. In the icing wind tunnel, hydrocarbon treated surfaces showed a 50 s ice build-up delay on the leading edge as well as a smoother ice surface compared to the reference. To demonstrate the erosion resistance of these surfaces, long-term field tests on a small-scale wind turbine were performed under alpine operating conditions. The results showed only minor erosion wear of micro- and nano-structures after a period of six winter months. Full article

To enhance the energy efficiency of exploding foil initiator systems (EFIs) and mitigate energy loss due to ablation in the bridge-wing regions, a low-energy bridge-wing-thickened EFI chip was designed and fabricated. Computational analysis revealed that increasing the thickness of the bridge flanks significantly reduces ablation within the bridge region during the electrical explosion. The refinement of the design led to the adoption of a bridge flank thickness of 19 μm, with the bridge area dimensions specified as 0.25 mm × 0.25 mm × 4 μm. This bridge-wing-thickened EFI chip was produced by employing micro-electro-mechanical systems (MEMS) technology and underwent rigorous performance evaluations. The empirical results closely matched the computational predictions, thereby corroborating the precision of the proposed model in simulating the temperature distribution seen during the explosion process. Notably, this enhanced EFI design achieves a flyer velocity of 3800 m/s at a condition of 900 V/0.22 μF, signifying a significant advancement in EFI system efficiency and performance. Full article

Morphing structures are a relatively new aircraft technology currently being investigated for a variety of applications, from civil to military. Despite the lack of literature maturity and its complexity, morphing wings offer significant aerodynamic benefits over a wide range of flight conditions, enabling reduced aircraft fuel consumption and airframe noise, longer range and higher efficiency. The aim of this study is to investigate the impact of morphing horizontal tail design on aircraft performance and flight mechanics. This study is conducted on a 1:5 scale model of a Preceptor N-3 Pup at its trim condition, of which the longitudinal dynamics is implemented in MATLAB release 2022. Starting from the original horizontal tail airfoil NACA 0012 with the elevator deflected at the trim value, this is modified by using the X-Foil tool to obtain a smooth morphing airfoil trailing edge shape with the same $C_{L_{\alpha }}$. By comparing both configurations and their influence on the whole aircraft, the resulting improvements are evaluated in terms of stability in the short-period mode, reduction in the parasitic drag coefficient $C_{D_0}$, and increased endurance at various altitudes. Full article

This work focused on the verification of the electrical parameters and the durability of side connectors installed in glass–glass photovoltaic modules. Ensuring the safe use of photovoltaic modules is achieved, among others, by using electrical connectors connecting the PV cell circuit inside the laminate with an external electric cable. In most of the cases for standard PV modules, the electrical connector in the form of a junction box is attached from the back side of the PV module. The junction box is glued to the module surface with silicone where the busbars were previously brought out of the laminate through specially prepared holes. An alternative method is to place connectors on the edge of the module, laminating part of it. In such a case, the specially prepared “wings” of the connector are tightly and permanently connected using laminating foil, between two glass panes protecting against an electrical breakdown. Additionally, this approach eliminates the process of preparing holes on the back side of the module, which is especially complicated and time-consuming in the case of glass–glass modules. Moreover, side connectors are desirable in BIPV applications because they allow for a more flexible design of installations on façades and walls of buildings. A series of samples were prepared in the form of PV G-G modules with side connectors, which were then subjected to testing the connectors for the influence of environmental conditions. All samples were characterized before and after the effect of environmental conditions according to PN-EN-61215-2 standards. Insulation resistance tests were performed in dry and wet conditions, ensuring full contact of the tested sample with water. For all modules, before being placed in the climatic chamber, the resistance values were far above the minimum value required by the standards, allowing the module to be safely used. For the dry tests, the resistance values were in the range of GΩ, while for the wet tests, the obtained values were in the range of MΩ. In further work, the modules were subjected to environmental influences in accordance with MQT-11, MQT-12, and MQT-13 and then subjected to electrical measurements again. A simulation of the impact of changing climatic conditions on the module test showed that the insulation resistance value is reduced by an order of magnitude for both the dry and wet tests. Additionally, one can observe visual changes where the lamination foil is in contact with the connector. The measurements carried out in this work show the potential of side connectors and their advantage over rear junction boxes, but also the technological challenges that need to be overcome. Full article

This paper presents a simplified mathematical model of a pumped hydrofoil (PH)—a surfboard elevated above water surface and connected to a tandem of hydrofoils by a strut. The PH is operated by a rider who stands on the surfboard and produces swinging up-and-down motions resulting in forward propulsion of the device. In the present paper, the description of the vertical motion of the PH is reduced to a linear oscillator excited by an oscillating mass coupled with the requirement that the weight is supported by dynamic lift of the foil(s). The inertial and damping influence of the hydrofoil(s) is accounted for by expanding unsteady lift force on the foil(s) in terms of kinematic parameters. The restoring term of the oscillator is associated with the phenomenon of automatic stabilization of shallowly submerged hydrofoils. The latter effect manifests itself in that when a hydrofoil approaches free surface, its lift decreases, and when it moves away from free surface, its lift increases. The analytical solution of the pumping foil mass-spring type forced oscillations equation allows one to calculate the flapping motion of the foil(s) and, thereafter, the period-averaged thrust generated by the PH. The resulting speed has been estimated on an assumption that the device enters its cruising mode when the thrust becomes equal to the drag, the latter comprising viscous, wave, and induced drag components. The model under discussion allows one to relate the main parameters of the system to its performance and, hopefully, provides further insight into the pumped hydrofoil phenomenon, its design methodology, and operation strategy. The review part of the paper focuses on two aspects of the problem: hydrodynamic behavior of the hydrofoil(s) in proximity to free water surface and their propulsion due to oscillations. Full article

The employment of fixed hydrofoils on existing planing craft is becoming a widely investigated topic, thanks to the opportunity of reducing the total drag forces and the consumptions of main engines, with a positive impact also in terms of air pollutant emissions in the atmosphere. The design of fixed hydrofoils for planing craft is investigated after developing the wing hydrodynamic model, capable of capturing the main forces acting on the craft longitudinal plane. An iterative procedure is developed to solve the nonlinear equilibrium equations and detect the minimum thrust configuration of the fixed hydrofoils at the cruise speed. The new iterative procedure allows investigating the entire design space of fixed hydrofoils and detecting the best configuration for both new and existing craft, with a positive impact in terms of time effort amount and design efficiency. A simplified seakeeping model is also developed to evaluate the impact of fixed hydrofoils on the craft hydrodynamics in a seaway. The USV01 planing craft is assumed as reference for the case study. The wing optimization procedure is employed and the seakeeping analysis in the foil-borne mode is subsequently performed by a set of dedicated codes developed in Matlab. The obtained results are discussed and some suggestions for the reliable design of fixed hydrofoils are provided. Full article

Flapping foils for augmenting thrust production have drawn attention as a means of assisting ship propulsion in waves due to their high efficiency rate compared to traditional screw propellers. However, they can also offer substantial resistance reduction when used as stabilizers. In this work, the aim is to investigate the feasibility of a symbiotic concept combining the ship’s propeller with a foil arranged at the ship’s bow at a fixed position operating as a trim-pitch stabilizer. The work presents results obtained from experiments conducted in the towing tank of the Laboratory of Ship and Marine Hydrodynamics of the National Technical University of Athens (LMSH NTUA), as well as results from an in-house CFD solver. The test cases focused on the resistance and the dynamic behavior of the wing–vessel configuration in calm water conditions and in head waves. All results were compared against the performance of a bare hull (without foil). The findings of this work are based both on numerical and experimental data and indicate that a bow wing in static mode can be used for trim-control of a vessel by altering the angle of attack leading to a possible drop in wave resistance both in calm water and in waves. In the latter case, utilizing the wing in head waves results in a significant reduction in the pitching and heaving responses of the vessel, which may lead to substantial enhancement of the propulsion performance. Full article

Flapping-foil thrusters arranged at the bow of the ship are examined for the exploitation of energy from wave motions by direct conversion to useful propulsive power, offering at the same time dynamic stability and reduction of added wave resistance. In the present work, the system consisting of the ship and an actively controlled wing located in front of its bow is examined in irregular waves. Frequency-domain seakeeping analysis is used for the estimation of ship-foil responses and compared against experimental measurements of a ferry model in head waves tested at the National Technical University of Athens (NTUA) towing tank. Next, to exploit the information concerning the responses from the verified seakeeping model, a detailed time-domain analysis of the loads acting on the foil, both in head and quartering seas, is presented, as obtained by means of a cost-effective time-domain boundary element method (BEM) solver validated by a higher fidelity RANSE finite volume solver. The results demonstrate the good performance of the examined system and will further support the development of the system at a larger model scale and the optimal design at full scale for specific ship types. Full article

The creation of an ideal surfboard is art. The design and construction depend on the individual surfer’s skill level and type of the required performance. In this research, four fuselage concepts were carefully explored to meet the following unique needs: lightweight, strong, and a fast-manufacturing process. The fuselages were manufactured by compression moulding using skin and core materials. The skin material was selected to be unidirectional (UD) carbon fibre, discontinuous carbon fibre (SMC) and Filava quadriaxial fibre impregnated with epoxy, while the core material was selected to be lightweight PVC foam. To assess the mechanical performance, three-point bending has been performed according to BS-ISO 14125 and validated using Finite Element Analysis (FEA) using Ansys software. As expected, the flexural test revealed that the UD carbon fibre fuselage was the strongest and SMC was the weakest, while large deflection was seen in Filava fibre fuselages before failure, showing great reactive flex that promotes projection during surfing. The experimental results show good agreement with FEA simulation, and the locations of the physical failure in the fuselage matches the location of maximum flexural stress obtained from FEA simulation. Although all fuselages were found to carry a surfer weight of 150 kg, including a factor of safety 3, except the SMC fuselage, due to shrinkage. The Filava fibre fuselages were seen to have a large deflection before failure, showing great flexibility to handle high ocean waves. This promotes the potential use of reactive flex in high performance sports equipment, such as surfing boards. A large shrinkage must be taken under consideration during compression moulding that depends on fibre orientation, resin nature, and part geometry. Full article

This work demonstrates the advantages of using laser powder bed fusion for producing a rudder bulb of a moth class sailing racing boat via laser powder bed fusion (LPBF). The component was designed to reduce weight using an AlSi7Mg0.6 alloy and incorporated a biomimetic surface texture for drag reduction. For the topological optimization, the component was loaded structurally due to foil wing’s lift action as well as from the environment due to hydrodynamic resistance. The aim was to minimize core mass while preserving stiffness and the second to benefit from drag reduction capability in terms of passive surface behavior. The external surface texture is inspired by scales of the European sea bass. Both these features were embedded to the component and produced by LPBF in a single run, with the required resolution. Drag reduction was estimated in the order of 1% for free stream velocity of 2.5 m s⁻¹. The production of the final part resulted in limited geometrical error with respect to scales 3D model, with the desired mechanical properties. A reduction in weight of approximately 58% with respect to original full solid model from 452 to 190 g was achieved thanks to core topology optimization. Sandblasting was adopted as finishing technique since it was able to improve surface quality while preserving fish scale geometries. The feasibility of producing the biomimetic surfaces and the weight reduction were validated with the produced full-sized component. Full article

During the recent period intensive research has focused on the advancement of engineering and technology aspects concerning the development and optimization of wave and current energy converters driven by the need to increase the percentage of marine renewable sources in the energy-production mix, particularly from offshore installations. Most stream energy-harvesting devices are based on hydro-turbines, and their performance is dependent on the ratio of the blade-tip speed to incident-flow speed. As the oncoming speed of natural-occurring currents varies randomly, there is a penalty for the latter device’s performance when operating at non-constant tip-speed ratio away from the design value. Unlike conventional turbines that are characterized by a single degree of freedom rotating around an axis, a novel concept is examined concerning hydrokinetic energy converters based on oscillating hydrofoils. The biomimetic device includes a rotating, vertically mounted, biomimetic wing, supported by an arm linked at a pivot point on the mid-chord. Activated by a controllable self-pitching motion the system performs angular oscillations around the vertical axis in incoming flow. In this work, the performance of the above flapping-foil, biomimetic flow energy harvester is investigated by application of a semi-3D model based on unsteady hydrofoil theory and the results are verified by comparison to experimental data and a 3D boundary element method based on vortex rings. By systematical application of the model the power extraction and efficiency of the system is presented for various cases including different geometric, mechanical, and kinematic parameters, and the optimal performance of the system is determined. Full article

Flapping foils located beneath or to the side of the hull of the ship can be used as unsteady thrusters, augmenting ship propulsion in waves. The basic setup is composed of a horizontal wing, which undergoes an induced vertical motion due to the ship’s responses in waves, while the self-pitching motion of the wing is controlled. Flapping foil thrusters can achieve high level of thrust as indicated by measurements and numerical simulations. Due to the relatively small submergence of the above biomimetic ship thrusters, the free-surface effects become significant. In the present work, the effect of the free surface on the performance of flapping foil thruster is assessed by means of two in-house developed computational models. On one hand, a cost-effective time-domain boundary element method (BEM) solver exploiting parallel programming techniques and general purpose programming on graphics processing units (GPGPU) is employed, while on the other hand a higher fidelity RANSE finite volume solver implemented for high performance computing (HPC) is used, and comparative results are presented. BEM and RANSE calculations present quite similar trends with respect to mean submergence depth, presenting 12%, 28%, and 18% of differences concerning the mean values of lift, thrust, and moment coefficients, respectively. The latter differences become very small after enhancement of the BEM model to include viscous corrections. Useful information and data are derived supporting the design of the considered biomimetic thrusters, for moderate submergence depths and conditions characterized by minor flow separation effects. Full article
