Sea surface height (SSH) serves as a fundamental geophysical parameter in oceanographic research. In 2023, China successfully launched the world’s first spaceborne interferometric GNSS-R (iGNSS-R) altimeter, which features dual-frequency multi-beam scanning, interferometric processing, and compatibility with three major satellite navigation systems: the BeiDou Navigation Satellite System (BDS), the Global Positioning System (GPS), and the Galileo Satellite Navigation System (GAL). This launch marked the first in-orbit validation of the iGNSS-R altimetry technology. This study provides a detailed overview of the iGNSS-R payload design and analyzes its dual-frequency delay mapping (DM) measurements. We developed a refined DM waveform-matching algorithm that precisely extracts the propagation delays between reflected and direct GNSS signals, enabling the retrieval of global sea surface height (SSH) through the interferometric altimetry model. For validation, we employed an inter-satellite crossover approach using Jason-3 and Sentinel-6 radar altimetry as references, achieving an unprecedented SSH accuracy of 17.2 cm at a 40 km resolution. This represents a breakthrough improvement over previous GNSS-R altimetry efforts. The successful demonstration of iGNSS-R technology opens up new possibilities for cost-effective, wide-swath sea level monitoring. It showcases the potential of GNSS-R technology to complement existing ocean observation systems and enhance our understanding of global sea surface dynamics. Full article

New observations of ocean surface topography obtained by wide-swath satellite interferometry require new capabilities to process spatially correlated errors in order to assimilate these data into numerical models. The sea surface height (SSH) variations have to be weighted against other types of assimilated data using information on their precision, as represented by the inverse of the SSH error covariance matrix $\mathit{R}$. The latter can be well approximated by a block-circulant (BC) structure and, therefore, allows numerically efficient implementation in operational data assimilation (DA) systems. In this note, we extend the technique of approximating $\mathit{R}$ for wide-swath altimeters by including the uncertainties associated with the state of the atmosphere. It is shown that such an extension keeps the BC approximation error within acceptable (±10%) bounds in a wide range of environmental conditions and could be beneficial for improving the accuracy of SSH retrievals from wide-swath altimeter observations. Full article

The SWOT satellite, carrying the KaRIN first wide-swath onboard altimeter, was launched in December 2022, and has now delivered more than a year of surface water elevation data over the ocean and inland lakes/rivers. These data are affected by systematic errors which constitute the dominant part of the error budget at scales larger than a few thousands of kilometers. Some strategies for their estimation and calibration were explored during the pre-launch studies with performance estimations. Now, based on the real data, we propose in this study to assess the systematic error budget with statistical methods relying on spectral and co-spectral analysis. From this assessment, suggesting very low error levels (below requirements), we propose the implementation of the calibration algorithms at Level-2 and Level-3 with a few minor adjustments justified by the error spectra. The calibrated products are then validated with usual CalVal metrics. Full article

Conventional altimetry has greatly advanced our understanding of mesoscale eddies but falls short in studying fine-scale eddies (<150 km). The newly launched Surface Water and Ocean Topography (SWOT) altimeter, however, with its unprecedented high-resolution capabilities, offers new opportunities to observe these fine-scale eddies. In this study, we use SWOT data to explore these previously elusive fine-scale eddies in the Kuroshio Extension. During SWOT’s fast sampling phase from 29 May 2023 to 10 July 2023, we identified an average of 4.5 fine-scale eddies within each 120 km wide swath. Cyclonic eddies, which are slightly more frequent than the anticyclonic ones (ratio of 1.16), have a similar mean radius of 23.4 km. However, cyclonic eddies exhibit higher amplitudes, averaging 3.5 cm compared to 2.8 cm for anticyclonic eddies. In contrast to the mesoscale eddies detected by conventional altimeters, the fine-scale eddies revealed by SWOT are characterized by smaller sizes and weaker amplitudes. This study offers a preliminary view of fine-scale eddy characteristics from space, highlighting SWOT’s potential to advance our understanding of these dynamic processes. Nonetheless, it also emphasizes the necessity for comprehensive analysis to fully exploit the satellite’s capabilities in monitoring and interpreting complex eddy behaviors. Full article

The recently deployed Surface Water and Ocean Topography (SWOT) mission for the first time has observed the ocean surface at a spatial resolution of 1 km, thus giving an opportunity to directly monitor submesoscale sea surface height (SSH) variations that have a typical magnitude of a few centimeters. This progress comes at the expense of the necessity to take into account numerous uncertainties in calibration of the quality-controlled altimeter data. Of particular importance is the proper filtering of spatially correlated errors caused by the uncertainties in geometry and orientation of the on-board interferometer. These “systematic” errors dominate the SWOT error budget and are likely to have a notable signature in the SSH products available to the oceanographic community. In this study, we explore the utility of the block-circulant (BC) approximation of the SWOT precision matrix developed by the Jet Propulsion Laboratory for assessment of a mission’s accuracy, including the possible impact of the systematic errors on the assimilation of the wide-swath altimeter data into numerical models. It is found that BC approximation of the precision matrix has sufficient (90–99%) accuracy for a wide range of significant wave heights of the ocean surface, and, therefore, could potentially serve as an efficient preconditioner for data assimilation problems involving altimetry observations by space-borne interferometers. An extensive set of variational data assimilation (DA) experiments demonstrates that BC approximation provides more accurate SSH retrievals compared to approximations, assuming a spatially uncorrelated observation error field as is currently adopted in operational DA systems. Full article

In order to accomplish the calibration and validation (Cal/Val) of altimeters, the Wanshan calibration site (WSCS) has been used as a calibration site for satellite altimeters since its completion in August 2019. In this paper, we introduced the WSCS and the dedicated equipment including permanent GNSS reference stations (PGSs), acoustic tide gauges (ATGs), and dedicated GNSS buoys (DGB), etc. placed on Zhi’wan, Wai’ling’ding, Dan’gan, and Miao’Wan islands of the WSCS. The PGSs data of Zhi’wan and Wai’ling’ding islands were processed and analyzed using the GAMIT/GLOBK (Version 10.7) and Hector (Version 1.9) software to define the datum for Cal/Val of altimeters in WSCS. The DGB was used to transfer the datum from the PGSs to the ATGs of Zhi’wan, Wai’ling’ding, and Dan’gan islands. Separately, the tidal and mean sea surface (MSS) corrections are needed in the Cal/Val of altimeters. We evaluated the global/regional tide models of FES2014, HAMTIDE12, DTU16, NAO99jb, GOT4.10, and EOT20 using the three in situ tide gauge data of WSCS and Hong Kong tide gauge data (No. B329) derived from the Global Sea Level Observing System. The HAMTIDE12 tide model was chosen to be the most accurate one to maintain the tidal difference between the locations of the ATGs and the altimeter footprints. To establish the sea surface connections between the ATGs and the altimeter footprints, a GPS towing body and a highly accurate ship-based SSH measurement system (HASMS) were used to measure the sea surface of this area in 2018 and 2022, respectively. The global/regional mean sea surface (MSS) models of DTU 2021, EGM 2008 (mean dynamic topography minus by CLS_MDT_2018), and CLS2015 were accurately evaluated using the in situ measured data and HY-2A altimeter, and the CLS2015 MSS model was used for Cal/Val of altimeters in WSCS. The data collected by the equipment of WSCS, related auxiliary models mentioned above, and the sea level data of the hydrological station placed on Dan’gan island were used to accomplish the Cal/Val of HY-2B, HY-2C, Jason-3, and Sentinel-3A (S3A) altimeters. The bias of HY-2B (Pass No. 375) was −16.7 ± 45.2 mm, with a drift of 0.5 mm/year. The HY-2C biases were −18.9 ± 48.0 mm with drifts of 0.0 mm/year and −5.6 ± 49.3 mm with −0.3 mm/year drifts for Pass No. 170 and 185, respectively. The Jason-3 bias was −4.1 ± 78.7 mm for Pass No. 153 and −25.8 ± 85.5 mm for Pass No. 012 after it has changed its orbits since April 2022, respectively. The biases of S3A were determined to be −16.5 ± 46.3 mm with a drift of −0.6 mm/year and −9.8 ± 30.1 mm with a drift of 0.5 mm/year for Pass No. 260 and 309, respectively. The calibration results show that the WSCS can commercialize the satellite altimeter calibration. We also discussed the calibration potential for a wide swath satellite altimeter of WSCS. Full article

Full tensor of gravity gradients contains extremely large amounts of information, which is one of the most important sources for research on recovery seafloor topography and underwater matching navigation. The calculation and accuracy of the full tensor of gravity gradients are worth studying. The Ka-band interferometric radar altimeter (KaRIn) of surface water and ocean topography (SWOT) mission enables high spatial resolution of sea surface height (SSH), which would be beneficial for the calculation of gravity gradients. However, there are no clear accuracy results for the gravity gradients (the gravity gradient tensor represents the second-order derivative of the gravity potential) recovered based on SWOT data. This study evaluated the possible precision of gravity gradients using the discretization method based on simulated SWOT wide-swath data and investigated the impact of instrument errors. The data are simulated based on the sea level anomaly data provided by the European Space Agency. The instrument errors are simulated based on the power spectrum data provided in the SWOT error budget document. Firstly, the full tensor of gravity gradients (SWOT_GGT) is calculated based on deflections of the vertical and gravity anomaly. The distinctions of instrument errors on the ascending and descending orbits are also taken into account in the calculation. The precision of the T_zz component is evaluated by the vertical gravity gradient model provided by the Scripps Institution of Oceanography. All components of SWOT_GGT are validated by the gravity gradients model, which is calculated by the open-source software GrafLab based on spherical harmonic. The T_zz component has the poorest precision among all the components. The reason for the worst accuracy of the T_zz component may be that it is derived by T_xx and T_yy, T_zz would have a larger error than T_xx and T_yy. The precision of all components is better than 6 E. Among the various errors, the effect of phase error and KaRIn error (random error caused by interferometric radar) on the results is greater than 2 E. The effect of the other four errors on the results is about 0.5 E. Utilizing multi-cycle data for the full tensor of gravity gradients recovery can suppress the effect of errors. Full article

The interferometric imaging radar altimeter (InIRA), mounted on the Tiangong-2 space laboratory, utilizes a small incidence and a short interferometric baseline to achieve altimetry for wide swathes of ocean surface topography and inland water surface elevation. To obtain a high-precision digital elevation model (DEM), calibration of the interferometric system parameters is necessary. Because InIRA utilizes the small-incidence interference system design, serious coupling occurs between the interferometric parameters. Commonly used interferometric calibration methods tend to fall into the local optimal solution for InIRA. Because evolutionary algorithms have a stronger robustness and global search ability, they are better suited to handling the solution space structure under the coupling of complex interferometric parameters. This article establishes an interferometric calibration optimization model for InIRA by utilizing the relative flatness of the lake surface as an inequality constraint. Furthermore, an adaptive penalty coefficient constraint evolutionary algorithm is designed to solve the model. The proposed method was tested on actual InIRA data, and the results indicate that it efficiently adjusts interferometric parameters, enhancing the precision of measurements for Qinghai Lake elevation. Full article

This paper presents for the first time the results of marine gravity recovery using the ocean observation data acquired by Tiangong-2 interferometric imaging radar altimeter (TG2 InIRA) which demonstrate not only the balanced accuracies of the north and east components of deflection of the vertical (DOV) as envisaged, but also the improved spatial resolutions of DOV compared with that by conventional altimeters (CAs). Moreover, much higher measurement efficiency owing to the wide-swath capability and the great potential in accuracy improvement of marine gravity field are also demonstrated. TG2 InIRA adopts the interferometry with short baseline and takes small incidence angles, by which wide-swath sea surface height (SSH) can be measured with high accuracy. Gravity recovery experiments in the Western Pacific area are conducted to demonstrate the performance, advantages and capability of TG2 InIRA. SSH data processing algorithms and DOV calculation have been designed by taking the wide-swath feature into account, based on which, the gravity anomalies are then calculated using the inverse Vening Meinesz formula. The derived gravity anomalies are compared with both the published gravity models and the shipborne gravity measurements. The results show that the accuracy of TG2 InIRA is equivalent to, or even a little better than, that of CAs. The fused gravity result using equal TG2 InIRA data and CAs data performs better than those using TG2 InIRA data alone or CAs data alone. Due to the signal bandwidth of TG2 InIRA is only 40 MHz which is much smaller than that of CAs, much higher accuracy can be hopefully achieved for future missions if larger signal bandwidth is used. Full article

The upcoming technology of wide-swath altimetry from space will enable monitoring the ocean surface at 4–5 times better spatial resolution and 2–3 times better accuracy than traditional nadir altimeters. This development will provide a chance to directly observe submesoscale sea surface height (SSH) variations that have a typical magnitude of a few centimeters. Taking full advantage of this opportunity requires correct treatment of the correlated SSH errors caused by uncertainties in environmental conditions beneath the satellite and in the geometry and orientation of the on-board interferometer. These observation errors are highly correlated both along and across the surface swath scanned by the satellite, and this presents a significant challenge for accurate processing. In particular, the SWOT precision matrix has off-diagonal elements that are too numerous to allow standard approaches to remain tractable. In this study, we explore the utility of a block-diagonal approximation to the SWOT precision matrix in order to reconstruct SSH variability in the region east of Greenland. An extensive set of 2dVar assimilation experiments demonstrates that the sparse approximation proposed for the precision matrix provides accurate SSH retrievals when the background-to-observation error ratio ν does not exceed 3 and significant wave height is below 2.5 m. We also quantify the range of ν and significant wave heights over which the retrieval accuracy of the exact spatially correlated SWOT error model will outperform the uncorrelated model. In particular, the estimated range is found to be substantially wider ($\nu <10$ with significant wave heights below 8–10 m), indicating the potential benefits of further improving the accuracy of approximations for the SWOT precision matrix. Full article

Surface wind speed measurements from a satellite radar altimeter are used to adjust altimeter sea level measurements via sea state bias range correction. We focus here on previously neglected ocean radar backscatter and subsequent wind speed variations due to sea surface temperature (SST) change that may impact these sea level estimates. The expected error depends on the radar operating frequency and may be significant at the Ka band (36 GHz) frequency chosen for the new Surface Water and Ocean Topography (SWOT) satellite launched in December 2022. SWOT is expected to revolutionize oceanography by providing wide-swath Ka band observations and enhanced spatial resolution compared to conventional Ku band (14 GHz) altimetry. The change to the Ka band suggests a reconsideration of SST impact on wind and sea level estimates, and we investigate this in advance of SWOT using existing long-term Ku and Ka band satellite altimeter datasets. This study finds errors up to 1.5 m/s in wind speed estimation and 1.0 cm in sea level for AltiKa altimeter data. Future SWOT data analyses may require consideration of this dependence prior to using its radar backscatter data in its sea level estimation. Full article

The baseline error is a primary error source of the wide-swath altimeter, directly related to the cross-track distance, and can lead to serious height errors at the swath’s outer edge. Cross-calibration using discrepancies with reference data can effectively estimate and correct the baseline error. However, building a reference surface that accurately describes the sea surface at the observation time is necessary to use this cross-correction method. The dynamic ocean environments where the sea surface structure changes over time are challenging. This paper proposes a method for constructing reference topography data (RTD) based on multi-source data products to correct the baseline error of the wide-swath altimeter. The effectiveness of the proposed method is evaluated using HYCOM ocean model data to assess the timeliness of the baseline error correction. The results demonstrate that using RTD at the observation time of the wide-swath altimeter can significantly correct the baseline error. The RMSE of the corrected sea surface height (SSH) in different regions is typically between 1~2 cm, except in some regions with strong currents where the RMSE is approximately 3~4 cm. However, the time interval between the RTD and the observation time of the wide-swath altimeter can affect the accuracy of the baseline error correction. The timeliness of this correction is influenced by the variability of SSH in different regions. In regions with relatively slow SSH changes near the equator, the effective time based on HYRTD and MORTD can basically reach more than 7 days. In regions where the SSH changes more rapidly, the correction result may no longer be reliable in only 1~3 days. Full article

In this study, elevation change and surface morphology of CookE2, one of the most active subglacial lakes in East Antarctica, were analyzed by using Differential Interferometric Synthetic Aperture Radar (DInSAR) and a newly adapted Time-Segmented Persistent Scatterer Interferometric Synthetic Aperture Radar (TS-PSInSAR) techniques. Firstly, several DInSAR pairs were used to study the surface morphology of the subglacial lake during the rapid discharge event in 2007 and the subsequent recharge in 2010 by using ALOS PALSAR data and the continuous recharge from 2018 to 2020 by using Sentinel-1 SAR data. For time-series observation from 2018 to 2020, however, simple integration of DInSAR deviates largely from the satellite altimeter data because errors from the horizontal flow of the surrounding ice field or atmospheric phase accumulate. Conventional PSInSAR deviates from the altimeter data if the LOS displacement exceeds 300 mm, i.e., approximately 1/4 of the slant range resolution of the Sentinel-1 SAR in Interferometric Wide-swath (IW) mode, during the time window. Therefore, a series of Time-Segmented PSInSAR with a 4-month time window could accurately distinguish 1.10 ± 0.01 m/year of highly linear (R² = 0.99) surface rise rate of CookE2 and 0.63 m/year of horizontal deformation rate of the surrounding ice field from 2018 to 2020. Full article

The upcoming technology of wide-swath altimetry from space will deliver a large volume of data on the ocean surface at unprecedentedly high spatial resolution. These data are contaminated by errors caused by the uncertainties in the geometry and orientation of the on-board interferometer and environmental conditions, such as sea surface roughness and atmospheric state. Being highly correlated along and across the swath, these errors present a certain challenge for accurate processing in operational data assimilation centers. In particular, the error covariance matrix $\mathit{R}$ of the Surface Water and Ocean Topography (SWOT) mission may contain trillions of elements for a transoceanic swath segment at kilometer resolution, and this makes its handling a computationally prohibitive task. Analysis presented here shows, however, that the SWOT precision matrix ${\mathit{R}}^{-1}$ and its symmetric square root can be efficiently approximated by a sparse block-diagonal matrix within an accuracy of a few per cent. A series of observational system experiments with simulated data shows that such approximation comes at the expense of a relatively minor reduction in the assimilation accuracy, and, therefore, could be useful in operational systems targeted at the retrieval of submesoscale variability of the ocean surface. Full article

The interferometric imaging radar altimeter (InIRA) adopts a short baseline along with small incidence angles to acquire interferometric signals from the sea surface with high accuracy, thus the wide-swath sea surface height (SSH) and backscattering coefficient (${\sigma }_0$) can be obtained simultaneously. This work presents an approach to jointly retrieve the wind speed and significant wave height (SWH) for the Chinese Tiangong-2 interferometric imaging radar altimeter (TG2-InIRA). This approach utilizes a multilayer perceptron (MLP) joint retrieval model based on ${\sigma }_0$ and SSH data. By comparing with the European Center for Medium-Range Weather Forecasts (ECMWF) reanalysis data, the root mean square errors (RMSEs) of the retrieved wind speed and the SWH are 1.27 m/s and 0.36 m, respectively. Based on the retrieved SWH, two enhanced wind speed retrieval models are developed for high sea states and low sea states, respectively. The results show that the RMSE of the retrieved wind speed is 1.12 m/s when the SWHs < 4 m; the RMSE is 0.73 m/s when the SWHs ≥ 4 m. Similarly, two enhanced SWH retrieval models for relatively larger and relatively smaller wind speed regions are developed based on the retrieved wind speed with corresponding RMSEs of 0.19 m and 0.16 m, respectively. The comparison between the retrieved results and the buoy data shows that they are highly consistent. The results show that the additional information of SWH can be used to improve the accuracy of wind speed retrieval at small incidence angles, and also the additional information of wind speed can be used to improve the SWH retrieval. The stronger the correlation between wind speed and SWH, the greater the improvement of the retrieved results. The proposed method can achieve joint retrieval of wind speed and SWH accurately, which complements the existing wind speed and SWH retrieval methods for InIRA. Full article
